DSR4x1
DSR8x1
Analog Reference Video Input
Manual Version
B
E
URST
LECTRONICS INC
A
LBUQUERQUE, NM 87109
(505) 898-1455
(505) 890-8926 Tech Support
(505) 898-0159
www.burstelectronics.com
Hardware, software and manual copyright by Burst Electronics. All rights reserved. No part
of this publication may be reproduced or distributed in any form or by any means without the
written permission of Burst Electronics.
4-Input and 8-Input
HD/SD Video Switchers with
1.01
USA
VOICE
FAX
Made in USA
Advertisement
Related Manuals for Burst Electronics DSR4x1
Summary of Contents for Burst Electronics DSR4x1
- Page 1 (505) 890-8926 Tech Support (505) 898-0159 www.burstelectronics.com Hardware, software and manual copyright by Burst Electronics. All rights reserved. No part of this publication may be reproduced or distributed in any form or by any means without the written permission of Burst Electronics.
- Page 2 Reference Input. This manual will explain the various functions of these models (as well as operational use of the RS232 and DTMF options). Unless otherwise stated, all functions of the DSR4x1 are identical to that of the DSR8x1. Overview The model DSR4x1 is a four (4) input, full bandwidth digital HD and SDI switcher (DSR8x1 is an eight (8) channel switcher).
-
Page 3: Operation
As with analog vertical interval video switchers, your digital video sources should be genlocked. On the rear panel of the DSR8x1, the Ref Input port can be configured as a secondary video output. To DSR8x1 & DSR4x1 HD/SD SDI Video Switcher... - Page 4 SW#1 Closed, SW#2 Open 19.2k Baud NOTE: Leave SW#3 and SW#4 in the OPEN position. Closing these switches will stop the unit from transmitting status commands to the computer. Any terminal emulator (i.e. Windows Hyperterminal or DSR8x1 & DSR4x1 HD/SD SDI Video Switcher...
- Page 5 Procomm) is all that is required to communicate with the switcher. The command set for the DSR4x1 consists of a two character command followed by a carriage return (<CR>). The first character can be either upper or lower case. Status sent...
-
Page 6: Rs232 Error Codes
The DSR8x1 is ID addressable by holding down one of the front panel switches when you turn on power (i. e. holding pushbutton #1 during power up will address the unit as #1, holding pushbutton #6 during power up DSR8x1 & DSR4x1 HD/SD SDI Video Switcher... - Page 7 “UnitID # Channel *”. Example; 1#5* = Unit ID 1 will switch to Channel 5 6#2* = Unit ID 6 will switch to Channel 2 DSR8x1 & DSR4x1 HD/SD SDI Video Switcher...
-
Page 8: Specifications
Levels (HD/SD SDI) – 800mV nominal Re-clocked Jitter – HD 0.06 UI; SD 0.02UI Matrix Configurations: DSR8x1 – 8 inputs x 1 output DSR4x1 – 4 inputs x 1 output Inputs can be mixed standards Local Controls: 4 or 8 momentary switches with LED indicators... - Page 9 14.2W x 3.81H x 18.54D (cm) DSR4x1 - 4.2W x 1.5H x 5.5D (inches) 10.67W x 3.81H x 13.97 (cm) Weight DSR8x1 - 1.5 (lbs) 0.68 (kg) DSR4x1 - 1 (lbs) 0.45 (kg) DSR8x1 & DSR4x1 HD/SD SDI Video Switcher...
- Page 10 DSR8x1 & DSR4x1 HD/SD SDI Video Switcher...
- Page 11 DSR8x1 & DSR4x1 HD/SD SDI Video Switcher...
- Page 12 DSR8x1 & DSR4x1 HD/SD SDI Video Switcher...
