Page 1: Quick Installation Guide
CAT5 Audio/Video Display Quick Installation Guide International HQ North American HQ German Europe Italy Jerusalem, Israel Linden, New Jersey Zurich, Switzerland Rome Tel: + 972 2 535 9666 Tel: + 1 908 4862100 Tel: + 41 1 455 6220 Tel: + 39 06 8209 7902 minicom@minicom.com... -
Page 2: What Is The Cat5 Audio/Video Display System
AVDS systems that have different part numbers. Part numbers are located on the back of each unit. Shielded CAT5 FTP cables connect the AVDS system. The Remote Dongles can be up to 110m/360ft away from the Broadcaster. 2. The multi-functional AVDS system... -
Page 3: The Avds Units
QUICK INSTALLATION GUIDE 3. The AVDS units The figures below illustrate the Broadcaster Unit, Line Splitter and Remote Dongles. Power connector System cables Monitor Audio cables Sound Card 12VDC VIDEO OUT Speaker Headset CONTROL SYSTEM VIDEO IN Video Microphone & Control Unit cable speaker... -
Page 4: Expanding The Avds System
Remote Dongles connected to it. (See the configuration diagram on page 4). 5. Pre-installation instructions Note! In the AVDS system the CAT5 cables carry electrical power. Therefore do NOT connect them to any other device. To avoid this we recommend you attach the stickers provided to the ends of each CAT5 cable. -
Page 5: The Avds Configuration For A Cbt Application
7. The AVDS configuration for a CBT application The figure below illustrates the AVDS configuration with the AVDS Control Unit and the optional remote computers. VDS Control Unit Broadcaster Unit Audio cables CAT5 cables to Remote Dongles Video cable or Line Splitters Broadcaster computer... -
Page 6: Avds Detailed Connections
PHANTOM CARD STARTER KIT CAT5 AUDIO/VIDEO DISPLAY 8. AVDS detailed connections The figure below illustrates the detailed connections of the AVDS units. Control Unit VDS Control Unit Master Dark CAT5 cables to to all Remote Dongles MINICOM or Line Splitters To Mic. -
Page 7: The Avds Configuration Without Remote Computers
Remote Dongles. Connect the Broadcaster and Line Splitters as in the figure on page 5. The figure on page 7 illustrates the detailed connections of the Remote Dongle. CAT5 cables to Remote or Line VDS Control Unit... -
Page 8: The Control Unit
PHANTOM CARD STARTER KIT CAT5 AUDIO/VIDEO DISPLAY CAT5 cable to Broadcaster or Line Splitter Remote Dongle AUDIO PICTURE 10. Operating the AVDS system Once connected the AVDS system broadcasts to all remote monitors/speakers. The Control Unit The Control Unit is illustrated below. -
Page 9: 12. Technical Specifications
QUICK INSTALLATION GUIDE 12. Technical specifications SYSTEM Up to 1600x1200 @ 75 Hz Resolution System cable Shielded CAT5 FTP cable Max distance 110m/360ft Input/Output Video Signals Analog signal red, green, blue 0.7v p-p 75 Ohm Sync. TTL compatible Horizontal/Vertical Sync. Polarity...
