AS8x8
Manual Version 2.01
B
E
URST
LECTRONICS INC
A
LBUQUERQUE, NM 87109
(505) 898-1455
VOICE
(505) 898-0159
FAX
www.burstelectronics.com
Hardware, software and manual copyright by Burst Electronics. All rights reserved. No part
of this publication may be reproduced or distributed in any form or by any means without the
written permission of Burst Electronics.
Crosspoint Audio
Switch 8 by 8 Stereo
USA
Made in USA
Advertisement
Related Manuals for Burst Electronics AS8x8
Summary of Contents for Burst Electronics AS8x8
- Page 1 (505) 898-1455 VOICE (505) 898-0159 www.burstelectronics.com Hardware, software and manual copyright by Burst Electronics. All rights reserved. No part of this publication may be reproduced or distributed in any form or by any means without the written permission of Burst Electronics.
- Page 2 The switch matrix utilizes monolithic, CMOS matrix IC's to achieve minimal crosstalk. The AS8x8 can be manually controlled using the front panel controls or remotely controlled via a standard, asynchronous RS232 Serial Interface. The eight audio inputs are fully buffered.
- Page 3 Interface common to most all personal computers. Refer to the Appendix section, for detailed information on the serial interface connections. For systems employing a single AS8x8 unit, the serial cable is connected to the rear panel RJ11 connector labeled HOST. For systems using multiple AS8x8's, the systems are "daisy-chained"...
- Page 4 Mode 1: Scanned Manual Mode In this mode, the front panel thumbwheel switches are continuously scanned for any changes. When a change is detected, the unit automatically switches the audio switch setting. Mode 2: Triggered Manual Mode AS8x8 Audio Routing Switch...
- Page 5 The front panel thumbwheel switch labeled Channel 2 is used to program the baud rate for the RS232 interface. The serial interface parameters are 1 stop bit, 8 data bits, and no parity. The AS8x8 supports the following baud rates: Switch Setting...
-
Page 6: Operation
Operation The following paragraphs detail the operating procedures for each of the four operating modes that can be programmed into the AS8x8 Audio Crosspoint Switch. Mode 1 (Scanned Manual Mode) When operated in this mode, the user sets the front... - Page 7 The following is a list of the commands used by the AS8x8. Each command must be terminated by a carriage return (hex 0D). All characters that are transmitted to the unit are echoed back to the host...
-
Page 8: Command Description
The unit switches immediately after receiving the carriage return. R (READ) This command causes the AS8x8 to transmit the current settings of all 8 audio outputs to the host computer. No carriage return is necessary. L (LOCK) When received , this command locks the current audio setting to prevent changes. - Page 9 Mode 4. You must use both Channel 3 and Channel 4 to set the ID address. The range of ID address supported with the AS8x8 is 01 to 99. As you can see, ideally, nearly one hundred units can be controlled in this manor.
- Page 10 ID address 01). A carriage return is required after this command is entered. SP (Sleep) This command is used to stop an AS8x8 from acting upon commands that may be sent to a different ID addressed AS8x8 connected to the same RS232 line.
-
Page 11: Specifications
Distortion: .03% THD Headroom: +12 dB Bandwidth: 10 Hz to 40 kHz ± 0.25 dB S/N: 91 dBA Electrical Power Supply: 9-12 VDC @ 250 mA Mechanical Height: 1.75H x 16.5W x 6.0D i nches Rack Mount: RM-Ear AS8x8 Audio Routing Switch... - Page 12 Notes...
