- Page 1 Contents Network Viedo Recorder User Manual The manual is applied to the following model: Model No: NRM 303 Note: The manual is subject to change without notic...
-
Page 2: Table Of Contents
Preface ontents Preface Chapter 2: Jumpers and Connectors Copyright ..........................vi Before You Begin ........................9 Precautions ..........................9 Disclaimer ..........................vi Jumper Settings ........................10 Acknowledgements ......................vi The NRM303 Series System Components ..............11 Regulatory Compliance Statements................vi Locations of the Jumpers and Connectors for MVSB 5200 ......11 Declaration of Conformity .................... - Page 3 Preface Internal Connectors ......................22 LAN2 Port (Co-layout with J3 and J4)..............38 USB 2.0 Connector ....................22 LAN1 and USB 3.0/USB 2.0 Ports .................39 Front Panel Audio Connector ................22 (Co-layout with J6 and J7) ..................39 CFast Card Slot (For PC System Only) ..............23 GPIO/CAN Connector .....................39 GPS Connector ......................23 (Co-layout with J8, J9 and J10) ................39...
- Page 4 Preface External I/O Interfaces ....................55 Tracker ..........................72 KVM Switch Connector ...................55 1. Config1 ........................73 Audio Line-out ......................55 2. Config2 ........................76 USB 2.0 Ports .......................56 3. G-Sensor ........................77 Reset Connector ......................56 4. iButton ........................77 Internal Connectors ......................57 5. RFID ...........................78 LAN Connector ......................57 6.
- Page 5 Preface Event ............................97 (In NVR) ..........................97 (In PC-NVR Communication Tool) ................. 100 KVM ............................101 Selecting Hardware/Software Setting ..............101 Log ............................103...
-
Page 6: Declaration Of Conformity
CE compliant. part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from Divio Tec Declaration of Conformity International Co., Ltd. - Page 7 (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, Divio Tec has established an engineering and manufacturing task force to implement the introduction of green products.
-
Page 8: Safety Information
Preface Safety Information Installation Recommendations Before installing and using the device, note the following precautions: Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small ▪ Read all instructions carefully. components separated. -
Page 9: Safety Precautions
Preface Safety Precautions 11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 1. Read these safety instructions carefully. 12. Never pour any liquid into an opening. This may cause fire or electrical 2. - Page 10 Preface Technical Support and Assistance Conventions Used in this Manual 1. For the most updated information of Divio Tec products, visit Divio Tec’s Warning: website at www.Divio Tec.com. Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself 2.
-
Page 11: Physical Features
Preface 1: P haPter roduCt ntroduCtIon Physical Features NRM303 Front View NRM303 Rear View USB 3.0 SIM1 / SIM2 / CFast indicators USB 2.0 slot cover Reset Line-out Mic-in PoE1 to PoE8 DC Output DC Input Output GPIO Multi OBDII LVDS COM1 COM2... -
Page 12: Overview
Preface Overview Key Features ▪ Multitasking PC + NVR + tracker function The NRM303 series for mobile and railway applications respectively, perform 8-CH live view when keeping recording the video simultaneously without lags. ▪ Vehicle information stamp in video (NRM303 Series) The two series provide multitasking capability such as running video analytics software like people counting continuously while recording real-time videos. -
Page 13: Hardware Specifications
Preface Hardware Specifications Video Stamp ▪ Capability to show and record vehicle and railway information in video NVR System *AMTK camera is required Video Codec Camera Setting ▪ H.264 ▪ Auto search, profile selectable, ONVIF support Audio Codec Disk Management ▪... -
Page 14: Nrm303
Preface ▪ Optional modules with Dead Reckoning available ▪ 1x 9~36VDC input with ignition and 80W typical power consumption ▪ Built-in G-sensor (NRM303 series) ▪ 1x dual USB type A connector for USB 3.0 port + USB 2.0 port ▪ 2x phone jacks 3.5mm for 1x Mic-in and 1x Line-out Power over Ethernet (NRM303 series) ▪... - Page 15 Preface ▪ Operating temperatures (without internal battery): software. Setting 8-level power on/ off delay time by software. Support S3/S4 suspend mode -30°C~50°C (w/ industrial SSD) with air flow ▪ Optional internal 1100mAh, Li-Polymer rechargeable battery ▪ Operating temperatures (with internal battery, discharging): -20°C~45°C (w/ industrial SSD) with air flow ▪...
-
Page 16: Mechanical Dimensions
Preface Mechanical Dimensions NRM303... -
Page 17: Before You Begin
Preface 2: J haPter umPers and onneCtors This chapter describes how to set the jumpers and connectors on the dry environments. A grounding strap is warranted whenever danger of NRM303 series motherboard. static electricity exists. Before You Begin Precautions ▪ Ensure you have a stable, clean working environment. Dust and dirt can Computer components and electronic circuit boards can be damaged by get into components and cause a malfunction. -
Page 18: Jumper Settings
Preface Jumper Settings A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. -
Page 19: The Nrm303 Series System Components
Preface The NRM303 Series System Components The NRM303 series consist of a MVSB 5200 motherboard and I/O board. This chapter lists the location and pinout assignment of the jumpers and connectors on each component. Locations of the Jumpers and Connectors for MVSB 5200 Top View CON1/CON2 CON3... -
Page 20: Bottom View
Preface Bottom View CN13 CN12... -
Page 21: Dip Switch Settings
Preface DIP Switch Settings ME/RTC Clear Switch CN6 VCC Select Switch Connector location: SW3 Connector location: SW1 Function Definition Function Definition Clear CMOS/ME 1-2 ON CN6 3.3V *1-2 OFF Normal *1-2 OFF CN6 3.6V 1-2 ON (*) Default (*) Default... -
Page 22: Input Voltage Control
Preface Input Voltage Control MDIO Power Switch Connector location: SW4 Connector location: SW2 1 2 3 4 Definition Function Definition Function 9~36V PULL UP V3P3 DON’T CARE POWERSW (Pin 1 & 4) H (SW OFF) H (SW OFF) L (SW ON) 12V 24V (Pin 1 &... -
Page 23: Pcm Switch (For 3G Voice)
Preface PCM Switch (For 3G Voice) Connector location: SW10 1 2 3 4 Function Definition Enable 1, 4 ON Disable 2, 3 OFF Definition Definition PCM_TX PCM_RX PCM_TX PCM_RX PCM_RX_SW PCM_RX_SW PCM_TX_SW PCM_TX_SW... -
Page 24: Connector Pin Definitions
Preface Connector Pin Definitions External I/O Interfaces - Front Panel USB 3.0/USB 2.0 Ports (Co-layout with J26 and J27) LED Indicators Connector type: USB 3.0 and USB 2.0 port, Type A Connector location: CN9 Connector location: LED4 and LED5 WWAN WLAN Definition Definition... -
Page 25: Reset Switch (Co-Layout With J29)
Preface Reset Switch (Co-layout with J29) Connector location: SW5 Definition RESET... -
Page 26: External I/O Interfaces - Rear Panel
Preface External I/O Interfaces - Rear Panel Audio Connector (Audio-IP CON For Audio) Line-out Connector Connector type: 3.5mm audio jack Connector location: CN1 Definition Definition Definition Definition MIC_JD SURR_OUT_R SURR_JD MIC_R SURR_OUT_R SURR_OUT_L SURR_JD SURR_OUT_L... -
Page 27: Mic-In Connector
Preface Mic-in Connector LAN1 to LAN8 Ports (Co-layout with J2 to J17) Connector type: 3.5mm audio jack Connector type: RJ45 port with LEDs (NRM303) Connector location: CN2 Connector location: CON4A to CON4D (LAN1 to LAN4) CON3A to CON3D (LAN5 to LAN8) LINK Definition Definition... -
Page 28: V-36V Dc Power Input (Co-Layout With Con2)
Preface 9V-36V DC Power Input (Co-layout with CON2) Connector type: Phoenix Contact 1x5 5-pin terminal block Connector location: CON1 Definition Definition GND_IN GND_IN V_IN V_IN IGNITION... -
Page 29: Dc Output (Co-Layout With Cn4)
Preface DC Output (Co-layout with CN4) Connector type: 2x3 6-pin connector Connector location: CN3 Definition Definition VIN BY PASS 12V OUT I2C_CLK I2C_DAT... -
Page 30: Internal Connectors
Preface Internal Connectors USB 2.0 Connector Front Panel Audio Connector Connector type: 1x4 4-pin header, 2.0mm pitch Connector type: 1x6 6-pin header, 1.0mm pitch Connector location: J26/J27 Connector location: J1 Definition Definition Definition Definition USB0/1_N SURR_OUT_L SURR_JD USB0/1_P SURR_OUT_R MIC_R MIC_JD... -
Page 31: Cfast Card Slot (For Pc System Only)
Preface CFast Card Slot (For PC System Only) GPS Connector Connector type: Standard CFast connector Connector type: 1x6 6-pin header, 1.0mm pitch Connector location: CN7 Connector location: J22 Definition Definition GPS_BAT GPS_LED# PC17 GPS_TX GPS_RX VCC3_GPS Definition Definition SATA2_TXP SATA2_TXN SATA2_RXN SATA2_RXP CFAST_CDI... -
Page 32: Gps-Dr Connector
Preface GPS-DR Connector SIO Temp2 Connector type: 1x4 4-pin header, 1.0mm pitch Connector type: 1x2 2-pin header, 2.54mm pitch Connector location: J21 Connector location: JP5 Definition Definition Definition 1PPS Temp DR_ODOMETER_M DR_DIRECTIO_M... -
Page 33: Rtc Battery Connector
Preface RTC Battery Connector Debug 80 Port Connector Connector type: 1x2 2-pin header, 1.25mm pitch Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J23 Connector location: J25 Definition Definition Definition PCIRST# RTC_BAT 33M_CLK LPC_FRAME# LPC_AD3 LPC_AD2 LPC_AD1 LPC_AD0 VCC3 VCC3... -
Page 34: Reset Connector
Preface Reset Connector Power Switch Connector Connector type: 1x2 2-pin header, 1.25mm pitch Connector type: 1x2 2-pin header, 2.5mm pitch Connector location: J29 Connector location: J28 Definition Definition PWRBT_IN# RESET... -
Page 35: Mcu Debug Com Connector
Preface MCU Debug COM Connector SIM Card Connectors (SIM1 and SIM2) Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: CN13 (SIM1) and CN12 (SIM2) Connector location: JP2 Definition Definition Definition UART5_TX SIM PWR SIM RST UART5_RX SIM CLK SIM DAT... -
Page 36: Reset
Preface Reset MCU Update Connector Connector type: 1x2 2-pin header, 2.54mm pitch Connector type: 2x4 8-pin header, 1.27mm pitch Connector location: JP3 Connector location: JP4 Definition Definition Definition STM_RESET V3P3 STM_NJTRST STM_JTDI STM_JTMS STM_JTCK STM_JTDO STM_RST... -
Page 37: Pin Definition
Preface DB15 Connector USB Output Connector type: 1x16 16-pin header, 1.0mm pitch Connector type: 1x4 4-pin header, 1.0mm pitch Connector location: J20 Connector location: J24 Definition Definition Definition Definition ANA_GND 12VDC USB2_6_P 12VDC USB2_6_N USB2_6_PWR U5TX_RF U5RX_RF iButton_R SPEED DR_DIRECTIO_M Analog_IN1 MDI2_DB2R MDI1_DB1R... -
Page 38: Board To Board Connector (To Io Board)
Preface Board to Board Connector (to IO Board) Connector location: J19 Definition Definition SATA_TXN2 PCIE_CLK1P SATA_TXP2 USB2_3_N USB2_3_P USB2_5_N PCIE_P5_RX0N USB2_5_P PCIE_P5_RX0P Definition Definition SATA_RXN3 PCIE_P5_TX0N PCIE_P2_RXN SATA_RXP3 PCIE_P5_TX0P EDP_LANE1_N PCIE_P2_RXP EDP_LANE1_P SATA_TXN3 PCIE_CLK0N PCIE_P2_TXN SATA_TXP3 PCIE_CLK0P EDP_LANE0_N PCIE_P2_TXP EDP_LANE0_P USB3_2_RXN DPC2_AUXP PCIE_CLK2N... -
Page 39: Board To Board Connector (To Io Board)
Preface Board to Board Connector (to IO Board) Connector location: JP1 Definition Definition USB_PWREN DI_3 USB_OC13# DI_2 DI_1 DCD2# MINICARD1_EN RXD2 PCIE1_LED_R TXD2 MINICARD1_DIS# DTR2# MINI_BT_DIS# Definition Definition DSR2# CH7511RST_GPIO47 RTS2# DPC2_HPD CH7511_ENVDD VCC3_POK CTS2# DCD1# CH7511_ENBKL SMB_CLK RI2# RXD1 PM_SLP_S0# SMB_DATA TXD1... -
Page 40: Io Board Power Connector
Preface IO Board Power Connector VIN Connector Connector type: 1x3 3-pin header, 3.96mm pitch Connector type: 1x6 6-pin header Connector location: CN11 Connector location: CON2 Definition Definition Definition VCC3 GND_IN GND_IN V_IN V_IN VCC5 IGNITION IGNITION (CON4 only) -
Page 41: Battery Connector
Preface Battery Connector Battery Power Connector Connector type: 1x10 10-pin header, 1.0mm pitch Connector type: 2x20 20-pin header, 2.0mm pitch Connector location: J18 Connector location: CN5 Definition Definition Definition Definition BAT_GND BAT_GND VIN_M BACKUP_BAT BAT_PRECHG BAT_TEST BAT_GND BACKUP_BAT BAT_SMBDAT 3V3ALW_BAT BAT_GND BACKUP_BAT BAT_SMBCLK... -
Page 42: Lan Connectors (Two 4-Pin Connectors For Each Lan)
Preface LAN Connectors (Two 4-pin Connectors for Each LAN) NVR LAN Connector Connector type: 1x4 4-pin header, 2.5mm pitch Connector type: 2x10 20-pin header, 1.0mm pitch Connector location: J2 to J17 (LAN 1 to LAN 8) Connector location: CN8 J2 ~ J9 J10 ~ J17 J2 ~ J9 Definition... -
Page 43: Pcm_Rx_Sw
Preface Mini-PCIe Connector for 3G Connector location: CN6 Definition Definition Definition Definition MIC_P/WAKE_N +V3.3A_MINI4 SPI_MOSI_3G UIMA_PWR UMTS_RESET# UIMA_DAT USB- VCC_MSM26_DIG UIMA_CLK USB+ SPI_MRDY_3G UIMA_RST +V3.3A_MINI4 SPI_SCLK_3G +V3.3A_MINI4 WWAN_LED# USART6_TXD_3.5G 3.5G_GPS_EXTINT USART6_RXD_3.5G 3.5G_DIS# PCM_CLK GPS_TXD_3.5G 3.5G_RST# PCM_RX 3.5G_GPSPWREN SPI_SRDY_3G +V3.3A_MINI4 PCM_TX SPI_MISO_3G PCM_SYNC +V3.3A_MINI4... -
Page 44: Locations Of The Jumpers And Connectors For The I/O Board
Preface Locations of the Jumpers and Connectors for the I/O Board CN11 CN17 Top View CN6B CN6A CN12 CN16 CN13 CN14 CN15 CN18 CN10... -
Page 45: Bottom View
Preface Bottom View... -
Page 46: Connector Pin Definitions
Preface Connector Pin Definitions External I/O Interfaces LAN1 Port (Co-layout with J1 and J2) LAN2 Port (Co-layout with J3 and J4) Connector type: RJ45 port with LEDs (NRM303) Connector type: RJ45 port with LEDs (NRM303) Connector location: CN1 Connector location: CN2 LINK LINK Definition... -
Page 47: Lan1 And Usb 3.0/Usb 2.0 Ports
Preface LAN1 and USB 3.0/USB 2.0 Ports GPIO/CAN Connector (Co-layout with J6 and J7) (Co-layout with J8, J9 and J10) Connector type: USB 3.0 and USB 2.0 port, Type A Connector type: 2x8 16-pin switch Connector location: CN3 Connector location: CN4 Pin 9 Pin 16 Pin 1... -
Page 48: Com1 Port (Co-Layout With Cn7)
Preface COM1 Port (Co-layout with CN7) COM2 Port (Co-layout with CN8) Connector type: DB-9 port, 9-pin D-Sub Connector type: DB-9 port, 9-pin D-Sub Connector location: CN6B Connector location: CN6A Definition Definition Definition Definition COM1_DCD#_TX- COM1_RX_TX+ COM2_DCD#_TX- COM2_RX_TX+ COM1_TX_RX+ COM1_DTR#_RX- COM2_TX_RX+ COM2_DTR#_RX- COM1_GND COM1_DSR#... -
Page 49: Lvds Port
Preface LVDS Port VGA and DVI-D Connectors (Co-layout with J13) Connector type: 26-pin female port Connector type: DB-15 port, 15-pin D-Sub Connector location: CN11 Connector location: CN17 Definition Definition Definition Definition LVDS_DDC_CLK LVDS_DDC_DATA GREEN Panel_VDD LVDSA_DATA0 BLUE CH7517_SPC LVDSA_DATA3 LVDSA_DATA#0 M_DET LVDSA_DATA#3 Panel_VDD... -
Page 50: Internal Connectors
Preface Internal Connectors VGA Connector LAN1 Connectors Connector type: 1x16 16-pin header, 1.0mm pitch Connector type: 1x4 4-pin header, 2.0mm/2.5mm pitch Connector location: J13 Connector location: J1 and J2 Definition Definition Definition Definition VGA_VCC LAN_MDI_2P_R LAN_MDI_2N_R VGA_CLK VGA_DAT LAN_MDI_3P_R LAN_MDI_3N_R VGA_VS VGA_HS VGA_GND... -
Page 51: Lan2 Connectors
Preface LAN2 Connectors COM1 and COM2 Connectors Connector type: 1x4 4-pin header, 2.0mm/2.5mm pitch Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J3 and J4 Connector location: CN7 and CN8 Definition Definition Definition Definition LAN_MDI_2P_R LAN_MDI_2N_R LAN_MDI_3P_R LAN_MDI_3N_R DTR_RX- RXD_TX+ RI_PWR TXD_RX+... -
Page 52: Gpio Connector
Preface GPIO Connector CAN Module Connector Connector type: 1x10 10-pin header, 1.0mm pitch Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: J9 Connector location: J8 and J10 Definition Definition Definition Definition ISO_GND ISO_GND CAN1_H_R CAN1_L_R GPIO8 GPIO7 CAN_M_L_R CAN_M_H_R GPIO6 GPIO5 GPIO4... -
Page 53: Usb 2.0 Connector
Preface USB 2.0 Connector SATA Power Connector Connector type: 1x4 4-pin header, 2.5mm pitch Connector type: 1x2 2-pin header, 2.5mm pitch Connector location: J6 and J7 Connector location: J11 and J12 Definition Definition Definition USB2_7N VCC5 USB2_7P USB_R_PWR Definition Definition USB2_1N USB2_1P USB_R_PWR... -
Page 54: Can Module Connector
Preface CAN Module Connector SATA Power Connectors Connector type: 2x5 10-pin header, 2.0mm pitch Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: JP2 and JP3 Connector location: CN9 and CN16 JP2 Input Definition Definition Definition TXD5 RXD5 VCC12 CAN_DI1 CAN_DO1 VCC5 CAN_M_VCC5... -
Page 55: Sata Connectors
Preface SATA Connectors 24V Battery-out Connector Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector type: 1x4 4-pin header, 1.25mm pitch Connector location: CN5 and CN12 Connector location: J15 Definition Definition Definition Definition SATA1/0_TXP CHG-OUT_24V CHG-OUT_24V SATA1/0_TXN SATA1/0_RXN SATA1/0_RXP... -
Page 56: V Battery-In Connector
Preface 12V Battery-in Connector GPIO Switch Connector type: 1x2 2-pin header, 2.54mm pitch Connector type: 8-pin DIP switch Connector location: CN18 Connector location: SW1 1 2 3 4 5 6 7 8 Definition Definition Definition CHG-IN_12V GPO_1 GPO_2 GPO_3 GPO_4 GPI_1 GPI_2 GPI_3... -
Page 57: Io Board Power Connector
Preface IO Board Power Connector SIM Card Slot Connector type: 1x3 3-pin header, 3.96mm pitch Connector location: CN13 Connector location: CN10 Definition Definition Definition VCC3 UIM_PWR UIM_RESET UIM_CLK VCC5 UIM_DATA... -
Page 58: Mini-Pcie Connector For Wlan/Bluetooth1
Preface Mini-PCIe Connector for WLAN/Bluetooth1 Connector location: CN14 Definition Definition Definition Definition +V3.3_MINI1 +V1.5S_MINI1 SMBCLK +V1.5S_MINI1 PCIE_TX0N SMBDAT UIMB_PWR PCIE_TX0P UIMB_DATA USB- PCIE_CLK0N UIMB_CLK USB+ PCIE_CLK0P UIMB_RST +V3.3_MINI1 +V3.3_MINI1 PCIE1_LED_R MINICARD1_DIS# PCIE1_LED CB_RESET#_B +V1.5S_MINI1 PCIE_RX0N +V3.3_MINI1 PCIE_RX0P MINI_BT_DIS# +V3.3_MINI1... -
Page 59: Mini-Pcie Connector For Msata (For Pc System Only)
Preface Mini-PCIe Connector for mSATA (For PC System Only) Connector location: CN15 Definition Definition Definition Definition +V3.3_MINI3 +V1.5S_MINI3 +V1.5S_MINI3 SATA_TXN3 SATA_TXP3 PCIE_CLK0N PCIE_CLK0P +V3.3_MINI3 +V3.3_MINI3 +V3.3_MINI_3 +V1.5S_MINI3 SATA_RXP3 +V3.3_MINI3 SATA_RXN3 Z1001 +V3.3_MINI3... -
Page 60: Board To Board Connector (To Motherboard)
Preface Board to Board Connector (to Motherboard) Connector location: J14 Definition Definition SATA_TXN2 PCIE_CLK1P SATA_TXP2 USB2_3_N USB2_3_P USB2_5_N PCIE_P5_RX0N USB2_5_P PCIE_P5_RX0P Definition Definition SATA_RXN3 PCIE_P5_TX0N PCIE_P2_RXN SATA_RXP3 PCIE_P5_TX0P EDP_LANE1_N PCIE_P2_RXP EDP_LANE1_P SATA_TXN3 PCIE_CLK0N PCIE_P2_TXN SATA_TXP3 PCIE_CLK0P EDP_LANE0_N PCIE_P2_TXP EDP_LANE0_P USB3_2_RXN DPC2_AUXP PCIE_CLK2N USB3_2_RXP... -
Page 61: Board To Board Connector (To Motherboard)
Preface Board to Board Connector (to Motherboard) Connector location: JP1 Definition Definition USB_PWREN DI_3 USB_OC13# DI_2 DI_1 DCD2# MINICARD1_EN RXD2 PCIE1_LED_R TXD2 MINICARD1_DIS# DTR2# MINI_BT_DIS# Definition Definition DSR2# CH7511RST_GPIO47 RTS2# DPC2_HPD CH7511_ENVDD VCC3_POK CTS2# DCD1# CH7511_ENBKL SMB_CLK RI2# RXD1 PM_SLP_S0# SMB_DATA TXD1 RXD5... -
Page 62: Locations Of The Jumpers And Connectors For The Nvr Board
Preface Locations of the Jumpers and Connectors for the NVR Board... -
Page 63: Connector Pin Definitions
Preface Connector Pin Definitions External I/O Interfaces KVM Switch Connector Audio Line-out Connector type: 2-pin terminal block Connector type: 3.5mm audio jack Connector location: J11 Connector location: J1 Definition Definition Definition SURR_OUT_L 4 MIC_R SURR_JD 5 MIC_JD SURR_OUT_R 6 GND... -
Page 64: Usb 2.0 Ports
Preface USB 2.0 Ports Reset Connector Connector type: USB port, Type A Connector location: J5 Connector location: JP7 and JP8 Definition Definition Definition USB_P USB_N USB_PWR RESET... -
Page 65: Internal Connectors
Preface Internal Connectors NVR/X86 VGA Connectors LAN Connector Connector type: 1x10 10-pin header Connector type: 2x10 20-pin header Connector location: J3 and J4 Connector location: JP1 Definition Definition Definition Definition LSW1-2_0P NVR_12V SCL2 LSW1-2_0N NVR_12V SDA2 LSW1-2_1P LSW1-2_1N NVR_GPIO LSW1-2_2P DGND LSW1-2_2N NVR_GND... -
Page 66: Gpio Connectors
Preface GPIO Connectors SATA Connectors Connector type: 1x4 4-pin header, 2.5mm pitch Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector location: JP2 and JP3 Connector location: CN2 and CN3 Definition Definition Definition Definition DIGITAL_IN2 DGND SATA1/0_TXP SATA1/0_TXN DIGITAL_IN3 DGND SATA1/0_RXN SATA1/0_RXP Definition... -
Page 67: Sata Power Connectors - 5V
Preface SATA Power Connectors - 5V Internal USB Connector Connector type: 1x2 2-pin header, 2.5mm pitch Connector type: 1x4 4-pin header, 2.5mm pitch Connector location: JP4 and JP5 Connector location: JP9 Definition Definition Definition VCC5 USB_P USB_N USB_PWR... -
Page 68: Removing The Chassis Bottom Cover
Preface Preface 3: s haPter ystem etuP Removing the Chassis Bottom Cover Prior to removing the chassis cover, make sure the unit’s power CAUTION! CAUTION! is off and disconnected from the power sources to prevent CAUTION! electric shock or system damage. 1. -
Page 69: Installing A Ssd/Hdd Drive (For Nvr System Only)
Preface Installing a SSD/HDD Drive (For NVR System Only) 1. The two SSD/HDD bays on the front are used to install 2.5” hard drives. 2. Insert the hard drive into the drive bay with the SATA data and power Loosen the thumb screws and remove the cover. connector facing towards the end. - Page 70 Preface 3. Connect the SATA data and power connectors on the hard drive to the 4. Place the dampers onto the damper bracket, then insert the HDD SATA connector on the hard drive bracket and screw the connectors in bracket into the damper bracket. place.
- Page 71 Preface 5. With the damper bracket secured, install it on top of the metal base and secure it using screws. Metal base...
- Page 72 Preface 6. Connect the SATA data and power connectors to their respective 7. Reinstall the SSD/HDD drive bay cover and tighten the thumb screws to connectors on the motherboard. secure it. JP5 (SATA power) CN2 (SATA data) JP4 (SATA power) CN3 (SATA data)
-
Page 73: Installing A Wlan Module
Installing a WLAN Module Installing an mSATA Module (For PC System Only) 1. Locate the WLAN Mini PCI Express slot (CN14). Insert the module into the Mini PCI Express slot at a 45 degrees angle until the gold-plated 1. Locate the mSATA slot (CN15). Insert the module into the Mini PCI Express connector on the edge of the module completely disappears inside the slot at a 45 degrees angle until the gold-plated connector on the edge of slot. -
Page 74: Installing A Wwan Module
Preface Installing a WWAN Module 1. Locate the WWAN Mini PCI Express slot (CN6). Insert the module into the Mini PCI Express slot at a 45 degrees angle until the gold-plated connector on the edge of the module completely disappears inside the slot. Then fasten screws into the mounting holes to secure the module. -
Page 75: Installing A So-Dimm
Preface Installing a SO-DIMM 1. Push the ejector tabs which are at the ends of the socket outward. Then insert the module into the socket at an approximately 30 degrees angle. Apply firm even pressure to each end of the module until it slips down into the socket. -
Page 76: Installing An Obdii Module
Preface Installing an OBDII Module 1. Locate the OBDII connectors (JP2 and JP3). 2. Connect the OBDII module to JP2 and JP3 and secure the OBDII module with screws. Mounting screws... -
Page 77: Installing Rackmount Brackets
Preface Installing Rackmount Brackets The rackmount brackets provide a convenient and economical way of mounting the system on the wall. 1. The mounting holes are located at the bottom of the system. Secure the 2. Now mount the system on the wall by fastening screws through the brackets on each side of the system using the provided mounting screws. -
Page 78: Menu Screen
Divio Tec’s software demo utility enables users to test and control different I/O port functions on the NRM303 series. This document shows how to use the utility. There are also source code files of the utility in the CD. Users can refer to the source codes to develop their applications. -
Page 79: G-Sensor
Preface G-Sensor iButton... -
Page 80: Rfid
Preface RFID Tracker... -
Page 81: Config1
Preface 1. Config1 1.1 MCU Version 1.4 Frequency-In Shows the MCU Version. If the Version is R18, VS520R18 is shown. Shows the Frequency-In. 1.2 Ignition 1.5 Analog-In Voltage Shows the Ignition Status. Shows the Analog-In Voltage. ON …… Signal of ignition is high. OFF …... - Page 82 Preface 1.7 Battery Temperature 1.10 GPS Shows the Battery Temperature. Enables or disables the GPS function. 1.8 Battery Status Shows the Battery Status. 1.11 SIM Card Selects the SIM Card. 1.9 WWAN Enables or disables the WWAN/WWAN Wakeup function. The setting can also be cleared by the Set button. 1.12 WDT Enables or disables the WDT function.
- Page 83 Preface 1.13 MDI 1.16 Wi-Fi Sets the MDI1/MDI2 function. Enables or disables the Wi-Fi function. 1.14 MDO 1.17 VIOB-CAN-03 Sets the MDO function. Enables or disables the VIOB-CAN-03 function. 1.15 POE Sets the POE function.
-
Page 84: Config2
Preface 2. Config2 2.1 Low Battery Voltage Protection 2.4 Delay Time Sets the Low Battery Voltage Protection Startup/Shutdown voltage level during 12V/24V. Enables or disables the delay time function. There are several selections of delay time. 2.5 Wake Up Timer 2.2 Low Voltage Status Sets the Alarm wake up timer. -
Page 85: G-Sensor
Preface 3. G-Sensor 4. iButton Refer to the G-sensor utility screen to set up and save your request. Refer to the iButton utility screen to set up and save your request. -
Page 86: Rfid
Preface 5. RFID 6. Tracker Refer to the RFID utility screen to set up and save your request. Refer to the Tracker utility screen to set up and save your request. -
Page 87: Ublox-Neo M8 Overview
Preface B: GPs f PPendIx eature uBlox-NEO M8 Overview Technical Specifications The NEO-M8 series of standalone concurrent GNSS modules is built on the Features exceptional performance of the u-blox M8 GNSS (GPS, GLONASS, Galileo, Receiver type 72-channel u-blox M8 engine BeiDou, QZSS and SBAS) engine in the industry proven NEO form factor. - Page 88 Preface Features cont. Package Anti jamming Active CW detection and removal. Extra 24 pin LCC (Leadless Chip Carrier): 12.2 x 16.0 x 2.4 mm, 1.6 g onboard SAW band pass filter (NEO-M8N/Q) Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N) Supported antennas Active and passive Pinout Odometer...
-
Page 89: Gpio Pinout Description
Preface C: s dI/do PPendIx IGnal onneCtIon of GPIO Pinout Description SW1 Setting 1-4 ON GPIO ISO1_VCC5 Pin 9 Pin 16 DP_GPO_1 R251 220E 0805 GPO1 DP_GPO_2 R250 220E 0805 GPO2 DP_GPO_3 GPO3 R249 220E 0805 DP_GPO_4 GPO4 R248 220E 0805 Pin 1 Pin 8... -
Page 90: Digital Input
Preface Digital Input CN3 connector for GPI signal (digital signal input) The CN3 has 4 digital input channels by default. Wet Contact (default) Dry Contact: The GPI signals have a pull up resistor to 5V internally. Internal External The figure below shows how to connect an external output source to one of the input channel. -
Page 91: Digital Output
Preface Digital Output CN3 connector for GPO signal (digital signal output) The CN3 connector has 4 digital output channels by default. The signal connection of CN3 support two connected methods for output signal type. The output signal has two states, one is low level (driven to 0V from GPO signal) other is open (high voltage is provided from external device). -
Page 92: Startup And Shutdown Voltage Setting
Preface d: V PPendIx ehICle ower anaGement etuP Startup and Shutdown Voltage Setting Set the startup voltage to 11.5V or 23V and the shutdown voltage to Set the startup voltage to 12.0V or 24V and the shutdown voltage to 10.5V or 21V 11.0V or 22V If the input voltage is 12V: set the startup voltage to 11.5V and the shutdown If the input voltage is 12V: set the startup voltage to 12V and the shutdown... - Page 93 Preface Set the startup voltage to 12.5V or 25V and the shutdown voltage to Set the startup voltage to 12.5V or 25V and the shutdown voltage to 11.0V or 22V 11.0V or 22V If the input voltage is 12V: set the startup voltage to 12.5V and the shutdown If the input voltage is 12V: set the startup voltage to 12.5V and the shutdown voltage to 11V.
-
Page 94: Power-On Delay Setting
Preface Power-on Delay Setting Disable Power-on Delay Aptio Setup Utility - Copyright (C) 2016 America Megatrends, Inc. Advanced Power Management Configuration Power On Delay Setting ** Startup & Shutdown Voltage Setting ** Input Voltage 9-36V Startup,Shutdown [(11.5,10.5)/(23,21)] ** Delay Time Setting ** Power On Delay [Disabled] Power Off Delay... - Page 95 Preface Enable Power-on Delay Delay time can be set at 10sec/30sec/1min./5min./10min./15min./30min./1hour. Aptio Setup Utility - Copyright (C) 2016 America Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2016 America Megatrends, Inc. Advanced Advanced Power Management Configuration Power Management Configuration Power On Delay Setting Delay On Time selection Setting ** Startup &...
-
Page 96: Power-Off Delay Setting
Preface Power-off Delay Setting Disable Power-off Delay Aptio Setup Utility - Copyright (C) 2016 America Megatrends, Inc. Advanced Power Management Configuration Power Off Delay Setting ** Startup & Shutdown Voltage Setting ** Input Voltage 9-36V Startup,Shutdown [(11.5,10.5)/(23,21)] ** Delay Time Setting ** Power On Delay [Disabled] Power Off Delay... - Page 97 Preface Enable Power-off Delay Delay time can be set at 20sec/1min./5min./10min./30min./1 hour/6 hour/18 hour. Aptio Setup Utility - Copyright (C) 2016 America Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2016 America Megatrends, Inc. Advanced Advanced Power Management Configuration Power Management Configuration Power Off Delay Setting Delay Off Time selection Setting...
-
Page 98: Pc-Nvr Communication Tool
Preface e: PC-nVr C PPendIx ommunICatIon tIlIty PC-NVR Communication Tool Port for External Switch, PC VGA Output VGA Input Port & NVR VGA Output Port... -
Page 99: Ip Settings
Preface IP Settings 1. Check the IP address (Default: 192.168.0.200) on the Network settings page in NVR, and make sure the IP address is in the same subnet as the 2. Check the HTTP Port (Default: 80) on the Network settings page in NVR, make the port number is same as the HTTP port number. - Page 100 Preface 3. Press the Connect button. When connected successfully, the message Note: The IP address of the PC must be in the same network segment as the “connect to NVR success” will be shown in the Log Screen. NVR in order to establish a connection.
-
Page 101: Display Mode
Preface Display Mode (Example) The Send_Display option is used to configure the screen layout and division. Normal: The row of System Function is shown. Full Screen: The row of System Function is hidden. Division: Support 1, 4 and 9 screen divisions. - Page 102 Preface...
- Page 103 Preface...
-
Page 104: Osd Function
Preface OSD Function Transparency: Define the transparency level of the background color. Second(s): Define how long the message is shown. If “0” is specified, the message will be shown constantly. OSD String: Define the text message. Maximum of 300 characters. Camera: Select which camera the message will be shown on. -
Page 105: Event
Preface Event 2. Press Local and select Add, then choose one of the events from Event 1~5. Press OK. There are 5 different events that can be defined. Example: Event 2 is selected. (In NVR) 1. Define the type of Event. Press Function and select Event Setting. - Page 106 Preface 3. Define the time period of the event. Press Event 2 to select Event 2, then 4. Press Add for defining the action type of triggering alarm for Event 2. press Add. Fill in the Start Time and End Time, then define the Alarm Press OK.
- Page 107 Preface After Event 2 is defined, the Action Types will be shown.
- Page 108 Preface (In PC-NVR Communication Tool) Select the event that was already defined in NVR. Enable Status. Press Send_Event. For example, if Event 2 is selected, the message “Event 2” will be shown on the division that you defined in the Display on Channel function.
-
Page 109: Selecting Hardware/Software Setting
Preface Selecting Hardware/Software Setting (Enable Hardware Setting in NVR) Press Function, select KVM Setting. Enable Manual. PC VGA output or NVR VGA output can then be selected by external switch. The VGA port on NVR can have PC VGA output or NVR VGA output (default setting). - Page 110 Preface (Enable Software Setting in NVR) (Enable Software Setting in PC-NVR Communication Tool) Press Function, select KVM Setting. Enable Software control and press Select Software and press Send_KVM. PC VGA output or NVR VGA output Switch. PC VGA output or NVR VGA output can then be selected by can then be selected by software.
- Page 111 Preface Stop log: Stop showing log message. Clear: Clear all log messages.
