Zaxcom RX-12R Specifications

Frame specifications
Analog audio output
Digital audio output
Audio connectors
RF connectors
RF impedance
RF gain input-output
RF amp noise figure
RF amp IP3
RF filter band pass
RF tuning range
Power
LCD screen
Size
QRX212 Module specifications
Receivers per module
Receiver modulation
Tuning range
Power consumption
Size
All Specifications are subject to change without notice.
Balanced 0dB @-20dBFS (2 channels receiver)
AESEBU (2 pair per receiver)
6 - XLRM / DB25
4 BNC including loop trough (post band pass)
50 ohms
4.0dB
.5dB
+30dB input
35 MHz
512MHz- 698MHz
8VDC -18VDC (12VDC nominal @100ma) 2 Hirose- HR10A-7P-4P
TFT daylight readable color 2.2" diagonal
L=19 inches W=12 inches H=2.625 inches
2
Zaxcom digital
512MHz- 698MHz
300ma @12VDC
.8" x 3.0" x 5.0"
23
