Sanyo CE32WH3-F Service Manual

Hide thumbs

Table of Contents

Quick Links

Download this manual

Colour Television

Service Manual

Model CE32WH3-F

Service Ref. No. CE32WH3-F-01

PRODUCT CODE: 111340310

ORIGINAL VERSION: Chassis Series: WB5

Give complete "SERVIC E REF. NO." for parts order or

servicing. It is shown on the rating plate at the cabinet

back of the unit.

Note

This TV receiver will not work properly in foreign

countries where the television transmission

system and power source differ from the design

specification. Refer to the specifications for the

design specifications.

Contents

Safety precautions/Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Digital scan operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power supply & protection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Option setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Service adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-15

CPU port functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-18

IC block diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-27

Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-31

Pin description of semi-conductors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parts description and reading in schematic diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cabinet parts List/T V Stand parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34-36

Chassis electrical parts lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Part No. SKSM0325

F7YLV

SEPT 1999

32WH3

-F

. . . . . . .2

. . . . . . . . . .6-8

. . . . .9

. . . . .32

. . . . . . .37-60

Table of Contents

Summary of Contents for Sanyo CE32WH3-F

Page 1: Table Of Contents
Colour Television 32WH3 Service Manual Model CE32WH3-F Service Ref. No. CE32WH3-F-01 PRODUCT CODE: 111340310 ORIGINAL VERSION: Chassis Series: WB5 Give complete “SERVIC E REF. NO.” for parts order or servicing. It is shown on the rating plate at the cabinet back of the unit.
Page 2: Safety Precautions/Specifications
SAFETY PRECAUTION 1: An isolation transformer should be connected in the 3: When replacing a chassis in the cabinet, always be power line between the receiver and the AC line certain that all the protective devices are installed when a service is performed on the primary of the properly, such as, control knobs, adjustment covers converter transformer of the set.
Page 3: Block Diagram
CHASSIS BLOCK DIAGRAMS This is a diagram for all models and therefore differs slightly from the actual block diagram. Outline Fig.-1 F7YLV...
Page 4 Video signal routeing IF Stage IC101 IC201 IC202 IF/VIDEO/ SHARPNESS CHROMA <TDA9178> <TDA9330H> <TDA9321H> SAW Filter IC731 R-VIDEO OUT <TDA6111Q> 2(Y, U, V) Y, U, V DIGITAL SCAN IC721 CONVERTER G-VIDEO OUT H-Sync CIRCUIT <TDA6111Q> Filtering V-Sync circuit Picture Tube IC711 B-VIDEO OUT <TDA6111Q>...
Page 5: System Control
System control RL1601 Q1652 Power CVBS input Supply Power ON/OFF Circuit 60 48 49 44-47 42 Photo Sensor IC802 IC801 19 20 21 22 23 RC Pre-amp. C Bus C Bus SDA/SCL-1 SDA/SCL-2 MEMORY SDA/SCL-3 IC804 IC806 Bus-SW. Bus-SW. C Bus SDA/SCL Fig.-4 Deflection circuit...
Page 6: Digital Scan Operation
DIGITAL SCAN OPERATION 100Hz Digital Scan Converter circuit 100Hz converter circuit consists of the following ICs. - SAA4977H A/D, D/A, Timing generator - SAA4991WP 100Hz converting processor - SAA4955TJ x2 1.9Mbit field memory -MC74HC4046AF PLL(Phase Locked Loop) The Y/U/V signals decoded in the HOP IC (IC101) are sent to the scan converter circuit. The Y/U/V signals are sent to SAA4977H through the AC coupling capacitors and converted to 8bit digital data with 16MHz sampling clock at the A/D converting stage in the IC respectively.
Page 7 50Hz 100Hz 100Hz A' = A, B'= B (b) Normal Double Scan (C) Digital Double Scan (a) Normal Scan Fig.-8 the fields and other one is simply reading out field data twice with double scanning frequency. In the SAA4977H, the converted 8bit Y-signal is added sharpness processing and the converted 8bit U/V-signals are added the CTI processing.
Page 8 sampling clock=16MHz=1024/1 horiz. sampling clock=32MHz=2048/1 horiz. 1024 sampling 1024 sampling 1024 sampling Double Scan Converting Write (R-Y (B-Y0)' Time divided multiplex Read out in double clock R-Y5 (R-Y (B-Y (B-Y (R-Y (R-Y B-Y4 Fig.-9 2) 100Hz Normal scan odd field even field odd field even field...
Page 9: Power Supply & Protection Diagram
POWER SUPPLY & PROTECTION DIAGRAMS Power supply & Protection circuit Fig.-5 F7YLV...
Page 10: Disassembly
DISASSEMBLY CABINET BACK DISASSEMBLY 1. Remove 10 screws(A) and 2 screws(B) 2. Pull out the cabinet back. ANALOGUE ANT.75Ω -10- F7YLV...
Page 11: Option Setting
OPTION SETTING [After replacing the Memory IC (IC803)] The memory IC, IC803, stores the option data of TV set and service adjustments data for each circuit, therefore, when the memory IC is replaced, it should be programmed with the following setting and “SERVICE ADJUSTMENT” on next page.
Page 12: Service Adjustments
SERVICE ADJUSTMENTS Note: Some items of the service adjustments for this chassis are controlled by the CPU, IC801, and the adjustments are carried out by using the RC handset. [After replacing the Memory IC (IC803)] The memory IC, IC803, stores the service adjustments data for each circuit, therefore, when the memory IC is replaced, it should be programmed with “OPTION SETTING”...
Page 13 To select the mode and service item and change data value + Highlight the desired adjustment mode by using the UP or DOWN button and then press the OK button. + To select the adjustment item, use the UP or DOWN button. + To change the service data, use the Volume -(LEFT) or Volume + (RIGHT) button.
Page 14 ADJUSTMENTS IMPOTANT NOTICE Do not attempt to adjust the following service adjustments except requiring the readjustments in servicing otherwise it may cause loss of performance and product safety. POWER SUPPLY CONFIRMATION VIDEO LEVEL ADJUSTMENT 1. Receive white raster pattern. 1. Receive colour bar pattern. 2.
Page 15 FOCUS ADJUSTMENT HORIZONTAL ADJUSTMENT By using FOCUS VR, adjust focus control to obtain HORIZONTAL CENTRING ADJUSTMENT sharpest picture. 1. Receive circular pattern and set screen mode to “FULL”. 2. Enter to the service mode and select mode “WIDE”, item “WIDE 8.P H-P”. GREY SCALE ADJUSTMENT 3.
Page 16: Cpu Port Functions
CPU PORT FUNCTIONS Pin No. Function Name Function IN/OUT MMU0 MMU3 ADDR10 Address bus 10 ADDR11 Address bus 11 ADDR9 Address bus 9 ADDR8 Address bus 8 OSC-IN Clock Input OSC-OUT Clock Output ADDR13 Address bus 13 ADDR14 Address bus 14 MMU1 MMU2 MMU4...
Page 17 Pin No. Function Name Function IN/OUT WSCF VDD-A PXFM RESET Reset Input MCFM JTRSTO TXCF CVBS0 TEST0 CVBS1 CVBS2 GND-A DAT3 Data bus 3 DAT4 Data bus 4 DAT5 Data bus 5 DAT6 Data bus 6 DAT7 Data bus 7 DAT2 Data bus 2 DAT1...
Page 18 I/O Expander 1 (IC809)Pin Function Table (CXA1315) Pin No. Function Name Function Action IN/OUT Power failuer detection Input Front AV Switch “H” Front AV “L” AV3 DAC4 50/60hz Switch “H” 50Hz “L” 60Hz DAC3 CS Switch “H” Normal/Natural Wide DAC2 H-Size Control DAC1 Naormal Switch...
Page 19: Ic Block Diagrams
IC BLOCK DIAGRAMS IC001 TA8200 <Audio Output> TA8200AH AMP2 AMP1 SPEAKER SPEAKER IC101 TDA9321H <IIC bus controlled TV input processor> -19- F7YLV...
Page 20 IC201 TDA9178T <YUV Picture Improvement> Sout spectral processing luminance vector processing Yout smart peaking input- luminance output Uout stage processing black stretch stage Vout histogram processing gamma control colour vector processing delay saturation control correction colour supply skin tone correction processing 'ground green enhancement...
Page 21 IC807 PCF8574AT <I/O Expander> INTERRUPT LP FILTER LOGIC PCF8574 INPUT I C BUS SHIFT CONTROL FILTER 8 BIT REGISTER PORT WRITE pulse READ pulse POWER-ON RESET MBD980 IC809 CXA1315 <I/O Expander> SAD2 SAD1 SAD0 SW0~SW3 10 9 Open collector CXA1315P Level Level LATCH...
Page 22 IC1201 MM1313BD <AV Selector> IC3451 TDA9875A <NICAM & Stereo Decoder> AUXOR SIF1 AUXOL SIF2 -22- F7YLV...
Page 23 IC3501 MM1369AD <3D Surround Decoder> Lout SIMULATED STEREO VIRTUAL AUDIO MM1369AD QXPANDER PROCESSOR SIMULATED STEREO Rout IC471 MB3759 <Switching Control> OUTPUT CONTROL 0.2V DEAD TIME PULSE STEERING F/F CONTROL ERROR AMP 1 PWM COMPARATOR REFERNCE REGULATOR ERROR AMP 2 FEED BACK IC501 LA7846 <Vertical Outputr>...
Page 24 IC611 STR-F6656 <Power Switching Controller> IC711, IC721, IC731 TDA6111Q <Video Output> supply voltage feednback input HIGH output MIRROR MIRROR Follwers cathode Vbias transient output Cpar cathode inverting DC output input Differential TDA6111Q non-inverting Stage black current input measurement output Current MIRROR MIRROR Source...
Page 25 IC1301 LA6393D <Comparator> V CC 100 µA 100 µA V OUT V IN V IN IC1303 M34225M1 <Single Chip Micro-computer> -25- F7YLV...
Page 26 IC7101 CXD2064Q <Digital Comb Filter> Vertical enhancement circuit NTSC:1H NTSC:1H ADIN PAL : 2H PAL : 2H CLPO CLAMP Adaptive filter operation Logical operation 4fsc Phase comparator PLSL PLSL PLSL IC7201 SAA4977H <BESIC A/D, D/A & Controller> -26- F7YLV...
Page 27 IC7205 SAA4991WP <MELZONIC Digital Scan Conversion> IC7206, IC7207 SAA4955TJ <Field Memory> -27- F7YLV...
Page 28: Waveforms
WAVEFORMS TPVIDEO, K8M-12 K8M-10 Composite Y-input Video K8M-8 K8P-12 Chroma- H-sync input K8P-9 K8P-5 V-sync S.C.-pulse K8A-12 K8Q--7 Video- Y-output input -28- F7YLV...
Page 29 (10) K8Q-9 K8Q-11 U(B-Y)- V(R-Y)- output output (12) (11) K8R-10 K8R-12 2U(B-Y)- 2Y-input input (13) (14) K8R-8 K8R-6 2V(R-Y)- H-Sync input output (15) (16) K8R-5 K8R-3 V-Sync 2HD-input output -29- F7YLV...
Page 30 (17) (18) K8R-2 K3D-2 2VD-input R-output (19) (20) K3D-3 K3D-4 G-output B-output (21) (22) K2E-4 K2E-6 Pcc- Vert-drive output (23) (24) K2E-7 K2E-8 Vert- Vert-drive Blanking output -30- F7YLV...
Page 31 (25) (26) K2D-3 IC711-8 H-drive Blue- output output (27) (28) IC721-8 IC731-8 Green- Red- output output (29) (30) IC501-3 Q402-C Vert.- Horiz. output Drive -31- F7YLV...
Page 32: Pin Description Of Semiconductors
PIN DESCRIPTION OF SEMICONDUCTORS Diode Diode K: Cathode A: Anode Transistor/FET Transistor/FET C: Collector D: Drain B: Base G: Gate Index E: Emitter S: Source C1 C2 C1 C2 (GND) RESET (IN) (OUT) Index Index Index Index Index Index Index Index Index -32-...
Page 33: Parts Description And Reading In Schematic Diagram
PARTS DESCRIPTION AND READING IN SCHEMATIC DIAGRAM 1. The parts specification of resistors, capacitors and Resistor Reading coils are expressed in designated code. Please Example 1/2 D J 10K B check the parts description by the following code table. Characteristic 2.
Page 34: Cabinet Parts List/T V Stand Parts List
DEC IND B-F7HL 610 279 4557 DEC CONTROL SHEET-F7HC 610 253 2449 AC CORD HOLDER-U-D4VA 610 261 3032 SPRING-E7GC 645 034 8228 BADGE,SANYO*53.5X12 BROWN 610 104 2505 LATCH PUSH,7.9X6.9BK SKZZ0089 DC HOLDER-F2KA 1AA2HLM0111A- HOLDER DC GBR-HBZ 610 235 1347 WIRE HOLDER-E5BE...
Page 35 -35- F7YLV...
Page 36 Item Part No. Description TV STAND-WST3291 SKZZ0139 TOP BOARD-WST3291 SKZZ0137 SIDE BOARD-WST3291 SKZZ0136 PROFILE-WST3291 SKZZ0141 BASE BOARD-WST3291 SKZZ0147 CASTON-WST3291 X4 SKZZ0143 GLASS DOOR-WST3291 SKZZ0145 SHELF-WST3291 SKZZ0135 ACCESSORY PACK-WST3291 SKZZ0146 SCREW PACK-WST3291 -36- F7YLV...
Page 37: Chassis Electrical Parts Lists
Note: Parts order must contain Service Ref. No., Part No., and descriptions. The main unit will be supplied without tuner and lyback transformer. They should be ordered separately. Chassis Construction : CE32WH3-F Read description in the Capacitor and Resistor as follows: Service Ref. No. CE32WH3-F-01 CAPACITOR CERAMIC 100P K 50V 013F7YL ELECTRICAL PART S Page 37...
Page 38 Ref. No. Part No. Description Ref. No. Part No. Description 405 015 8902 TR 2SC2812-L7-TB 405 002 6706 TR 2SA1179-M6-TB Q1206 405 014 4509 TR 2SC2412K T146 R 405 002 6904 TR 2SA1179-M7-TB 405 014 4608 TR 2SC2412K T146 S Q1227 405 002 0308 TR 2SA1037K T146 R...
Page 39 Ref. No. Part No. Description Ref. No. Part No. Description C1260 403 085 4107 NP-ELECT 10U M R1261 401 105 5202 MT-GLAZE 470 JA 1/16W C1261 403 164 0204 CERAMIC 0.1U Z R1262 401 105 1501 MT-GLAZE 1.5K JA 1/16W C1262 403 125 5002 NP-ELECT...
Page 40 Ref. No. Part No. Description Ref. No. Part No. Description MISCELLANEOUS L043 645 008 5635 INDUCTOR,12U K L1101 645 001 4567 INDUCTOR,10U K K12A 645 018 9463 PLUG,PWB-PWB 20P L1106 645 001 4567 INDUCTOR,10U K K12B 645 018 9470 PLUG,PWB-PWB 25P L1902 645 001 4727 INDUCTOR,10U K...
Page 41 Ref. No. Part No. Description Ref. No. Part No. Description RESISTOR 405 015 8704 TR 2SC2812-L6-TB R1021 401 105 5905 MT-GLAZE 560 JA 1/16W 405 015 8902 TR 2SC2812-L7-TB R1022 401 105 0504 MT-GLAZE 1K JA 1/16W Q101 405 014 4509 TR 2SC2412K T146 R 405 014 4608 TR 2SC2412K T146 S...
Page 42 Ref. No. Part No. Description Ref. No. Part No. Description Q201 405 002 0308 TR 2SA1037K T146 R 405 014 4608 TR 2SC2412K T146 S 405 002 0407 TR 2SA1037K T146 S 405 015 8704 TR 2SC2812-L6-TB 405 002 6706 TR 2SA1179-M6-TB 405 015 8902 TR 2SC2812-L7-TB...
Page 43 Ref. No. Part No. Description Ref. No. Part No. Description 405 015 8704 TR 2SC2812-L6-TB 403 237 8007 MT-COMPO 0.1U J 405 015 8902 TR 2SC2812-L7-TB C018 403 200 0700 MT-POLYEST 0.1U J Q378 405 014 4509 TR 2SC2412K T146 R 403 237 8007 MT-COMPO 0.1U J...
Page 44 Ref. No. Part No. Description Ref. No. Part No. Description C203 403 168 8800 MT-POLYEST 0.22U J C358 403 049 0008 ELECT 1U M 403 237 7901 MT-COMPO 0.22U J C359 403 049 0008 ELECT 1U M C204 403 139 7306 CERAMIC 18P J C360...
Page 45 Ref. No. Part No. Description Ref. No. Part No. Description C838 403 041 2109 ELECT 47U M R162 401 105 0504 MT-GLAZE 1K JA 1/16W C839 403 149 9208 CERAMIC 0.01U Z R163 401 105 0504 MT-GLAZE 1K JA 1/16W C840 403 041 2109 ELECT...
Page 46 Ref. No. Part No. Description Ref. No. Part No. Description R226 401 105 4205 MT-GLAZE 33K JA 1/16W R323 401 105 6506 MT-GLAZE 680 JA 1/16W R231 401 105 0405 MT-GLAZE 100 JA 1/16W R324 401 105 6506 MT-GLAZE 680 JA 1/16W R232 401 105 0405 MT-GLAZE...
Page 47 Ref. No. Part No. Description Ref. No. Part No. Description VARIABLE RESISTOR R813 401 105 0405 MT-GLAZE 100 JA 1/16W R814 401 105 0603 MT-GLAZE 10K JA 1/16W VR181 645 002 3521 VR,SEMI,470 S R816 401 105 0603 MT-GLAZE 10K JA 1/16W R817 401 105 0603 MT-GLAZE...
Page 48 Ref. No. Part No. Description Ref. No. Part No. Description D802 407 149 0807 DIODE 1SS355-TE-17 645 004 2928 PLUG,6P D803 407 149 0807 DIODE 1SS355-TE-17 X131 421 008 0906 SAW F TSB6315T D811 408 008 2406 DIODE 1N4148 X132 421 002 2609 SAW F TSF5315 407 013 4306...
Page 49 Ref. No. Part No. Description Ref. No. Part No. Description 405 011 8609 TR 2SC1740S-S C483 403 049 4204 ELECT 10U M 405 012 2002 TR 2SC1815-GR C490 403 185 8807 MT-POLYEST 1U K 250V 405 012 2309 TR 2SC1815-Y C504 403 148 0404 ELECT...
Page 50 Ref. No. Part No. Description Ref. No. Part No. Description RESISTOR R601 401 007 2903 CARBON 1M JA 1/2W R602 401 007 2903 CARBON 1M JA 1/2W R402 401 016 2604 CARBON 220 JA 1/4W R603 401 069 4501 OXIDE-MT 68K JA R403 401 026 6609...
Page 51 Ref. No. Part No. Description Ref. No. Part No. Description D411A-1 610 269 6752 HEAT SINK (HKG) F3TV 407 099 5204 ZENER DIODE MTZJ5.1B D411A-3 411 045 2209 SCR PAN+SW 3X10 407 063 8705 ZENER DIODE MTZJ5.1C D411A-4 411 004 4404 NUT HEX 3 D514 407 063 8606...
Page 52 Ref. No. Part No. Description Ref. No. Part No. Description 407 054 8301 ZENER DIODE RD18EB1 405 012 2002 TR 2SC1815-GR 407 054 8400 ZENER DIODE RD18EB2 405 012 2101 TR 2SC1815-O D642 407 099 3309 ZENER DIODE MTZJ13C 405 012 2309 TR 2SC1815-Y D643 407 005 4505...
Page 53 Ref. No. Part No. Description Ref. No. Part No. Description C709 403 049 0008 ELECT 1U M R740 402 002 4305 FUSIBLE RES 33 J- C710 403 023 9607 CERAMIC 39P J R743 401 025 7409 CARBON 220 JA 1/6W C712 403 161 9200 MT-POLYEST...
Page 54 Ref. No. Part No. Description Ref. No. Part No. Description 405 014 4608 TR 2SC2412K T146 S C3512 403 192 5905 CERAMIC 0.1U K 405 015 8704 TR 2SC2812-L6-TB C3513 403 157 7302 CERAMIC 6800P K 405 015 8902 TR 2SC2812-L7-TB C3514 403 049 4204 ELECT...
Page 55 Ref. No. Part No. Description Ref. No. Part No. Description ASSY,PWB,3L Y/C-F7HL 1AA0B10E478A0 405 015 8704 TR 2SC2812-L6-TB 405 015 8902 TR 2SC2812-L7-TB Q7052 405 014 4509 TR 2SC2412K T146 R TRANSISTOR 405 014 4608 TR 2SC2412K T146 S Q1301 405 014 4509 TR 2SC2412K T146 R 405 015 8704...
Page 56 Ref. No. Part No. Description Ref. No. Part No. Description C7032 403 157 4202 CERAMIC 220P J R2512 401 105 0603 MT-GLAZE 10K JA 1/16W C7034 403 043 9106 ELECT 47U M R2514 401 105 1105 MT-GLAZE 12K JA 1/16W C7035 403 149 9208 CERAMIC...
Page 57 Ref. No. Part No. Description Ref. No. Part No. Description TRANSFORMER Q7306 405 014 4509 TR 2SC2412K T146 R T7051 645 028 2454 FILTER,LP 6MHZ 405 014 4608 TR 2SC2412K T146 S T7052 645 028 2454 FILTER,LP 6MHZ 405 015 8704 TR 2SC2812-L6-TB 405 015 8902 TR 2SC2812-L7-TB...
Page 58 Ref. No. Part No. Description Ref. No. Part No. Description C7222 403 039 6508 ELECT 100U M 645 018 8930 R-NETWORK 47X4 1/16W C7223 403 164 0204 CERAMIC 0.1U Z RB7213 645 037 0670 R-NETWORK 47X4 0.063W C7224 403 164 0204 CERAMIC 0.1U Z 645 018 8930...
Page 59 Ref. No. Part No. Description Ref. No. Part No. Description R7329 401 105 6506 MT-GLAZE 680 JA 1/16W XL7207 645 025 0620 FILTER,EMI 85PF R7330 401 105 0504 MT-GLAZE 1K JA 1/16W XL7208 645 025 0620 FILTER,EMI 85PF R7331 401 105 0504 MT-GLAZE 1K JA 1/16W XL7209...
Page 60 PC5991A 610 273 7929 HOLDER LED-S4KF All information in this manual is correct at the start of production. Sanyo reserves the right to modify components and procedures in order to comply with their continuous improvement policy. Printed in UK. Sanyo Industries (UK) Ltd...
Page 61 I suddetti componenti devono essere sostituito con 2SA933(Q,R), SERVICE REF.NO. CE32WH3-F-01 specified on the part service manual and controls adjusted for normal picture. posizioni normali ed il commutatore AFC in sostituti esclusivamente con quelli indi-...
Page 62 ASSY,PWB,MAIN-F7HL/YL(1AA0B10E474B0) PB101 A4B10E18600 PWB,MAIN-F7HA (1AA4B10E18600) IC674 7.5V IC674A IC674B IC674E 2HEF0080-- ZB13: E4628 ZB29 BA05T 7.1V 5.0V C005 R678 AUDIO GND 16KK 1SJ5.6 0.1GQ AUDIO GND 5VTV C673 C684 C686 AUDIO GND C675 KZ0.01 KZ0.01 10EM 16EM D679 AUDIO GND 1SS355 IC673 IC673A...
Page 63: Audio Out
ASSY,PWB,AUDIO F7HA (1AA0B10E47700) C3513 R3501 C3510 C3509 C3508 C3507 9.0V-REG KK6800 C3514 J3458 1/16GF KK0.01 KK0.01 KK0.01 KK0.01 PWB,AUDIO F7HA (1AA4B10E1920A) EM10 7.5KC 1/16 GZ0C IC3500 C3512 C3511 25KK 25CJ BA178M09T 0.1BA 1000CGQ :L78M09CV :MC78M09CT C3522 16KK 0.33BA: 16KK 0.33GMB C3500 C3520 C3519...
Page 64 ASSY,PWB,FRONT-F7HL(1AA0B10E473BC) <P3> PWB,FRONT-F7HA (1AA4B10E1880C) K19F 12VTV R820 1/16GJ100C J10EA120N R834 D817 1/16GJ UDZ12B 100C R885 R848 1/16GJ 10KC C813 R894 D825 C814 IC001A IC001B KZ0.01 1/16GJ ZB13: HE0099C-- UDZ12B ZB29 10EM47 100C R855 IC001 TA8200AH 1/16GJ C822 C818 C816 C811 10KC D827 R826...
Page 65 ASSY,PWB,SCAN CONV-F7HL(1AA0B10E48300) IC7206 RB7210 QXXAVB336P PWB,SCAN CONV-F7HL (1AA4B10E20000) R1EA SAA4955TJ/V1 4704G TP-E1 RB7211 R1EA 4704G GND-P GND-P RB7212 R1EA GND-O 4704G V0_M2I8 L7212 V0_M2O8 V1_M2I9 IC7351 EZ0070XXA V1_M2O9 L88M05TP U0_M210 U0_M2O10 R7223 C7224 C7229 U1_M2I11 1/16 25KZ 25KZ U1_M2O11 L7214 GJ47C 0.1GQF 0.1GQF...
Page 66 ASSY,PWB.FRONT-F7HL(1AA0B10E473BC) K19G K19J K19E1 K19E2 K19E3 K19E4 C1974 PWB.FRONT-F7HA (1AA4B10E1880C) J30B0250N POWER RC AMP D1907 C1972 C1973 1SS133 A1901 D1903 D1906 U20B07200 SLP-181B51 K1101 ;U2R0003-- 1SS133 MANU SERVIS J31B01001 DOWN DOWN VIDEO D1904 SW1901 SW1902 SW1903 SW1904 SW1905 SW1906 SW1907 SW601H1 SW601H2 1SS133...
Page 67 TO FRONT TO TER K19C K12EA 99,08,25 <P3> K12C C1239 Q1217 K12E C1237 25KZ R1269 D1218 16EM 0.1GQF 1/16 UDZ12B J10AR050N GJ560C C1238 R1267 J10EQ080N 16EM 1/16 R1268 R1271 100S GJ470C R1272 1/16 1/16 R1285 GJ1.5KC GJ100KC Q1216 1/16GJ5.6KC Q1215 D1217 R1263 C1236...
Page 68 MAIN BOARD CIRCUIT SIDE MAIN BOARD COMPONENT SIDE...
Page 69 POWER DEFLECTION BOARD CIRCUIT SIDE POWER DEFLECTION BOARD COMPONENT SIDE Part No. 1AA6P2P0955-- F7YLV (SHEET 5/9)
Page 70 BACK TERMINAL BOARD TERMINAL BOARD CIRCUIT SIDE CIRCUIT SIDE TERMINAL BOARD COMPONENT SIDE BACK TERMINAL BOARD COMPONENT SIDE FRONT BOARD CIRCUIT SIDE...
Page 71 AV SW BOARD CIRCUIT SIDE AV SW BOARD COMPONENT SIDE FRONT BOARD COMPONENT SIDE Part No. 1AA6P2P0955-- F7YLV (SHEET 6/9)
Page 72 3L Y/C BOARD AUDIO BOARD CIRCUIT SIDE CIRCUIT SIDE 3L Y/C BOARD COMPONENT SIDE AUDIO BOARD COMPONENT SIDE CRT BOARD CIRCUIT SIDE...
Page 73: Crt Board
CRT BOARD COMPONENT SIDE SUB POWER BOARD CIRCUIT SIDE SUB POWER BOARD COMPONENT SIDE Part No. 1AA6P2P0955-- F7YLV (SHEET 7/9)
Page 74 SCAN CONVERTER BOARD HAR SENSOR BOARD CIRCUIT SIDE CIRCUIT SIDE SCAN CONVERTER BOARD COMPONENT SIDE HAR SENSOR BOARD COMPONENT SIDE SENSOR BOARD SENSOR BOARD COMPONENT SIDE CIRCUIT SIDE...
Page 75 WAVEFORMS (17) (18) K8R-2 K3D-2 2VD-input R-output TPVIDEO, K8M-12 K8M-10 Composite Y-input Video (19) (20) K3D-3 K3D-4 G-output B-output K8M-8 K8P-12 Chroma- H-sync input (21) (22) K2E-4 K2E-6 Pcc- Vert-drive output K8P-9 K8P-5 V-sync S.C.-pulse (23) (24) K2E-7 K2E-8 Vert- Vert-drive Blanking output...
Page 76 Exit from the Service Mode OPTION SETTING + Press the RECALL button or turn off the TV set by using the Mains switch. [After replacing the Menory IC (IC803)] The memory IC, IC803, stores the option data of TV set and service adjustments data for each circuit, therefore, when the memory IC is replaced, it should be performed following setting and “SERVICE ADJUSTMENT”...
Page 77 CPU PORT FUNCTIONS Pin No. Function Name Function IN/OUT I/O Expander 1 (IC809)Pin Function Table (CXA1315) MMU0 Pin No. Function Name Function Action IN/OUT MMU3 Power failuer detection Input ADDR10 Address bus 10 Front AV Switch “H” Front AV “L” AV3 DAC4 50/60hz Switch “H”...
Page 78 CHASSIS BLOCK DIAGRAMS This is a diagram for all models and therefore differs slightly from the actual block diagram. System control RL1601 Outline Q1652 Power CVBS input Supply Power ON/OFF Circuit 60 48 49 44-47 42 Photo Sensor IC802 IC801 19 20 21 22 23 RC Pre-amp.
