Acer M330 Service Manual

Hide thumbs Also See for M330:
Table of Contents

Advertisement

Quick Links

See also: User Manual
M330
SERVICE
GUIDE
1

Advertisement

Table of Contents
loading

Related Manuals for Acer M330

Summary of Contents for Acer M330

  • Page 1 M330 SERVICE GUIDE...

  • Page 2: Table Of Contents

    Full OS and Factory OS switching method………………….………………...……..………...67-73 FASTMMI functional testing…………………………………………………..………....74-103 Chapter 5 Serial Number Definition Introduction of Acer FG SN………………………………………………………...………….104-111 Introduction of Acer KC PN and Acer KC SN…………………………………....112-113 Chapter 6 FRU (Field Replaceable Unit) List Exploded Diagram………………………………………………………………..………….…114-116 FRU List………………………………………………………………………………...….117-121...

  • Page 3: Revision History

    Update Copyright Copyright 2015 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 4 For Acer-authorized service providers: Your Acer office may have a different part number code than those given in the FRU list of this printed service guide. The list provided by your regional Acer office must be used to order...
  • Page 5 CHAPTER 1 Product Features and Hardware Specifications Product Features and Hardware Specifications Features………………………………………………….……………………………….. .……...…1-5 Phone Tour………………………………………………………………………….…………..…6 Front View………………………………………………………………………………….….……..….7 Rear View…………………………………………………………………………….………..……..…8 Top View………………………………………………………………………….…. ……….….……..9 Bottom View………………………………………………………………………………….……..10 Left View………………………………………………………………………………………..………11 Right View……………………………………………………..……………...…………………..….12 System Block Diagram………………………………………………………………………….…..13...

  • Page 6: Chapter 1 Product Features And Hardware Specifications

    □G/G ■G/F □G/F/F □Single Glass (OGS2 , Gorilla 3 , 2.5D Touch Lens Type, glass)□ On cell □In cell Air Gap Air bonding – Cover Surface Hardness Feature With Anti-Finger print Coating, without Quick touch Printing Acer logo Dimensions 136 X66.5 X 9.6mm Weight 142g (with battery)
  • Page 7 Wireless LAN IEEE 802.11 b/g/n GPS, with A-GPS support and SUPL ■Yes (Using Headset as antenna) □No ■Yes Micro-USB □No ■No HDMI □Yes ■Yes Acer Cloud □No ■No □Yes ■No Wireless Display(Miracast) □Yes; Type Connectivity ■No WiFi Direct □Yes ■No Wireless Charging □WPC □A4WP...
  • Page 8 Audio Jack 3.5mm Speaker Single (without Box) Media Format and Video Encoder H.263, H.264 AVC, Codec Support Video Decoder H.263, H.264 AVC, H.265 HEVC, MPEG-4 SP, VP83, VP9 (Android 4.4+), WMV9 Audio Encoder AAC LC, AMR-NB, AMR-WB, PCM/WAVE (Android 4.0+), AAC+ (Android 4.1+), AAC ELD (Android 4.1+) Audio Decoder AAC LC, AAC+, eAAC+, WAV, MP3, MIDI, Vorbis, AMR-NB, AMR-WB,...
  • Page 9 PTCRB report Certification TW SKU : NCC/CE JP SKU : JATE/TELEC/VCCI/PSE(Battery) ■No □Yes Must Comply with acer 707-0008-V7 Guidance of Restricted Substances In proceducts Complete acer Eco-profile (including attachments) and tender questionnaire if any. ■Yes Green Design RoHS/WEEE □No ■No PVC Free □Yes...
  • Page 10 Accessory Adapter : ■ CE logo for EU EMC (CB test report & EMC test report) /. Certification Safety: □ UL license (for America safety) ■ TUV Certification (for German safety) ■ Gost-R license (for Russia) □ C-Tick license (for Australia) / …… ■...

  • Page 11: Phone Tour

    Phone Tour Six View...

  • Page 12: Front View

    Front View Figure 1.1 Front View Item Description FRONT CAMERA 6.5*6.5*3.9_500W IR HOLE LED LAMP TOUCH SCREEN Cutting glass, bottom silkscreen RECEIVER DECEORAION Aluminum, silver RECEIVER MESH Black...

  • Page 13: Rear View

    Rear View Figure 1.2 Rear View Item Description REAR COVER PC, black REAR CAM LENS Black, cutting glass, bottom silkscreen FLASH LAMP PMMA, transparent SPEAKER MESH Black...

  • Page 14: Top View

    Top View Figure 1.3 Top View Item Description POWER KEY BUTTON Power on or off the phone. AUDIO JACK...

  • Page 15: Bottom View

    Bottom View Figure 1.4 Bottom View Item Description USB Port...

  • Page 16: Left View

    Left View Figure 1.5 Left View...

  • Page 17: Right View

    Right View Figure 1.6 Right View Item Description FRONT COVER PC+10%GF, black MIDDLE COVER PC, silver VOLUME KEY BUTTON Increases or decreases the volume.

  • Page 18: System Block Diagram

    System Block Diagram...

  • Page 19: Chapter 2 Diagnostic Utilities

    CHAPTER 2 Diagnostic Utilities Introduction The M330 has a Qualcomm Multiple Download Tool designed to software upgrading and a WriteStation Tool designed to write SN/IMEI/BT/Wifi, etc. Qualcomm Multiple Download Tool Guide 1. Purpose: This document is Qualcomm platform EMMC multiple download tool operating instructions. Applicable to HQXA_CustomerDL_EMMC_V *.
  • Page 20 Pic 1 3.2 Install Process Pic 2 3.3 Driver Warning Driver is not certified WHQL. The first installation will show the following dialog box. Please click still proceed with the installation. The installation process to support multi-port will Tip many times. Pic 3...
  • Page 21 3.4 Driver Finish Pic 4 After the installation is complete, the drive will need to restart the computer drives can automatically take effect. simpleio_win7.zip should install after Run installsimpleio.bat after extraction...
  • Page 22 4. Procedure 4.1 Program Install The program can decompress compressed files used. 4.2 System Connect PC through the USB port and the phone connection and to be upgraded 4.3 Run Program (1) Connect to PC (2) Run “PhoneOS.exe” Program. Program will starts normal. (3) Will show as below.
  • Page 23 Pic2 Support 1 drag 8 upgrade 5. Download Configure 5.1 Path Configure The need for the path and port software to configure the software after the open as below.
  • Page 24 Pic 6 Select the software version FFU file 6. Download Process After you configure the path and port directly point the main interface "Start" button to start the download process. This tool supports up to 8 threads to download...
  • Page 25 Pic 13 7. Flash Result Upgrade is complete, if successful, the CMD window will disappear, if failed, will stay in the form.
  • Page 26 After flash done, M330 will boot and remain in Factory mode as pic. Please click “FullOS” and status will show “Change mode success” , long press “Power key” to shut off M330. Press power key to boot M330 can enter User mode OS.
  • Page 27 8. Download Except Process At the same time holding down the power button and volume+ key. Waiting for the phone to vibrate and loosen the power button. Long press the volume+ key, until the image below. Then Should use PhonesOS tool change OS in FT OS Encountered in the process of download abnormal situation lead to the upgrade fails.
  • Page 28 D:QL621\A\Acer_TM01_1.007.00_EMEA_BGCS_EMMC_TES T_20151228 Pic 16...
  • Page 29 9. FAQ (1) No Phone Device Manager has a port, but the tool still shows No Phone, because there may be other tools occupy Diag port. Investigation as follows: Step 1: Please see if there is open to other PC side tools such as QPST and other tools on the computer. Yes please turn off.
  • Page 30 Click Next:...
  • Page 31 Automatic install:...

  • Page 32: Qualcomm Writestation User Guide

    2.4: All tools or drivers are mentioned above can be download from: http://192.168.25.184/wiki/tools.html 4：Write 4.1：Double click the icon show as below picture to run WriteStation： Note: M330 all operation should be done when phone is powered on, and change OS in FTOS.
  • Page 33 CHAPTER 4 Diagnostic Tool SOP Full OS and Factory OS switching method Please refer to 4.2：User interface of WriteStation...
  • Page 35 4.3. Set parameters...
  • Page 36 Password: 20120405...
  • Page 37 4.4. Set platform information A: Input number by manual Config the tool M330 should Config Platform YEP Acer M330: indicates feature phone platform of YEP Spread: indicates Spread platform...
  • Page 38 4.7：Project information set Print: print only Write: write number only Print&Write: write number first and then print these numbers. SN: SN writing will be enabled if this box is checked and disabled wile unchecked. BT: BT writing will be enabled if this box is checked and disabled wile unchecked. WIFI: WIFI writing will be enabled if this box is checked and disabled wile unchecked.
  • Page 39 Trace： here are two trace mode, “none” and “Access”, “none” indicates no trace information will be recorded and “Access” indicates that written information will recorded in a access table. When user has chosen “Access” as trace mode, the written information will be recorded in a file named “Database.mdb” at the tool’s installation directory.
  • Page 40 4.9：BT control information set lowerRange：the lower range of BT. upperRange：the upper range of BT. If the low value and the upper value are not zero at the same time，the tool will compare the BT which will be written with the low value and the upper value. AuotAssign: decide if BT will be assigned automatically from the BT excel file configured at “BT File”, if this button is checked, only BT could be written.
  • Page 41 lowerRange：the lower range of WIFI. upperRange： the upper range of WIFI. If the low value and the upper value are not zero at the same time， the tool will compare the WIFI which will be written with the low value and the upper value. AuotAssign: decide if WIFI will be assigned automatically from the WIFI excel file configured at “WIFI File”, if this button is checked, only WIFI could be written.

  • Page 42: Chapter 3 Service And Maintenance

    CHAPTER 3 Service and Maintenance Introduction This document contains general information about the phone, a list of tools needed to perform the required maintenance and steps on how to disassemble and re-assemble parts from the phone. Disassembly and Assembly Guide I.
  • Page 43 II. Appropriate Tools for Reference The illustrations below show the appropriate tools that should be used for the phone’s service and repair. (1) Screwdriver (2) Tweezers Use a pair of tweezers to remove/insert cables. (3) Disassembly Blade...
  • Page 44 III. Disassembly Steps (1) Disassemble the battery cover. Insert the disassembly blade to the hook and take off the battery cover. (2) Remove the screws. Use screw-driver to remove the 12 screws circled in red.
  • Page 45 (3) Disassemble the 4G antenna cover. Insert disassembly blade to the gap of antenna cover and rear cover, then take off the antenna cover. Use tweezers to remove the speaker from the corner, please be careful when removing to avoid back...
  • Page 46 foam being separated from speaker. (4) Disassemble the rear cover and side key buttons.
  • Page 47 Insert disassembly blade to the gap of rear cover and front cover, then separate the rear cover from front cover. Use tweezers to take off the power key button from two buckles circled in red. Use tweezers to take off the volume key button from two buckles circled in red.
  • Page 48 The remaining part is the defined rear cover module, which includes the rear cover and camera lens. (5) Disassemble the RF cable and rear camera. Use tweezers to remove two ends of RF cable from MB and SB, then separate the rear camera from MB connector.
  • Page 49 (6) Disassemble the MB assembly. Use tweezers to disassemble the LCD connector circled in red, the TP connector circled in yellow and the power key FPC circled in blue from MB. Disassemble the LINK FPC connector and take off the MB.
  • Page 50 Disassemble the front camera (including back conductive fabric) and G-sensor rubber case. The remaining part is the defined MB Module, which includes MB, power key FPC, waterproof label and G-sensor rubber case (which also is taken as L2 repair material).
  • Page 51 (7) Disassemble the SB assembly. Disassemble LINK FPC connector, use tweezers to loosen the motor from groove. The remaining part is the defined SB module, which includes the SB and motor.
  • Page 52 (8) Disassemble the volume key FPC. Use tweezers to disassemble the FPC, please be careful to avoid back gum of FPC being separated.
  • Page 53 (9) Disassemble the receiver. Use tweezers to disassemble the receiver from this direction, please be careful when removing to avoid back gum being separated from receiver.
  • Page 54 (10) Disassemble the device label and LINK FPC. Please be careful when removing the LINK FPC to avoid back gum being separated from LINK FPC.
  • Page 55 (11) When finishing disassembly steps, all the defined parts and modules are shown as below.
  • Page 56 IV. Re-assemble Steps (1) Assemble the LINK FPC. Gently assemble the LINK FPC aligning to two positioning holes. (2) Paste the device label. Paste the device label from the right bottom corner.
  • Page 57 (3) User tweezers to assemble the receiver on LCD module, remind that its shrapnels are downward. (4) Assemble the volume key FPC. Use tweezers to paste the volume key FPC aligning to two positioning holes first, then paste the left side along the front cover.
  • Page 58 (5) Assemble the SB module. Firstly, connect SB with LINK FPC, remind that FPC’s white line should be parallel to connector cover. Then fix the SB according to the positioning hole. Finally, twist the motor coil for 2 circles and fix the motor on the groove.
  • Page 59 (6) Assemble MB assembly. Firstly, assemble the front camera on MB connector. Remind that FPC’s white line should be parallel to connector cover. And camera’s back conductive fabric should be pasted on MB. Then, assemble the G-sensor on MB.
  • Page 60 Thirdly, slightly lift the left corner of device label and connect MB with LINK FPC. Remind that FPC’s white line should be parallel to connector cover. (7) Assemble MB module on LCD module. Firstly, Assembly the MB aligning to 4 hooks and the front camera should be assembled in the groove. Then connect the TP FPC &...
  • Page 61 (8) Assemble the rear camera and RF cable. Assemble the rear camera on MB connector, and connect the RF cable to MB & SB. (9) Assemble the side key buttons and rear cover. Assemble the volume key button and power key button on the rear cover.
  • Page 63 Then combine and compress the rear cover with LCD module & MB. (10) Assemble the antenna cover. Assemble the speaker on antenna cover, remind that two shrapnels of speaker are rightward.
  • Page 64 Then compress the antenna cover on rear cover. (11) Assemble 12 screws circled in red on the rear cover.
  • Page 65 (12) Combine and compress the battery cover with the handset.

  • Page 66: L2 Troubleshooting Guide

    V. L2 Troubleshooting Guide 1. Fail to power on Issue Description Cause Solution Side key FPC isn’t welded well re-weld Fail to power on side key FPC breaks replace side key FPC MB has defects Refer to MB Service Manual 1.
  • Page 67 3. TP issue Issue Description Cause Solution FPC isn’t well assembled re-assemble TP FPC TP touch pad fails FPC breaks replace TP MB is damaged refer to MB Service Manual TP scratches replace TP TP appearance has defects TP is damaged replace TP 1.
  • Page 68 4. Side key buttons issue Issue Description Cause Solution Side key FPC’s connection has replace FPC defects Side key button has no response 1.replace the battery cover Side key button has defects 2.replace side key FPC 1. Check the side key button’s touching, if it is assembled in place.
  • Page 69 6. Rear camera issue Issue Description Cause Solution Rear camera FPC isn’t well re-assemble camera FPC assembled Camera not prepared, not working/No function Rear camera is defective Replace the camera MB is damaged Repair MB Cannot start rear Rear camera is defective Replace the camera camera FPC isn’t well assembled or...
  • Page 70 1. Check if the camera FPC is assembled in place or breaks. 2. Use fixture or good MB to test the camera quality. 3. Check and repair MB. 8. Antenna cover issue Issue Description Cause Solution Antenna cover appearance is defective Replace antenna cover no signal Antenna shrapnel badly connect to SB...
  • Page 71 10. Earphone issue Issue Description Cause Solution Earphone socket is defective replace earphone socket No function MB is damaged Repair MB Earphone acoustic Earphone socket is defective replace earphone socket anomaly MB is damaged Repair MB 11. Receiver/speaker box issue Issue Description Cause Solution...
  • Page 72 12. Microphone issue Issue Description Cause Solution MIC has defects replace Acoustic problem Miss assembling MIC rubber case Re-assemble MB has defects Repair MB MIC has no sound MB has defects Repair MB 13. Battery issue Issue Description Cause Solution Screen shows MB has defects Repair MB...

  • Page 73: Chapter 4 Diagnostic Tool Sop

    CHAPTER 4 Diagnostic Tool SOP Full OS and Factory OS switching method 1. Qualcomm platform of Windows 10 mobile phone has two modes, Full OS respectively (user mode) and the Factory OS (Factory production mode). (1) Full OS screenshot: (2) FactoryOS screenshot:...
  • Page 74 2. Qualcomm platform of Windows 10 mobile phones has the following two key combination, they can enter the different state. (1)Flashing mode A. At the same time holding down the power button and volume+ key. Waiting for the phone to vibrate and loosen the power button.
  • Page 75 C. Enter the file emmcdl (In the attachment). D. Input command: FFUTool–list. As shown, says it has connected computer.
  • Page 76 3、In the Flashing mode，Full OS and Factory OS switching method 1）Connect the computer and enter the Flashing mode. 2）Switch from Full OS to Factory OS, input command: FFUTool -setBootMode 1 Factory. The phone automatically restart, and boot into the Factory OS.
  • Page 77 3）Switch from FactoryOS to FullOS, input command: FFUTool -setBootMode 0. The phone automatically restart, and boot into the FullOS. 4、In the Mass Storage mode, Full OS and Factory OS switching method 1）Connect the computer and enter the Mass Storage mode. 2 ）...
  • Page 78 3 ） Switch from FactoryOS to FullOS, input command: emmcdl -p 1 -b BOOTMODE bootmode_fullos.bin，Below said switching is successful, then blackout and reboot phone, phone will enter the FullOS.

  • Page 79: Fastmmi Functional Testing

    FASTMMI functional testing 1. Preface This document use for qualcomm platform smartphone production test process, to certain model of qualcomm platform smartphone functional test instruction in production, the purpose is to confirm the item function is normal or not. 2. Functional testing detail Assembly micro SD card, SIM card into the phone or testing jig and connect USB cable before testing.
  • Page 80 2.1.1 Auto Run all This test item use to PCB testing by jig, the program will detect SD card and SIM card after select this test item. The warning message will show as below figure if the device not detected SD card and SIM card. It should be Power off the phone and confirm SD card and SIM card.
  • Page 81 2.1.2 Auto Run all phone This test item use to whole phone after Assemble, the program will detect SD card and SIM card after select this test item. The warning message will show as below figure if the device not detected SD card and SIM card. It should be Power off the phone and confirm SD card and SIM card.
  • Page 82 2.1.4 Reset test Results This item is use to clear the test result for retest.
  • Page 83 2.1.5 System information This item is use to check the phone information, such as OS version/firmware version/ hardware version/manufacturer/Radio software version/screen resolution/WLAN MAC/BT MAC/ IMEI/SN/PCBA flag/Phone flag/BT flag/FT flag and so on.
  • Page 84 2.1.5 Power down This item is use to power down the phone after finished test...
  • Page 85 2.1.6 Language This item is use to select the language, the device only support Chinese and English MMOS version default Chinese.
  • Page 86 2.2 Testing Item Description Below will show each testing item detail and notes 2.2.1 Bluetooth This item is use to Bluetooth function testing. Bluetooth testing interface as blow figure, if the interface show Bluetooth signal source (green color word), that indicated test pass, you can select pass go to next.
  • Page 87 2.2.2 WIFI 2.2.3 This item is use to WIFI function testing, WIFI testing interface as blow figure, if the interface show WIFI signal source (yellow color word), that indicated test pass, you can select pass go to next. If the test failed, pass item can’t be selected, only fail item can be selected, exit and go to next testing item.
  • Page 88 2.2.4 GPS This item is use to GPS function testing, GPS testing interface as blow figure, if the interface show GPS signal source, that indicated test pass, you can select pass go to next. If the test failed, pass item can’t be selected, only fail item can be selected, exit and go to next testing item.
  • Page 89 2.2.5 LCD Display This test item is use to LCD display color test, this testing interface as below figure, check the color is ok or not, check the LCD spot, click LCD will change another color interface. If LCD test ok, select pass item to go to next, if not(display issue), select fail item.。...
  • Page 90 2.2.5 LED Test This item test use to test 3 colors led(this led near receiver), the interface show as below figure, click LED ON, you can see LED show 3 color in turns per time(green, red, blue), it indicate test pass, if not, it is meaning fail. Notes: click “LED ON”...
  • Page 91 2.2.6 Touch This item use to test touch function, testing interface show as below, finger touch between two white line. During test, not allow touch the white line, white line change to green color. if not, white line change to red color that must be test again. If pass, the white line will disappear.
  • Page 92 2.2.8 Vibrator This item use to test motor vibrator, testing interface show as below, click the “ON/OFF” to control motor ON /OFF, if motor working ok, it indicate pass, if not is meaning fail. If vibrator is normal, click on the "pass"; If not, need to click on the "fail" button, it is going to the next test.
  • Page 93 2.2.9 LCD Backlight This item use to test lcd backlight, testing interface show as below, If you can see the backlight brightness change, and is gradually, according to a percentage to change shows that the test is successful, when the backlight changes from 0% to 100%, and then from 100% to 0%, then you can click on the "pass"...
  • Page 94 2.2.11 Back camera This item use to test back camera function, testing interface show as below, click photograph to take a picture, check the picture is clear or not, if effect is ok, select pass, if not is meaning fail, you can test again and exit to next.
  • Page 95 2.2.12 Front camera This item use to test front camera function, testing interface show as below, click photograph to take a picture, check the picture is clear or not, if effect is ok, select pass, if not is meaning fail, you can test again and exit to next. (note: during camera test , if you click on the photograph, it will generated an images, then don't put more than 1 min, or it can't open the camera if you test again, it will solve after restart)
  • Page 96 2.2.13 Proximity sensor This item use to test proximity sensor function, testing interface show as below, hand keep out near the sensor position (usually next to the receiver), if the proximity sensor detect obstructions, the screen will show "detected close to the object", shows that the tests pass, then click on the "PASS", Otherwise when shows "not found object”, "pass"...
  • Page 97 2.2.14 Light sensor This item use to test light sensor function, testing interface show as below, if the light sensor working, screen will show ambient light , XX lux, it is meaning test pass, click pass button to next,. If not, the pass button no use, select fail button exit and go to next.
  • Page 98 2.2.15 Acceleration sensor This test is used to test the acceleration sensor function, into the acceleration sensor testing interface (as shown in the figure below), if sensor read data, the screen will show the data, green arrows indicate identification data, it is meaning test pass, then click on the "pass" button and go to next test, if not is meaning failure, only click on the "fail"...
  • Page 99 2.2.16 Receiver This test is used to test receiver, go into the receiver testing interface (shown as below figure ), then click "paly preset file", you can hear the music, click on the "pass" button to next, if not hear the music, "pass" button is not working, click on the "fail" button and go to the next test.
  • Page 100 2.2.17 Speaker This test is used to test Speaker, go into the speaker testing interface (shown as below figure ), then click "paly preset file", you can hear the music, click on the "pass" button to next. if not hear the music, "pass" button is not working, click on the "fail" button and go to the next test.
  • Page 101 2.2.18 Headset test This test is used to headset test, please insert the headset, go into the testing interface (as shown in figure 1), if the device detect headset, testing interface becomes as shown in figure 2, then click on the "loopback mode" button, speaker to the headset MIC, you can hear the sound of the corresponding from headset;...
  • Page 102 2.2.19 Main MIC This test is used to test main MIC function, please insert the headset, and then go into the microphone test interface (show as below figure 1), if mobile detected the headset, will change testing interface, show as below figure 2, then click on the "loopback mode" button, speak to main MIC, you can hear the sound of the corresponding from headphones, If the above tests are normal, the tests pass, click on the "pass"...
  • Page 103 2.2.20 Sub MIC This test is used to test Sub MIC function, please insert the headset, and then go into the sub MIC test interface (show as below figure 1), if mobile detected the headset, will change testing interface, show as below figure 2, then click on the "loopback mode" button, speak to sub MIC, you can hear the sound of the corresponding from headphones, If the above tests are normal, the tests pass, click on the "pass"...
  • Page 104 2.2.21 FM This test is used to test FM function, go into an FM function testing interface (show as below figure), insert the headset, then device will automatically search FM station, interface shows FM signal that it search, if you can hear the voice from FM, click on the "pass" button, if not is meaning test fail, click on the "fail"...
  • Page 105 2.2.22 SIM This test is used to test SIM card identification, if a SIM card is detected, will display the card slot number and SIM card IMSI number, it said the tests pass, click on the "pass" button, if not is meaning test fail, click on the "fail" button exit and go to the next test. Notes: whatever you select “Auto Run all”...
  • Page 106 2.2.23 Call(note: this test only in the Auto Run all phone test list) This item use to call function, auto run all test list not cover this item, select pass to be next. But auto run all phone must test pass. SIM card 1: click on the "SIM card 1", when registered on the network, please click on the "start/end call", phone will dial fixed number, the number is "8588455446", the status bar shows: call 8588455446.
  • Page 107 2.2.24 Battery This test is used to test mobile phone battery and charge, go into the battery and charging test interface (show as below figure), you can see the battery status changes, from "state of battery discharge" to "the battery state of charge", if above test is success, click pass to next, Note: this test will automatically detect, when insert USB cable, mobile phone state change is detected, device will pass and exit, .If state of battery is the same , phone will always stay in the...
  • Page 108 2.2.25 keypad This item use to test volume up key, volume down key and power key. Click these keys, the keys indicate icon disappear, that is meaning test pass, click pass and go to next. If there is a not disappeared, need to confirm again whether button failure, if it is a failure, need to manually click on the "fail"...

  • Page 109: Chapter 5 Serial Number Definition

    PPPPPPPPPP: Acer FG PN which is from the BOM by PM, 10 characters, without dots here. There are 12 characters in Acer FG PN with the format of 2-5-3 code including two dots. For example: LX.G5808.039. Remove dots to get 10 characters of PPPPPPPPPP.
  • Page 110  The week with the year’s first Thursday in it (the formal ISO definition),  The week with 4 January in it,  The first week with the majority (four or more) of its days in the starting year,  The week starting with the Monday in the period 29 December – 4 January. ...
  • Page 111 * SSSSS: One counter to generate sequence number even different platform, product….. >Manufacturer code, two digits defined by Acer SIC. >It only apply by ODM manufacturer location not factory. >Use alphanumeric characters, including 0~9 and A~Z only (Excluding O, I, A, K and U).
  • Page 112 >Maintain one and only one counter to generate sequence numbers at a manufacture site in different factory (Factory1/Factory2) and different product (NB,/Tablet/SHH) that with a unique MM code >Engineering version code of hardware, two characters defined by ODM/vendor. Please use alphanumeric characters, including 0~9 and A~Z only (Excluding O and I).
  • Page 113 M m m Definition Year Week Sequence Number YWW: 1 digit of year & 2 digits for week code, the same as Acer FG SN. dddddd: 6 decimal numbers transferred from 5 hexadecimal numbers SSSSS of Acer 22_Code_FG_SN Transfer formula for S...
  • Page 114 Transfer formula for Base 36 Example: If Acer FG SN (MM) = 3E, SNID (Mmm) = 314 The following table shows two methods to count sequence numbers. Suppose factory manufactures two models A and B at the same time. Divide...
  • Page 115  http://www.barcode-college.com.tw/barcode.htm Note 4.1: Acer label size is 1 cm * 5 cm. This label size is for reference only. ODM can adjust a little the label size to meet physical requirements. ODM also can discuss with related Acer PM to define the best location to stick Acer FG label.
  • Page 116 Note 4.2: Every Acer FG SN in databases is the same as the characters and the meaning of barcode printed on its own label.

  • Page 117: Introduction Of Acer Kc Pn And Acer Kc Sn

    Acer SIC FTP server. There are also 22 characters in an Acer KC SN. The format of Acer KC SN is almost the same as Acer FG SN. Acer KC SN does not have its related SNID.
  • Page 118 Note 6.0.2: Every ODM KC PN can be found in Acer SPL database. (Please contact with the Acer PIC in CSD.) Note 6.0.3: Acer KC PN is more important than Acer KC SN for repair centers.
  • Page 119 Acer office to order FRU parts for repair and service of customer machines. NOTE: To scrap or to return the defective parts, users should follow local government ordinances or regulations on proper disposal, or follow the rules set by the regional Acer office on how to return the defective parts.

  • Page 120: Exploded Diagram

    Exploded Diagram and Description...
  • Page 121 Item Part Name Touch panel (including in LCD Module) LCD (including in LCD Module) Front cover (including in LCD Module) Light Diffuser piece (including in LCD Module) Power key FPC (including in MB Module) Front camera (including back conductive fabric) G-sensor rubber case (including in MB Module) Power key button Rear camera...

  • Page 122: Fru List

    FRU List Category Part NO. Description Battery BATTERY KT.0010K.007 (BAT-A11)_2000mAh_SP44 5162SE-C_acer_BAT-A11 USB Cable HC.70211.04K Micro 5P 1000A_1m Adapter ADAPTER_US_PSA05A-05 KP.0050P.006 0QL6A-H Earphone BLACK_1.5m_3.5mm HC.00111.00A US Standard Front Camera KR.05M0W.002 6.5*6.5*3.9_500W...
  • Page 123 Rear Camera KR.05M0K.001 8.6*8.5*4.25mm_500W Speaker 23.HPUHC.001 16*09*3.3mm Receiver 60.HPUHC.003 06*12*2.3mm Volume Key FPC 60.HPUHC.004 LINK FPC 50.HPUHC.001 CONNECT MB & SB RF Cable 50.HPUHC.002 84.5mm Antenna Cover...
  • Page 124 60.HPUHC.005 4G-EU MAIN ANTENNA Battery Cover 60.HTNHC.003 BLACK_UV PAINT Power Key Button 60.HPUHC.007 BLACK_UV PAINT Volume Key Button 60.HPUHC.008 BLACK_UV PAINT Screw for Rear Cover & Antenna Cover 86.LB6N8.001 M1.4*3.5mm_BLACK Warranty Label...
  • Page 125 47.HPUHC.002 DIAMETER 2.3mm Cooling Membrane for Battery Cover 60.HPUHC.009 55.0*53.0*0.06_BLACK LCD Module 1. TP 2. LCM 3. Front cover 6M.HPUHC.001 4. Light Diffuser 5.TP Landing Conductive Fabric Rear Cover Module...
  • Page 126 Rear cover 60.HPUHC.002 Rear camera lens MB Module Main Board Power Key FPC HB.70511.08Z G-sensor Rubber Case Waterproof Label MB Soldering Spare Part Power key FPC PN: HQ22001114000/HQ22001112000 SB Module Sub board 55.HTNHC.001 Motor SB Soldering Spare Part Motor PN: HQ20400059000,HQ20400076000...
