OPERATING MANUAL
OPERATING MANUAL
MW / SW / FM STEREO
24 MEMORY PRESETS
PRESET
/ TIMER / SLEEP
/ DIRECT ENTRY
MANUAL TUNING / SEEK TUNING
MONO / STEREO SELECTABLE
LOCK SWITCH
AUTO CUT OFF WITH LOWER POWER
LIGHT INDICATOR
DX / LOCAL SWITCH
BUILT - IN SPEAKER
2 WAY POWER WITH AC / DC OPERATIONS
EXTERNAL ANTENNA JACK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DEGEN DE106
Summary of Contents for DEGEN DE106
- Page 1 OPERATING MANUAL OPERATING MANUAL MW / SW / FM STEREO 24 MEMORY PRESETS PRESET / TIMER / SLEEP / DIRECT ENTRY MANUAL TUNING / SEEK TUNING MONO / STEREO SELECTABLE LOCK SWITCH AUTO CUT OFF WITH LOWER POWER LIGHT INDICATOR DX / LOCAL SWITCH BUILT - IN SPEAKER 2 WAY POWER WITH AC / DC OPERATIONS...
-
Page 2: Location Of Controls
LOCATION OF CONTROLS TELESCOPIC POWER VOLUME SLEEP STAND ANTENNA LOCK STEREO/MONO 0...9 SCAN+/HR EXT.ANT.JACK SCAN-/MIN RESET EARPHONE JACK DC JACK DX/LOCAL ENTER LIGHT BAND BATTERY METER COMPARTMENT MODE/ALARM MEMO/TIME... -
Page 3: Lcd Identification
BATTERY OPERATION LCD IDENTIFICATION Slide the battery cover in the direction of the arrow. Insert two AA batteries with correct polarity as shown. Slide back the battery cover, make sure that it is snapped into place. FREQUENCY / TIME FM STEREO INDICATOR When the batteries become weak, please reduce FM BAND the volume or replace the batteries with new ones. -
Page 4: Ac Adapt Operation
Do not mix different types together (Alkaline, If the AC adaptor is connected when regular Carbon-Zinc, Nickel Cadmium etc.), or old batteries are installed, the unit automatically batteries with new ones. switches to the AC adaptor power and the batteries When the unit is not being used for a long period are not used. -
Page 5: Lock Function
TURN ON / OFF THE UNIT LOCK FUNCTION 1. Power On / Off When the unit is in lock status, lock indicator Press POWER to turn on the unit manually, the appears in the display. station you stoped listen last operation is heard. None of the buttons except LIGHT, MONO / ST and RESET button will work. -
Page 6: Band Selection
BAND SELECTION Press BAND button repeatedly to select FM, AM, SW1, SW2, the corresponding band indicator will show in the display. The unit will shut off automatically after the adjusted sleep time. To turn off the unit during sleep time, press SLEEP . To quit from sleep mode but listening to the Repeat BAND... -
Page 7: Tuning Into A Station
If tuning become slowly in a frequency range, TUNING IN TO A STATION try manual tuning to see if there are some weak Ê Ö ¶ ¯ Ë Ñ Ë ÷ 1. Manual Tuning stations. 3. Listening to Preset Stations Press SCAN button(+ ) to tune in to a ¼... -
Page 8: Presetting Stations
In general, set the switch in DX position 4. Direct Frequency Entry unless there is strong interference or when Direct frequency entry makes it extremely easy to LOCAL you are listening to local stations. tune in to a station if you knows its exact frequency. PRESETTING STATIONS Press BAND to select the... -
Page 9: Clock Set
If a station is already stored, the new station with the same preset number replaces the old one. If you can not complete step 3 while the indications 7,8,9,0 is invalid to store stations. flash time, repeat from step 1. Make sure to press STORE TIME after clock setting, CLOCK SET otherwise setting is failed. -
Page 10: Alarm Clock Setting
ALARM CLOCK SETTING There is 5 second's interval between each step, if no operation is set to next step, current Turn off the unit, press operation is cancel. MODE TIMER into Make sure to press STORE TIME after alarm ALARM setting mode clock setting, otherwise the setting may invalid. -
Page 11: Using Antenna
SW Reception USING ANTENNA Telescopic antenna functions as SW antenna. MW Reception Extending the antenna Magnetic antenna inside the unit functions as MW straight upward to get the antenna, it is strongly effected by the reception direction. best reception. When listening to MW broadcast, reorient the unit to find the position which gives the best reception. -
Page 12: Specifications
CAUTIONS SPECIFICATIONS On Handling Avoid exposure to temperature extremes, direct sunlight, 1. Frequency Range moisture, sand, dust or mechanical shock. Should anything wrong with the radio, please remove the 87.5 - 108.0 MHz battery and have the unit checked by qualified personnel 522 - 1620 before operating it any further.
