1. Overview

The BGR700 is a robust boarding gate reader for 2D-barcoded boarding passes, designed
specifically with a large throat to allow truly intuitive use with all media types including the latest
mobile devices and smartwatches.
The BGR700 reads boarding passes presented face up at any angle to ensure fast and intuitive
passenger processing. Speed of transaction is enhanced by near-zero latency, so that barcodes are
read instantly on presentation. A display, which can be easily read over a wide range of angles and
in bright ambient lighting conditions, presents information from the boarding pass to the operator
and passenger.
Designed for future-proof operation, the BGR700 can be upgraded for contactless near-field
communication (NFC) operation in the field. This allows it to cater for the latest developments in
NFC-enabled mobile devices and contactless smartcards.
•
Fast, omnidirectional 1D/2D barcode imager.
•
Easy-to-read colour LCD display (480 x 272 px) for passenger information.
•
Large document throat allows smartphones, tablets, and smartwatches to be easily read.
•
Reads a barcode printed at any position on an A4 (European) or Letter (American) document.
•
Wide face-up 'read zone' allows for intuitive use and fast barcode reads.
•
Reads IATA-recommended PDF417, QR, Aztec and other 2D and linear symbologies.
•
Configurable green and red
indicator beacons and audio
beeper to confirm
successful data capture.
•
A wide range of
configurations are available
for connection to Common
Use Terminal Equipment
(CUTE®) or dedicated
systems.
•
RS232 or USB connection
to host.
•
RS232 serial port for receipt
printer functionality, for
example, seat, flight and
passenger data from M1
format barcode documents.
•
Upgradeable software.
•
Ethernet port and three
USB ports (for future use).
•
Optional quick release
bracket for secure
mounting.
Page 4 of 14
Figure 1: BGR700 compact boarding pass reader
