CM2020 68dB Manual
NOTE: Keep the separation distance between the inside and outside antennas to at least 80 ft apart to avoid RF oscillation.
If not, then the amplification gain must be reduced with gain control switches on both side of the unit for uplink and downlink.
STEP 4. Connect the Power Cord.
Warning: To prevent damage to the Amplifier, before you plug in the Amplifier to an AC power outlet,
please make sure that both sides are already connected with the cables from both the outdoor and
indoor antennas.
WARNING: after power is on, and before making any cellular phone calls, if either
800MHz or 1900MHz UPLINK lights marked "full" is on, that means that the
oscillation is about to or already happen and ALC, automatic level control circuits,
start working. You should then POWER OFF immediately, then reduce both the uplink
gain and downlink gain via the gain control switches, or further increase separation
distance, or do both until neither of the uplink light are on when you are not making
cellular phone calls.
Note: 1. Power lights for both uplink and down link will always be on after you power up.
2. During Cellular phone Conversations, it's normal to see uplink full light turn on and off.
STEP 5. After solving all oscillation problems, users can make cellular phone calls to test how the repeater system works,
further adjust gain as needed.
Safety Warning:
1. The input voltage for the Amplifier is 9V. DO NOT use this Amplifier with a regular 12V power supply. If a 12-volt power
supply is connected directly to this Amplifier, it will be damaged.
2. Never plug in the power supply to the amplifier without the outdoor antenna and indoor antenna cables having been attached
to the amplifier.
3. Ensure that the distance between inside and outside antennas is a minimum of 80 feet for the amplifier.
4. If the Uplink Full light is on when you are not making cellular phone calls, DO NOT use the amplifier, turn it off immediately,
since it may cause damage to the amplifier.
Amplifier Gain Control
Each Attenuation Gain Switches control a certain level of gain. Each button has a certain dB gain, which is on the top of the amplifier.
Those values are 16, 8, 4, 2, and 1 for the five switches respectively.
TROUBLESHOOTING GUIDE
