SYSTEM COMPONENT INDEX

Part No. Description
429853 Mechanical AUTOMAN Regulated Release
Shipping Assembly
Includes: Regulated Release Mechanism in
Stainless Steel Mounting Enclosure
429856 Electric AUTOMAN Regulated Release
Shipping Assembly (120VAC)
Includes: Regulated Release Mechanism with
Solenoid and Switch in
Stainless Steel Mounting Enclosure
429850 Regulated Actuator Shipping Assembly
Includes: Actuator and Regulator in
Stainless Steel Mounting Enclosure
429870 Stainless Steel Mounting Box Shipping Assembly
Includes: Stainless Steel Mounting Box
429872 Two Tank Enclosure Shipping Assembly
Includes: Two Expellant Gas Hoses
Two Grommets
Stainless Steel Mounting Box
429859 24VDC Regulated Release Shipping Assembly
Includes: 24VDC AUTOMAN II-C Release
Mechanism in Stainless Steel
Mounting Box
430299 3 Gallon Mechanical Release Shipping Assembly
including:
429853 Mechanical Regulated Release Assembly
429862 3 Gallon Tank Assembly
430300 1.5 Gallon Mechanical Release Shipping Assembly
including:
429853 Mechanical Regulated Release Assembly
429864 1.5 Gallon Tank Assembly
430309 3 Gallon Regulated Actuator Shipping Assembly
including:
429850 Regulated Actuator Assembly
429862 3 Gallon Tank Assembly
430316 1.5 Gallon Stainless Steel Enclosure Shipping
Assembly including:
429870 Single Tank Mounting Box Assembly
429864 1.5 Gallon Tank Assembly
430317 3 Gallon Stainless Steel Enclosure Shipping
Assembly including:
429870 Single Tank Mounting Box Assembly
429862 3 Gallon Tank Assembly
430324 6 Gallon Stainless Steel Enclosure Shipping
Assembly including:
429872 Two Tank Mounting Box Assembly
429862 3 Gallon Tank Assembly (2)
430332 3 Gallon Mounting Bracket Shipping Assembly
including:
429878 3 Gallon Mounting Bracket Assembly
429862 3 Gallon Tank Assembly
2014-SEP-01
Part No. Description
418054 OEM Regulated Electric Release Shipping
Assembly (120VAC)
Includes: Regulated Release Mechanism with
Solenoid and Switch
1/4 in. Hose and Mounting Bracket
79493 OEM Regulated Mechanical Release Shipping
Assembly
Includes: Regulated Release Mechanism
1/4 in. Hose and Mounting Bracket
418691 OEM Regulated Actuator Shipping Assembly
Includes: Actuator and Regulator
Hose
Bracket
429878 3 Gallon Bracket Assembly
(Bracket Only)
433485 Remote Release Assembly
439946 OEM Remote Release Assembly
418522 OEM Regulated Actuator Shipping Assembly
Includes: Actuator and Regulator
Hose
429862 3 Gallon Tank Shipping Assembly
429864 1.5 Gallon Tank Shipping Assembly
56972 Regulator Test Kit
Includes: Gauge, Hose and Valve Assembly
79694 1.5 Gallon (5.8 L) Container of ANSULEX Low pH
Liquid Fire Suppressant
79372 3.0 Gallon (11.6 L) Container of ANSULEX Low
pHLiquid Fire Suppressant
423429 Cartridge Shipping Assembly (LT-20-R) (TC/DOT)
423435 Cartridge Shipping Assembly (LT-30-R) (TC/DOT)
423493 Cartridge Shipping Assembly (R-102 Double-Tank)
(TC/DOT)
423491 Cartridge Shipping Assembly (LT-A-101-30)
(TC/DOT)
423439 Cartridge Shipping Assembly (101-10) (TC/DOT)
15850 Cartridge Shipping Assembly (101-10) (DOT)
423441 Cartridge Shipping Assembly (101-20) (TC/DOT)
423443 Cartridge Shipping Assembly (101-30) (TC/DOT)
428440 Cartridge Shipping Assembly (LT-20-R) (European)
428441 Cartridge Shipping Assembly (LT-30-R) (European)
428446 Cartridge Shipping Assembly (R-102 Double Tank)
(European)
428442 Cartridge Shipping Assembly (LT-A-101-30)
(European)
SECTION 9 – APPENDIX
UL EX3470 ULC EX3470
REV. 11 PAGE 9-5
