Code 3 3599L5 Installation & Operation Manual page 5

Public Safety Equipment, Inc.
5. To install the positive and negative power wires, strip 1/4" of insulation from the end of the wires, insert the wire into the
quick-on connector (supplied) and crimp securely with proper tool. Connect the red wire to "+12V" position and black
wire to the "NEG " position of the connectors on 3599L5. The "+12V" position may be connected either directly to a
+12V source (such as a battery), or through a switch (such as an ignition switch). Special care should be taken if the
3599L5 is connected directly to a battery as it will always have a small current draw, even in standby mode (up to 180
mA). If it is necessary to leave the car off for long periods of time (5 or more days), a battery shut off device may need
to be installed to prevent the siren from draining the battery.
www.code3pse.com
St. Louis, MO 63114
For Technical Support or
Service Call 314-996-2800
A - LEVEL 1
B - LEVEL 2
C - LEVEL 3
D - AUX 1
E - AUX 2
F - AUX 3
G - AUX 4
+12V LTG.
60A MAX
BAT
12V DC
SPEAKER 1
VEHICLE
HORN
CUT
+12V
HORN
SWITCH/RELAY
A B C D E F G
SPEAKER 2
Figure 1 - Wiring Diagram
