- Page 1 Junction Box Quick Start Guide Illustra Flex 3MP Outdoor Bullet Camera 8200-1454-01 B0...
-
Page 2: Product Overview
Product overview The Junction Box, IFBMNTBOX, is compatible with the Illustra Flex 3MP Outdoor camera IFS03BIBNWIT. Table 1 provides the product code and description of the camera. Use the Junction Box kit to mount the camera on a ceiling or wall surface. -
Page 3: Installation And Mounting
Check everything in the box matches the order form and packing slip. Contact your dealer if any item is missing. The box contains the following items: • One junction box IFBMNTBOX • One Quick Start Guide 8200-1454-01 A0 • One waterproof rubber sealing gasket •... - Page 4 Figure 3. Securing the camera to the adaptor plate 5. From the rear side, cover the cable thread with the waterproof rubber sealing and fasten them to the holding bracket plate using 3 T20 screws fixed onto the exact place. Figure 4.
- Page 5 Figure 5. Assembling the Junction Box with the adaptor plate You have completed the installation of the camera on a wall or surface, as displayed in Figure 6 below. Figure 6. Final mounting Notes and warnings • It is advised to apply rubber tape splicing tape around the required cables, which are slated for passing through either the bottom or side conduit hole, for securing waterproof function.
-
Page 6: Mounting Template
Mounting Template The Junction Box, IFBMNTBOX, mounting template is below. Use this template to locate where to drill the holes for the mounting and installation of the camera. The height by width of the template below is 136 mm x 136 mm.
