Kärcher 1105 VAPORAPID Manual

Hide thumbs

Advertisement

Table of Contents

Contents
1. Equipment features ......................... 2
3. Getting started ................................. 6
4. Information on usage ....................... 8
6. Maintenance .................................. 10
7. Safety devices .............................. 11
8. General information ....................... 12
10. Technical specifications ................ 13
11. Spare Parts List ............................ 15
5.960-099
(07/01)
CAUTION
DO NOT USE THIS PRODUCT ON DELICATE FABRICS
INCLUDING DRALON, ANY ITEMS PROTECTED BY
SCOTCH GUARD OR ANY SIMILAR SUBSTANCE.
BEFORE CLEANING UPHOLSTERY TEST ON A
SECTION NOT NORMALLY VISIBLE.

Advertisement

Table of Contents
loading

Related Manuals for Kärcher 1105 VAPORAPID

Summary of Contents for Kärcher 1105 VAPORAPID

  • Page 1: Table Of Contents

    Contents 1. Equipment features ......2 2. SAFETY INSTRUCTIONS ... 3 3. Getting started ......... 6 4. Information on usage ....... 8 5. How to use the accessories ..... 8 6. Maintenance ........10 7. Safety devices ......11 8. General information ....... 12 9.

  • Page 2: Equipment Features

    1. Equipment features A1 Cover on main unit socket A2 Safety cap A3 Funnel inlet for filling boiler A4 Heater switch with indicator lamp A5 Steam supply switch with indicator lamp A6 Indicator lamp – low water warning (red) A7 Indicator lamp – heater (orange) C1 Steam gun C2 Release button C3 Steam switch...

  • Page 3: Safety Instructions

    – If a 13 Amp BS 1363 plug is used it should be fitted with a 13 Amp fuse If any doubt, contact your nearest Karcher Authorised Agent or Quali- fied Electrician...
  • Page 4 2. SAFETY INSTRUCTIONS Steam Cleaner The extension cord must have the cross-section specified in the Operating If you notice any transport damage whi- Instructions, and must be spray-water le unpacking the unit, notify your dealer protected. The cable coupling must not immediately.
  • Page 5 2. SAFETY INSTRUCTIONS must be observed. Operation of the unit ons and, while working with the unit, in explosive environments is prohibited. take into account the presence of third persons, and especially children. The unit must be placed securely on a firm surface.

  • Page 6: Getting Started

    3. Getting started 3.1 Unpacking the cleaner • To detach the accessories, press the re- While you are unpacking the cleaner, check lease button and pull the items apart. that all accessories have been included. If any items are missing, please contact your dealer. If you notice any damage that has been caused in transit, please inform your dealer immediately.
  • Page 7 3. Getting started 3.4 Switching the cleaner ON • The heater is repeatedly switched on while you are using the cleaner, in order to main- Do not switch the cleaner on if there is no water tain the pressure inside the boiler. At the in the boiler, otherwise it could overheat.

  • Page 8: Information On Usage

    4. Information on usage 5. How to use the accessories 4.1 Cleaning textiles 5.1 Steam gun (C1) Before you use the steam cleaner on textiles The steam gun can be used without any addi- including delicate fabrics like Dralon, velvet, lea- tional accessories.
  • Page 9 5. How to use the accessories • Work on heavily soiled areas at a slower • When you press the switch on the iron, speed so that the steam has more time to steam is discharged out of holes in the face act on the dirt.

  • Page 10: Maintenance

    5. How to use the accessories 6. Maintenance 5.7 Wallpaper remover 6.1 Cleaning the boiler Note: If you always use demineralised or distil- The wallpaper remover is available as led water, it will not be necessary to clean the a special accessory - see page 12 boiler.

  • Page 11: Safety Devices

    6. Maintenance 7. Safety devices This steam cleaner is equipped with several In order to avoid damage to the cleaner, only safety devices which provide multiple levels of use products that have been approved by safety. The most important safety devices are Kärcher.

  • Page 12: General Information

    8. General information 9. Accessories and replacement parts 8.1 Warranty The applicable warranty conditions in different Only accessories and replacement parts ap- countries are issued by the respective natio- proved by the manufacturer may be used with nal distributor of KÄRCHER products. During this cleaner.

  • Page 13: Technical Specifications

    10. Technical specifications Voltage ..........220-240 V Max. steam volume ........60 g /min Type of current ....single phase, 50/60 Hz Weight without accessories ....... 4.2 kg Voltage in hand-gun ........24 V Max. water capacity ........1.2 l Heater power consumption ....
  • Page 14 EU Declaration of Conformity We hereby declare that the equipment described below conforms to the relevant fundamental safety and health requirements of the appropriate EU Directives, both in its basic design and construction as well as in the version marketed by us.This declaration will cease to be valid if any modifications are made to the machine without our express approval.

  • Page 15: Spare Parts List

    11. Spare Parts List 1105 QVC 1.204-906.0 *GB 4.862-060.0 4.130-130.0 6.369-357.0 4.130-111.0 5.130-191.0 6.370-990.0 6.362-924.0 2.863-058.0 4.321-088.0 6.362-922.0 4.127-012.0 4.590-062.0 5.363-502.0 6.647-841 4.127-012.0 6.362-922.0 5.515-102.0 5.515-103.0 12.07.2001 12.07.2001...
  • Page 16 Kärcher (U.K.) Ltd. Kärcher House, Beaumont Road Banbury Oxon, OX16 7TB ( 0 12 95 27 15 23...
