- Page 1 Model. UBR510B Software & Hardware Upgrade! 5.1CH Surround AV Amplifier Package with 3D HDMI and Bluetooth INSTRUCTION MANUAL (Preset to 230V) Switchable Dual Voltage : 115V or 230V NOTICE Please make sure to set a right voltage before power on!
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information Safety Precautions Some Do’s and Don’ts On The Safe Use Of Equipment Introduction Features Accessory List Panel and Remote Operation Front and Back Panel Remote Control Input Modes Switching Input Modes Reference Troubleshooting Specifications... -
Page 3: Safety Information
SAFETY INFORMATION Safety Precautions To achieve the utmost in enjoyment and performance, and in order to become familiar with its features, please read this manual carefully before attempting to operate this product, this will assure you years of trouble free performance and listening pleasure. Important Notes This safety and operating instruction should be retained for future reference. -
Page 4: Some Do's And Don'ts On The Safe Use Of Equipment
SAFETY INFORMATION Some Do’s and Don’ts on the Safe Use of Equipment This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. -
Page 5: Introduction
INTRODUCTION Features - Home Entertainment AV Receiver Package with 5.1CH Speakers - Bluetooth Connectivity - 4 HDMI Input, 1 HDMI Output - Easy Selectable Button to choose HDMI Receiver Mode or HDMI Switch Mode. - 3D(1080P) HDMI Video ready - 4K x 2K resolution support(HDMI 1.4) - 3.5mm Aux in for MP3 Players as iPhone - AM/FM Tuner with 22 Radio Presets(11 FM, 11AM) - 2 MIC Input with independent MIC controls for Treble/Bass and Volume... -
Page 6: Panel And Remote Operation
11. MP3/iPhone: Switch to MP3/iPhone (3.5mm AUX- in jack) input 12. MUTE: Mute or unmute audio output 13. TUNER: Adjust FM/AM tuner frequency 14. MIC2 Vol: Adjust MIC2 volume independently 15. MP3/iPhone: 3.5mm aux input jack * UBR510B(HDMI 1.4) is not compatible with Ethernet & ARC. - Page 7 PANEL AND REMOTE OPERATION FrontPanelDisplayWindow Name Function 1.STEREO DV D/CD/PHONE/TUNER/MP3/ Light up when DVD, CD, PHONE, FM/AM, Mp3/ iPhone INPUT iPhone input. 2.AC-3PROLOGIC HDMI INPUT Light up when 5.1channel or HDMI 1/2/3/4 input. 3.DSP DSP STATE ICON Light up when play DSP effect. Light up to display value of current input mode.
-
Page 8: Remote Control
PANEL AND REMOTE OPERATION Remote Control POWER: Turn unit on or back to Standby. Receiver Switch : Choose Receiver mode or Switch mode (Default set to receiver mode) HDMI 1/2/3/4 : Switch to HDMI input 1-4. AUX 1/2/3 : Switch to AUX input 1-3. MP3/iPhone : Switch to MP3/iPhone (3.5mm aux in jack) input. - Page 9 PANEL AND REMOTE OPERATION Battery Installation CAUTION To prevent damage to the remote control, make sure to install batteriescorrectly. Do not mix old and new batteries. Dispose of batteries safely and appropriately. Contact your local authorities or dealer for advice on battery disposal. Keep batteries out of reach of children.
-
Page 10: Input Modes
INPUT MODES There are many input options available with this unit, enabling multiple connections set up at the same time and easy switching with the touch of a button. Ensure that all cable connections are fuly set up before turning the system on. Press the corresponding input source button on the remote control or main unit front panel to switch to the desired mode. - Page 11 INPUT MODES 1). Make sure that the media play/ TV is turned on. AUX1 2). Switch to AUX1 by pressing on the remote control or main unit. 3). Start playback on the connected media player/TV. 4). Adjust the master and/or surround speaker volumes as desired. 3.
- Page 12 INPUT MODES 6. Bluetooth Operation Connect wirelessly to the unit using Bluetooth technology and play music through the home theatre’s speakers. Example: iPhone connecting to the unit to play music via Bluetooth 1). Make sure that the iPhone is turned on and has music ready to play on the iPod app. 2).
-
Page 13: Reference
REFERENCE Troubleshooting: Problem Possible Reasons Solutions The plug is not connected properly Check power supply and plug The socket has no power Check socket and power supply power/display does not turn The POWER button was not pressed Press the POWER button The fuse is broken Replace the fuse If irregular current is output to the... -
Page 14: Specifications
Move closer and face the front of Operation is out of range the unit where the sensor is Batteries are weak or flat Replace with new batteries Error Contact UBX’s customer The unit may be malfunctioning message support hotline Specifications GENERAL... - Page 15 5.1CH Surround AV Amplifier Package with 3D HDMI and Bluetooth Model. UBR510B...
