Skimmer Connection

1. Push universal adapter into the
suction line in the bottom of
the skimmer.
2. Insert flow regulator into the
universal adapter.
3. Feed any hose section without weights
through the skimmer opening and
attach it to the flow regulator.
Deep Skimmer
45 Elbow

For Australian Skimmer Connections Only

Vacuum plate is not included. Contact an authorized Polaris dealer for more information.
Standard Skimmer
45 Elbow
Vacuum
Plate

Connecting the Hose

1. Set aside the two hose sections with hose weights.
2. Assemble the remaining hose sections, pushing hose cuffs securely together.
3. Attach the two hose sections with weights.
4. Connect assembled hose to the hose section already attached to the pool.
Flow
Regulator
Universal
Adapter
Shallow Skimmer
90 Elbow
Deep Skimmer
Standard
Hose
Vacuum
Plate
www.polarispool.com
Hose
Suction
Line
On some skimmers it may be
necessary to install an elbow
connector to keep the hose from
kinking. For deep skimmers, install
the 45-degree elbow between the
flow regulator and the hose. For
shallow skimmers, use the
90-degree elbow.
Shallow Skimmer
90 Elbow
Vacuum
Plate
