Page 1
™ Manual LCD Television Questions? Need some help? This manual should help you understand your new product. If you have questions, call our helpline number found on the insert with this icon: Or visit www.polaroid.com.
TABLE OF CONTENTS • Warnings and Precautions ............1 • Introduction to Your LCD TV ................ Cleaning Your LCD TV ....................3 Your LCD TV’s Digital Tuner ..................3 Package Contents ......................4 Key Features ........................5 • Setting Up Your LCD TV .............7 How to Remove the TV Stand ..................
WARNINGS AND PRECAUTIONS To prevent any injuries, use the following safety precautions during the installation, use, and maintenance of this equipment. This equipment must not be disassembled by anyone other than a qualifi ed service professional. Defi nition of Symbols: WARNING CAUTION Avoid risk of...
As a consumer, you are responsible for ensuring that this product is disposed of properly. To fi nd out how to properly dispose of this product, please go to www.polaroid.com and click on “Company“ or call the customer service number for your country listed in the instruction manual.
These items are all you need to set up and operate your LCD TV in its basic confi guration. *Note: The Power Cord may differ depending on country. Make sure all of the above materials are included in the box. If you are missing any items, please contact the Polaroid customer service department using the Polaroid Contact insert.
HD-Ready Liquid Crystal Display (LCD) ▪ Offers amazing picture quality when connected to an HD source or digital signal. Polaroid Defi nia™ Video Processor with Digital Noise Reduction ▪ Increases sharpness and reduces imperfections for a pure, true-to-life picture. 3D Comb Filter with Motion Adaptation ▪...
Page 8
▪ Allows you to conserve energy when the TV is not in use. Multilingual On-Screen Display, Remote Control & Sleep Timer ▪ Features provide the convenience and functionality that you need. Questions about your TV’s features? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Setting Up Your LCD TV How to Remove the TV Stand from Your LCD TV If you prefer to mount your new Polaroid TV on a wall, please reference the instructions included in the wall- mounting kit (sold separately). To mount your TV, verify what size VESA standard wall-mounting kit should be used by looking at the Specifi...
(not included) to mount your television. To reattach the speakers, follow these instructions in reverse. Need help setting up your TV? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Connect any other audio/video equipment to your LCD TV, using the instructions in the section entitled “Connecting Your LCD TV” in this User’s Manual. Questions about your remote control? Call our helpline customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
The Energy Effi cient AC Power Switch allows you to conserve energy when the TV is not in use. Questions about your TV’s features? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Understanding Your LCD TV Back View of TV HDMI 1 & HDMI 2 Inputs Connect HD digital AV equipment with the HDMI connector. HDMI AC Power supports enhanced, high-defi nition Switch video and two-channel digital audio. D-SUB (VGA) Input AC Power Connect to a Personal Cord Input Computer, or other AV...
Understanding Your LCD TV Your Remote Control Put the LCD TV in or out of Standby Mode TELETEXT Press the button to show the TELETEXT Service Toggle between TEXT / MIX / PAT / OFF INDEX ATV (Analogue): Go to page100 (TELETEXT reset) DTV (Digital): Display info when banner is on HOLD...
Page 15
Understanding Your LCD TV Your Remote Control (Continued) ARC (Aspect Ratio Control) In Video mode, toggle picture mode between Auto Image / Panoramic / 16:9 / 14:9 / 4:3 / Zoom In VGA (PC) mode, toggle picture mode between 16:9 / 4:3 In OSD menu, setup a function or enter a sub-menu ◄...
ANT IN: Antenna (Aerial) In NOTE: Not all cables are included. Questions about your connections or cables? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
• No audio cable is needed with an HDMI connection. • Either HDMI 1 or HDMI 2 can be used. Questions about your connections or cables? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
PC AUDIO IN jack on the TV and AUDIO OUT jack on a PC. NOTES: • VGA and PC-Audio cables are not included. Questions about your connections or cables? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
TV will turn red. AC Power Switch Power Cord (Power cord will vary depending on country) Questions about your connections or cables? Call our toll-free customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Using Your LCD TV Turning your TV ON and OFF TURN ON Once all of your connections have been made and the AC Power Switch is ON, press the button on the side of the TV or on the remote control to turn on the TV. The indicator light will turn blue. BLUE TURN OFF When the TV is on and the AC Power Switch is turned on, press the...
Using Your LCD TV How To Operate Your TV for the First Time Once all of your connections have been made and the AC Power Switch has been turned on, press button on the side of the TV or on the remote control to turn on the TV. The indicator light will turn blue.
Using Your LCD TV How to Operate the Main Menu With the AC Power Switch turned, press the button to turn on the LCD TV. Press the MENU button on the remote control or on the side of the TV to display the on-screen Main Menu. Use the ◄►...
Using Your LCD TV How to Customise the Picture Settings With the power ON, in any mode, press the SOURCE button to choose desired source. Press MENU. Use the ◄► buttons to select VIDEO and press ▼ button. Use the ▲▼ buttons to highlight your desired VIDEO option. Press OK to enter the Sub-Menu. Use the ◄►...
Using Your LCD TV How to Customise the Sound Settings With the power ON, in any mode, press the SOURCE button to choose desired source. Press MENU. Use the ◄► buttons to select AUDIO and press ▼ button. Use the ▲▼ buttons to highlight your desired AUDIO option. Press OK to enter the Sub-Menu. Use the ◄►...
Using Your LCD TV How To Customise ARC - Aspect Ratio Control Press the ARC button to change to a different picture format on the screen. When connected to certain sources, some modes maybe unavailable. AUTO IMAGE In this mode, the TV can automatically select the best aspect ratio for the broadcast.
Using Your LCD TV How To Use Picture-in-Picture (PIP) Functions Use these buttons on the remote control to use the PIP functions. ON/OFF Select a mode of the PIP mode. Press repeatedly to turn PIP ON or OFF. POSITION Move the sub-picture from corner to corner on the TV screen. Press repeatedly to change the POSITION. SIZE Select a size of the sub-picture: Small--Middle--Large.
Using Your LCD TV How to Setup Analogue TV (ATV) With the power turned on, press the TV button to select ATV mode and enter Analogue TV mode. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄ or ► buttons to select Channel Options and press ▼.
Using Your LCD TV How to Manage Your Analogue Channels: Rename, Sort, Delete With the power turned on, in ATV Analogue TV mode, press TV button to select ATV mode. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select “Channel Options”...
Using Your LCD TV How to Setup Digital TV (DTV) With the power turned on, press TV button to select DTV mode. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select “Channel Options”...
Only one channel may be recorded at a time. Have questions about your TV’s menus? Call our helpline customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Using Your LCD TV How to Perform Channel Scan in Digital TV (DTV) Mode With the power turned on, press TV button to select DTV mode. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select Channel Options and press ▼.
Using Your LCD TV How to Setup Additional DTV Features With the power turned on, in DTV mode, press SOURCE button to choose desired source. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select Channel Options and press ▼.
Using Your LCD TV How to Setup “New Channel Alert” in DTV Mode With the power turned on, in DTV mode, press SOURCE button to choose desired source. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select Channel Options and press ▼.
Using Your LCD TV How to Use the DTV Information Banner With the power turned on, in DTV mode, press SOURCE button to choose desired source. Use the CH ▲▼/ OK/ or ▲▼ buttons to display the banner. Once the banner appears on the screen, the following options will be available: •...
Using Your LCD TV How to Use the EPG (Electronic Programme Guide) in DTV Mode EPG (Electronic Programme Guide) is only available with Digital TV. Users can research and view a list of current and future broadcast television programmes. With the power turned on, in DTV mode, press TV button to select DTV source. Press the GUIDE button on the remote control to display the EPG.
Using Your LCD TV How to Manage Your Preferred Digital (DTV) Channels After completing Channel Scan, follow the steps below to use the DTV Guide: Press GUIDE on the remote control once to enter the EPG DTV Guide (see picture 1 below). Press again to setup your preferred channels in DTV mode (see picture 2 below).
Using Your LCD TV How to Set Your Preferences in DTV Mode With the power turned on, in DTV mode, press SOURCE button to choose desired source. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select Preferences and press ▼.
Using Your LCD TV How to Use Child Lock With the power turned on, press SOURCE button to choose desired source. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄ or ► button to select Preferences and press ▼.
Using Your LCD TV How to Use the Timer Features Sleep Timer Feature With the power turned on, press the SLEEP button on your remote control. Select a time to automatically turn off your TV. Timer can be set 00 to 120 minutes in 10 minute intervals. On Timer Feature With the power turned on, in DTV mode, press SOURCE button to choose desired source.
Using Your LCD TV How to Use PC and SCART Connectivity Menu With the power turned on, press PC/HD button to select VGA mode. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select Connectivity and press ▼.
Using Your LCD TV How to View Your TV’s Information and Reset Your Settings Information: With the power turned on, in any mode, press SOURCE button to select desired source. Press the MENU button on the remote control to display the on-screen Main Menu. Use the ◄► buttons to select Information.
Using Your LCD TV How to Use the TELETEXT Functions TELETEXT is an information service broadcast offered by some TV stations (depending on the country) which gives up- to-the-minute information, news, weather, television programs, share prices, subtitles, and so on. This TV has 100 Teletext page number memories.
Page 43
Using Your LCD TV How to Use the TELETEXT Functions TELETEXT Remote Control Functions: Press the INDEX button on the remote control to display the Index Page and the list of INDEX TELETEXT contents. Press the REVEAL button once to display concealed information, such as solutions to riddles, puzzles, or a quiz.
AC 100~240V, 50/60HZ Power Consumption <190W Dimensions & Weight 722.5 x 947 x 240mm, (HxWxD) 25kg VESA wall-mount size 200 x 100 “Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation. For service, support and warranty information, visit www.polaroid.com.
Page 45
<310W Dimensions & Weight 816 x 1067 x 270mm, (HxWxD) 36.1kg VESA wall-mount size 638 x 310 Have questions about your TV’s specifi cations? Call our helpline customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Picture is not clear. ▪ The source signal may be weak. ▪ The provider may be experiencing diffi culties. ▪ Check input connections. Need help troubleshooting? Call our helpline customer service number. Look for the insert with this icon: Or visit www.polaroid.com.
Page 47
Troubleshooting (Continued) Picture is light or improperly tinted. ▪ Check the Hue, Saturation and Colour adjustments. ▪ Reset the TV to the factory default settings. The picture is too dark. ▪ Select a different APC mode. ▪ Check the Brightness of Picture Settings. ▪...
Page 48
Troubleshooting (Continued) The picture is not sharp. ▪ The signal source may be weak. ▪ The provider may be experiencing diffi culties. ▪ Check input connections. ▪ Check the Sharpness of Picture Settings. The picture moves. ▪ The source signal may be weak. ▪...
Page 49
Questions? Need some help? Call our helpline number found on the insert with this icon: Or visit www.polaroid.com. 20071024...
