Nordic ID MERLIN Quick Manual page 7

NORDIC ID MERLIN CHARGERS
DESKTOP/VEHICLE CHARGER AND ITS SWIVEL FASTNER
Included items:
- Charger body
- Swivel with assembly plate
- Power supply
The charger has a slot for handheld
charging with locking mechanism, USB
connector, power connector for power
supply, and place for fixed mounting
power supply.
Swivel is used for supporting the charger
in desktop use and in installing the
charger to wall, car etc. Swivel bottom
1.
plate can be used in fixed installations.
Swivel position can be adjusted by
loosening joint screw and installing it in
different position against back of the
charger body.
PARTS
1. Charging connectors
2. USB cable
3. Power cable
4. Connector screw
2.
3.
VEHICLE
CHARGER SET
2.
1.
4.
