Summary of Contents for Teac CT-F803
- Page 15 CTF803 PART_NO DESCRIPTION QTY LOCATION 155-R83308-00-00 REMOTE CONTROL ASSEMBLY CF701 107-800455-4G RESONATOR 455 KHZ ET455Z PO TUNG R701,703 113-109005-17 CARBON FILM RESISTOR 1 OHM 1/16W +-5% R702 113-221005-17 CARBON FILM RESISTOR 220 OHM 1/16W +-5% C701,702 123-151350-93 CERAMIC CAP. 150 PF 50V +-10% (NPO) C703 127-105072-06 ELECT CAP.
- Page 16 CTF803 PART_NO DESCRIPTION QTY LOCATION DEGAUSSING 580-102261-00 CABLE TIE L=200MM W=3.5MM COIL DEGAUSSING 580-103261-00 CABLE TIE L=300MM W=3.5MM COIL 611-733A01-00 GIFT BOX-BOTTOM 951(W) X680(D) X 309(H)MM W/HANDLE {K33333K} 618-733A01-00 PACKING PAD FOR EARE CAB AND OTHER 622-882802-00 FELT L240 X W17 X T0.5MM W/TAPE PARTS 12 FOR CRT MTG 630-238010-00...
- Page 17 CTF803 PART_NO DESCRIPTION QTY LOCATION L903 008-120331-05 DEGAUSSING COIL 120T L=3750MM (5 TAPE) #XC-GW 74B "ART-TECH" CF101 107-105500-66 SOUND TRAP CERAMIC FILTER 5.5MHZ WEI HAW SAW101 107-731500-00 SAW FILTER TSB-5308U (SANYO) SAW102 107-738916-00 SAW FILTER TSF-5316 SANYO R708,707,716,71 7,(ON CHANNEL 113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% P.C.B)
- Page 18 CTF803 QTY LOCATION PART_NO DESCRIPTION C702 (CHANNEL 127-106042-06 ELECT CAP. 10 MFD 16V +-20% {TAPING TYPE} P.C.B),C701 (SENSOR PCB) FOR MAIN SPK R `-' TO 127-225072-28 ELECT. CAP. 2.2 MFD 50V +-20% (NON-POLAR) "JAMICON" TWEETER SPK FOR TWEETOR 127-225072-28 ELECT. CAP. 2.2 MFD 50V +-20% (NON-POLAR) "JAMICON" C803 127-477042-06 ELECT CAP.
- Page 19 CTF803 PART_NO DESCRIPTION QTY LOCATION 1-L MAIN SPK .`- ' TO L 172-626036-40 UL1007 TOP COAT WIRE AWG26 360MM BLACK 10 X 10MM TWEETER (-), 1-R MAIN SPK. (- ) TO R 172-626036-40 UL1007 TOP COAT WIRE AWG26 360MM BLACK 10 X 10MM TWEETER (-) 1-L MAIN SPK 172-626036-43...
- Page 20 CTF803 PART_NO DESCRIPTION QTY LOCATION `5'TO`5',`6'TO`6' 191-701209-10 7 PIN FLAT CABLE L=60MM (1 SIDE SOCKET, 1 SIDE PLUG) ,`7'TO`7' FOR TWEETER 515-303408-10 SELF-TAPPING SCREW 3 X 8 W/B/T (HARDEN) FOR AV PCB 515-303410-10 SELF-TAPPING SCREW 3 X 10 W/B/T (HARDEN) 610-733A01-00 GIFT BOX TOP - 976(W) X 701(D) X 777(H)MM W/HANDLE {K33333K} 810-052204-14...
- Page 21 CTF803 PART_NO DESCRIPTION QTY LOCATION R637,638,309,31 0,313,316,923,9 113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% R100,502,503,32 113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% 3,324,327,328 R504,329,630,14 3,148,163,162,3 113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% 07,308 R926 113-101305-75 METAL OXIDE FILM RESISTOR 100 OHM 1W +-5% R421,116,223,14 9,922,920,928,1 113-102005-17...
- Page 22 CTF803 PART_NO DESCRIPTION QTY LOCATION R919 113-243101-67 METAL FILM RESISTOR 24K OHM 1/4W +-1% R201 113-271005-17 CARBON FILM RESISTOR 270 OHM 1/16 W +-5% R436 113-272205-12 CARBON FILM RESISTOR 2.7K OHM 1/2W +-5% R640,823,337,14 113-273005-17 CARBON FILM RESISTOR 27K OHM 1/16W +-5% R910,117 113-330005-17 CARBON FILM RESISTOR 33 OHM 1/16W +-5%...
- Page 23 CTF803 PART_NO DESCRIPTION QTY LOCATION C148,168,303 123-102350-91 CERAMIC CAP. 0.001 MFD 50V +-10% (B TYPE) {TAPING TYPE} C504,934,936 123-102850-10 CERAMIC CAP. 0.001 MFD 2KV +-10% MATSUSHITA C149,113,221,22 123-103370-91 CERAMIC CAP. 0.01 MFD 50V +80 -20% {TAPING TYPE} 2,483,321 C132 123-104270-90 CERAMIC CAP.
- Page 24 CTF803 PART_NO DESCRIPTION QTY LOCATION C180,428,429,10 126-224060-21 METALIZED POLYESTER FILM CAP. 0.22 MFD 63V +-5% C910 126-273252-0P MYLAR CAP. 0.027 MFD 250V +-20% "SHENZHEN XINGUANG" C201,213 126-333071-07 MYLAR CAP. 0.033 MFD 50V +-10% {TAPING TYPE} C141,142 126-472071-0Q MYLAR CAP 0.0047 MFD 50V +-10% {TAPING} "SHENZHEN XINGUANG" C181,182,916 126-473071-0Q MYLAR CAP.
- Page 25 CTF803 PART_NO DESCRIPTION QTY LOCATION C469 127-478068-01 ELECT CAP. 4700MFD 35V D101,102,103,10 4,301,302,111,4 130-134148-01 SILICON DIODE IN4148 10,412,107,601, D106,602,603,50 7,508,509,510,5 130-134148-01 SILICON DIODE IN4148 12,901,402 D906,907,908,91 130-310001-00 RECTIFIER DIODE EU1 0.25A/400V SANKEN BR901 130-310005-00 BRIDGE RECTIFIER DIODE D5SB "KARIN" D411 130-310012-00 RECTIFIER DIODE RU2 SANKEN D408...
- Page 26 CTF803 PART_NO DESCRIPTION QTY LOCATION IC407 133-207812-31 IC L7812CV SGS-THOMSON IC306 133-517805-61 I.C. KA7805 SAMSUNG X201 137-245760-30 CRYSTAL 24.576MHZ X102 137-357954-25 CRYSTAL 3.57954 MHZ +-30PPM 18PF "JOIN MARK" X101 137-443362-22 CRYSTAL 4.433619 MHZ +-30PPM 20PF M.CAP 20.6PF "JOIN MARK" X601 137-800000-20 CRYSTAL 8.0 MHZ KITRONICS FOR CN501...
- Page 27 CTF803 PART_NO DESCRIPTION QTY LOCATION R113,444,913,C 318,815,971,977 172-726000-99 BARE WIRE 54MM ,W806 W144-146,181- 172-726000-99 BARE WIRE 54MM 182,901-915,121- 126,625-630 D906,909,911,40 6,408,409,411,R 179-001010-00 OIL SLEEVING 1 mm DIA. 0.23 443,460,469 L=200MM,100M M FOR SPK.`L' 179-105000-00 UL PVC TUBE 5mm DIA 100MM FOR SPK .`R' 120MM FOR AC 179-105000-00...
- Page 28 CTF803 PART_NO DESCRIPTION QTY LOCATION CN902 TO 191-501220-10 5 PIN FLAT CABLE L=60MM (1 SIDE SOCKET, 1 SIDE PLUG) CN602 CN405 TO 191-601228-10 6 PIN FLAT CABLE L=60MM (1 SIDE SOCKET, 1 SIDE PLUG) CN102 CN106 `1' TO CN503 `1',`2' TO 191-701009-10 7 PIN FLAT CABLE L=500MM (PIN 1-4, 5-7) `2',`3' TO `3'...
- Page 29 CTF803 PART_NO DESCRIPTION QTY LOCATION 668-881301-07 FUSE LABEL (A) - (T4A/250V) 18 X 5 mm 728-931302-00 SENSOR P.C.B. SUPPORT 746-063101-01 AC LINE CORD PIN IC405,Q402,IC9 750-063101-00 SOLDERING LUG LEG:8X4MM 1 FOR AC LINE 750-063102-01 35MM SOLDERING LUG OD:7 ID:3.2 LEG:4X35MM CORD FOR TUNER TO 750-063102-01...
- Page 30 CTF803 PART_NO DESCRIPTION QTY LOCATION 181-200TXT-00-00 TXT PCB ASSY R820,821,840,84 113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% 1,842 R826,845 113-102005-17 CARBON FILM RESISTOR 1K OHM 1/16W +-5% R838 113-123005-17 CARBON FILM RESISTOR 12K OHM 1/16W +-5% R844 113-273005-17 CARBON FILM RESISTOR 27K OHM 1/16W +-5% R805,807,808,80 9,811,812,813,8 113-472005-17...
