Specifications; Maintenance; Warranty - Code 3 3599L5 Installation & Operation Manual

Specifications

Siren Section
Input Voltage
Input Current
Standby Current
Output Voltage
Operating Temperature
Dimensions (HWD):
Handheld controller
Amplifier
Weight – Siren (approx):
Weight – Controller (approx):
Base:
Mounting – Siren:
Mounting – Controller:
Compliance:

Warranty:

Lighting Section
Warning Light Control
Level 1
Level 2
Level 3
AUX 1
AUX 2
AUX 3
AUX 4

Maintenance

Your Code 3 siren has been designed to provide trouble free service. In case of difficulty, consult the Troubleshooting Guide
of this manual. Also check for shorted or open wires. The primary cause of short circuits has been found to be wires passing
through firewalls, roofs, etc. If further difficulty persists, contact the factory for troubleshooting advice or return instructions.
Public Safety Equipment, Inc. maintains a complete parts inventory and service facility at the factory and will repair or re-
place (at the factory's option) any unit found to be defective under normal use and in warranty. Any attempt to service a unit
in warranty, by anyone other than a factory-authorized technician, without the express written consent of the factory, will
void the warranty.
Units out of warranty can be repaired at the factory for a nominal charge on either a flat rate or parts and labor basis. Contact
the factory for details and return instructions. Public Safety Equipment, Inc. is not liable for any incidental charges related to
the repair or replacement of a unit unless otherwise expressly agreed to in writing by the factory.
Parts List
Part Number
T15060
T15061
T15062
T15064
T15065
T15066
T15068
10-16VDC (negative ground)
17 Amps @ 13.6VDC (dual 100W speakers)
Less than 180 mA, Less than 140 mA when Keypad lights turned off.
Maximum 200W @ 12VDC (dual 100W speakers)
-30 °C to +65 °C
1.2"X2.4"X5.9"
2.7"X6.2"X7.1"
4.0 lbs
0.5 lbs
Black anodized
4-hole flange mounting on base & mounting hardware
Cradle & mounting hardware
SAE J1849, 2004/104/EC, California Title 13
5 years
7 levels
20A maximum
20A maximum
20A maximum
10A maximum
10A maximum
10A maximum
10A maximum
Description
Siren (Amplifier)
Hand Held Controller with Coil Cord
Hand Held Controller Mounting Bracket
Eight Position Pluggable Connector
Parts Bag
25' Extension Cord
Installation & Operation Manual
Quantity
1
1
1
1
1
1
1
12
