OPERATING INSTRUCTIONS
BITZER AUSTRALIA
BUFFALO TRIDENT HEAT EXCHANGE
BDC Series Air Cooled Condensers
Models:
Contents
1. Important Recommendations ........................... 1
2. Safety Recommendations ................................ 1
3. Application Ranges .......................................... 2
4. Installation Guide ............................................. 2
5. Electrical Connections ..................................... 7
6. Wiring Diagram .................................................8
1.

Important Recommendations

• BDC air cooled condensers are intended for installation only by Qualified Refrigeration Personnel
and are to be installed in accordance with the guidelines mentioned in this manual.
• All electrical work is to be carried out by Qualified Electrical Personnel and to be in accordance with
local electrical regulations.
2.

Safety Recommendations

• Condensers are supplied with a Nitrogen Holding Charge. (Release pressure fully before accessing the
connection points).
• Electrical power is to be isolated prior to the commencement of any electrical work.
• During normal operation Pressurised Refrigerant is contained within the condenser. Extreme care
should be taken to avoid leakage, as personal injury may occur. (Avoid the use of sharp objects in
close proximity to refrigeration piping).
• Extensive gas loss in enclosed area may result in asphyxiation.
• Contact with refrigerant may cause personal injury (freeze burns).
• Normal operating conditions involve hot surfaces within the condenser. Extreme care should be taken
to avoid contact.
• Avoid contact with condenser fins as sharp edges may cause personal injury.
BDC 152 (2F) (V) BDC 152 (2F) (H)
BDC 228 (3F) (V) BDC 228 (3F) (H)
BDC 304 (4F) (V) BDC 304 (4F) (H)
BDC 380 (5F) (V) BDC 380 (5F) (H)
BDC 456 (6F)
BDC 608 (8F)
BDC 760 (10F)
7. Commissioning Instructions ............................. 9
8. Maintenance Instructions ................................. 9
9. De-commissioning Instructions ........................ 9
10. Manufacturer ....................................................9
11. Service Address ................................................9
HXO-504-1 AUS
