- Page 1 User Manual UNO-IPS2730 Intelligent Power System for PCs...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
Class I, Division 2, Groups A, B, C and D indoor hazards. Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. -
Page 4: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. -
Page 5: Battery Information
Battery Information Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. UNO-IPS2730 User Manual... - Page 6 UNO-IPS2730 User Manual...
-
Page 7: Table Of Contents
Figure 2.3 Overview..............8 Figure 2.4 IO Connectors ............8 DIN-rail Installation..................9 Power cable & Control Cable Installation..........10 Chapter UNO-IPS2730 Adjustment Tool ..11 Notice of Use................... 12 3.1.1 Operating System Setting Environment........12 UI Introduction - Base ................12 3.2.1... - Page 8 UNO-IPS2730 User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information This chapter gives background information on the IPS. Sections include: Introduction Specifications Dimensions... -
Page 10: Introduction
This product is intended to be supplied by a Listed Power Adapter or DC power source, rated 18 - 36 VDC, 5.5-3.0A minimum and Tma 45 degree Celsius, if need further assistance with purchasing the power source please contact Advantech for further information. -
Page 11: Dimensions
Dimensions 216.8 215.8 203.8 191.8 53.1 55.6 164.80 154.80 125.40 107.90 90.40 UNO-IPS2730 User Manual... - Page 12 UNO-IPS2730 User Manual...
-
Page 13: Chapter 2 Installation
Chapter Installation Sections include: Introduction LED indication Battery safety protection control A quick tour DIN-Rail installation Power cable & control cable Installation... -
Page 14: Introduction
The UNO-IPS2730 module serves as temporary power during power spikes. When the power is off, the UNO-IPS2730 delays the shut down time to allow work to be finished. Once the delay shut down time has expired the UNO-IPS2730 sends a shutdown order to the PC. -
Page 15: Led Indication
BAT temperature ≥ 60° C, BAT & CHG LED blinking (0.5Hz), ≤ 55° C return normal state. Battery safety protection control a. Battery temperature ≥ 65° C, cut-off battery function. b. Battery capacity ≤ 5%, cut-off battery function. UNO-IPS2730 User Manual... -
Page 16: A Quick Tour
A Quick Tour Before setting up the UNO-IPS2730, take a moment to become familiar with the loca- tions and purposes of controls, connectors and ports, illustrated in the figures below. When placed upright on the desktop, UNO-IPS2730 look like this below. -
Page 17: Din-Rail Installation
DIN-rail Installation UNO-IPS2730 can be installed on a DIN-rail. Take the DIN-rail bracket and screws from the accessory bag and attach to UNO-IPS2730. UNO-IPS2730 User Manual... -
Page 18: Power Cable & Control Cable Installation
Power Cable & Control Cable Installation Connect the cables after installation of UNO-IPS2730. Below we use the example of an UNO-3382G as a loading machine. If customers use another PC as a loading machine, install cables according to the other machines connector pin definitions. -
Page 19: Chapter 3 Uno-Ips2730 Adjustment Tool
Chapter UNO-IPS2730 Adjustment Tool... -
Page 20: Notice Of Use
Notice of Use 3.1.1 Operating System Setting Environment UNO-IPS2730 Adjustment Tool supports Windows XP/7/8/8.1. For each operating system, a required .Net Framework installation will be necessary. Please refer to the following table for installation. .Net Framework requirement list: Operating System... -
Page 21: Select Com Port
Battery: Shows if UNO-IPS2730 battery is working normally or not. 3.2.4 Final Countdown for Shutdown The UNO-IPS2730 will shutdown / hibernate your PC after the timer counts down to zero. Note! The time can be adjusted between 5 to 360 seconds or maximum bat- tery supply time. -
Page 22: Auto Run
"Max" Time to PC Shut-down after Power Outage If users check on this option, the Final Countdown Time for Shutdown will be dynamic with the battery discharge state. UNO-IPS2730 will turn off your PC as soon as the battery reaches 15% or less of power capacity. - Page 23 UNO-IPS2730 User Manual...
- Page 24 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2016...
