MOTUS 990T SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M990T and is the answer not in the manual?

Questions and answers

Related Manuals for Motus M990T

Summary of Contents for Motus M990T

  • Page 1 MOTUS 990T SERIES...
  • Page 2 Class SB(studio) : professional and/or commercial use. For information about the product, contact MOTUS customer service(Motus Customer Service) or your dealer. This manual is property of Motus, it is prohibited to copy this manual without Motus prior consent. Rev1.0...

  • Page 3: Table Of Contents

    Safety Warnings & precautions Grounding Instruction Installation precautions Precautions before use Cautions during use Management & Maintenance precautions Product Features Name of Each Part Name of Display Console Name & Function of Each Control Key Precautions before use(Operating procedure) Quick Start Exercise program type Preprogrammed program Custom Program...
  • Page 4 Use the treadmill only for its intended use as described in this manual. Do not attach accessories that are not recommended by Motus. It can cause an accident. Stop using the treadmill and contact your dealer for repair, if the product is wet, if it is not working properly, if it has a damaged cord or plug or if it has been dropped or damaged.
  • Page 5 When you move the product, do not collide the product with the wall or drop it on the floor. The lubricant used in the treadmill shall use only the lubricant designated or provided by Motus. If you use the general industrial lubricant or the one provided by other companies, the deck and running belt may be damaged.
  • Page 6 M990T SERIES WARNING Check power source before use whether the Place the plug completely into the outlet. Bad connection with power source may cause an treadmill is proper for 120V AC or 230V AC. explosion or a fire. Do not use a warn-out plug or damaged outlet.
  • Page 7 M990T SERIES Do not use extension cord. Do not place the machine near a heating device. Long cord can cause malfunction or stop of (Do not place the machine or line cord near a heating device.) treadmill due to voltage drop.
  • Page 8 M990T SERIES WARNING Do not push buttons with sharp object or pin etc. During operation, do not touch any moving parts or This can cause electric shock. rotating parts with one s hand or any other object. This can lead to severe injury to your body or damage on the product.

  • Page 9: Grounding Instruction

    M990T SERIES If you feel pain, dizziness, shortness of breath or abnormal symptoms during the exercise, Stop the exercise immediately and consult with a physician. Please refrain from unnecessary action during the exercise. Unnecessary actions like mobile phone conversation, talking with other the person, taking beverage and etc. can cause unexpected accident.
  • Page 10 M990T SERIES M990T series treadmill is distinct product line from Motus in its unique design and reliable functions as advanced commercial treadmill. Low Noise and Vibration Through long-time manufacturing experience and know-how, up-to-date structure analysis and repeated tests, low noise is achieved and vibration is minimized in wide speed range from low speed to high speed.

  • Page 11: Heart Rate Course

    The workout programs based on heart rate monitoring are the optimal way to exercise safely and efficiently within user’s fitness capability. M990T series is equipped with built-in contact heart rate system and optional telemetry heart rate system, which measures user’s heart rate exactly and then adjust the workout intensity according to target heart rate.
  • Page 12 M990T SERIES Display Console Accessory Tray Accessory Tray Emergency Key & Button Audio Jack Side Handlebars Upright Front Handlebar Handle Posts (Contact H/R) Motor Hood Running Belt Side Platforms Adjustable Rear Feets End Caps MOTUS...
  • Page 13 (FND : Flexible Numeric Display) Program Selection Key Speed/Incline Conversion Key Window Scan Key One Touch Control Key (Numeric Key) [ M990T/ M995T ] LCD Screen Program Selection Key Channel / Volume Adjust Key Program Profile Window (Smart Graphic Display) TV on/off...
  • Page 14 M990T SERIES MOTUS...

  • Page 15: Quick Start

    M990T SERIES Picture(symbols) Description Check to ensure that the emergency key is in the right place If emergency button is pressed, release it by turning it toward arrow direction Plug in Turn on the main power switch front-bottom of treadmill Start exercise after selecting program - Do not press START/STOP button while treadmill is already in the middle of STOP.
  • Page 16 M990T SERIES How to use quick start Touch Start / Stop button then treadmill starts to run. Treadmill starts after sign on the screen. - Treadmill starts at 1km/h of Speed and 0% of Incline. Select a desired speed by using SPEED button.
  • Page 17 M990T SERIES How to measure H/R with contact heart rate sensor 1. During exercise or treadmill stops, grasp contact heart rate sensor on the front handgrip with both hands. Grasp the center of right and left heart rate sensor at the same time.
  • Page 18 To improve entire stamina of user's and to exercise for marathon course. To manage user s weight adequately. - M990T, M990TL : All of 10 workouts are built-in. - M995T, M995TL : 5 workouts are built-in. (Rhythmic I, Rhythmic II, Rhythmic III, Dynamic I, Dynamic II )
  • Page 19 M990T SERIES 1. Select preprogrammed workout If you press PROGRAM button, the message “SELECT WORKOUT / + ENTER” scrolls out on the screen. 2. Select workout program Touch ‘ENTER/PAUSE’ key after selecting one program with SPEED / ’ and or numeric key.
  • Page 20 M990T SERIES This function allows you to select exercise with the workout patterns you want according to your fitness ability. You can edit the speed and incline for each 5~10 programs. 1. Select Custom Mode If you press ‘CUSTOM’ button, the message “SELECT WORKOUT / + ENTER”...
  • Page 21 M990T SERIES How to use Cardiovascular workout Calculate maximum heart rate and target heart rate Maximum heart rate (MHR) = 220 – AGE (YR), Target heart rate (THR) = MHR 0 .8 - Contact H/R sensor is less accurate than wireless polar heart rate sensor. For H/R Note exercise, it is recommended to use wireless polar heart rate sensor.
  • Page 22 M990T SERIES 6. Set up Target Heart Rate After the message “SET HEARTRATE / + ENTER”, heart rate value 148 will be displayed on the screen as a recommended THR for 35 years old user. If you want to change the recommended THR, touch ‘ENTER/PAUSE’...
  • Page 23 M990T SERIES How to use Fat Burn workout Calculate maximum heart rate and target heart rate Maximum heart rate (MHR) = 220 – AGE (YR), Target heart rate (THR) = MHR 0 .65 - Contact H/R sensor is less accurate than wireless polar heart rate sensor. For H/R Note exercise, it is recommended to use wireless polar heart rate sensor.
  • Page 24 M990T SERIES 6. Set up Target Heart Rate After the message “SET HEARTRATE / + ENTER”, heart rate value 148 will be displayed on the screen as a recommended THR for 35 years old user. If you want to change the recommended THR, touch ‘ENTER/PAUSE’...
  • Page 25 M990T SERIES Goal-oriented mode has 3 kinds of program, DISTANCE, CALORIES, and TIME. You can choose and exercise one of them. Each exercise ends automatically once each goal (DISTANCE, CALORIES, and TIME) is met. (A) Distance Goal Exercise 1. Select Goal oriented Mode When you press MANUAL button, the message “SELECT WORKOUT /...
  • Page 26 M990T SERIES 6. Set up Incline After the message “SET INCLINE / + ENTER” is displayed on the screen, the message “IN00” comes out to indicate default incline is 0%. Touch ‘ENTER/PAUSE’ button after setting up the incline with ‘SPEED / ’...
  • Page 27 M990T SERIES 4. Set up Weight After the message “SET WEIGHT / + ENTER” is displayed on the screen, the message “WT60” comes out to indicate default user weight is 60kg. Touch ‘ENTER/PAUSE’ button after setting up user’s weight with ‘SPEED / ’...
  • Page 28 M990T SERIES (C) Time Goal Exercise 1. Select Goal oriented Mode When you press MANUAL button, the message “SLECT WORKOUT / + ENTER” is displayed on the screen. 2. Select Time Goal Course Touch ‘ENTER/PAUSE’ button after selecting “TIME’’ of goal oriented programs with ‘SPEED / ’...
  • Page 29 M990T SERIES 6. Set up Incline When the message “SET INCLINE / + ENTER” is displayed on the screen, the message “IN00” comes out to indicate default incline is 0%. Touch ‘ENTER/PAUSE’ button after setting up incline with ‘SPEED / ’ or numeric key. If you don’t press ‘ENTER/PAUSE’ but ‘START/STOP’...

  • Page 30: Custom Program

    M990T SERIES 1. Quick Start ‘START/STOP’ ‘SPEED ‘ / ’ ‘INCLINE / ’ ‘START/STOP’ (If the final speed is over 8km/h, exercise ends after Cool Down) 2. Preprogrammed Mode ‘PROGRAM’ Select program profile ‘ENTER/PAUSE’ Set up time ‘ENTER/PAUSE’ Set up weight ‘ENTER/PAUSE’...

  • Page 31: Manager Mode

    M990T SERIES Manager mode helps club manager to manage the treadmill more conveniently. Description Item Default Value WORKOUT DURATION 30 [Min] Set up maximum exercise time from 10 to 99 minutes M990T 21 [km/h] Set up maximnum speed from 8 to 21km/h...
  • Page 32 To enjoy music from your personal MP3 player, please follow directions below. 1) Connect output signal from MP3 player to upper jack of the left down on display console. 2) Connect head phone Motus provided to lower jack to the left down on display console. MOTUS...

  • Page 33: Protective Function

    M990T SERIES The proper use and safety of the treadmill can be maintained only if it is examined regularly for damage or wear. You as club manager or owner are responsible for maintenance tasks. Stop using the treadmill until defective parts are repaired or replaced.

  • Page 34: Belt Alignment

    M990T SERIES Corrective Action Malfunction Probable cause (Condition) No power Check if power exists at wall outlet and at (No display treadmill, respectively. Check if line cord is Power connection. on Console) damaged. 3-pin connector is loose on power board or...
  • Page 35 Trouble in internal EEPROM due to external noise or high temperature. A EEPROM lot of parameters are saved in the EEPROM. Contact with MOTUS. Tripped out Failure caused intentionally by input terminal. It is not implemented in the from external treadmill.
  • Page 36 M990T SERIES 1. Check if the running surface of treadmill is even with the ground. A BUBBLE LEVEL can be used as shown in the figure. - It may be impossible to adjust incase of bumpy ground condition 2. How to use Adjustable rear foot Loosen the nut on the top of adjustable rear foot by turning it clockwise.
  • Page 37 Do not exceed one full turn of the adjusting Right End Cap bolts in either direction. If the belt does not appear properly centered after on full turn, contact Motus local dealer. Roller M990T SERIES...
  • Page 38 OFF the treadmill. 4. Use the lubricant provided by Motus only. 1. Fill the lubricator with the oil Motus provided. 2. The conduction hole for the lubrication is at the right corner on the front of the treadmill as shown in the picture.
  • Page 39 1) Turn OFF the treadmill and detach motor hood. 2) Open the cap of oil tank by turning it with hand. 3) Fill the empty tank fully with the oil provided by Motus. If oil is not filled full, automatic lubrication system doesn’t work properly.
  • Page 40 M990T SERIES 4) Put 10mm wrench into the hole of the Right End Cap as below. 5) Turn the wrench 1/4 turn clockwise. 6) Put 10mm wrench into the hole of the Left End Cap as below. 7) Turn the wrench 1/4 turn clockwise.

  • Page 41: Specification

    M990T SERIES Specifications can be changed without notice for product improvement or quality. M990T SERIES...

  • Page 42: Customer Service

    M990T SERIES Customer Service At your request for service, your dealer shall provide the service.. The gratuitous period of warranty shall be 2 years. Since this period shall be calculated from the date that you purchase the product, you shall have the date written on your guarantee.
  • Page 43 MOTUS 990T SERIES M990TL/M995TL M990T/ M995T Authorized Partner Suite 401, Ilsan TechnoTown-A, 1141-1 Baekseok-dong, Ilsan-gu, Goyang-si, Gyeonggi-do, Korea. Tel) +82-31-905-3300 / Fax) +82-031-908-6588 www.motus.co.kr...
