Page 1: User Manual
HD2SDI BOX User Manual Rev1.0 ENABLE YOUR MEDIA WORKFLOWS www.media-power.it... -
Page 2: Table Of Contents
Index Feature ................... 3 Front Panel ................4 Rear Panel ................4 Dip Switch ................5 EDID Leaning ................7 Specifications ................8 Firmware Upload ................ 9 ENABLE YOUR MEDIA WORKFLOWS www.media-power.it... -
Page 3: Feature
Feature Supports HD formats: 720p50 & 60 1080i50 & 60 1080p24, 25, 30, 50 & 60 Support 525i & 625i SD D1 format Support up to 2ch of audio output Auto 3G/HD/SD-SDI detection HDMI 1.3 supported SDI compliant outputs External DIP Switch Configuration Firmware is upgradable in the field using the integrated USB port The converter is Plug-and-Play ENABLE YOUR MEDIA WORKFLOWS www.media-power.it... -
Page 4: Front Panel
Front Panel 1 2 3 3G/HD/SD-SDI Output 1 3G/HD/SD-SDI Output 2 3G/HD/SD/HDCP LED indicator Rear Panel 1. Power (+6V ~ + 15V) 2. HDMI Input 3. Power LED indicator 4. Dip Switch: Pin On (↑): Enable Pin OFF (↓): Disable a. EDID b. LED Mode c. NA ENABLE YOUR MEDIA WORKFLOWS www.media-power.it... -
Page 5: Dip Switch
Dip Switch EDID: In order to keep the compatibility of HDMI to most monitors, HD2SDI features EDID learning ability. Pin On (↑): Default EDID Pin OFF (↓): Leaning EDID LED Mode: Pin OFF (↓): Resolution SD LED HD LED 3G LED HDCP LED 720 x 480 i ○ ○ ○ ● (NTSC) 720 x 576 i ○ ○ ● ○ ( PAL ) 1280 x 720 p50 ○ ○ ● ● 1280 x 720 p60 ○ ● ○ ○ 1920 x 1080 i50 ○ ● ○ ●... - Page 6 ○ : LED OFF ENABLE YOUR MEDIA WORKFLOWS www.media-power.it...
-
Page 7: Edid Leaning
EDID Leaning 1. Turn off HD2SDI Box and EDID pin is pull down. 2. Connect the TV monitor thru HDMI port to HD2SDI box, and then turn on HD2SDI box. 3. The LED of HD2SDI box will light, which indicates the EDID learning process is finished. LED Sequence SD LED HD LED 3G LED HDCP LED ○ ○ ○ ● Start ○ ○ ● ● ○ ● ● ● ● ● ● ● Finish ○ ○ ○ ○ ● : LED ON ○ : LED OFF 4. Connect HD2SDI box to the HDMI source through a HDMI cable ENABLE YOUR MEDIA WORKFLOWS www.media-power.it... -
Page 8: Specifications
Specifications DESCRIPTION SD – 720 x 480 i (NTSC) / 720 x 576 I (PAL) HD– 1280 x 720 p 1920 x 1080 50i/60i Support Video Resolution 1920 x 1080 24p/25p/30p 3G– 1920 x 1080 50p/60p 2K– 2048 x 1080 24p/30p SD-SDI(SMPTE 259M) SDI format HD-SDI(SMPTE 292M) 3G-SDI (SMPTE 424M / SMPTE 425M) Audio Support 2 Channel Audio Sample Auto Ra-sample to 48Khz (For Stereo) Coaxial Cable Type RG6/RG59(75Ω) 3G: 100m of RG6/ 86m of RG59 HD: 170m of RG6/ 120m of RG59 SD: 400m of RG6/ 280m of RG59 Cable Equalization *1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275 Cable *2 Cable Length Performance: Depending on SDI Signal and Cable Quality Input 1 x HDMI... -
Page 9: Firmware Upload
Firmware Upload Firmware is upgradable in the field using the integrated USB port How to Firmware upgrade: Step 1. Open Upload Firmware Program tools.exe and connect box to PC by USB Cable. Step 2. Plug and un-plug “DC adapter” to power on/off the converter box (the connection check status will be changed to “Connect”) ENABLE YOUR MEDIA WORKFLOWS www.media-power.it... - Page 10 Step 3. Plug and un-plug “DC adapter” again (the connection check status will be changed to “Connected”) and Please click the Open File button to select the firmware bin file. Step 4. Please click “Start’ Button to proceed with new firmware programming. The PASS message will appear when the procedures finished. Step 5. Close Upload Firmware Program tools ENABLE YOUR MEDIA WORKFLOWS www.media-power.it...
- Page 11 ENABLE YOUR MEDIA WORKFLOWS www.media-power.it...
