Elephant M40D Installation Manual page 11

• Any part of an electric animal fence that is installed along a public road or pathway shall
be identified by electric fence warning signs (4002555) at regular intervals that are securely
fastened to the fence posts or firmly clamped to the fence wires.
• The size of the warning sign shall be at least 100mm x 200mm.
• The background colour of both sides of the warning sign shall be yellow. The inscription on the
sign shall be black and shall be either:
- the substance of "CAUTION: Electric Animal Fence" or,
- the symbol shown:
• The inscription shall be indelible, inscribed on both sides of the warning sign and have a height
of at least 25mm.
• Ensure that all mains operated, ancillary equipment connected to the electric animal fence
circuit provides a degree of isolation between the fence circuit and the supply mains equivalent
to that provided by the energizer.
• Protection from the weather shall be provided for the ancillary equipment unless this equipment
is certified by the manufacturer as being suitable for use outdoors, and is of a type with a
minimum degree of protection IPX4.
This energizer complies with international safety regulations and is manufactured to international
standards.
Elephant reserves the right to make changes without notice to any product specification to
improve reliability, function or design. E & OE.
The author thanks the International Electrotechnical Commission (IEC) for permission to
reproduce Information from its International Publication 60335-2-76 ed.2.0 (2002). All such
extracts are copyright of IEC, Geneva, Switzerland. All rights reserved. Further information on
the IEC is available from www.iec.ch. IEC has no responsibility for the placement and context in
which the extracts and contents are reproduced by the author, nor is IEC in any way responsible
for the other content or accuracy therein.
Service of double-insulated appliances
In a double-insulated controller, two systems of insulation are provided instead of grounding.
No equipment grounding means is provided in the supply cord of a double-insulated
controller, nor should a means for equipment grounding be added to the controller. Servicing
a double-insulated controller requires extreme care and knowledge of the system, and
should be done only by qualified service personnel. Replacement parts of a double insulated
controller must be identical to the parts they replace. A double insulated controller is marked
with the words "DOUBLE INSULATION" or "DOUBLE INSULATED". The symbol for double
insulation may also be marked on the appliance.
