E 5 2 8 P r o d u c t G u i d e
The "YY" numbers are the second and third digits and designate the option or combination of options. When
more than one option is selected, the "YY" option numbers are added, as in Examples B and C shown below.
YY Option #
00
01
02
03
04
08
16
32
Example A
100V-277VAC e with no options = Model e
4
Example B
100-277V e4 with H + PIR options = Model e4-812 [X = 5, YY = (04 {H} + 08 {PIR}) = 12]
Example C
OLD 24V e4 with IR5 + PIR options =
NOTE: This assembly would be 01-9560.310 and calls for a 03-9460 which uses old P supply and 9496.
For the RF capable thermostats, the complexity engendered by the multiplicity of power supplies, logic boards,
and communications and other option call for a larger OPN incorporating a more granular scheme (Figure 13,
below). Table 9 lists the options available for the RF E528:
Model
This character set defines the model name for the e528.
OP/N Code
e528 DDC Thermostat
Option
None No Options
IR3 02-9464.1 IR3 PCBA option
IR5 02-9467 IR5 PCBA option
IR3+ 02-9464.3 IR3+ PCBA option
H Humidity Sensor
PIR Passive IR Motion Sensor
DM Do-Not-Disturb & Make-Up-Room Buttons
P2 Flat PIR
-800 [X = 8, YY = 00]
4
Model e4-310
Figure 10 e528 3G OPN
Figure 11 RF Capable e528 OPN
Table 9. RF capablee528 Ordering Options
Description
Description
(with 2.2 FLA high fan relay)
[X = 3, YY = (02 {IR5} + 08 {PIR} = 10]
P a g e 1 4 o f 1 8
(with 3.6 FLA high fan relay)
Part Number
01-9911
