aegex 10 User Manual page 9

REPLACING BATTERY / ADDING SIM CARD
When putting the battery back in place:
1. Make sure the battery securely clicks in
place on both sides.
REPLACING BATTERY / ADDING SIM CARD
End
2. Replace battery cover by pushing down on the lid carefully by
following the steps illustrated in the image:
A) Align the battery door to the back housing. The corner with the
slant is positioned to align with the enlarged access point in the
lower left corner of the case.
B) Engage the battery cover snaps by:
i. Snapping in the middle top snaps first
ii. Pressing down the battery cover edge by using two hands
a) Moving out symmetrically from the top center
to the top left and right corners
b) Then from top to bottom on both side edges
c) And then from the bottom corners in to the
bottom middle symmetrically
d) Finish at the bottom middle snaps
C) Verify that the battery cover is flush with the rear housing on
all edges and confirm that there is no bulge or gap. If you feel
resistance, check pin alignment. Do not force the cover down as
damage to connecting pins will occur.
3. Then replace the 4 corner hex screws
of the battery cover using the provided
hex tool. The recommended torque for
the screw is 10-12Ncm.
9
