- Page 1 Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Hardware Installation Guide Models GC510P and GC510PP September 2017 202-11780-02 350 E. Plumeria Drive San Jose, CA 95134...
- Page 2 For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621. Compliance For regulatory compliance information, visit http://www.netgear.com/about/regulatory. See the regulatory compliance document before connecting the power supply. Trademarks NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks are used for reference purposes only.
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction Overview........................6 Features.........................7 Safety Instructions and Warnings................8 Chapter 2 Hardware Overview Hardware Description..................12 Front Panel......................12 Back Panel......................12 LEDs.......................13 Switch Hardware Interfaces.................14 RJ-45 Ports for 10/100/1000M BASE-T Ethernet Connectivity.......14 SFP Ports for Fiber Connectivity..............15 Multi-Function Reset Button................15 Chapter 3 Applications PoE Applications....................18 PoE Overview....................18 Connect PoE Equipment in a Business Environment........19... - Page 4 Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Chapter 5 Troubleshooting Troubleshooting Chart..................35 PoE Troubleshooting Suggestions...............36 Additional Troubleshooting Suggestions..............36...
-
Page 5: Chapter 1 Introduction
IP security cameras. The switches differ in their maximum PoE power budget: • Model GC510P. This model can supply up to 30W PoE (IEEE 802.3at) to each port, with a maximum PoE power budget of 134W across all active PoE+ ports. -
Page 6: Overview
The switch integrates full-duplex, nonblocking switch fabric that provides full-wire speed for all packet sizes. The switch supports PoE+ on all copper ports with a maximum PoE power budget of 134W (model GC510P) or 195W (model GC510PP) across all active PoE+ ports. -
Page 7: Features
Two dedicated Gigabit SFP fiber ports. • PoE and PoE+ on copper ports: Eight ports PoE+ supporting both IEEE 802.3af and IEEE 802.3at Total PoE power budget of 134W (model GC510P) or 195W (model GC510PP) • MAC table size of 16K entries. •... -
Page 8: Safety Instructions And Warnings
Any device that is located outdoors and connected to this product must be properly grounded and surge protected. To the extent permissible by applicable law, failure to follow these guidelines can result in damage to your NETGEAR product, which might not be covered by NETGEAR’s warranty. • Observe and follow service markings: Do not service any product except as explained in your system documentation. - Page 9 Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports • If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact your trained service provider: The power cable, extension cable, or plug is damaged. An object fell into the product.
- Page 10 Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports • Position system cables and power cables carefully. Route cables so that they cannot be stepped on or tripped over. Be sure that nothing rests on any cables. •...
-
Page 11: Chapter 2 Hardware Overview
Hardware Overview This chapter describes the switch hardware features. The chapter includes the following sections: • Hardware Description • Switch Hardware Interfaces... -
Page 12: Hardware Description
Figure 1. Front panel Back Panel Both model GC510P and model GC510PP provide eight 10/100/1000BASE-T RJ-45 PoE+ ports and two dedicated Gigabit SFP fiber ports. Both models integrate a fixed, internal power supply unit (PSU). Model GC510PP also integrates a fan. -
Page 13: Leds
Solid blue. The switch is connected to the cloud server and is set up to be managed by the NETGEAR Insight app. Off. The switch is not connected to the cloud server or is set up to be managed by the local browser interface. -
Page 14: Switch Hardware Interfaces
Solid blue. The switch is connected to the cloud server and is set up to be managed by the NETGEAR Insight app. Off. The switch is not connected to the cloud server or is set up to be managed by the local browser interface. -
Page 15: Sfp Ports For Fiber Connectivity
The factory default settings function of the Reset button is available only after you use the NETGEAR Insight app to remove the switch from your network. - Page 16 Power LED lights amber. • Return the switch to its factory default settings. After you use the NETGEAR Insight app to remove the switch from your network, press the Reset button for at least five seconds. The switch restarts and returns to its factory default settings. During this process, the Power LED lights amber.
-
Page 17: Chapter 3 Applications
Applications The switch is designed to provide flexibility in configuring network connections. The switch can be used as your only network traffic–distribution device for PoE+, PoE, and non-PoE devices or with 10 Mbps, 100 Mbps, and 1 Gbps Ethernet and fiber hubs, routers, and switches. This chapter includes the following sections: •... -
Page 18: Poe Applications
The switch supports eight Power over Ethernet Plus (PoE+) ports and can supply up to 30W PoE+ (IEEE 802.3at) to each port up to its total maximum PoE power budget of 134W (model GC510P) or 195W (model GC510PP) across all active PoE+ ports. The switch is backward compatible with PoE (IEEE 802.3af). -
Page 19: Connect Poe Equipment In A Business Environment
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Connect PoE Equipment in a Business Environment The following figure shows an example of how you can connect PoE wireless access points that require 802.11af only, PoE VoIP phones, and PoE surveillance equipment to the switch in a business environment. In a small office or home office network, the blue network icon represents a router that is connected to an Internet modem. -
Page 20: Connect Poe Equipment For Surveillance And Security
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Connect PoE Equipment for Surveillance and Security The following figure shows an example of how you can connect PoE and non-PoE equipment to the switch for surveillance and security purposes. In a small office or home office network, the blue network icon represents a router that is connected to an Internet modem. -
Page 21: Desktop Switching
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Desktop Switching You can use the switch as a desktop switch to build a small network that provides up to 1 Gbps access to servers such as a file server. In a small network such as a small office or home office network, connect the switch to a router that, in turn, is connected to an Internet modem. -
Page 22: Chapter 4 Installation
Installation This chapter describes the installation procedures for the switch. Switch installation involves the steps described in the following sections: • Step 1: Prepare the Site • Step 2: Protect Against Electrostatic Discharge • Step 3: Unpack the Switch • Step 4: Install the Switch •... -
Page 23: Step 1: Prepare The Site
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Step 1: Prepare the Site Before you install the switch, make sure that the operating environment meets the site requirements that are listed in the following table. Table 5. -
Page 24: Step 3: Unpack The Switch
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports • When unpacking a static-sensitive component from its shipping carton, leave it in the antistatic package until you are ready to install it. Just before unwrapping the antistatic package, discharge static electricity from your body. -
Page 25: Step 4: Install The Switch
• Rubber footpads for tabletop installation If any item is missing or damaged, contact your local NETGEAR reseller for replacement. Step 4: Install the Switch You can also use any off-the-shelf 75 mm VESA standard mount to secure the switch to a wall, a pole, or another surface. -
Page 26: Wall-Mount The Switch Horizontally With The Back Panel Facing Down
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Wall-Mount the Switch Horizontally With the Back Panel Facing Down To mount the switch horizontally to a wall with the back panel facing down (that is, with the cables at the bottom): Locate the four holes on the bottom panel of the switch. -
Page 27: Wall-Mount The Switch Horizontally With The Back Panel Facing Up
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Leave about 6 mm (¼ inch) of each screw protruded from the wall so that you can insert the screws into the holes on the bottom of the switch. Line up the holes on the bottom panel of the switch with the screws in the wall and mount the switch to the wall. - Page 28 Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports The four mounting holes must be in a square at precise distances of 75 mm (2.953 inches) from each other. In the following figure, each green arrow represents 75 mm. Drill holes into the wall for four anchors in which you will insert M4 x L25 mm screws.
-
Page 29: Wall-Mount The Switch Vertically With The Back Panel Facing Left
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Wall-Mount the Switch Vertically With the Back Panel Facing Left To mount the switch vertically to a wall with the back panel facing left (that is, with the cables on the left): Locate the four holes on the bottom panel of the switch. -
Page 30: Poor Wall-Mounting Position
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Leave about 6 mm (¼ inch) of each screw protruded from the wall so that you can insert the screws into the holes on the bottom of the switch. Line up the holes on the bottom panel of the switch with the screws in the wall and mount the switch to the wall. -
Page 31: Mount The Switch To A Pole Or Another Surface
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Mount the Switch to a Pole or Another Surface You can use an off-the-shelf 75 mm VESA standard mount to secure the switch to a pole or another surface. The bottom panel of the switch provides four mount holes that are VESA-compliant. -
Page 32: Step 6: Connect Devices To The Switch
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports Note Contact your NETGEAR reseller to purchase these modules. If you do not want to install an SFP module, skip this procedure. To install an SFP transceiver module: Insert the transceiver into the SFP port. -
Page 33: Step 8: Apply Power And Check The Leds
Step 9: Manage the Switch Using the NETGEAR Insight app, you can discover the switch on the network and add the switch to the NETGEAR Insight app so that you can perform basic management and monitoring tasks from your smartphone. -
Page 34: Troubleshooting
Troubleshooting This chapter provides information about troubleshooting the switch. The chapter includes the following sections: • Troubleshooting Chart • PoE Troubleshooting Suggestions • Additional Troubleshooting Suggestions... -
Page 35: Troubleshooting Chart
Make sure that the switch is connected to the Internet or is not yet discovered and Internet and that you discover and add the activated through the NETGEAR switch to your network by using the NETGEAR Insight app. Insight app. A combined speed and activity Port connection is not working. -
Page 36: Poe Troubleshooting Suggestions
Switch integrity. If necessary, verify the integrity of the switch by resetting it. To reset the switch, disconnect the AC power from the switch and then reconnect the AC power. If the problem continues, contact NETGEAR technical support. For more information, visit the support website at support.netgear.com.
