Installation
Instructions
Questions? Call 1-800-561-3344 or
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT –
instructions for local inspector's use.
IMPORTANT –
governing codes and ordinances.
Note to Installer –
instructions with the consumer.
Throughout this manual, features and appearances may vary from your model
Visit our Website at:
Save these
Observe all
Be sure to leave these
Above the Cooktop
Microwave Oven
PVM1899 & PVM2155
GEAppliances.ca
Note to Consumer –
for future reference.
• Skill Level – Installation of this appliance requires basic
mechanical and electrical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the warranty.
Keep these instructions
Co ok ing
Co ok ing
Co nv en ien ce
Co nv en ien ce
Pot ato
Pot ato
Bev era ge
Bev era ge
Pop cor n
Pop cor n
Co ok
Co ok
De fro st
De fro st
Tim e
Tim e
Reh eat
Wei ght/ Tim
e
Reh eat
Wei ght/ Tim
e
Tim er
Tim er
On/ Off
Exp res s Co ok
On/ Off
Exp res s Co ok
Add
Add
3
3
30 Sec .
2
30 Sec .
1
2
1
Tur nta ble
6
Tur nta ble
6
5
4
5
4
Sur fac e
Sur fac e
9
9
8
Lig ht
8
Lig ht
7
7
Set
Ven t
Set
Ven t
0
Pow er
0
Pow er
Clo ck
Clo ck
Lev el
Lev el
Sta rt
Sta rt
Ca nc el
Ca nc el
Pau se
Pau se
Off
Off
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
05-16 MCC
29-6080

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PVM1899 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GE PVM1899

  • Page 1 Installation Above the Cooktop Microwave Oven Instructions PVM1899 & PVM2155 Questions? Call 1-800-561-3344 or GEAppliances.ca Visit our Website at: BEFORE YOU BEGIN Note to Consumer – Read these instructions completely and carefully. • Keep these instructions IMPORTANT – for future reference.
  • Page 2: Table Of Contents

    Installation Instructions Table of Contents Safety Definitions Pg # WARNING 1 ....Safety Definitions 2 ....IMPORTANT SAFETY INSTRUCTIONS This indicates that death or serious injuries may occur as a result of non-observance of this warning. 2 ....Appliance Handling Safety 2 ....Safety Codes and Standards 2 ....Electric Safety CAUTION 2 ....Microwave Safety...
  • Page 3: Important Safety Instructions

    Installation Instructions IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS Electric Safety INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE AFTER INSTALLATION IS COMPLETE. IMPORTANT: SAVE THESE INSTRUCTIONS FOR THE WARNING LOCAL ELECTRICAL INSPECTOR’S USE Before you plug in an electrical cord or turn on power supply, make sure all controls are in the OFF position.
  • Page 4: Related Equipment Safety

    Installation Instructions IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS GROUNDING INSTRUCTIONS This appliance must be grounded. Grounding reduces the risk of electric shock by providing a safe pathway for electric current in the event of a short circuit. This appliance is equipped with a cord having a grounding wire with a grounding plug.
  • Page 5: Checklist For Installation

    Installation Instructions Checklist for Installation Use this checklist to verify that you have completed each 6. Attach the mounting plate to the wall. step of the installation process. This can help you avoid Section: Install Appliance - Attaching the mounting plate common mistakes.
  • Page 6: Parts Included

    Installation Instructions Parts Included Location requirements Installation dimensions 13-3/4" (349mm) min. You will find the installation hardware contained in packet with the unit. Check to make sure you have all these parts: min. 12" (305mm) Top mounting bolts: max. 14" (356mm) Self-aligning machine screws (3) min. 16-1/2" Toggle bolts (3/16"x 3") (419mm) Wall mounting hardware: Toggle wings...
  • Page 7: Power Requirements

    Installation Instructions Power Requirements Appliance dimensions The outlet must be properly grounded in accordance with all applicable codes. It can be installed inside the cabinet above the appliance. 16-1/2" (419mm) 29-7/8" 15-3/8" (760mm) (390mm) Electrical Installation Electrical Requirements: • a three prong grounded outlet •...
  • Page 8: Install Appliance

    Installation Instructions Install Appliance No wall studs at corner holes Removing the mounting plate Note: To avoid possible damage to the work surface or to the bottom of the appliance, cover the work surface. 1. Remove any remaining contents from the microwave oven cavity.
  • Page 9: Attaching The Mounting Plate To The Wall

    Installation Instructions Attaching the mounting plate to the wall Attaching the mounting plate 1. Remove the toggle wings from the bolts. Preparing rear wall 2. Insert the bolts into the mounting plate through the holes designated to go into drywall. CAUTION Wear gloves to avoid cutting fingers on sharp edges.
  • Page 10: Adapting Microwave Blower

    Installation Instructions Adapting microwave blower This microwave is shipped assembled for Room Venting Installation. The blower unit is already in place and must not to be adapted. Adapting microwave blower for roof venting 1. Remove and save the screws holding the blower motor and the blower plate.
  • Page 11: Preparing Cabinet

    Installation Instructions Mounting the microwave oven 6. Replace the blower plate and secure with the screws removed in Step 1. Notes • If the bottom of the upper cabinet is recessed or has front overhang, you will need to prepare 2" x 2" (51 mm x 51 mm) - depth equivalent to cabinet recess or overhang) filler blocks to provide additional support for the bolts: • mark the center of each filler block and drill a 3\8"...
  • Page 12: Hood Exhaust

    Installation Instructions 4. Insert the two remaining self-aligning screws through outer 7. Install grease filters by sliding them into the side slots, then pushing up and toward oven to lock (image top cabinet holes. Turn two full turns on each screw. shows bottom view of appliance). Hood exhaust When venting exhaust to the outside, hood exhaust ducts will be required.
  • Page 13: Testing Operation

    Installation Instructions Duct Pieces Number used Equivalent Length 90° Elbow 25 ft (7.6 m) 45° Elbow 5 ft (1.5 m) Roof Cap 24 ft (7.3 m) Straight Duct 6" (152 mm) Round or 3 1/4" x 10" 1 ft (0.3 m) (82 x 254 mm) Rectangular Total Ductwork = * If a rectangular-to-round transition adapter is used, first...
  • Page 14: Before You Use Your Microwave Oven

    Installation Instructions BEFORE YOU USE YOUR MICROWAVE OVEN Make sure the microwave oven has Read the Quick Use & Care. been installed according to instructions. Remove all packing material from the KEEP INSTALLATION INSTRUCTIONS microwave oven. FOR THE LOCAL INSPECTOR’S USE. Install turntable and turntable ring in cavity.
