Yamaha RX-V565 Service Manual

Yamaha RX-V565 Service Manual

Av receiver / av amplifier
Hide thumbs Also See for RX-V565:

Advertisement

This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known
and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service
departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and
specifi cations are subject to change without notice or obligation to retrofi t. Should any discrepancy appear to exist, please contact the
distributor's Service Division.
WARNING:
IMPORTANT:
■ CONTENTS
TO SERVICE PERSONNEL ............................................2
FRONT PANELS .........................................................3-4
REAR PANELS ...........................................................5-9
REMOTE CONTROL PANEL ..........................................9
SPECIFICATIONS / 参考仕様 ................................. 10-16
INTERNAL VIEW .......................................................... 17
UPDATING FIRMWARE /
ファームウェアの書き込み .....................................21-32
ダイアグ(自己診断機能) .......................................33-66
1 0 1 1 3 3
AV RECEIVER/AV AMPLIFIER
RX-V565/HTR-6250/
Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury,
destruction of expensive components, and failure of the product to perform as specifi ed. For these reasons, we advise
all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or
the appointed service representative.
The presentation or sale of this manual to any individual or fi rm does not constitute authorization, certifi cation or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
Copyright © 2009
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
AX-V565
SERVICE MANUAL
IMPORTANT NOTICE
DISPLAY DATA .......................................................67-68
IC DATA ...................................................................69-86
PIN CONNECTION DIAGRAMS .............................87-89
BLOCK DIAGRAMS ................................................90-93
PRINTED CIRCUIT BOARDS ................................94-111
SCHEMATIC DIAGRAMS ................................... 113-124
REPLACEMENT PARTS LIST ............................ 125-143
REMOTE CONTROL ........................................... 144-146
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
animate '09.03

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha RX-V565

  • Page 1: Table Of Contents

    This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    RX-V565/HTR-6250/AX-V565 ■ TO SERVICE PERSONNEL AC LEAKAGE 1. Critical Components Information WALL EQUIPMENT TESTER OR Components having special characteristics are marked OUTLET UNDER TEST EQUIVALENT must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only)
  • Page 3: Front Panels

    RX-V565/HTR-6250/AX-V565 ■ FRONT PANELS Top view U, C, R, T, K, A, B, G, E, F, L models J model Front view RX-V565 (U, C, R, K, A, B, G, E, F, L models) RX-V565 (T model)
  • Page 4 RX-V565/HTR-6250/AX-V565 HTR-6250 (U, C, K, F models) AX-V565 (J model)
  • Page 5: Rear Panels

    RX-V565/HTR-6250/AX-V565 ■ REAR PANELS RX-V565 (U model) RX-V565 (C model) RX-V565 (R model)
  • Page 6 RX-V565/HTR-6250/AX-V565 RX-V565 (T model) RX-V565 (K model) RX-V565 (A model)
  • Page 7 RX-V565/HTR-6250/AX-V565 RX-V565 (B, G, E, F models) RX-V565 (L model) HTR-6250 (U model)
  • Page 8 RX-V565/HTR-6250/AX-V565 HTR-6250 (C model) HTR-6250 (K model) HTR-6250 (F model)
  • Page 9: Remote Control Panel

    RX-V565/HTR-6250/AX-V565 AX-V565 (J model) ■ REMOTE CONTROL PANEL RAV293 (U, C, R, T, K, A, B, G, E, F, L, J models)
  • Page 10: Specifications / 参考仕様

    RX-V565/HTR-6250/AX-V565 ■ SPECIFICATIONS / 参考仕様 ■ Audio Section / オーディオ部 ■ Video Section / ビデオ部 Minimum RMS Output Power (Power Amp. Section) / Video Signal Type / ビデオ信号方式 定格出力(パワーアンプ部) Gray back / グレーバック (1 kHz, 0.9 % THD) U, C, R, K, J models .............. NTSC FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK L/R T, A, B, G, E, F, L models ............
  • Page 11 F ....Russian model K ..... Korean model L ....Singapore model A ....Australian model J ....Japanese model “x.v.Color” is a trademark of Sony Corporation. 「x.v.Color」は、ソニー株式会社の商標です。 “SILENT CINEMA” is a trademark of Yamaha Corporation. 「サイレントシネマ™ SILENT CINEMA ™」はヤマハ株式会社の登録商標で す。 AAC ロゴマーク はドルビーラボラトリーズの商標です。...
  • Page 12 RX-V565/HTR-6250/AX-V565 • DIMENSIONS / 寸法図 Top view Front view 395 (15-1/2") 435 (17-1/8") Unit: mm (inch) 単位 : mm(インチ) • SCENE TEMPLATE Name BD/DVD RADIO AV-1 AV-3 INPUT HDMI1 TUNER (Component / Optical) (Video / Coaxial) MUSIC ENHANCER Sound field mode...
  • Page 13 RX-V565/HTR-6250/AX-V565 • SOUND FIELD PARAMETERS Category Program MOVIE ● Standard ● ● ● ● ● ● ● ● ● ● ● Spectacle ● ● ● ● ● ● ● ● ● ● ● Sci-Fi ● ● ● ● ● ●...
  • Page 14 RX-V565/HTR-6250/AX-V565 • SET MENU TABLE / セットメニュー MAIN MENU SUB MENU PARAMETER VALUE [INITIAL VALUE] 1 • Speaker Setup 1 Auto Setup (YPAO) Extra SP Assign [Zone2] / Presence / None EQ Type [Natural] / Flat / Front Start [ENTER]: Start...
  • Page 15 RX-V565/HTR-6250/AX-V565 MAIN MENU SUB MENU PARAMETER VALUE [INITIAL VALUE] 3 Volume Adaptive DRC Auto / [Off] Max Volume -30.0 dB to +15.0 dB / [+16.5 dB], 5.0 dB step Init. Volume [Off] / Mute / -80.0 to +16.5 dB, 0.5 dB step...
  • Page 16 RX-V565/HTR-6250/AX-V565 MAIN MENU SUB MENU PARAMETER VALUE [INITIAL VALUE] DSP Level -6 to +3 dB, [0 dB] Init. Delay 1 to 99 ms P. Init. Dly S. Init. Dly 1 to 49 ms Room Size P. Room Size 0.1 to 2.0 S.
  • Page 17: Internal View

    RX-V565/HTR-6250/AX-V565 ■ INTERNAL VIEW VIDEO (2) P.C.B. VIDEO (3) P.C.B. MAIN (3) P.C.B. (R, L models) MAIN (2) P.C.B. VIDEO (1) P.C.B. DIGITAL P.C.B. VIDEO (8) P.C.B. (J model) AM/FM TUNER VIDEO (9) P.C.B. (B, G, E, F models) OPERATION (2) P.C.B.
  • Page 18: Disassembly Procedures / 分解手順

    RX-V565/HTR-6250/AX-V565 ■ DISASSEMBLY PROCEDURES / 分解手順 (Remove parts in the order as numbered.) (番号順に部品を取り外してください。 ) Disconnect the power cable from the AC outlet. AC 電源コンセントから、電源コードを抜いてください。 1. Removal of Top Cover 1. トップカバーの外し方 a. Remove 4 screws ( ① ) and 5 screws ( ② ). (Fig. 1) a.
  • Page 19 RX-V565/HTR-6250/AX-V565 3. Removal of DIGITAL P.C.B. 3. DIGITAL P.C.B. の外し方 a. Remove 2 screws ( ⑥ ) and 5 screws ( ⑦ ). (Fig. 2) a. ⑥ のネジ 2 本、⑦ のネジ 5 本を外します。 (Fig. 2) b. Remove screw ( ⑧ ). (Fig. 2) b.
  • Page 20 RX-V565/HTR-6250/AX-V565 When checking the P.C.B.s: P.C.B. をチェックする場合には: • Place the P.C.B.s (with rear panel) upright. (Fig. 3) ・ リアパネルと一緒に P.C.B. を立ち上げて置きます。 (Fig. 3) • Connect the ground points of the heat sink, rear pan- el and MAIN (1) P.C.B. (G1000) to the chassis with a ・...
  • Page 21: ファームウェアの書き込み

    RX-V565/HTR-6250/AX-V565 ■ UPDATING FIRMWARE / ファームウェアの書き込み Note) The user memories (sound field parameters, 注意) ファームウェアの書き込みを行っても、ユーザー system memory, tuner presetting, etc.) are kept メモリー(音場プログラムのパラメーターやシス stored even when you write the firmware. テムメモリー、チューナープリセット等)は保持 されます。 When replacing the following parts, be sure to write the 下記の部品をサービス部品に交換した場合、最新のファー...
  • Page 22 RX-V565/HTR-6250/AX-V565 Writing method using the CD CD を使用して書き込む方法 ● Required Tools ● 必要なツール • DVD or CD player (with DIGITAL OUTPUT (OPTICAL ・ DVD ま た は CD プ レ ー ヤ ー(DIGITAL OUTPUT or COAXIAL) jack) (OPTICAL または COAXIAL)端子付き)...
  • Page 23 RX-V565/HTR-6250/AX-V565 ● Connection ● 接続 Connect this unit and DVD/CD player as shown 本機と DVD/CD プレーヤーを下記のように接続しま below. (Fig. 1) す。 (Fig. 1) Example of OPTICAL jack / OPTICAL 端子使用例 This unit / 本機 DVD/CD player / DVD/CDプレーヤー Optical cable 光フ ァ イバーケーブル...
  • Page 24 RX-V565/HTR-6250/AX-V565 ● Operation Procedures ● 操作手順 1. While pressing the “STRAIGHT” key of this unit, 1. 本機の STRAIGHT キーを押しながら、本機の電 connect the power cable of this unit to the AC 源コードを AC コンセントに接続します。 (Fig. 2) outlet. (Fig. 2) FIRMWARE UPDATE モ ー ド が 起 動 し、 CDDA The FIRMWARE UPDATE mode is activated and Upgrader が表示されます。...
  • Page 25 RX-V565/HTR-6250/AX-V565 When the version of the firmware to be written ※ 本機に既存のファームウェアと、書き込もう is the same as the one existing in this unit, としているファームウェアのバージョンが同 “Same Version”, “Please...” and “Power off!!” じ場合、 Same Version 、 Please... 、 Power are displayed repeatedly. (Upgrading is not off!! の表示が繰り返されます。...
  • Page 26 RX-V565/HTR-6250/AX-V565 Writing method using PC (RS232C) PC(RS232C)を使用して書き込む方法 ● Required Tools ● 必要なツール • Firmware downloader program ・ ファームウェア書き込み用プログラム For microprocessor: DSP_FLASHER_v3.0.exe マイコン用: DSP_FLASHER_v3.0.exe For DSP (TI flash ROM): DSP(TI fl ash ROM)用: DSP_FLASHER Ver2.7.exe DSP_FLASHER Ver2.7.exe • Firmware ・ ファームウェア...
  • Page 27 RX-V565/HTR-6250/AX-V565 ● Connection ● 接続 1. Remove the top cover. (See “DISASSEMBLY 1. トップカバーを取り外します。 ( 分解手順 参照) PROCEDURES”) 2. 本機の書き込み用ポート(DIGITAL P.C.B. CB27) 2. Connect the writing port (CB27 of DIGITAL P.C.B.) と PC のシリアルポート(RS232C)を下記のよう of this unit to the serial port (RS232C) of the PC に接続します。...
  • Page 28 RX-V565/HTR-6250/AX-V565 ● Operation Procedures ● 操作手順 Writing to the microprocessor マイコンへの書き込み With the power cable of this unit unconnected to the 本機の電源コードを AC コンセントに接続していない AC outlet, start up DSP_FLASHER_v3.0.exe. 状態で、DSP_FLASHER_v3.0.exe を起動します。 The screen appears as shown below. (Fig. 2) 下記の画面が表示されます。 (Fig. 2)...
  • Page 29 RX-V565/HTR-6250/AX-V565 Connect the power cable of this unit to the AC outlet. 本機の電源コードを AC コンセントに接続します。 Click [E.P.] to start writing. (Fig. 3) 4. [E.P.] をクリックして書き込みを開始します。 (Fig. 3) When writing of the firmware is completed, “Program ファームウェアの書き込みが完了すると、 Program Finished!” is displayed. (Fig. 3) Finished! が表示されます。...
  • Page 30 RX-V565/HTR-6250/AX-V565 Writing to DSP DSP への書き込み With the power cable of this unit unconnected to the 本機の電源コードを AC コンセントに接続していない AC outlet, start up DSP_FLASHER Ver2.7.exe. 状態で、DSP_FLASHER Ver2.7.exe を起動します。 The screen appears as shown below. (Fig. 4) 下記の画面が表示されます。 (Fig. 4) Click [Vx61 DSP]. (Fig. 4) 2.
  • Page 31 RX-V565/HTR-6250/AX-V565 Click [RDY]. (Fig. 6) 4. [RDY]をクリックします。 (Fig. 6) Fig. 6 While pressing the “DIRECT” key of this unit, connect 本機の DIRECT キーを押しながら、本機の電源コー the power cable of this unit to the AC outlet. (Fig. 7) ドを AC コンセントに接続します。 (Fig. 7)...
  • Page 32 RX-V565/HTR-6250/AX-V565 When writing of the firmware is completed, “Vx61 ファームウェアの書き込みが完了すると、 Vx61 DSP DSP Flash finished!” is displayed. (Fig. 3) Flash fi nished! が表示されます。 (Fig. 3) Click [EXIT] to end DSP_FLASHER_v2.7.exe. (Fig. 8) 7. [EXIT]をクリックして DSP_FLASHER_v2.7.exe を終 了します。 (Fig. 8) Fig. 8 Start up the self-diagnostic function and select “25.
  • Page 33: Self-Diagnostic Function / ダイアグ(自己診断機能

    RX-V565/HTR-6250/AX-V565 ■ SELF-DIAGNOSTIC FUNCTION / ダイアグ(自己診断機能) This unit has self-diagnostic functions that are intended 本機には、検査、測定、不良個所の発見を目的にしたダ for inspection, measurement and location of faulty point. イアグ(自己診断機能)があります。 There are 25 main menu items, each of which has sub- メ イ ン メ ニ ュ ー は 25 個 あ り、 そ の そ れ ぞ れ に サ ブ メ...
  • Page 34 RX-V565/HTR-6250/AX-V565 Main menu Sub-menu XM STATUS (U model) 4 XM Tone /44kHz Not applied to these models. / このモデルには適用 5 ISO Tone /44kHz されません。 6 1k -1dB /32kHz 7 1k -61dB /32kHz 8 Mute /32kHz 9 XM Tone /32 kHz...
  • Page 35 RX-V565/HTR-6250/AX-V565 ● Starting Self-Diagnostic Function ● ダイアグの起動 While pressing those 2 keys of this unit as shown in the 本機の下図に示す 2 つのキーを押しながら STANDBY/ figure below, press the “STANDBY/ON” key to turn on the ON キーを押して電源を入れます。 power. ダイアグが起動します。 The self-diagnostic function mode is activated.
  • Page 36 RX-V565/HTR-6250/AX-V565 ● Display provided when Self-Diagnostic ● ダイアグ起動時の表示 Function started 本機の FL ディスプレイにプロテクション履歴情報が表示 The FL display of this unit displays the protection されます。数秒後、メインメニュー No. 1 BYPASS のサブ function history data then the main menu (sub-menu メニュー 1. ANALOG BYPAS が表示されます。...
  • Page 37 RX-V565/HTR-6250/AX-V565 When there is a history of protection function due to abnormal DC output DC 出力異常によるプロテクション履歴がある場合 P R D P R T : x x x AD value when the protection function is working/ 電圧の A/D 変換値 Cause: DC output from the power amplifier is abnormal.
  • Page 38 RX-V565/HTR-6250/AX-V565 When there is a history of protection function due to excessive heat sink temperature ヒートシンクの異常温度によるプロテクション履歴がある場合 T H M P R T : x x x AD value when the protection function is working/ 電圧の A/D 変換値 Cause: The temperature on the heat sink is excessive.
  • Page 39 RX-V565/HTR-6250/AX-V565 ● Operation procedure of Main menu ● メインメニューとサブメニューの操作 and Sub-menu ダイアグには No. 1 ∼ 25 のメインメニューがあり、その There are 25 main menu items, each of them having sub- それぞれにサブメニューがあります。 menu items. メインメニューの選択 Main menu selection SCENE TV (順送り) 、 SCENE BD/DVD (逆送り)キー...
  • Page 40 RX-V565/HTR-6250/AX-V565 ● Details of Self-Diagnostic Function menu ● ダイアグメニュー詳細 1. BYPASS 1. BYPASS Using the sub-menu, it is possible to select ANALOG サブメニューにより、ANALOG BYPASS/DSP BYPASS BYPASS output or DSP BYPASS output. が選択可能です。 ANALOG BYPASS ANALOG BYPASS The analog input audio signal is output to FRONT L/R in アナログ入力の音声信号が...
  • Page 41 RX-V565/HTR-6250/AX-V565 DSP BYPASS FL / FR LC89058 (DECODE) C / SW (POST PROCESSING) TI D70Y SL / SR SBL / SBR PCM1803 DRAM (Shaded items not used in this example) 2. RAM THROUGH 2. RAM THROUGH Using the sub-menu, it is possible to select MARGIN サブメニューにより、MARGIN/FULL BIT が選択可能...
  • Page 42 RX-V565/HTR-6250/AX-V565 RAM FULL BIT RAM FULL BIT The audio signal is output in digital full bit without 音声信号がヘッドマージンを含まず、デジタルフルビッ including the head margin. トで出力されます。 The SUBWOOFER signal is output but not in digital full SUBWOOFER は出力されますが、デジタルフルビットで bit. はありません。 2 . R A M F U L L A L L...
  • Page 43 RX-V565/HTR-6250/AX-V565 RAM FULL CENTER RAM FULL CENTER The audio signal is output to only CENTER in digital full 音声信号がヘッドマージンを含まず、デジタルフルビッ bit without including the head margin. トで CENTER のみへ出力されます。 2 . R A M F U L L C INPUT: AV5 ANALOG...
  • Page 44 RX-V565/HTR-6250/AX-V565 3. HDMI AUDIO 3. HDMI AUDIO Using the sub-menu, the audio signals input to HDMI サブメニューにより、HDMI IN に入力された音声信号 IN are selected and output. が選択、出力されます。 When selecting “DSD”, be sure to connect an ※ DSD を選択する場合、必ず DSD 出力が可能な HDMI unit equipped with DSD output function to HDMI 機器を接続してください。...
  • Page 45 RX-V565/HTR-6250/AX-V565 4. SPEAKER SET 4. SPEAKER SET The analog switch settings for each sub-menu are as 各サブメニューにおけるアナログスイッチの設定は shown in the table below. 以下の通りです。 FRONT CENTER SURROUND SURROUND BACK SUBWOOFER FRNT : SML 0dB SMALL LARGE LARGE LARGE SWFR CENTER : NONE...
  • Page 46 RX-V565/HTR-6250/AX-V565 FRONT : SML 0dB 4 . F R N T : S M L 0 d B The FRONT L/R signal, when 90 Hz or lower, is mixed to the channel specified by LFE/BASS. 90 Hz 以下の信号が LFE/BASS で指定したチャンネルへミックスされて出力されます。...
  • Page 47 RX-V565/HTR-6250/AX-V565 5. MULTI CH-INPUT 5. MULTI CH-INPUT 8 ch INPUT 6 ohms 8 ch INPUT 6 ohms Not applied to these models. このモデルには適用されません。 5 . 8 c h I N P U T _ 6 ^ INPUT: MULTI CH INPUT...
  • Page 48 RX-V565/HTR-6250/AX-V565 LIM / PLDET / THM LIM / PLDET / THM LIM: Setting value of LIM (Limiter control) LIM: LIM(リミッター制御)の設定値 Do not change the value settings because ※ 開発スタッフ専用メニューですので、設定値 this menu is only for the use of development の変更は行わないでください。 staff.
  • Page 49 RX-V565/HTR-6250/AX-V565 FL/OSD CHECK 7. FL/OSD CHECK This menu is used to to check the FL display and FL 表示部および映像表示部のチェックプログラムで video control sections. When checking the video す。映像制御部をチェックする場合には、 TV モニター control section, connect a TV monitor to this unit with と本機をコンポーネント /D ビデオケーブル、S ビデ...
  • Page 50 RX-V565/HTR-6250/AX-V565 Segment conditions of the FL driver and the FL tube 全セグメント消灯・全セグメント点灯により FL ドラ are checked by turning ON and OFF all segments. イバー、FL 管のセグメントの不良を確認します。 Next, the operation of the FL driver is checked by 次に、ディマーコントロールによって FL ドライバー using the dimmer control. Then a short between seg- の動作チェックを行います。...
  • Page 51 RX-V565/HTR-6250/AX-V565 9. A/D DATA CHECK 9. A/D DATA CHECK This menu is used to display the A/D conversion 本機パネルキー、プロテクションなどを検出してい value of the microprocessor which detects panel keys るマイコンの A/D 変換値を、サブメニューで表示し of this unit and protection functions by using the sub- ます。...
  • Page 52 RX-V565/HTR-6250/AX-V565 DC/TH DC/TH Power amplifier DC (DC voltage) output is DC: パワーアンプ DC(直流電圧)出力の検出 detected. 正常値: 23 ∼ 70 Normal value: 23 to 70 (基準電圧:3.3 V = 255) (Reference voltage: 3.3 V=255) Temperature on the heat sink is detected. TH: ヒートシンク温度の検出...
  • Page 53 RX-V565/HTR-6250/AX-V565 DST/DK DST/DK DST: Destination detection DST: 仕向け先の検出 (Reference voltage: 3.3 V=255) (基準電圧:3.3 V = 255) DOCK type detection DK: DOCK タイプの検出 (Reference voltage: 3.3 V=255) (基準電圧:3.3 V = 255) D S T : 0 2 7 D K : 2 5 5...
  • Page 54 RX-V565/HTR-6250/AX-V565 10. VIDEO CHECK 10. VIDEO CHECK I2C check I2C check The I2C (Inter integrated circuit) bus line connection is I2C(Inter integrated circuit)バスラインの接続をチェッ checked. クします。 0 : No error detected / 不良検出なし I 2 C : 0 0 0 0 0 0 0 0 1 : An error is detected / 不良検出あり...
  • Page 55 RX-V565/HTR-6250/AX-V565 Digital CVBS (Video) Digital CVBS(Video) The video signal is converted and output as shown below. 映像信号が以下のように変換され、出力されます。 D I G I T A L C V B S Digital CVBS (Video) DIGITAL DIGITAL IC71 ABT1012 DIGITAL DIGITAL Sil9134 I/P SCALER...
  • Page 56 RX-V565/HTR-6250/AX-V565 Analog bypass Analog bypass The video signal is converted and output as shown below. 映像信号が以下のように変換され、出力されます。 A N A L O G B Y P A S S Analog bypass DIGITAL DIGITAL IC71 ABT1012 DIGITAL DIGITAL Sil9134 I/P SCALER IC70...
  • Page 57 RX-V565/HTR-6250/AX-V565 11. XM STATUS (U model) Not applied to these models. 1 kHz, -1 dB / 44.1 kHz 1 k - 1 d B / 4 4 1 kHz, -61 dB / 44.1 kHz 1 k - 6 1 d B / 4 4 Mute / 44.1 kHz...
  • Page 58 RX-V565/HTR-6250/AX-V565 12. SIRIUS (U model) Not applied to these models. SIRIUS: S I R I U S : - - S R : F F 0 0 F F SSP: S S P : 0 0 0 0 0 0...
  • Page 59 RX-V565/HTR-6250/AX-V565 14. DOCK 14. DOCK This menu is used to check the DOCK connector iPod 本体無しで、DOCK コネクターの検査を行うメ without the iPod itself. ニューです。 With the power to this unit turned off, short between 本機の電源を切った状態で、DOCK コネクターの 14 pins No. 14 (TX) and No. 18 (RX), between pins No.
  • Page 60 HDMI モジュールに書き込まれている本機のプロダクト ID が表示されます。 3138 : RX-V565 3139 : HTR-6250 313A : AX-V565 HDMI vendor name V N : Y A M A H A The vendor name “YAMAHA” of this unit written in HDMI module is displayed. HDMI モジュールに書き込まれている本機のベンダー名“YAMAHA”が表示されます。...
  • Page 61 RX-V565/HTR-6250/AX-V565 16. HDMI SELECT 16. HDMI SELECT Using the sub-menu, the selected input signal is サブメニューにより , 選択された入力信号が HDMI output to HDMI OUT. OUT へ出力されます。 Support audio is set to “OTHER”. ※ SUPPORT AUDIO は OTHER に設定されます。 HDMI none H D M I N O N E No signal is output.
  • Page 62 RX-V565/HTR-6250/AX-V565 HDMI up-conversion through DIGITAL DIGITAL IC71 ABT1012 DIGITAL DIGITAL Sil9134 I/P SCALER IC70 Sil9233A ADV7800 Up-conversion through VIDEO DECODER IC309 LC74782 17. USB 17. USB Not applied to these models. このモデルには適用されません。 USB file 1 USB fi le 1 1 7 : U S B f i l e 1 USB file 2 USB fi...
  • Page 63 RX-V565/HTR-6250/AX-V565 18. IF STATUS (Input function status) 18. IF STATUS(Input function status) Not applied to these models. このモデルには適用されません。 DSP status DSP status D S T : 7 7 0 0 0 2 0 0 0 0 19. BUS CHECK 19. BUS CHECK Communication and bus line connection between DSP P.C.B.
  • Page 64 RX-V565/HTR-6250/AX-V565 20. NO MENU (Invalidity) 20. NO MENU(Invalidity) I n v a l i d i t y 21. PROTECTION HISTORY 21. PROTECTION HISTORY The history of protection function is displayed. 過去のプロテクション履歴が表示されます。 Select this menu and press the “STRAIGHT” key, and サブメニューを選んだ後、...
  • Page 65 RX-V565/HTR-6250/AX-V565 24. FACTORY PRESET 24. FACTORY PRESET This menu is used to reserve and inhibit initialization バックアップ用 IC(音場プログラムのパラメーター of the back-up IC. やセットメニュー内容等)の初期化を予約/禁止し ます。 PRESET INHIBIT (Initialization inhibited) / PRESET INHIBIT(初期化禁止) 2 4 . P R E S E T I N H I Back-up IC initialization is not executed.
  • Page 66 231 ±4 Destination B, G, E, F MODEL detection value Detection value 46 ±4 72 ±4 Model name V5 (RX-V565, AX-V565) H5 (HTR-6250) VERIFY error V e r i f y 0 0 0 Not applied to these models. このモデルには適用されません。...
  • Page 67: Display Data

    RX-V565/HTR-6250/AX-V565 ■ DISPLAY DATA ● V4001 : 18-MT-09GNK (OPERATION P.C.B.) PATTERN AREA ● PIN CONNECTION Pin No. 68 67 Connection F2 NX 29 28 Pin No. Connection Note : 1) F1, F2 ..Filament pin 2) NP ..No pin 3) NX ..
  • Page 68 RX-V565/HTR-6250/AX-V565 ● ANODE CONNECTION 1G-14G –...
  • Page 69: Ic Data

    RX-V565/HTR-6250/AX-V565 ■ IC DATA IC44: D70YE101BRFP266 (DIGITAL P.C.B.) Decoder/Post processor * No replacement part available. / サービス部品供給なし SPI0_SIMO EM_CKE SPI0_SOMI/I2C0_SDA EM_CLK AXR0[0] EM_WE_DQM[1] AXR0[1] EM_D[8] AXR0[2] AXR0[3] EM_D[9] EM_D[10] AXR0[4] AXR0[5]/SPI1_SCS EM_D[11] AXR0[6]/SPI1_ENA AXR0[7]/SPI1_CLK EM_D[12] EM_D[13] EM_D[14] AXR0[8]/AXR1[5]/SPI1_SOMI EM_D[15] AXR0[9]/AXR1[4]/SPI1_SIMO...
  • Page 70 RX-V565/HTR-6250/AX-V565 Function Name TYPE PULL GPIO Detail of Function (P.C.B.) AHCLKX0/AHCLKX2 – McASP0 and McASP2 transmit master clock AMUTE0 – McASP0 mute output AMUTE1 – McASP1 mute output AHCLKX1 – McASP1 transmit master clock ACLKX1 – McASP1 transmit bit clock...
  • Page 71 RX-V565/HTR-6250/AX-V565 Function Name TYPE PULL GPIO Detail of Function (P.C.B.) EM_D[10] – EMIF data bus [lower 16-Bits] EM_D[9] – EMIF data bus [lower 16-Bits] CVDD EM_D[8] – EMIF data bus [lower 16-bits] EM_WE_DQM[1] – Write enable or byte enable for EM_D [15:8]...
  • Page 72 RX-V565/HTR-6250/AX-V565 Function Name TYPE PULL GPIO Detail of Function (P.C.B.) 123 CVDD 124 VSS 125 DVDD McASP0 serial data 8 or McASP1 serial data 5 or SPI1 data pin slave 126 /SPI1_SOMI – out master in McASP0 serial data 9 or McASP1 serial data 4 or SPI1 data pin slave in 127 /SPI1_SIMO –...
  • Page 73 RX-V565/HTR-6250/AX-V565 IC402: M66003-0131FP (OPERATION P.C.B.) FL display driver Display code CGROM SEG00 (35-bit x 166) (8-bit x 60) Segment SEG25 Code output write SEG26 circuit CGROM SEG34 dot data Serial data (35-bit x 16) write receive Code/ circuit SDATA command...
  • Page 74 RX-V565/HTR-6250/AX-V565 Pin No. Port Name Function Name Detail of Function Vcc1 Positive power supply for internal logic. SEG34 SEG33 SEG32 SEG31 SEG30 Segment output Connect to segment (anode) pins of VFD. SEG29 SEG28 SEG27 SEG26 Vcc2 Positive power supply for DIG and SEG outputs.
  • Page 75 RX-V565/HTR-6250/AX-V565 IC41: LC89058WD-E (DIGITAL P.C.B.) Digital audio interface receiver MOUT AUDIO XMODE Fs calculator GPIO0 Microcontroller 40 CL GPIO1 GPIO2 Cbit, Pc GPIO3 RXOUT2 RXOUT1 Input RERR Demodulation Selector & SDIN Data Lock detect Selector RDATA Clock RMCK Clock Selector...
  • Page 76 RX-V565/HTR-6250/AX-V565 Pin No. Function Name Detail of Function RXOUT1 RX0-6 input S/PDIF through output pin 1 5V withstand voltage TIL input level compatible S/PDIF input pin (pd) (connected to GND when RX1 is set) Co-axial compatible S/PDIF input pin I(pd)
  • Page 77 RX-V565/HTR-6250/AX-V565 IC153: R2A15220FP (MAIN P.C.B.) 8-channel electronic volume with 11 input selector and tone control 49 48 46 45 38 37 34 33 TRER MUTE AVEE AVCC BASSR2 A VEE BASSR1 ADCL 0/-6/-12/-18dB TREL ADCR SUB2 AGND BASSL2 MAIN INR1...
  • Page 78 RX-V565/HTR-6250/AX-V565 Pin No. Port name Function Name Detail of Function AGND Analog ground of internal circuit SBROUT VOSBL Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel SBR Pre-OUT VOPSBL Pre-output pin of FL/FR/SL/SR/SBL/SBR channel SBRC Connects capacitor for reducing click noise of L/R/C/SW/SL/SR/SBL/SBR channel volume...
  • Page 79 RX-V565/HTR-6250/AX-V565 Pin No. Port name Function Name Detail of Function INL2 AU1R Input pin of L/R channel (Input selector) INR3 AV-6L Input pin of L/R channel (Input selector) INL3 AV-6R Input pin of L/R channel (Input selector) INR4 AV-5L Input pin of L/R channel (Input selector)
  • Page 80 RX-V565/HTR-6250/AX-V565 IC20: M3087BFKBGP (DIGITAL P.C.B.) Microprocessor Port P0 Port P1 Port P2 Port P3 Port P4 Port P5 Port P6 < > < > CC1 (3) Peripheral Functions Clock Generation Circuit A/D Converter: 1 circuit Timer (16 bits) Standard: 10 inputs...
  • Page 81 RX-V565/HTR-6250/AX-V565 Function Port Name Name Detail of Function (P.C.B.) TXD4 P96/ANEX1/TXD4/ IPD_MOSI Asynchronous data output for iPod SDA4/SRXD4 SCPU_SCK P94/DA1/TB4in/ SCPU_CTS Input for transmission control for SubCPU (clear to send) CTS4/RTS4/SS4 P93/DA0/TB3in/ AMP_LMT Limiter control output CTS3/RTS3/SS3 TB2in RDS_RDY RDS RRADY input...
  • Page 82 RX-V565/HTR-6250/AX-V565 Function Port Name Name Detail of Function (P.C.B.) P81/TA4in/U/INPC15/ DSP_N_RDY DA70Y RDY OUTC15/CTS5/ RTS5/RTP23 DIR_WCK CDDA writing DIR_WCK input RXD5 P80/TA4out/U/ DSP_MISO Synchronous data input for DIR, DA70Y, DAC ISRXD0/RXD5 CLK5 P77/TA3in/INPC14/ DSP_SCK Synchronous clock output for DIR, DA70Y, DAC...
  • Page 83 RX-V565/HTR-6250/AX-V565 Function Port Name Name Detail of Function (P.C.B.) SCL0 HDMI RX/TX, Video Enc/Dec I2C SDA input/output (400 kHz device) P62/RXD0/SCL0/ HDMI_SCL Pull up at HDMI block STXD0/IrDAin HDMI RX/TX: 5V tolerant 46 P61 232C_PON H: ON, L: OFF P60/CTS0/RTS0/...
  • Page 84 RX-V565/HTR-6250/AX-V565 Function Port Name Name Detail of Function (P.C.B.) SPRY_C Center speaker relay control P43/A19 Vcc2 Vcc2 MCU MCU MCU MCU MCU Microprocessor power supply Vcc2 SPRY_S Surround speaker relay control P42/A18 MCU MCU MCU MCU MCU Microprocessor GND VOL_SCK...
  • Page 85 RX-V565/HTR-6250/AX-V565 Function Port Name Name Detail of Function (P.C.B.) INT3 REM_IN Remote control pulse input P15/D13/INT3 105 P14 XM_PON DOCK power supply ON/OFF control DOCK_PON P13/D11 H: ON, L: OFF IOXV_N_CS IO extended IC (for video) chip select P12/D10 IOXV_N_RST...
  • Page 86 RX-V565/HTR-6250/AX-V565 Function Port Name Name Detail of Function (P.C.B.) KEY2 AD value taken in KEY2 Duing PSW_DET interruption, distinguishes the used keys which are P106/AN6/KI2/RTP32 switched to AD PS1_PRT PS protection detection 1 P105/AN5/KI1/RTP31 PS2_PRT PS protection detection 2 P104/AN4/KI0/RTP30...
  • Page 87: Pin Connection Diagrams

    RX-V565/HTR-6250/AX-V565 ■ PIN CONNECTION DIAGRAMS • ICs ABT1012Q100 ADV7800BSTZ-80 BD9323EFJ-E2 D70YE101BRFP266 FHP3350IM14X K4S641632N-LC60000 M30878JBGP SiI9233ACTU KIA7912PI LA73050-TLM-E LC709004A-TLM-E LC72725KM-UY-TLM-E LC74782JM-8A16-TLMC LC89058WD-E LE25LA322M-TLM-E LM19CIZ/LF M66003-0131FP-R MX29LV160DBTI-70G NJM2388F05 NJM2396F05 NJM2581M NJM2867F3-05 NJM4565M NJM4565M (TE1) 1. IN 1. V 2. V 2. V 3.
  • Page 88 RX-V565/HTR-6250/AX-V565 NJM7812FA NJM78M05DL1A (TE1) PCM1680DBQR 3: IN 1: INPUT 1: OUT 2: COM 2: GND 3: OUTPUT PCM1803DBR R1172H181B-T1-F R1172S121D-E2-F R2A15220FP SN74LVC245APWR R1172H331D-T1-F R1172H501D-T1-F 1: CE 2: GND 3: NC 4: V 5: V SN74LVTH245APW STK433-130-E STK433-330-E SiI9134CTU TC74HC4051AFEL TC74HC4053AF...
  • Page 92 IDCK HSYNC HSYNC VSYNC VSYNC Q[0:35] Q[0:35]...
  • Page 94: Printed Circuit Boards

    CB25 CB73 CB72 IC70 IC75 IC74 IC11 IC44 IC66 IC65 CB61 CB62 CB63...
  • Page 96 CB403 SW414 SW405 SW408 SW409 SW406 SW403 SW413 SW401 SW416 SW420 SW423 SW443 CB401 CB402...
  • Page 98 CB461...
  • Page 100 CB474...
  • Page 102 IC103 IC104 CB153 CB154 CB155 CB152...
  • Page 104 CB157...
  • Page 106 CB349 IC334 CB303 CB332...
  • Page 114 Port P7 Port P8 Port P9 Port P10 < >...
  • Page 115 Sense AMP...
  • Page 125: Replacement Parts List

    RX-V565/HTR-6250/AX-V565 ■ REPLACEMENT PARTS LIST • ELECTRICAL COMPONENT PARTS WARNING ● Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally installed. ● 印のある部分は、安全確保部品を示しています。部品の交換が必要な場合、パーツリストに記載されている部品を使用し てください。 ● 部品価格ランクは、予告なく変更することがあります。 ABBREVIATIONS IN THIS LIST ARE AS FOLLOWS: C.A.EL.CHP...
  • Page 126 RX-V565/HTR-6250/AX-V565 P.C.B. DIGITAL Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 127 RX-V565/HTR-6250/AX-V565 P.C.B. DIGITAL Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 128 RX-V565/HTR-6250/AX-V565 P.C.B. DIGITAL Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 129 RX-V565/HTR-6250/AX-V565 P.C.B. DIGITAL Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 130 RX-V565/HTR-6250/AX-V565 P.C.B. DIGITAL and P.C.B. OPERATION Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 131 RX-V565/HTR-6250/AX-V565 P.C.B. OPERATION Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 132 RX-V565/HTR-6250/AX-V565 P.C.B. OPERATION Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 133 RX-V565/HTR-6250/AX-V565 P.C.B. MAIN Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 134 RX-V565/HTR-6250/AX-V565 P.C.B. MAIN Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 135 RX-V565/HTR-6250/AX-V565 P.C.B. MAIN and P.C.B. VIDEO Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 136 RX-V565/HTR-6250/AX-V565 P.C.B. VIDEO Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 137 RX-V565/HTR-6250/AX-V565 P.C.B. VIDEO Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 138 RX-V565/HTR-6250/AX-V565 P.C.B. VIDEO Ref No. Part No. Description Remarks Markets 部 品 名 ランク ✻ New Parts *新規部品...
  • Page 147: Advanced Setup / 本機の設定を変更する

    RX-V565/HTR-6250/AX-V565...
  • Page 148 RX-V565/HTR-6250/AX-V565...
  • Page 149 RX-V565/HTR-6250/AX-V565 MEMO...
  • Page 150 RX-V565/HTR-6250/ AX-V565...

This manual is also suitable for:

Htr-6250Ax-v565

Table of Contents
