E 5 2 8 P r o d u c t G u i d e

Load Specifications

The following load specification table (Table 6) describes the submitted load characteristics for testing and UL
certification of UL 873. The device complies with the requirements of CAN/CSA C22.2 No. 24-93.
MODEL e528-A2L2-I0P0-
00WH
Voltage 24VAC
Heat 3 amps
Relay K4-5 125-277VAC
General purpose
Cool 3 amps
Relay K4-5 125-277VAC
General purpose
High Fan 3 amps
Relay K1 125-277VAC
General purpose
Medium Fan 3 amps
Relay K2-3 125-277VAC
General purpose
Low Fan 3 amps
Relay K2-3 125-277VAC
General purpose
Figure 8 Electrical Box Connections 24VAC
Table 6. Load Specifications
e528-A3L2-I0P0- e528-A1L2-
00WH I0P0-00WH
24VAC 24VAC
3 amps 240 VA PD
125-277VAC
General purpose
3 amps 240 VA PD
125-277VAC
General purpose
3 amps 2.2 FLA
125-277VAC 13.2 LRA
General purpose
3 amps 2.2 FLA
125-277VAC 13.2 LRA
General purpose
3 amps 2.2 FLA
125-277VAC 13.2 LRA
General purpose
P a g e 1 1 o f 1 8
e528-B0L2- e528-C0L2-
I0P0-00WH I0P0-
00WH
100-240VAC 220-
277VAC
240 VA PD 240 VA PD
240 VA PD 240 VA PD
3.6 FLA 3.6 FLA
21.6 LRA 21.6 LRA
2.2 FLA 2.2 FLA
13.2 LRA 13.2 LRA
2.2 FLA 2.2 FLA
13.2 LRA 13.2 LRA
e528-B1L2-I0P0-
00WH
100-277VAC
3 amps
125-277VAC
General purpose
3 amps
125-277VAC
General purpose
3.6 FLA
21.6 LRA
2.2 FLA
13.2 LRA
2.2 FLA
13.2 LRA
