FEATURES
1
• Low Supply-Voltage Range, 1.8 V to 3.6 V
• Ultralow Power Consumption
– Active Mode (AM): TBD μA/MHz
– Standby Mode (LPM3 WDT Mode): TBD μA
– Off Mode (LPM4 RAM Retention): TBD μA
– Shutdown Mode (LPM5 RTC Mode): TBD μA
– Shutdown Mode (LPM5): TBD μA
• Wake-Up From Standby Mode in Less Than
5 μs
• 16-Bit RISC Architecture, Extended Memory,
up to 20-MHz System Clock
• Flexible Power Management System
– Fully Integrated LDO With Programmable
Regulated Core Supply Voltage
– Supply Voltage Supervision, Monitoring,
and Brownout
• Unified Clock System
– FLL Control Loop for Frequency
Stabilization
– Low Power/Low Frequency Internal Clock
Source (VLO)
– Low Frequency Trimmed Internal Reference
Source (REFO)
– 32-kHz Crystals (XT1)
– High-Frequency Crystals Up to 32 MHz
(XT2)
• 16-Bit Timer TA0, Timer_A With Five
Capture/Compare Registers
• 16-Bit Timer TA1, Timer_A With Three
Capture/Compare Registers
• 16-Bit Timer TA2, Timer_A With Three
Capture/Compare Registers
• 16-Bit Timer TB0, Timer_B With Seven
Capture/Compare Shadow Registers
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCT PREVIEW information concerns products in the
formative or design phase of development. Characteristic data and
other specifications are design goals. Texas Instruments reserves
the right to change or discontinue these products without notice.
MIXED SIGNAL MICROCONTROLLER
• Two Universal Serial Communication
Interfaces
– USCI_A0 and USCI_A1 Each Supporting
– Enhanced UART supporting
Auto-Baudrate Detection
– IrDA Encoder and Decoder
– Synchronous SPI
– USCI_B0 and USCI_B1 Each Supporting
2 TM
– I C
– Synchronous SPI
• Full-Speed Universal Serial Bus (USB)
– Integrated USB-PHY
– Integrated 3.3-V/1.8-V USB Power System
– Integrated USB-PLL
– Eight Input, Eight Output Endpoints
• 12-Bit Analog-to-Digital (A/D) Converter With
Internal Shared Reference, Sample-and-Hold,
and Autoscan Feature
• Dual 12-Bit Digital-to-Analog (D/A) Converters
With Synchronization
• Comparator
• Integrated LCD Driver With Contrast Control
for up to 160 Segments
• Hardware Multiplier Supporting 32-Bit
Operations
• Flash Memory
– Serial Onboard Programming, No External
Programming Voltage Needed
– Enhanced Data Integrity
• Six-Channel Internal DMA
• Real-Time Clock Module With Supply Voltage
Backup Switch
• Family Members are Summarized in
• For Complete Module Descriptions, See the
MSP430x5xx/MSP430x6xx Family User's Guide
(SLAU208)
Copyright © 2009, Texas Instruments Incorporated
MSP430F663x
SLAS566 – OCTOBER 2009
Table 1
