- Page 1 Contents Network Viedo Recorder User Manual The manual is applied to the following model: Model No: NRM 310 Note: The manual is subject to change without notic...
-
Page 2: Table Of Contents
Contents ontents Preface Locations of the Jumpers and Connectors ................ 13 Jumper Settings ........................... 15 Copyright ............................iv Voltage Setup Selection (SW3) ....................15 Disclaimer ............................iv Start-up Mode / Pre-Heater Control (SW2) ..............15 Acknowledgements ........................iv PCI-104 VI/O Voltage Setting (JP4) ..................15 Regulatory Compliance Statements ..................iv CMOS Input Voltage Select (SW1, JP5) ................15 Declaration of Conformity ......................iv Connectors ............................ - Page 3 Contents MCU COM Port (JP3) ....................... 31 Serial-ATA Power Input (CN9, CN11, CN14, CN16) ............31 Serial-ATA 2.0 (CN13, CN15) ....................32 Serial-ATA 3.0 (CN8, CN10) ....................32 USB connector (J13, J16) ..................... 33 Pre-Heater Sensor Connector (J6) ..................33 USB Connectors (CN25) ......................
-
Page 4: Preface
European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining NRM310 series is a trademark of Divio Tec International Co., Ltd. All other product CE compliance also requires proper cable and cabling techniques. -
Page 5: Rohs Compliance
In order to meet the RoHS compliant directives, Divio Tec has established an engineering and manufacturing task force in to implement the introduction of green products. The task force will ensure that we follow the standard Divio Tec development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which Divio Tec are renowned. -
Page 6: Safety Information
The load of the system unit does not solely rely for support from the If RMA goods can not be repaired, Divio Tec will return it to the customer rackmounts located on the sides. Firm support from the bottom is highly without any charge. -
Page 7: Safety Precautions
Preface Safety Precautions If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. Read these safety instructions carefully. Never pour any liquid into an opening. This may cause fire or electrical shock. -
Page 8: Technical Support And Assistance
Conventions Used in this Manual Warning: Information about certain situations, which if not 1. For the most updated information of Divio Tec products, visit Divio Tec’s observed, can cause personal injury. This will prevent injury to website at www.Divio Tec.com. -
Page 9: Overview
Chapter 1: Product Introduction 1: P haPter roduCt ntroduCtIon Overview Key Features • High performance processor with Intel Core™ i7 3517UE/ i5 3610ME ® • Four Removable 2.5” SSD tray • Fanless and rugged design • DC power input with isolated protection • Support ignition signal for delay-time control • Support 8 channels POE with IEEE802.3af for optional • Support software base RAID 0/ 1/ 5/ 10... - Page 10 Chapter 1: Product Introduction NRM310 series is targeted for the rolling stock market with special design scheme to meet the criteria of installation in the vehicle on the rolling stock. They pass numerous environmental tests and are compliant EN50155 standard. Rapid transit system, metropolitan rail, commuter rail, high speed rail, tram, and train will make the best use of nROK.
-
Page 11: Hardware Specifications
Chapter 1: Product Introduction Hardware Specifications • 1x DB9 female connector for GPI / GPO connector • Intel Core™ i7 3517UE 1.7GHz Digital Input (source type: 0~30V) ® • Intel Core™ i5 3610ME 2.7GHz Digital Output (sink type: 20mA max) ®... - Page 12 Chapter 1: Product Introduction System Dimensions • 482.6mm (W) x 400mm (D) x 88mm (H) (19” x 15.75” x 3.46”) Construction • Sheet metal with heat sink Environment • Operating temperatures Ambient with air: -40°C to 70°C (EN50155 Class TX) • Storage temperatures: -40°C to 80°C • Damp heat test: 55°C, 95% RH (non-operating, EN 50155) • Relative humidity: 0% to 90% (non-condensing)
-
Page 13: Getting To Know Nrm310
Chapter 1: Product Introduction Getting to Know NRM310 Front Panel LAN 1-2 / PoE LAN 1-8 Connectors USB2.0 RS232 RS485/422 PWR switch LAN HDMI GPIO Line-in Connector pin definition Definition Definition LAN1_MDI_1N LAN1_MDI_1P LAN1_MDI_2N LAN1_MDI_3P LAN1_MDI_3N LAN1_MDI_2P LAN1_MDI_4N LAN1_MDI_4P LEDs Removable SSD Tray USB3.0 PoE LAN... - Page 14 Chapter 1: Product Introduction USB 2.0 Connector RS232 and RS485/422 Connectors Connector pin definition Connector pin definition RS232 Definition Definition Definition Definition USB_D- USB_D+ DCD1 RXD1 USB_VCC USB_GND TXD1 DTR1 USB_D- USB_D+ DSR1 USB_VCC USB_GND RTS1 CTS1 RS485 Definition Definition RS422_RX+ / RS485_+ RS422_RX- / RS485_- RS422_TX+...
- Page 15 Chapter 1: Product Introduction GPIO Connector Connector pin definition Connector pin definition Definition Definition Definition Definition INPUT_1 PORT INPUT_2 PORT GREEN INPUT_3 PORT INPUT_4 PORT BLUE OUTPUT_1 PORT OUTPUT_2 PORT / OUTPUT_3 PORT OUTPUT_4 PORT DDCDAT Hsync Vsync DDCCLK OPEN...
- Page 16 Chapter 1: Product Introduction HDMI USB 3.0 Connector pin definition Connector pin definition Definition Definition Definition Definition HDMI1_DATA2-P USB0- HDMI1_DATA2-N HDMI1_DATA1-P USB0+ HDMI1_DATA1-N USB3_RX0- USB3_RX0+ HDMI1_DATA0-P USB3_TX0- HDMI1_DATA0-N HDMI1_CLK-P USB3_TX0+ HDMI1_CLK-N USB1- USB1+ USB3_RX1- HDMI1_DDC_SCL HDMI1_DDC_SDA USB3_RX1+ VCC5 USB3_TX1- USB3_TX1+ HDMI1_HPD_R...
-
Page 17: Rear Panel
Chapter 1: Product Introduction Getting to Know NRM310 Rear Panel DC Input 24V/110V (Circle Type Connector) DC Input 24V/110V Definition Definition Ignition V- Ground Ignition WLAN WWAN/ WWAN WLAN GPS/WWAN/WLAN/BT Module Antenna Mounting Hole The antenna mounting holes are used to mount and connect antennas to the GPS/WWAN/WLAN/BT module. - Page 18 Chapter 1: Product Introduction Mechanical Dimensions...
-
Page 19: Before You Begin
Chapter 2: Jumpers and Connectors 2: J haPter umPers and onneCtors This chapter describes how to set the jumpers on the motherboard. Note that dry environments. A grounding strap is warranted whenever danger of static electricity exists. the following procedures are generic for all NRM310 series. Before You Begin Precautions ▪... -
Page 20: Jumper
Chapter 2: Jumpers and Connectors Jumper A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. -
Page 21: Locations Of The Jumpers And Connectors
Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors T h e... - Page 22 Chapter 2: Jumpers and Connectors Bottom View...
-
Page 23: Jumper Settings
Chapter 2: Jumpers and Connectors Jumper Settings Start-up Mode / Pre-Heater Control (SW2) (*) for default setting Voltage Setup Selection (SW3) SW2.1 Start up by PW Start up by Ignition(*) SW2.2 Pre-Heater on Pre-Heater off PCI-104 VI/O Voltage Setting (JP4) ON(*) SW3.1 GPI0 PULL UP 5V... -
Page 24: Connectors
Chapter 2: Jumpers and Connectors Connectors High speed board-to-board connector: COM Express Row A and Row B A. Connector size: 2 x 110 = 220 pin-header B. Connector location: J9A Com Express A&B Connector Connector pin definition Row A Row B Row A Row B PCIE_TX4-... - Page 25 Chapter 2: Jumpers and Connectors Row A Row B Row A Row B GBE0_CTREF SMB_DAT PCIE_TX0- PCIE_RX0- SUS_S3# SMB_ALERT# SATA0_TX+ SATA1_TX+ LVDS_A0+ LVDS_B0+ SATA0_TX- SATA1_TX- LVDS_A0- LVDS_B0- SUS_S4# SUS_STAT# LVDS_A1+ LVDS_B1+ SATA0_RX+ SATA1_RX+ LVDS_A1- LVDS_B1- SATA0_RX- SATA1_RX- LVDS_A2+ LVDS_B2+ LVDS_A2- LVDS_B2- SATA2_TX+ SATA3_TX+...
- Page 26 Chapter 2: Jumpers and Connectors Row A Row B Row A Row B USB2- USB3- TYPE10# SPI_CS# USB2+ USB3+ SER0_TX RSVD USB_23_OC# USB_0_1_OC# SER0_RX RSVD USB0- USB1- A100 B100 USB0+ USB1+ A101 SER1_TX B101 FAN_PWMOUT VCC_RTC EXCD1_PERST# A102 SER1_RX B102 FAN_TACHIN EXCD0_CPPE# EXCD1_CPPE#...
-
Page 27: High Speed Board-To-Board Connector: Com Express Row C And Row D
Chapter 2: Jumpers and Connectors High speed board-to-board connector: COM Express Row C and Row D A. Connector size: 2 x 110 = 220 pin-header B. Connector location: J9B Com Express C&D Connector Connector pin definition Row C Row D Row C Row D PEG_RX1-... - Page 28 Chapter 2: Jumpers and Connectors Row C Row D Row C Row D PEG_RX5- PEG_TX5- DDI1_PAIR6+ DDI1_CTRLCLK DDI1_PAIR6- DDI1_CTRLDATA PEG_RX6+ PEG_TX6+ RSVD RSVD PEG_RX6- PEG_TX6- RSVD RSVD PCIE_RX6+ PCIE_RX6+ PEG_RX7+ PEG_TX7+ PCIE_RX6- PCIE_RX6- PEG_RX7- PEG_TX7- PCIE_RX7+ PCIE_RX7+ RSVD RSVD PCIE_RX7- PCIE_RX7- PEG_RX8+ PEG_TX8+...
- Page 29 Chapter 2: Jumpers and Connectors Row C Row D Row C Row D DDI3_PAIR1+ DDI2_PAIR1+ RSVD RSVD DDI3_PAIR1- DDI2_PAIR1- PEG_RX14+ PEG_TX14+ DDI3_HPD DDI2_HPD PEG_RX14- PEG_TX14- RSVD RSVD C100 D100 DDI3_PAIR2+ DDI2_PAIR2+ C101 PEG_RX15+ D101 PEG_TX15+ DDI3_PAIR2- DDI2_PAIR2- C102 PEG_RX15- D102 PEG_TX15- RSVD RSVD...
-
Page 30: Pcie X16 (Cn12)
Chapter 2: Jumpers and Connectors PCIe x16 (CN12) A. Connector size: PCI-E slot 164 pin B. Connector location: Connector pin definition Row A Row B Row A Row B PRSNT1# VCC12 PERn6 VCC12 VCC12 PETp7 VCC12 CC12 PETn7 PERp7 SMCLK PERn7 PRSNT2#_3 SMDAT... - Page 31 Chapter 2: Jumpers and Connectors Row A Row B Row A Row B PERp1 PERp11 PERn1 PERn11 PETp2 PETp12 PETn2 PETn12 PERp2 PERp12 PERn2 PERn12 PETp3 PETp13 PETn3 PETn13 PERp3 PERp13 PERn3 RSVD PETp14 PRSNT2#_2 PETn14 VCC12 PERp14 VCC12 PETp4 PERn14 PETn4 PETp15...
-
Page 32: Pci-104 Connector (Cn7)
Chapter 2: Jumpers and Connectors PCI-104 Connector (CN7) Connector location: Connector pin definition Reserved AD00 AD21 AD20 AD19 VI/O AD02 AD01 +3.3V AD23 AD22 +3.3V AD05 AD04 AD03 IDSEL0 IDSEL1 IDSEL2 C/BE0# AD07 AD06 AD24 C/BE3# VI/O IDSEL3 AD09 AD08 AD26 AD25 AD11... -
Page 33: Main Board Led Indicator Connector (Cn6, Cn24)
Chapter 2: Jumpers and Connectors Main board LED Indicator Connector (CN6, CN24) RS422/485 Connector (CN19) A. Connector size: 2 x 7 = 14-pin header, (2.0mm pitch) A. Connector size: 2 x 5 = 10-pin header, (2.0mm pitch) B. Connector location: B. -
Page 34: Rs232 Connector (Cn22, Cn23)
Chapter 2: Jumpers and Connectors RS232 Connector (CN22, CN23) RS232 Connector (CN21) A. Connector size: 2 x 5 = 10-pin header, (2.0mm pitch) A. Connector size: 2 x 5 = 10-pin header, (2.0mm pitch) B. Connector location: B. Connector location: Connector pin definition Connector pin definition Definition... -
Page 35: Gpio Connector (Cn20)
Chapter 2: Jumpers and Connectors GPIO Connector (CN20) LAN Connector (a. J11, J14 / b. J12, J15 / c. J7, J8) A. Connector size: 2 x 5 = 10-pin header, (2.0mm pitch) A. Connector size: JST-1x4-180-2.5mm-MALE+JST-1x4-180-2.0mm-MALE B. Connector location: B. Connector location: Connector pin definition Connector pin definition a. -
Page 36: Lan Connector (Cn17)
Chapter 2: Jumpers and Connectors LAN Connector (CN17) VGA Connector (CN29) A. Connector size: RJ-45 A. Connector size: DB15 B. Connector location: B. Connector location: Connector pin definition Connector pin definition Definition Definition Definition Definition LAN1_MDI_1N LAN1_MDI_1P GREEN LAN1_MDI_2N LAN1_MDI_2P BLUE LAN1_MDI_3N LAN1_MDI_3P... -
Page 37: Hdmi Connector 1 (Cn27)
Chapter 2: Jumpers and Connectors HDMI Connector 1 (CN27) HDMI Connector 2 (CN28) Connector location: Connector location: Connector pin definition Connector pin definition Definition Definition Definition Definition HDMI1_DATA2-P HDMI2_DATA2-P HDMI1_DATA2-N HDMI1_DATA1-P HDMI2_DATA2-N HDMI2_DATA1-P HDMI1_DATA1-N HDMI2_DATA1-N HDMI1_DATA0-P HDMI2_DATA0-P HDMI1_DATA0-N HDMI1_CLK-P HDMI2_DATA0-N HDMI2_CLK-P HDMI1_CLK-N HDMI2_CLK-N... -
Page 38: Gal Programmer Pin Header (Jp1)
Chapter 2: Jumpers and Connectors GAL Programmer Pin Header (JP1) MCU Programmer Pin Header (JP2) A. Connector size: 1 x 6 = 6-pin header A. Connector size: 1 x 5 = 5-pin header B. Connector location: B. Connector location: Connector pin definition Connector pin definition Definition Definition... -
Page 39: Mcu Com Port (Jp3)
Chapter 2: Jumpers and Connectors MCU COM Port (JP3) Serial-ATA Power Input (CN9, CN11, CN14, CN16) A. Connector size: 1 x 3 = 3-pin header A. Connector size: 1 x 4 = 4-pin header B. Connector location: B. Connector location: Connector pin definition Connector pin definition Definition... -
Page 40: Serial-Ata 2.0 (Cn13, Cn15)
Chapter 2: Jumpers and Connectors Serial-ATA 2.0 (CN13, CN15) Serial-ATA 3.0 (CN8, CN10) A. Connector size: 1 x 7 = 7-pin SATA connector A. Connector size: 1 x 7 = 7-pin SATA connector B. Connector location: B. Connector location: Connector pin definition Connector pin definition Definition Definition... -
Page 41: Usb Connector (J13, J16)
Chapter 2: Jumpers and Connectors USB connector (J13, J16) Pre-Heater Sensor Connector (J6) A. Connector size: JST-1x4-180-2.5mm-MALE+JST-1x4-180-2.0mm-MALE A. Connector size: 1 x 3 = 3-pin header B. Connector location: B. Connector location: Connector pin definition Connector pin definition a. 2.5mm MALE Definition Definition Definition... -
Page 42: Usb Connectors (Cn25)
Chapter 2: Jumpers and Connectors USB Connectors (CN25) Connector location: Connector pin definition Definition Definition USB0- USB0+ USB3_RX0- USB3_RX0+ USB3_TX0- USB3_TX0+ USB1- USB1+ USB3_RX1- USB3_RX1+ USB3_TX1- USB3_TX1+... -
Page 43: Mini-Pcie (Wlan1) (Cn4)
Chapter 2: Jumpers and Connectors Mini-PCIe (WLAN1) (CN4) Connector location: Connector pin definition Definition Definition Definition Definition WAKE# +V3.3S +V1.5S SMB_CLK +V1.5S PETn0 SMB_DATA CLKREQ# PETp0 USB_D- REFCLK- USB_D+ REFCLK+ LED_WWAN# LED_WLAN# DISABLE# LED_WPAN# PERST# +V1.5S PERn0 +3.3S PERp0 +V3.3S... -
Page 44: Mini-Pcie (Wlan2) (Cn5)
Chapter 2: Jumpers and Connectors Mini-PCIe (WLAN2) (CN5) Connector location: Connector pin definition Definition Definition Definition Definition WAKE# +V3.3S +V1.5S SMB_CLK +V1.5S PETn0 SMB_DATA CLKREQ# USIM PWR PETp0 USIM DATA USB_D- REFCLK- USIM CLK USB_D+ REFCLK+ USIM RST LED_WWAN# LED_WLAN# DISABLE# LED_WPAN# PERST#... -
Page 45: Mini-Pcie (Wwan) (Cn3)
Chapter 2: Jumpers and Connectors Mini-PCIe (WWAN) (CN3) Connector location: Connector pin definition Definition Definition Definition Definition MIC + +V3.3S MIC - SPK + USIM PWR RESET USIM DATA USB_D- VCC_MSM26_DIG USIM CLK USB_D+ USIM RST +V3.3S +V3.3S LED_WWAN# W_DISABLE# +V3.3S... -
Page 46: Antenna Switch Connector (J2)
Chapter 2: Jumpers and Connectors Antenna Switch Connector (J2) SIM CARD Connector For WLAN (CN1, CN2) A. Connector size: JST-1x4-180-1mm-MALE SIM (CN1) is for Mini-PCIe (CN3) B. Connector location: SIM (CN2) is for Mini-PCIe (CN4) Connector location: Connector pin definition Definition Definition VCC3... -
Page 47: Power Input (Cn18)
Chapter 2: Jumpers and Connectors Power Input (CN18) Pre-heater Power Connector (J3) A. Connector size: 2 x 12 = 24-pin header A. Connector size: JST-1x4-180-1mm-MALE B. Connector location: B. Connector location: Connector pin definition Connector pin definition Definition Definition Definition Definition PSE 12V VCC12... -
Page 48: Line-In, Mic-In, Speaker (Cn26)
Chapter 2: Jumpers and Connectors Line-in, Mic-in, Speaker (CN26) Power On & SSD or HD Active LED Connector location: Connector location: Connector pin definition Connector pin definition Definition Definition LED No. Function Description AGND MICIN_L_CN POWER LED MIC_JD AGND SATA LED MICIN_R_CN GPS LED SURR_OUT_L_CA... -
Page 49: Wlan & Wwan & Lan Active Led
Chapter 2: Jumpers and Connectors WLAN & WWAN & LAN Active LED PSE LAN Active LED Connector location: Connector location: Connector pin definition Connector pin definition LED No. Function Description LED No. Function Description WWAN LED PSE_A1_ACT#_LED WLAN LED PSE_A2_ACT#_LED LAN0_LED PSE_A3_ACT#_LED LAN1_LED... -
Page 50: Gps Connector (J1)
Chapter 2: Jumpers and Connectors GPS Connector (J1) Port 80 Connector (J10) Connector size: 1 x 6 = 6-pin header Connector size: 1 x 10 = 10-pin header Connector location: Connector location: Connector pin definition Connector pin definition Definition Definition Definition Definition GPS_BAT... -
Page 51: Bluetooth Connector (J4)
Chapter 2: Jumpers and Connectors Bluetooth Connector (J4) RTC Battery Connector (J5) Connector size: 1 x 10 = 10-pin header Connector size: 1 x 2 = 2-pin header Connector location: Connector location: Connector pin definition Connector pin definition Definition Definition Definition BT_3.3V VBAT1... -
Page 52: Chapter 3: System Setup
Chapter 3: System Setup 3: s haPter ystem etuP Removing the Chassis Cover Prior to removing the chassis cover, make sure the unit’s power is off and disconnected from the power sources to prevent electric shock or system damage. 1. The screws on the chassis are used to secure the cover to the chassis. Remove these screws and put them in a safe place for later use Left Side View Right Side View Top View... - Page 53 Chapter 3: System Setup Removing the Chassis Cover 2. Lift the cover upward then remove it from the chassis.
-
Page 54: Installing The Wi-Fi And Gprs/Umts/Hsdpa Modules
Chapter 3: System Setup Installing the Wi-Fi and GPRS/UMTS/HSDPA Modules 1. The Mini PCI Express slot shown below is used to install a Wi-Fi, 3.5G communication module such as GPRS, UMTS or HSDPA module. WWAN Mini PCI Express slot Wi-Fi Mini PCI Express slot 3. -
Page 55: Installing Ssd Drive
Chapter 3: System Setup Installing SSD Drive 1. Open the cover on the right side of the panel. 3. Remove the SSD tray from the chassis, then place the SSD into the tray and fasten the 4 screws. 2. Press the button to eject the SSD tray. -
Page 56: Installing Pci-E Expansion Card
Chapter 3: System Setup Installing PCI-e Expansion Card 1. The PCI-e kit includes the following: 2. Fasten PCI-e card to the riser bracket with screw (50311F0102X00) x 3. • Riser Bracket x 1 • PCI-e Card x 1 • Screw (50311F0102X00) x 3 •... - Page 57 Chapter 3: System Setup 3. Plug PCI-e card into carrier PCA. 4. Fasten riser bracket with screw (50311F0095X00) x 4.
