Unitest TELARIS LOOP Instruction Manual page 17

Table with limit values for short-circuit currents for fuses according to DIN VDE 0636 characteristics gL:
Nominal current
during
6A
10A
16A
25A
40A
63A
100A
AC Voltage VAC
Range
0...300V
Mains Frequency f
Range
10..200Hz
Contact voltage detection:
UL= 25V..................................................25V
UL= 50V..................................................50V
*For large mains voltage fluctuations during measurements, the measurement error may increase.
Auto power off: ......................................after approx. 5 min.
Power supply: ........................................1x9V block, 6LR61
current consumtiom: ..............................approx. 20mA
Battery life:..............................................at average usage, approx. 1 year
Fuse: ......................................................1A / 250V slow blow 5x20mmI
Dimensions (LxWxH): ............................235x103x70mm (without plug)
Weight: ..................................................500g incl battery
Environmental conditions:
Relative humidity: ..................................max 80%, non condensing
Overvoltage category: ............................CAT III / 300V to ground
Pollution degree: ....................................2
Protective class / degree: ........................II / IP50
Height above MSL:..................................up to 2000m
Temperature ranges (operating): ............0°C ... 40°C
Temperature ranges (storage): ..............-20°C ... +70°C
Min. display for safe tripping
5s (in Amps)
32
53
81
135
228
414
714
Resolution Tolerance
1V ±(1% rdg. +3 Digit)
Resolution Tolerance
0,1 Hz ±(1% rdg. +2 Digit)
Min. display for safe tripping
during 0.2s (in Amps)
67
110
163
312
490
979
-
Overload Protection
400V / RI = 1 MΩ
Overload Protection
400V / RI = 1 MΩ
-5% /+15%
-5% /+15%
Warranty
