- Page 1 ® GARDENA Operating Instructions Water Timer Bruksanvisning Bevattningstimer Hasznбlati ъtmutatу Vнzprogramozу уra Nбvod k pouћitн Zavlaћovacн hodiny Инструкция по эксплуатации Карта датчика часов полива T 1030 card Art. 1830...
-
Page 2: Table Of Contents
Please keep these operating instructions in a safe place. Contents 1. Where to Use Your GARDENA Water Timer ....2. For Your Safety . -
Page 3: Where To Use Your Gardena Water Timer
1. Where to Use Your GARDENA Water Timer Intended use The GARDENA Water Timer is intended for private use in domestic and hobby gardens, exclusively for outdoor use, to control sprinklers and irrigation systems. Please note The GARDENA Water Timer must not be used for industrial purposes or in conjunction with chemicals, foodstuffs, easily flammable and explosive materials. -
Page 4: Function
Water Timer opens at the selected starting time. To avoid getting wet when operating the 3. Function The GARDENA Water Timer allows you to set different watering cycles for different watering times independent of whether you are using a sprinkler, a sprinkler system installation or drip-head watering system to irrigate your garden. - Page 5 Card slot : - To hold the programming card Red LED : - Indicates a fault Green LED : - Indicates the system is operating Red button : - Start reading in the program - Manual operation Storage - For storing the programming card compartment :...
-
Page 6: Putting Your Water Timer Into Operation
4. Putting Your Water Timer into Operation Inserting the batteries : 1. Turn battery cover anticlockwise and remove battery holder 2. Insert 4 x LR-6-AA (Mignon) alkaline batteries in the battery holder. Ensure that polarity is correct (+ /-). 3. Insert the battery holder in the correct position and close the battery cover Both LEDs are illuminated for 2 seconds and the Water... - Page 7 The functional safety of the water timer depends on the capability of the batteries. If you change the batteries the program is not saved. You must reprogram the Water Timer (see 5. Operation). Connecting your Water Timer : The Water Timer is fitted with a sleeve nut for taps with a 33.3 mm (G1”) thread.
-
Page 8: Operating Your Water Timer
Connect soil moisture In addition to time-based watering, it is also possible to include or rain sensor (optional) : the soil moisture or rain in the watering program. If the soil is moist enough, the program will be stopped, or a pro- gram will be prevented from starting. - Page 9 1. Setting the watering program on the programming card Push the timer slide to the actual time of day (e.g.: 12 o’clock). Push starting time slide to the starting time required (e.g.: 6 o’clock). Push watering time slide to the length of time required. (e.g.: 15 minutes).
- Page 10 Watering manually : On especially dry days the programmed watering cycle is sometimes insufficient. You can then turn on your water timer manually. The program you have set remains unchanged. 1. Insert programming card in the card slot of the Water Timer. 2.
-
Page 11: Trouble-Shooting
See instructions for is sufficient moisture). the sensor. Battery flat after working Alkaline batteries were v Use alkaline batteries. for a short time not used. If you have any other problems with your Water Timer, please contact GARDENA Service. -
Page 12: Putting Your Water Timer Out Of Operation
(in accordance with RL 2002 / 96 / EC) v Please return flat batteries to a GARDENA dealer or dispose of them properly at your nearest recycling centre. Disposing of flat batteries : Only dispose of batteries when they are flat. -
Page 13: Service
Approx. 1 year 9. Service Warranty GARDENA guarantees this product for 2 years (from date of purchase). This guarantee covers all serious defects of the unit that can be proved to be material or manufacturing faults. Under warranty we will either replace the unit or repair it free of charge if the following conditions apply: •... - Page 14 We expressly point out that, in accordance with the product liability law, we are not liable for any damage caused by our units if it is due to improper repair or if parts exchanged are not original GARDENA parts or parts approved by us, and, if the repairs were not carried out by a GARDENA Service Centre or an authorised specialist.
