Summary of Contents for Firetide FWB-205
- Page 1 User Guide Firetide FWB-205 Wireless Bridge 2011-09-25 3.1 The contents of this User Guide are subject to change without notice. Please refer to the Firetide partners web site, partners.firetide.com, for current versions.
- Page 2 Software will be uninterrupted or error free. these terms and conditions. The above warranties are void if the alleged defect cannot be verified by Firetide In the event that a product fails to meet this warranty and Firetide’s authorized...
-
Page 3: Table Of Contents
FWB-205 Specifications ........ -
Page 4: Chapter 1 Introduction
FWB-205 configuration is easy; it can be performed with a browser. Under normal circumstances, the two units exchange configuration information automatically. The FWB-205 Kit is shown in Figure 1. Each kit includes two radio modules, two 19-dBi MIMO antennas, RF cables, two Ethernet PoE injector/powersupplies, two short Ethernet cables, and mounting hardware. -
Page 5: Field Installation
The assembly must be grounded. If the mast is not already properly grounded, you will need appropriate grounding hardware. Consult local codes. Refer to “Chapter 4 Antenna Installation” on page 14 for complete installation instructions. July 2011 Firetide. Reliable Connectivity Anywhere. -
Page 6: Chapter 2 Initial Setup For The Fwb-205
Chapter 2 Initial Setup for the FWB-205 Initial Setup & Login The FWB-205 nodes are sold in pairs. and each pair has been programmed at the factory to work with each other. Installation of the nodes should only be done by qualified and experienced personnel. Outdoor installation involves many safety hazards, including electrocution, lightning strikes, and falls. - Page 7 Operating Country Some Firetide FWB-205 nodes require that you enter the country of operation to ensure compliance with the channel limitations, indoor/outdoor restrictions, and license requirements of your region. Selecting a country other than where you are using the device may result in illegal operation and may cause harmful interference to other systems.
- Page 8 The nodes should connect. If they do not, contact Firetide Customer Support. Extended Range can be set from 0 to 9 miles (0 to 14.5 km). Increasing the range setting does not actu- ally increase the range or power of the radios.
-
Page 9: Chapter 3 Radio And System Settings
Management VLAN status can be enabled or disabled. If you are unsure, leave it disabled. If enabled, select the appropriate management VLAN number. Click Apply to save settings. Link Security Settings Link Security Settings provide support for encryption. The default is Enabled, WPA2-PSK. July 2011 Firetide. Reliable Connectivity Anywhere. -
Page 10: Node Configuration
User Settings - Changing the Password Configure users with node management privileges here by adding & changing User Name and Password. Save/Restore Configuration You can save the current link configuration as a file, then restore the settings later. Firetide Wireless Bridge Reference Guide Version 3.1... - Page 11 Antenna Alignment Antenna alignment settings are available here. Alignment is on by default. To insure maximum perfor- mance, turn off the alignment feature after alignment is complete. July 2011 Firetide. Reliable Connectivity Anywhere.
-
Page 12: Status
RF channel, node MAC addresses, and IP addresses. The Manage Remote button lets you connect to and manage the remote node, as long as the RF link is up. Node Status Node Status is displayed here. Click Refresh to see the current status. Firetide Wireless Bridge Reference Guide Version 3.1... -
Page 13: Upgrade
Java applet will take a moment to load. Browse to select upgrade image. Click Start Upgrade to begin. Once started the upgrade can be cancelled by clicking Cancel Upgrade. Logout Select the Logout tab to exit from the session. July 2011 Firetide. Reliable Connectivity Anywhere. -
Page 14: Chapter 4 Antenna Installation
Chapter 4 Antenna Installation The FWB-205 Kit and its two 19 dBi antennas are intended for fixed, point-to-point applications only. Any other use is prohibited. Antenna(s) for the FWB-205 outdoor unit must be installed by a qualified profes- sional. Operation of the unit with non-approved antennas is a violation of U.S. FCC Rules, Part 15.203(c), Code of Federal Regulations, Title 47. - Page 15 Radio as shipped Radio w/ Mounting Plate The FWB-205 is shipped with a two-piece mounting plate already attached, as shown. Loosen the four fasteners, two on each side, to remove the hook-attachment plate. The captive screws are tight; you will need a Phillips screwdriver, or channel-lock or slip-joint pliers.
- Page 16 Cable connection pattern is critical. You must use the Radio 2 antenna connectors; these are on the right side of the unit when viewed from the front. The panel antennas included with the FWB-205 are ‘handed’; the individual antenna connections on the radio unit must be connected to the antenna in a specific way, and it is slightly different on each end of the link.
- Page 17 After physical installation, the antennas should be aligned. You and a co-worker will need to work to- gether; one at each end. Log into the FWB-205 pair and bring up the alignment screen, as shown. Alignment is on by default. To insure maximum performance, turn off the alignment feature after align- ment is complete.
-
Page 18: Chapter 5 Technical Information
Reset Procedure Firetide FWB-205s may be reset to factory parameters. This is useful when returning a unit from field ser- vice or in recovering a unit you cannot communicate with. You will need a long, thin shaft to reach the reset button, because the switch is recessed approximately 35 mm (1-3/8 in) inside the unit. -
Page 19: Regulatory Notices
FCC to operate this equipment. Installation The FWB-205 Kit and its two 19 dBi antennas are intended for fixed, point-to-point applications only. Any other use is prohibited. Antenna(s) for the FWB-205 outdoor unit must be installed by a qualified profes- sional. - Page 20 Channels 120, 124, and 128 have been removed from DFS service completely. These channels must not be used in the US anywhere, at any time. They do not appear in channel listing in any Firetide product, and are only listed here for historical reference.
- Page 21 W 111 55 47 N 40 58 02 5610 MHz 4219 80 VA Leesburg W 077 31 46 N 39 05 02 5605 MHz WI Milwaukee W 088 02 47 N 42 49 10 5603 MHz Latitude and Longitude based on NAD83 datum. July 2011 Firetide. Reliable Connectivity Anywhere.
- Page 22 +1 408 399 7771 © 2011 Firetide, Inc. All rights reserved. Information subject to change without notice. Firetide, HotPort, and HotPoint are registered trademarks of Firetide, Inc. Reliable connectivity anywhere, HotView, HotView Pro, MeshBridge, and AutoMesh are trademarks of Firetide, Inc.
