GPS Tracking Device
Notes: .................................................................................................................................................................. 1
1. Product Introduction .................................................................................................................................... 2
2. Characteristics ............................................................................................................................................... 3
2.1 Red LED (power/working status) ......................................................................................................... 3
2.2 Blue LED(GPS status indicator) ........................................................................................................... 3
2.3 Green LED（GSM status indicator） .................................................................................................. 3
2.4.Specifications ........................................................................................................................................ 4
2.5 Device outlet specification .................................................................................................................... 4
2.6 Device wiring diagram .......................................................................................................................... 5
3. Method of installation ................................................................................................................................... 6
3.1. Preparation before installation ............................................................................................................. 6
3.2 Installation ............................................................................................................................................. 6
4. Web based tracking online activation .......................................................................................................... 7
5. SMS Configuration ....................................................................................................................................... 7
6． Trouble shooting ........................................................................................................................................ 10
Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website:
ROPE INNOVATION CO., LTD.
Model NO.: M508
User Manual
Version ：Rope-E160704
CONFIDENTIAL NO.：ROPE-15121802
www.myrope.cn
Advertisement
Table of Contents
Related Manuals for Rope M508
Summary of Contents for Rope M508
-
Page 1: Table Of Contents
3.1. Preparation before installation ......................6 3.2 Installation ............................. 6 4. Web based tracking online activation ......................7 5. SMS Configuration ............................7 6． Trouble shooting ............................10 Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 2: Notes
When the device work unusually or cannot resume to normal even operated according to the instruction; When the device cannot work as usual after falling, throwing or breaking; When there is obvious damage in the device. Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 3: Product Introduction
PC or mobile phone. Our GPS Tracking device, with the best quality, stable performance and versatile functions，can be applied to various kind of fleet management like construction trucks, rental cars, logistics vehicles and public transportation, anti-theft system and security purpose. Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 4: Characteristics
Fast Flashing (bright 0.1s dark 2s) GSM working Slow flashing(bright 1s dark 2s) Start GSM Continuously in dark state Power off/Internal fault Alway keep on Dialing out /talking Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 5: Specifications
Power Black(V-) red (V+) Connect to vehicle storage battery white Connect to ACC ignition Motor yellow Connect to relay control line SOS button red, black Connect SOS button Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 6: Device Wiring Diagram
5th cable is for <5V low voltage detection 6th cable to TX of RFID reader 7nd cable is RX of RFID reader 8nd cable to power- of speakerThe 8nd cable to power- of speaker Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 7: Method Of Installation
3.2.4 The device has built-in GSM antenna and GPS antenna. During installation, please make sure the receiving side face is up, with no metal object above the device to interfere with GPS reception. The Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... -
Page 8: Web Based Tracking Online Activation
SOS specific numbers. leave it blank between“， ，” For example, if you want to delete phone number 1, the sms command as below: service, ,phone number 2,phone number 3,123456 Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... - Page 9 Config OK=Set successfully E.g : arm,123456 Config failed=fail to set After set up arm, ACC ignition will automatic to send an illegal igniton information to the server Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn...
- Page 10 Interval1 is for ACC ON, interval2 for location ACC OFF uploading Eg: interval,30,100,123456 (device version NO.before interval time 2016-04-07 08:00:00 use this 30==ACC ON 100==ACC OFF command: GINTERVAL,X1,X2,password) Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn...
-
Page 11: Trouble Shooting
SIM card support GPRS. c) check the IMEI number is correct or not It not replied: check the SMS command format, make ensure it is correction. Copyright © 2016 ROPE INNOVATION CO., LTD. All rights reserved. Website: www.myrope.cn... - Page 12 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Ru les. Operation is subject to the following two condition s: (1 ) Thi s d evice may n ot cau se h armful interfere nce, a nd (2) this device must acce pt any interfere nce received, incl uding interferen ce tha t may cause undesired operation.
