Neoway N3800 series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
N3800 Series Router

User Manual

Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N3800 series and is the answer not in the manual?

Questions and answers

Related Manuals for Neoway N3800 series

Summary of Contents for Neoway N3800 series

  • Page 1: User Manual

    N3800 Series Router User Manual Version 1.0...
  • Page 2 N3800 Series Router User Manual Copyright © Neoway Technology Co., Ltd. 2017. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Shenzhen Neoway Technology Co., Ltd.
  • Page 3 N3800 Series Router User Manual Revision Record Issue Date Changes V1.0 2017-04 Initial draft Copyright © Neoway Technology Co., Ltd.

  • Page 4: Table Of Contents

    N3800 Series Router User Manual Contents 1 Connection Debugging ....................1 2 Device Configuration ....................... 2 2.1 3G/4G Dialing ............................ 2 2.2 Dynamic DNS ............................ 4 2.3 Port Mapping ............................5 2.4 LAN Setting ............................5 2.5 Wireless Setting ..........................6 2.6 COM Server (DTU / Data Transparent Transmission) ...............

  • Page 5: Connection Debugging

    N3800 Series Router User Manual 1 Connection Debugging Connect the router to a computer. Power on the router, and set to "obtains an IP address automatically" on the computer. Manual configuration is also allowed. Ensure that the computer and the router share the same network segment before manual configuration.

  • Page 6: Device Configuration

    N3800 Series Router User Manual 2 Device Configuration After the ping test, access the router's web-based configuration pages to configure it. The default setup page of the router is http: //192.168.100.1. User name: admin Password: admin Follow the steps below to set up the router fast.
  • Page 7 N3800 Series Router User Manual Step 2 On the tab displayed, deselect Auto select 3G/4G ISP, and select one ISP to fill SIM/UIM card parameters manually. Step 3 Set up the rest of dialup information according to the ISP and router model.

  • Page 8: Dynamic Dns

    N3800 Series Router User Manual The current IP automatically acquired is 183.40.68.30. 2.2 Dynamic DNS Users can set dynamic DNS as required. Step 1 Choose 3G/4G from the main menu. Click DDNS. Step 2 On the tab displayed, click Enable behind DDNS.

  • Page 9: Port Mapping

    N3800 Series Router User Manual 2.3 Port Mapping Step 1 Choose Server from the main menu. Click Virtual Server. Step 2 Click Enable after Passive Virtual Server. Step 3 Configure the following parameters. Service Name: Used to identify this port mapping;...

  • Page 10: Wireless Setting

    N3800 Series Router User Manual IP Address: the LAN address of the router;  Subnet Mask: the subnet mask of the router;  Start IP Address: Start address assigned by the router to devices.  End IP Address: End address assigned by the router to devices.
  • Page 11 N3800 Series Router User Manual SSID: the name of the wireless network  Do Not Broadcast SSID: Whether to hide the wireless network name.  Channel: the wireless network channel from 1 to 13, or choose automatic.  Step 4 Click Security.

  • Page 12: Com Server (Dtu / Data Transparent Transmission)

    N3800 Series Router User Manual 2.6 COM Server (DTU / Data Transparent Transmission) Step 1 Choose Server from main menu. Click Com2Server. Step 2 On the tab, configure parameters. Server Addr: The network address of the server to receive data. It can be IP address or domain ...

  • Page 13: Vpn (Pptp) Setting

    N3800 Series Router User Manual 2.7 VPN (PPTP) Setting Step 1 Choose VPN from main menu. Click PPTP. Step 2 On the tab, configure parameters. PPTP Server: the address of the PPTP server  PPTP Username: PPTP user name ...

  • Page 14: Resetting To Factory Settings

    N3800 Series Router User Manual Step 3 Click APPLY. 2.9 Resetting to Factory Settings Default user name: admin  Default password: admin  Default IP address: 192.168.100.1  Default login address: http://192.168.0.254  Step 1 Choose Admin from main menu. Click Factory-Defaults.

  • Page 15: Firmware Upgrade

    N3800 Series Router User Manual Users can also press the reset hole (next to RJ-45) via a pin for 5 seconds to restore to the factory settings when the router is powered on. 2.10 Firmware Upgrade Step 1 Choose Admin from main menu. Click Firmware Upgrade.

  • Page 16: Technical Support

    N3800 Series Router User Manual 3 Technical Support To quickly solve the problems in the process and access to solutions to hardware, OS, installation and debugging problems, please contact us in the following way: Service Hotline: +086-0755-29672566  Corporate website: http://www.neoway.com...
