26"- 46" HD Widescreen Commercial LCD TV
USER'S MANUAL
Your LCD TV may look slightly different from the one pictured above.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20070918 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Polaroid 20070918

Summary of Contents for Polaroid 20070918

  • Page 1 26”- 46” HD Widescreen Commercial LCD TV USER’S MANUAL Your LCD TV may look slightly different from the one pictured above.

  • Page 2: Table Of Contents

    Table of Contents Important Safety Instructions ... 2 Accessory List ... 4 Disc Information ... 5 View of Unit ... 6 Remote Control... 9 System Connections ... 14 Connecting an External AV Signal Source (AV1)... 14 Connecting an External AV Signal Source (AV2)... 15 Connecting an External AV Signal Source (AV3 /AV4) ...

  • Page 3: Important Safety Instructions

    Important Safety Instructions The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrocution.
  • Page 4 Important Safety Instructions 1) Read and follow all directions. 2) Keep these instructions. 3) Heed all warnings. 4) Do not use near water. 5) Clean only with dry cloth. 6) Do block openings. Maintain well ventilated conditions around the product, Do not put product on bed, sofa or anything that blocks ventilation.

  • Page 5: Accessory List

    Accessory List ITEM Note: Accessories and their numbers are subject to modification without prior notice. NAME Remote Control (optional) Batteries for Remote Control (optional) Power Supply Cord (Cannot be removed from TVs 19” or smaller) Operation Manual...

  • Page 6: Disc Information

    Disc Information (for systems equipped with DVD Players) Discs Supported DISC LOGO JPEG The software maker specifies the operating method of some DVD discs. Please refer to the instruction manual of the disc. The unit will play most recordable (CD-R) or erasable (CD-RW) CDs, but playback of CD-R or CD-RW discs created on a computer requires proper formatting and finalization of the disc for audio playback.

  • Page 7: View Of Unit

    View of Unit Front and Right Side Panel (including optional DVD player) 1. Color TFT screen 2. INPUT button Press repeatedly to toggle between input sources: (Composite1), (Composite 2), AV3 (Component1), AV4 (Component2), VGA , HDMI or DVD mode. 3. MENU button Press to enter or exit system setup menu.
  • Page 8 View of Unit Rear Panel Open the back cover on the right side of the unit’s rear panel and all the jacks will appear, as shown on the figure below: 1. Y/Pr(Cr)/Pb(Cb) (Component) and L/R audio Input Jacks Connect Y/Pr(Cr)/Pb(Cb) source in AV3 (Component) mode.
  • Page 9 View of Unit Rear Panel Open the back cover on the right side of the unit’s rear panel and all the jacks will appear, as shown on the figure below: 13. RS232/SERVICE Jack (Hospitality VOD Use) 14. HDMI Jack Connect HDMI input source. 15.

  • Page 10: Remote Control

    Remote Control For TV Operation 1. POWER button Press to enter or exit standby mode. 2. 0~9 Number buttons Press to select numbers. 3. MTS button Press repeatedly to select SAP, Mono or Stereo mode in TV mode. 4. VOL +/- button Press to increase or decrease the volume.
  • Page 11 Remote Control For TV Operation button Press number buttons to select channel then press immediately to the selected channel. 13. +10/- button Used for selection of high-numbered (100+) channels while in TV mode. 14. Last button Press to return to the previously viewed channel in TV mode.
  • Page 12 Remote Control (Continued) For DVD Operation (for models so equipped) Play button Press to play the disc in DVD mode. Pause button During disc playback, press to pause playback or start step frame-by-frame playback. PLAY button to resume normal playback. button Press to activate fast backward playback function during disc playback.
  • Page 13 Remote Control For DVD Operation (for models so equipped) Eject button Press to eject the disc. 13. ■ Stop button In DVD mode, press to stop playback. Press the PLAY button to resume normal playback; press twice repeatedly to stop playback completely.

  • Page 14: Using Remote Control

    Remote Control Preparation Softly push the back cover to open the battery compartment. Insert two batteries (1.5V, size AAA), ensuring the polarity matches the marks inside the compartment. Softly press the back cover to close it. Remove batteries when the remote is not in use for a long time.

  • Page 15: System Connections

    System Connections • Do not connect the power cord until all other connections have been made. • Ensure that you observe and correctly connect colored cables when connecting audio and video cables. • Before connecting, open the cover on the right side of the unit’s rear panel. •...

  • Page 16: Connecting An External Av Signal Source (Av2)

    System Connections Connecting an External AV Signal Source (AV2) Use audio cables to connect an external signal source to the AV2 (Composite 2) audio input jacks on the jack panel of the unit. Use either composite video or S-Video cables for the video connection to the input jack on the jack panel of the unit.

  • Page 17: Connecting An External Av Signal Source (Av3 /Av4)

    System Connections Connecting External an AV Signal Source（AV3/AV4） Use AV cables to connect an external AV signal source to the Y/Pb (Cb) /Pr (Cr) (Component) input jacks on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source and press the Input button to select AV3 (Component) or AV4 (Component) mode.

  • Page 18: Connecting An Hdmi Signal Source

    System Connections Connecting an HDMI Signal Source Follow the figure below to connect an HDMI signal source to the HDMI jack on the rear panel of the unit. After connection, turn on the power to the television and the external HDMI device and use the Input button to select HDMI mode.

  • Page 19: Connecting An External Av Device (Av Output)

    System Connections Connecting a Digital Amplifier This unit is designed with an optical digital audio jack, can be connected to the digital amplifier, see the figure below:...

  • Page 20: Connecting A Pc

    System Connections Connecting a PC Follow the steps and figure below to connect PC to the unit. 1. Connect one end of the VGA cable to the VGA input jack on the jack panel of the unit and the other end to the PC VGA output. 2.

  • Page 21: Connecting A Tv Signal Source

    System Connections Connecting a TV Signal Source Connect a TV signal source (antenna or analog cable) to the RF (TV) jack on the jack panel of the unit. After connection, turn on the power of the unit and use the Input button to select TV mode. Connecting the Power Supply Connect one end of power supply cord to the power jack on the jack panel of the unit and the other end to the wall AC outlet.

  • Page 22: Connecting Earphones

    System Connections Connecting Earphones Connect earphones to the earphone jack on the jack panel of the unit for listening. When earphones are connected, the television will automatically mute internal speaker output. Note: Excessively loud volume could damage your hearing. Please turn down the television volume before connecting earphones, and then raise the volume to a comfortable level.

  • Page 23: Input Source Selection

    Input Source Selection The unit incorporates multiple video modes which can be selected via the Input button on the television or remote. Press the Input button to enter Input menu. The screen will display as shown below: On the input menu, press the button to select the desired video mode and press the Enter button.

  • Page 24: System Setup

    System Setup Preparation 1. After connection, press the POWER button to turn on the unit. 2. Use the Input button to select TV mode and follow the procedures below. Setup Settings Press the Menu button to enter the main setup menu as shown right. On the menu, press the ▲▼...
  • Page 25 System Setup Manual Ch Search Press the ▲▼ button to select the Manual Channel Search and press the Enter button to enter the menu as shown: On the menu, press the items and press the Enter button to confirm or set; press the Menu button again to return to the previous menu.
  • Page 26 System Setup Brightness Press the ▲▼ button to select Brightness and press the Enter button to enter the menu as shown. Within the menu, press the ◄ ► button to adjust the value and press the Enter button to store setup and return to the previous menu.

  • Page 27: Audio Settings

    System Setup Audio Settings Press the Menu button to enter the main setup menu. Press the ▲▼ button to select Audio and press the ◄ ► button to enter the menu as shown. Within this menu, press the ▲▼ button to select items; press the ◄ ►...
  • Page 28 System Setup Feature Settings Press the Menu button to enter the main setup menu. Press the ▲▼ button to select Feature and press the ◄ ► button to enter the menu, as shown. Within this menu, press the ▲▼ button to select items; press the ◄ ► button to return to the previous menu.
  • Page 29 System Setup Advanced Video Menu Press the ▲▼ button to select Advanced Video Menu and press the Enter button to enter the menu as shown. Within the menu, press the and press the Enter button to save; press the Menu button to return to the previous menu.
  • Page 30 System Setup Blockable content includes Fantasy violence [FV], adult language [L], sexual situations [S], violent scenes [V] and suggestive dialogues [D] On the menu, press the button to save. Press the Menu button to return to the previous menu. Closed Caption Mode Press the ▲▼...

  • Page 31: Special Features Of The Dvd Module

    Special Features of the DVD Module Your TV may have come equipped with an optional removable DVD player. The television is designed to allow simultaneous use of two different modules; the DVD player can be installed in three different positions. Please follow the procedures below to remove or install the DVD module. Notes: 1.

  • Page 32: Dvd Playback Operation

    DVD Playback Operation Preparation 1. Install the DVD module into the TV as detailed above. 2. Connect the module to the power supply and press the POWER button to turn on the unit. 3. Use the Input button on the TV or remote to select DVD mode. 4.
  • Page 33 DVD Playback Operation (Continued) Pause During playback, press the Pause button once to pause the playback; press it repeatedly to start step-by-step playback and press the Play button to resume normal playback. Previous and Next During playback, press the button to go to the next chapter. Press the button once to return to the beginning of the current chapter;...
  • Page 34 DVD Playback Operation (Continued) Various Camera Angles The movies on some discs have been recorded from various camera positions, which allow scene viewing from different perspectives. When playing a disc containing various camera angles, the camera symbol appears on the screen. Press the Angle button repeatedly until the desired perspective is shown.

  • Page 35: Jpeg Playback

    DVD Playback Operation (Continued) JPEG Playback JPEG is a common format for pictures and digital photographs. The DVD module is capable of displaying JPEG images stored on a DVD or CD disc. Play After loading a JPEG disc, a root menu appears on the screen. Use the Enter button and the direction button to select a submenu, and then use the ▲▼...

  • Page 36: Usb And Sd/Ms/Mmc Card Function

    USB and SD/MS/MMC Card Function Preparation In DVD mode, connect an external USB device to the USB port or insert a SD/MS/MMC card into the SD/MS/MMC card slot on the right side of the optional DVD module. Note Make sure that files are stored on the USB device or the SD/MS/MMC card before connection. File Playback 1.

  • Page 37: Dvd System Setup

    DVD System Setup Preparation 1. In DVD mode, press the Setup button to open DVD setup menu. 2. Press the button to select the Setup menu 3. Press the Setup button again to exit the DVD setup menu. General Setup Page Press the Setup button to enter the General Setup Page, as shown: TV Display Angle Mark...
  • Page 38 DVD System Setup OSD Lang Screen Saver Last Memory Media Center 1. Press the button to select OSD Language. 2. Press the Enter button to enter the setup. 3. Use the button to select the desired language. 4. Press the Enter button again to confirm selection and return to the previous menu.

  • Page 39: Audio Setup Page

    DVD System Setup Audio Setup Page Press the Setup button to enter the General Setup Page and then press the Audio Setup Page, as shown below: Dolby Digital Setup On Audio Setup Page, press the button to enter the setup, as shown: Dual Mono 1.
  • Page 40 DVD System Setup Dynamic HDCD Setup On Audio Setup Page, press the enter the setup, as shown below: Video Setup Press the Setup button to enter the General Setup Page and then press the Video Setup Page, as shown: 1. Press the button to select Dynamic.

  • Page 41: Video Quality Setup

    DVD System Setup HD Mode On Video Setup Page, press the the setup, as shown: Video Quality Setup On Video Setup Page, press the the setup, as shown: Sharpness button to select HD Mode and press the Enter button to enter 1.

  • Page 42: Preference Setup

    DVD System Setup Brightness Contrast Preference Setup Press the Setup button to enter the General Setup Page and then press the Preference Page, as shown: Audio 1. Press the button to select Brightness. 2. Press the Enter button to enter the setup. 3.
  • Page 43 DVD System Setup Subtitle Disc Menu Default 1. Press the button to select Subtitle. 2. Press the Enter button to enter the setup. 3. Press the button to select subtitle language. 4. Press the Enter button again to confirm selection and return to the previous menu.

  • Page 44: Use Of The Wall Mount

    Use of the Wall Mount Your TV may have come equipped with an optional wall mount, which can be attached to the TV through use of the mounting holes on the back of the system. We recommend removing the TV stand prior to wall mounting the TV.

  • Page 45: Troubleshooting

    Many simple problems can quickly be solved using the procedures below. Please follow the procedures below prior to contacting Polaroid customer service. If you suspect something wrong with this unit, immediately turn the power off and disconnect the power connector from the unit.

  • Page 46: Specifications

    Specifications Model 26” TFT-LCD Resolution 1366x768 TFT-LCD Screen Size 26 inches Laser Wavelength 780/650 nm Video System NTSC 20Hz Frequency Response ±2.5dB Audio Signal-to-noise ≤－70dB (1kHz) Rate ≥70dB (1kHz) Audio distortion+noise ≥80dB (1kHz) Channel Separation ≥80dB (1kHz) Dynamic Range Out Level: Analog Audio Audio Out 1.5V±...

  • Page 47: Warranty

    Warranty Warranty and service terms for your account are detailed in your Master Purchase Agreement. For warranty or service-related issues or concerns, please contact Polaroid at http://www.polaroid.com/service or by phone at 1-888-779-6779.
