- Page 1 ANALOG/DIGITAL2 SDI/HDMI User Manual...
-
Page 2: Table Of Contents
Content Feature ................... 3 Front Panel ................4 Rear Panel ................4 Side Panel ................5 DipSwitch/LED Control ..............6 Installation ................12 Package Contents ..........錯誤! 尚未定義書籤。 Specifications ................13 Firmware Upload ..............14 Appendix Table A ..............14... -
Page 3: Feature
Feature SDI Supports HD formats : 720p50 & 60 1080i50 & 60 1080p24, 25, 30, 50 & 60 SDI Support 525i & 625i SD D1 format Auto 3G/HD/SD-SDI detection Can be split one 3G-SDI displays simultaneously. ... -
Page 4: Front Panel
Front Panel Component Function SDI Output Port From your SDI Display Device plug into this ports HDMI output Port From your HDMI Display Device plug into this port Input Port/ Audio The LEDs are indicate Input Ports and Audio Source source LED Dipswitch Control the Box ( Input Port/Audio/Output Format) -
Page 5: Side Panel
Side Panel Component Function USB Port Upgrade firmware/Control Box From PC... -
Page 6: Dipswitch/Led Control
Two of kinds Audio input source Audio Source (Embedded audio/L/R Audio) Output format Control Box to switch Output Format. Input Source: MUTI2SDI/HDMI Box can choose one of three standard inputSource by DipSwitch. Input Source Dipswitch Indicates DVI-D(HDMI) DVI-A(VGA) YPbPr... - Page 7 Audio Source: MUTI2SDI/HDMI Box can be select audio source from L/R Audio. Resolution Dipswitch Indicates Internal (Default) L/R Audio Output Format: MUTI2SDI/HDMI box can be select 16 of kinds output format. Resolution Dipswitch Indicates Resolution 1920x1080p60 1920x1080i60 1920x1080p59...
- Page 8 1920x1080p23 720x576i50 LED Indicate: 2 3 4 5 Component Function Internal/L/R The LED is indicate Audio Source Audio indicate The LED is indicate DVI-D Signal DVI-D(HDMI) indicate The LED is indicate DVI-A Signal DVI-A(VGA) indicate The LEDs is indicate YPbPr Signal YPbPr indicate CVBS...
- Page 9 1. DVI-D + L/R Audio: DVI-D + L/R Audio DVI-D DVI-A YPbPr Cvbs S-Video ● ○ ○ ○ ○ Locked ● ○ ○ ○ ○ Un-locked ●(Blinking) ○ ○ ○ ○ MicroVision 2. DVI-A+ L/R Audio: DVI-A + L/R Audio...
- Page 10 DVI-D DVI-A YPbPr Cvbs S-Video ○ ● ○ ○ ○ Locked ○ ● ○ ○ ○ Un-locked 3. YPbPr + L/R Audio: YPbPr + L/R Audio DVI-D DVI-A YPbPr Cvbs S-Video ○ ○ ● ○ ○ Locked ○ ○ ● ○...
- Page 11 DVI-D DVI-A YPbPr Cvbs S-Video ○ ○ ○ ● ○ Locked ○ ○ ○ ● ○ Un-locked ○ ○ ○ ●(Blinking) ○ MicroVision 5. S-VIDEO + L/R Audio Composite(CVBS) + L/R Audio DVI-D DVI-A YPbPr Cvbs S-Video ○ ○ ○ ○...
-
Page 12: Installation
● Internal Audio ● L/R Audio Installation MULTI2SDI-PRO installation consists of the following: 1. Disconnect +12DC adaptor to converter. 2. Connect Video Source to the Input Connector. 3. Connect Display Equipment to the output’s connector 4. Connect the +12DC adaptor to the converter. -
Page 13: Specifications
Specifications MUTI2SDI/HDMI DESCRIPTION SDI Format SD-SDI, HD-SDI & 3G-SDI SDI Transition Rate 2.970Gb/s, 10485Gb/s and 270Mb/s HDMI(DVI-D) : 8-Channel L/R Audio : a. only 2 channel and splitter to 8 channel (HDMI/SDI Audio Support out) b. Input impedance = 10K. -
Page 14: Firmware Upload
USB Connector Mini-USB Dipswitch Output Format/Audio Source/Input Source Housing SECC Dimension L:153mm x W:63.3mm xH:26mm Power Source Power Adapter: AC 100 ~ 240 V/DC (+9 ~ 15 V) 0~50°C [32~114°F] Operation Temperature -20~+60°C Storage Temperature Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. - Page 15 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished.
-
Page 16: Appendix Table A
Step 5. Close Upload Firmware Program tools Appendix Table A Support Input Format: 720x480i60 720x576i50 720x480 p60 720x576 p50 1280x720p60 1280x720p50 1920x1080i60 1920x1080i50 1920x1080p24 1920x1080p25 1920x1080p30 1920x1080p60 1920x1080p50 640x350p85 640x400p85 720x400p85 640x480p60 640x480p72 640x480p75 640x480p85 800x600p56 800x600p60 800x600p72 800x600p75 800x600p85 848x480p60 1024x768p50 1024x768p59... - Page 17 1280x1024p75 1280x1024p85 1360x768p60 1366x768p50 1366x768p60 1400x1050p50 1400x1050p59 1400x1050p60 1400x1050p75 1440x900p60 1440x900p75 1440x900p85 1600x1200p50 1600x1200p59 1600x1200p60 1600x1200pRB 1680x1050pRB 1680x1050p60 1920x1200pRB 2048x1052p60 2048x1080p50 2048x1080p59 2048x1080p60 Support Output Format: HDMI Mode 720x480 i60 720x480 i59.94 720x576 i50 1280x720 p60 1280x720 p59.94 1280x720 p50 1920x1080 i60 1920x1080 i59.94 1920x1080 i50...
