IMPORTANT SAFETY INSTRUCTIONS

DANGER!
• NEVER attempt to service or perform maintenance functions while machine is plugged into an electrical
outlet.
• ALWAYS unplug machine before attempting to service the motorized brush attachment.
• NEVER operate in standing water. NEVER expose to rain. ALWAYS store indoors.
• NEVER overfill recovery tank or allow water to enter vacuum standpipe. This will cause damage to the
vacuum motor and possible electrocution.
• NEVER operate machine with a cut, abraded or taped cord.
• NEVER operate machine with a broken grounding blade on the plug.
• ALWAYS replace the entire cord when the cord or plug is damaged in any manner.
• NEVER handle the machine, cord or plug with wet hands.
• NEVER drop or insert any object into any machine opening.
• ALWAYS keep face, fingers, hair or any other body part, or loose clothing away from any machine
opening or any moving part, particularly the revolving brush.
• NEVER leave the machine unattended when plugged in. Unplug the machine from the electrical outlet
when not in use.
• ALWAYS turn the machine off before unplugging it from the electrical outlet.
• NEVER operate this machine in the presence of flammable or combustible liquids or fumes.
• When any electrical motor, switch, cord or plug service is required, maintenance should only be done by
an authorized service station, an electrician or other qualified persons.
• NEVER operate this machine if it is not working properly, if it as been dropped, damaged, exposed to
weather, or dropped into water. Return the machine to a service center for examination and repair.
• NEVER operate this machine with any air opening blocked. Keep all air openings free of dust, lint, hair,
ect.
• NEVER operate this machine without solution tank filter screens or vacuum standpipe filter screen in
place or if they are clogged. Clean all filter screens after every use.
• ALWAYS store this machine indoors. Protect it from rain or snow.
• NEVER spray the top of the machine with liquids.
• DO NOT pull or carry this machine by the electrical supply cord, use the cord as a handle, close a door on
the cord, pull the cord around sharp edges or corners, or expose to heated surfaces.
• NEVER disconnect the plug by pulling on the cord. To disconnect the cord from the outlet grasp the plug,
not the cord.
• ALWAYS unplug this machine before attempting to service.
• ALWAYS use a defoamer which will prevent a buildup of foam in the recovery tank. If a defoamer is not
used, the motor can be damaged from shampoo being pulled into the vacuum motor.
SAVE THESE INSTRUCTIONS
PREDATOR CXC100
READ AND UNDERSTAND ALL INSTRUCTIONS
BEFORE OPERATING OR SERVICING MACHINE
Failure to Observe These Instructions Can Cause Personal Injury
to Machine Operator, By-standers or Possible Machine Damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PREDATOR CXC100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NSS PREDATOR CXC100

  • Page 1: Important Safety Instructions

    PREDATOR CXC100 IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE OPERATING OR SERVICING MACHINE DANGER! Failure to Observe These Instructions Can Cause Personal Injury to Machine Operator, By-standers or Possible Machine Damage. • NEVER attempt to service or perform maintenance functions while machine is plugged into an electrical outlet.
  • Page 2: Cleaning Solutions

    5. Use neutral pH, water-based products only - NO SOLVENTS! INSPECTION: Carefully unpack and inspect the PREDATOR CXC100 for shipping damage. Each unit is tested and inspected before shipment. Any damage incurred during shipping is the responsibility of the carrier, who should be notified immediately.
  • Page 3: Pump Operation

    SET-UP: Fill the holding tank with clear water and add the detergent of your choice. Mix well. Plug in the electrical cord and turn on the pump and vacuum switches. You are now ready to begin cleaning. PUMP OPERATION: The 100 PSI-pump is a "demand" type design. The pump runs only when you depress the lever on your wand.
  • Page 4 PREDATOR CXC100 PARTS LIST ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION 4091011 Metal “T” Handle #31A 9120900 1/4 Hex Nut, Ny-Lok, ZP 4091231 Drain Gate 4090611 1/3-20 X 3/4” Hex Bolt, ZP 4090581 Screw, 10-32 X 5/8, S/S...
  • Page 5 PREDATOR CXC100 26 27 PREDATOR CXC100...
  • Page 6: Treatment Methods

    COMMON STAINS AND CLEANING TREATMENTS TREATMENT METHODS First: Remove excess material by blotting to absorb liquids, or by scraping with a dull edge (butter knife) is a solid. Second: Clean the remaining stain as directed by the chart below. Always follow the direction on the container.
  • Page 7: Wiring Diagram

    PREDATOR CXC100 WIRING DIAGRAM 120V & 240V *NOTE: Switches sit upside down in switch plate. BLACK CORD 1 WHITE GROUND ORANGE VAC 1 VAC 2 ORANGE WHITE BLUE PUMP 6/13/01...
  • Page 8 PHONE (419) 531-3761 • FAX (419) 531-3761 ® Enterprises, Inc. European Distribution Centre Unit II, Pinfold Trading Estate 55 Nottingham Road STAPLEFORD, NOTTINGHAM NG9 8AD ENGLAND U.K. PHONE: (44) 0115 939 1568 FAX: (44) 0115 949 0615 PREDATOR CXC100 ORIG. 05-00 9094002 WHW REV. B 08-01...
