Summary of Contents for Port A Cool PAC2K161FC22050

Page 1 Port-A-Cool® Products and Accessories Küül® Pads Cooling Media are manufactured by Port-A-Cool, LLC P.O. Box 2167 • 709 Southview Circle • Center, TX 75935 Phone 936-598-5651 • 800-695-2942 www.port-a-cool.com OWNERS MANUAL U.S. Patent 6,223,548 U.S. Patent D 362,905 U.S. Patent 6,502,414...
Page 3: Table Of Contents
READ AND SAVE THESE INSTRUCTIONS CONTENTS: I. INTRODUCTION A. What is Evaporative Cooling? B. Humidity and Evaporative Cooling. C. Evaporative Cooling and the PORT-A-COOL® unit. II. SETUP A. Unpacking the PORT-A-COOL® unit. B. Connecting the water and electricity or air. III. OPERATING PROCEDURES A.
Page 4: Introduction
100% indicates that the air at this temperature and pressure is holding all the moisture it can. If the air has less that 100% relative humidity when entering the PORT-A-COOL® unit, then it has the ability to hold more moisture, and will thus evaporate more water and cool more effectively.
Page 5: Humidity And Evaporative Cooling
The PORT-A-COOL® unit has incorporated all of these features and more. As explained in PART B of this section, the effectiveness of the PORT-A-COOL® unit is best appreciated when it is above 85˚F and below 75% relative humidity. By the time the outside temperature reaches 85˚F, the humidity is almost always below 75%.
Page 6: Electrical Connection
PORT-A-COOL® unit. It is a simple matter to cut the straps and remove the box by lifting it over the PORT-A-COOL® unit. Remove the protective plastic dust cover to expose the PORT-A-COOL® unit. The 16” model PORT-A-COOL® units are shipped in an enclosed corrugated box and need only be removed from the box.
Page 7: Operating Procedures
There are three primary considerations when deciding where to place the PORT-A-COOL® unit. 1) Fresh Air Supply - The inlet side of the PORT-A-COOL® unit (pad side) must be placed so as to insure that a smooth, uninterrupted supply of fresh air is available.
Page 8: Starting The Pump And Adjusting The Water Flow
It is important to insure that the spray bar is properly adjusted when first starting the water flow in the PORT-A-COOL® unit. Increasing the flow using the SPRAy BAR ADJUSTMENT valve on the side of the unit makes this adjustment.
Page 9: Maintenance And Storage
Once the sump is drained and the power disconnected, the pads may be removed to allow inspection of the sump tank. Assuming that the PORT-A-COOL® unit is in a dusty environment, dust will collect in the sump tank over time. This dirt and any remaining water may be vacuumed out using a wet/dry shop vacuum and wiped clean with a cloth.
Page 10: Troubleshooting & Repair
So while defining the problem, a careful check of all systems should be made to fully understand the extent of the problem. If you have a complete understanding of all the systems of the PORT-A-COOL® unit and how they depend on each other, it becomes much simpler to define and solve any problems.
Page 11 2007 PORT-A-COOL® Unit Electric Models BELT DRIVE MODELS pROBLEM CHECK Fan motor won’t run and Power cord, makes no sound. switches, circuit breaker, etc. Blade in contact with shroud Fan motor won’t run and makes a humming sound. Motor stalled...
Page 12 Water leaking from Drain Valve. Washer worn. Stem worn. Water leaking from Spray Bar Valve. Washer worn. Stem worn. 2007 PORT-A-COOL® Unit Electric Models SOLuTIOn Adjust water flow. Tighten connections and/or replace hose washers. Tighten connections and /or replace hose washers.
Page 13 2007 PORT-A-COOL® Unit Electric Models SpRAY BAR ASSEMBLY (ALL MODELS) pROBLEM CHECK Too many dry streaks in the pads. Holes in spray bar blocked by foreign material. Water spitting from the unit. Hose connection loose. Excess water in air Pad Installation coming from the fan.
Page 14 Breaker trips or fuse blows Pump motor locked. when switch is turned on. Pump won’t run and power Switch making closure contact. is available and pump is functional. 2007 PORT-A-COOL® Unit Electric Models SOLuTIOn Reconnect power, reset breaker. Remove object. Prime pump. Replace pump/motor.
Page 15: Repair And Replacement Procedures
2007 PORT-A-COOL® Unit Electric Models B. Repair and Replacement procedures Ensure that all water is removed from the PORT-A-COOL® unit and all power is disconnected. Remove all impediments to access the component you are checking or replacing. REpLACInG THE COOLInG MEDIA (pads) (...
Page 16 2) Motor is located in center of unit. Switch box is located in upper left. Locate motor harness wire (Figure 1) secured to fan bracket assembly using five plastic wire ties. Cut and remove plastic wire ties. DO NOT CUT ELECTRICAL WIRES.
Page 17 1) DISCONNECT POWER and remove pads as shown on page 15. 10.8 17.8 2) Pump is in lower right of unit. Control box is in upper left. Locate pump wire (å) secured to fan bracket 10.8 20.6 assembly using plastic wire ties. Cut and remove plastic ties. DO NOT CUT ELECTRICAL WIRES. (Figure 1) 10.8...
Page 18 (Figure 2) 4) Unscrew the 6” drain pipe located under the fan housing. Slide the tank outside the caddy base to access the pump bracket. 7) Remove the two screws that hold the bracket to the tank. Remove the bracket and hose from the pump by loosening the fastening screws and hose clamp.
Page 19: Technical Support
36.7 25.6 B. port-A-Cool® unit Limited Warranty OUTPUT TEMP. For one year from date of installation, Port-A-Cool, LLC. warrants any original component part or parts of the Drop °C °F Port-A-Cool® evaporative unit found, upon examination by factory-authorized personnel, to be defective in 29.5...
Page 20: Frequently Asked Questions
A: A new unit will go through a break-in period during which it may emit some odor. The pads, located in the back of your Port-A-Cool® unit, have never been wet. The resin in the pads will emit an odor the first time you wet them that lasts approximately one to three weeks. Keep the unit in an open area until the odor goes away or put a capful of laundry softener directly in the tank in the bottom of your unit.
