  • Page 1 DX 2000 SL DX 2000 SL DX 2000 SL DX 2000 SL DX 2000 SL DX 2000 SL DX 2000 SL DX 2000 CI DX 2000 CI DX 2000 CI DX 2000 CI DX 2000 CI DX 2000 CI DX 2000 CI...
  • Page 2: Table Of Contents

    - Digital Satellite Receiver DX 2000 CONTENTS Page Page CHANNEL MANAGER GENERAL INFORAMTION DX 2000 SL/CI Main Page Main Feature of Channel Manager For your Safety Favorite Channel Unpacking DX 2000 Move Channel General Operation of Lock Channel Remote Control Rename Channel Front Panel Delete Channel...
  • Page 3: General Inforamtion

    - 2 Scart sockets (TV, VCR) - 2 Slots Common Interface for Viaccess, Irdeto, CryptoWorks, Conax, Nagravision and more (only available in model DX 2000 CI ) - Provide friendly and easy-to-use menu system - Wizard install system in the earliest of the world...
  • Page 4: For Your Safety

    For Your Safety • Do not remove the cover • DX 2000 Allow clear space around the sufficient ventilation • Do not allow the unit to be exposed to hot, • Do not cover the DX 2000 or place it on a cold or humid conditions unit that emits heat •...
  • Page 5: Remote Control

    Remote Control Function Turns power ON/OFF of the DSR(Green lamp lights up when ON TV/RADIO Switches between TV and Radio mode When watching a channel, mutes the sound. ! ! ! ! PR Switches back to previous channel INFO Shows information of the current channel Press this key one time to run menu on MENU screen, and call command box...
  • Page 6: Front Panel

    FUNCTION Turns on and off the power of the receiver When watching, changing to the previous and next channel, or in the menu (behind the front door in model DX 2000 CI) Returns all data to factory (RESET) default settings.
  • Page 7: Installation Of Dx 2000

    INSTALLATION OF DX 2000 This section explains the installation of DX 2000 . Refer to the manuals supplied with the equipment for the installation of outdoor equipment such as the dish antenna. When adding new equipment, be sure to refer to the related parts of the manual for the installation.
  • Page 8: Connecting To Another Svr

    Connecting to another Satellite Receiver Connecting to Digital Audio...
  • Page 9: First Time Installaton

    FIRST TIME INSTALLATION DX2000 has “Easy Installation” system which NOTE : If you are operating a standard one or two satellite antenna system (ASTRA, allows users to set up the receiver setting only HOTBIRD) you easily can watch channels minimum configuration for viewing channels. just after connecting antenna signal and TV.
  • Page 10: Select Antenna Number

    Select Antenna Number Select the antenna number to which you want to place your desired satellite. These number is relating to the stored antenna selection table and you can select one of 16 antenna numbers to which your satellite will be assigned.
  • Page 11: Select Lnb

    Select LNB Select the type of your LNB. If you have Universal LNB, select YES. Otherwise select NO. Enter the LNB frequency Enter the proper LNB frequency referring to your LNB using numeric key on the Remote control. Or use KEY PAD displayed by OK key pressing.
  • Page 12: Confirmation Setup

    Confirmation Setup This message shows that you have completed the setting of one antenna. Then place the cursor on NO and select NEXT pressing OK key. If you have other antenna which you want to configure, select YES, then place the cursor on the NEXT pressing OK button.
  • Page 13: Common Interface

    COMMON INTERFACE (only model DX 2000 CI) DX 2000 CI Only makes you enjoy various scrambled channels encrypted by Viaccess, Nagravision, Irdeto, Conax and Cryptoworks. Preparing To be able to receive scrambled digital satellite channels you will need a Smartcard and a...
  • Page 14: General Viewing Function

    GENERAL VIEWING FUNCTION The following describes the basic functions of your receiver while watching satellite TV or listening to satellite radio. If you select a channel to which you do not have access, you will get a message on the screen. This message may vary, depending on type of program and Service Provider.
  • Page 15: Pause The Frame

    Pause the frame Press PAUSE key on the remote control to pause the screen. To bring it back to the normal mode, press PAUSE key once again. Previous channel recall Press <-PR key on the remote control to move the previous channel which you watched before.
  • Page 16: Channel Information

    Channel Information Every time you change channels, you will receive program information for a few second. While viewing channel, you can see the current channel information anytime, pressing INFO key on the remote control. Note : Channel information will be shown for 5 seconds.
  • Page 17: Channel Manager

    CHANNEL MANAGER DX 2000 provides most powerful channel managing function in the world and this function allows you to have a more interesting and useful operation as well as viewing channels simply. Main Page While viewing channels, press MENU key on the remote control, the Main Page box will be displayed on the Upper-Left side of the screen.
  • Page 18: Favorite Channel

    TV Channel manager In this menu you can see the channel list which DX 2000 searched in the left side and in the right side, Current channel information is displayed. Press MENU key on the remote control, then command menu will be displayed TV channel manager has 6 commands as below;...
  • Page 19: Move Channel

    Move channel In Main Page, press MENU key on the remote control, and then select MOVE on the commands. This MOVE command allows you to change the channel number. First select the channel, which number you want to change pressing OK key, and then using PR UP/DOWN key, move the channel on your desired location.
  • Page 20: Delete Channel

    Delete channel In Main Page, press MENU key on the remote control, and then select Delete on the command menu. This Delete command allows you to delete the channel permanently. First select the channels, which you want to delete, then selected channel number will be changed to yellow color.
  • Page 21: Fast Edit Mode

    Fast Edit mode Fast edit mode allows you to edit channel fast without showing channels selected. If you turn off the Fast edit mode, the receiver will show each channel selected in the TV Channel Manager mode and it takes few seconds. Note : Fast edit mode is not default, when you DX 2000 operate...
  • Page 22: Epg (Electronic Program Guide)

    ELECTRONIC PROGRAM GUIDE(EPG) DX 2000 provides EPG function for you to get access to the TV Guide (or Radio Guide if you are listening to radio channels) which will give the titles of the current and next programs on different channels.
  • Page 23: Timer

    TIMER The “TIMER” function allows you to program the timer with various ways. This function is one of the strong DX 2000. point of To activate the “Turn on time” and/or “Turn Off time”, Select YES and enter your desired time. DX 2000 Note : The displays the time which is given...
  • Page 24: User's Installation

    USER’S INSTALLATION DX 2000 is preprogrammed system which allows users to set up the receiver setting only minimum configuration for viewing channels. This User’s Installation is for the advanced user or DX 2000 installer to set up in detail or Up-grade the as their favorite way for advanced function.
  • Page 25 Channel Search If you entered correct value, run a Signal Level test in order to check whether you correctly entered value and positioned the antenna. If the level bar changed to yellow, select EXIT and press OK key. Now you can run a TP search or Satellite search.
  • Page 26 Channel Search If you want to set up the PID (Packet Identify), select the TP and press MENU button to display command box for Channel Search. And select SET PID command and press OK, then Set PID menu will be displayed. Enter the correct value and select OK.
  • Page 27: System Setting

    System Setting System Setting menu allows you to change the principal option which is set by Install Wizard and also set other items proper to your environment. 1) OSD Color : Select your favorite color 2) OSD Language : Select your desired language 3) Set local time : Select your local time difference to Greenwich time.
  • Page 28: Antenna Setup

    Antenna Setup Antenna Setup menu allows you to set up antenna more detail than Easy Install and Install Wizard. This menu is for advanced users, who do not want Wizard System because they have enough experience for satellite receiver or accustomed to this Menu.
  • Page 29: Antenna Positioning Help

    Antenna Direction help Although you entered correct value in Antenna Set up menu, if your antenna is positioned incorrectly, you could not receive signal form the Satellite. DX 2000 provides Antenna Positioning Help in order for you to have exact information for the position of your antenna.
  • Page 30: Parental Lock

    Parental Lock This function allows you to lock the channel with your password in order to prevent from accessing the channel by your children or any other person. And also you can protect your installed data and information using Install Lock. # How to change Password 1) Enter the current password.
  • Page 31: Easy Install

    Parent Lock # How to use Install Lock 1) Enter the current password. 2) Select ON at Install Lock 3) Enter new password 4) Confirm your new password entering new password again 5) Exit this menu and Turn off the DX 2000 6) Turn on receiver and press MENU key on the remote control...
  • Page 32: Factory Default

    Factory Default DX 2000 If you want to bring back to the factory default condition, select Factory Default and press OK key. Then Warning message will be displayed. To confirm select OK and press OK. Warning : You will loose all of data and information which was installed by yourself.
  • Page 33: How To Upgrade Dx 2000

    HOW TO UPGRADE DX 2000 DX 2000 you can download new software from Zehnders homepage http://www.zehnder-sat.de to up-grade your receiver with new operating system and new channel list by using RS232 interface. DX 2000 1. Connect to your PC using RS232C cable. DX 2000 2.
  • Page 34 HOW TO UPGRADE DX 2000 DX 2000 5. If select correct Port, the information of current version of will be displayed on the main menu. 6. If you want to upgrade now, press “Upgrade Software ” and find the “rom.bin” file to be up-graded in your PC. Then press “Open”. DX 2000 7.
  • Page 35 HOW TO UPGRADE DX 2000 Easy plug-and-play data transfer without PC Below you can find another easy method to upgrade operating software by easy plug-and-play data transfer from one receiver to the other. 1. Notice that both receivers, master and slave, are powered off . 2.
  • Page 36: Trouble Shooting

    TROUBLE SHOOTING Problem Possible causes What to do The display on the front panel Main cable is not connected. Check that the main cable is does not light up. plugged into the power socket. The DX 2000 is in standby No sound or picture, but the Press the standby button.
  • Page 37 TROUBLE SHOOTING Problem Possible causes What to do No Welcome Menu on the The system is connected by If the system is connected by screen after you switched on SCART leads and TV is not in SCART leads, switch the TV the DX 2000 for the first AV/EXT mode.
  • Page 38: Technical Specification

    Digital Audio Connector One RCA Output type SPDIF encoded signals Frequency rate 32, 44.1 or 48KHz CI module slot (only model DX 2000 CI) Connector 2 x JEIDA 4.0 PCMCIA type Module size PCMCIA Type III RS232 serial Data Speed max.
