AFBR-800EVK and AFBR-800EVB
MiniPOD Evaluation Kit and Evaluation Board
For MiniPOD Pluggable Parallel-Fiber-Optics Modules
User Guide
Introduction
The purpose of this evaluation kit an evaluation board is
to provide the designer with a convenient way to evaluate
the electrical and optical performance of the Avago
Technologies' Twelve-Channel MiniPOD transmitter and
receiver modules. This user guide off ers a description
of the AFBR-800EVB evaluation board along with basic
operating instructions.
The AFBR-800EVB Evaluation Rev. 4 board is to be used in
conjunction with the Avago Technologies AFBR-81uVxyZ
and AFBR-82uVxyZ family of Tx and Rx MiniPOD modules.
The AFBR-81uVxyZ and AFBR-82uVxyZ are twelve-chan-
nel, pluggable, parallel, fi ber-optic MiniPOD transmitter
and receiver modules, respectively. These high perfor-
mance modules are intended for short-range multi-lane
data communication and interconnect applications.
Twelve data lanes transport greater than 120 Gbps
aggregate bandwidth. Each lane can operate at 10.3125
Gbps up to 100 m using OM3 fi ber. These modules are
designed to operate over multimode fi ber systems using
a nominal wavelength of 850nm. The electrical interface
uses a 9x9 MEG-Array connector with 1.27 mm pitch and
4mm contact mate height. The optical interface uses
a 12-fi ber Prizm™ to MPO/MTP connector (included in
the kit). These modules incorporate Avago Technolo-
gies' proven integrated circuit and VCSEL technology to
provide reliable long life, high performance, and consis-
tent operation.
MiniPOD Eval Board (AFBR-800EVB) contents:
 1 x Evaluation board
 2 x pair DC connection wires
 CD-ROM which includes GUI software and User Guide
MiniPOD Eval kit (AFBR-800EVK) contents:
 1 x Evaluation board
 2 x pair DC connection wires
 MTP Adapter
 Prizm to Male MTP cable(Flat ribbon)
 Prizm to Male MTP cable(Round ribbon)
 CD-ROM which includes GUI software and User Guide

iPort USB interface (MIIC-204G)
Avago Technologies Confi dential. Restricted under NDA
Features
 The AFBR-800EVB Evaluation board can be used with
the
– Avago Technologies AFBR-81uVxyZ 12 channel
transmitter
– Avago Technologies AFBR-82uVxyZ 12 channel
receiver
 Access to Low speed signals, for example, Int_L/Reset_L
 24 Side mounted SMA connectors to connect to 12
diff erential TX or RX high speed lanes
Figure 1. MiniPOD Twelve-Channel Transmitter and Receiver
Modules with round cable option
Figure 2. MiniPOD Twelve-Channel Module Evaluation Board

Advertisement

loading
Need help?

Need help?

Do you have a question about the AFBR-800EVK and is the answer not in the manual?

Questions and answers

Summary of Contents for Avago AFBR-800EVK

  • Page 1  The AFBR-800EVB Evaluation board can be used with The purpose of this evaluation kit an evaluation board is to provide the designer with a convenient way to evaluate the electrical and optical performance of the Avago – Avago Technologies AFBR-81uVxyZ 12 channel Technologies’ Twelve-Channel MiniPOD transmitter and transmitter receiver modules.
  • Page 2 Recommended Equipment List AFBR-800EVB Evaluation Kit optical component part numbers 1. Avago Technologies MiniPOD module and AFBR- 800EVB Evaluation Board (Figure 1 and Figure 2) MPO Adapter: Molex 106114-1200 (key-up / key-down) 2. 3.3 V and 2.5 V power sources.
  • Page 3 4. iPort Interface connectors 5. Reset button Figure 4. Evaluation Board Diagram. The Evaluation Board depicted can run either 12 TX Channels or 12 RX Channels, depending on which module is plugged into the board. Avago Technologies Confi dential. Restricted under NDA...
  • Page 4 60h to 6Fh. respectively, in Figure 4. 3. Monitor points for the SDA, SCL, and Intl (directly from C. Connect iPort (supplied with the AFBR-800EVK but the MiniPOD module) NOT supplied with the AFBR-800EVB) to in Figure 4 to communicate to the DUT using a Host computer;...
  • Page 5 1. AFBR-81uVxyZ and AFBR-82uVxyZ Product Data Sheet enclosed CD. 2. “Critical Design Guidelines for Successful Application of Parallel Fiber Optic Modules”. Avago Technologies, **Note: This bill of materials is subject to change at any Inc. Application Note 1280 time. However, at the time of writing of this document, the BOM is accurate.
  • Page 6 Avago MiniPOD Software User Guide Installing the Avago MiniPOD Viewer Software matically. If this does not happen open ‘My Computer’ and Included with the Avago Evaluation Board is a CD that double-click the CD-ROM drive. contains the self-install customer user interface software.
  • Page 7 Once installed, an icon entitled “Avago’s MiniPOD Viewer” Connecting the Avago MiniPOD Evaluation Board will appear on the desktop along with an Avago ReadMe Before starting the GUI software it is recommended that text fi le which includes detailed reference information the user connect and power up the MiniPOD Evaluation about the GUI installation and revision.
  • Page 8 COM port assignments on the computer. clicking the desktop icon “Avago MiniPOD Viewer”. Once the software starts the Avago Technologies front page will The user can click the “About” tab to learn about the appear on the screen while the PC searches the COM ports Release version of the MiniPOD Evaluation software.
  • Page 9 ‘MiniPOD Tab’ . speeds. This tab serves as the front page and shows pictures of the MiniPOD Evaluation board as well as MiniPOD Trans- ceivers. Figure 10. MiniPOD Tab Avago Technologies Confi dential. Restricted under NDA...
  • Page 10 This tab serves as the front page and shows pictures of the MiniPOD Evaluation board as well as MiniPOD Trans- window will open starting with the ‘MiniPOD Tab’ . ceivers. Figure 11. Register Tab Avago Technologies Confi dential. Restricted under NDA...
  • Page 11 Also, by clicking an address in the “Register List” window, the corresponding register address in Hexadecimal is highlighted in the “Field Display” matrix window. Figure 12. Register List and Decoded Data Window Avago Technologies Confi dential. Restricted under NDA...
  • Page 12 Number” the report will be saved in the default folder just been written to the device. “Read Page” or “Read in location: C:\Program Files\Avago\MiniPOD Viewer\ Register” only updates the current page or current Reports\ register respectively. Figure 13. Register Reports Avago Technologies Confi dential. Restricted under NDA...
  • Page 13  High speed channel control: e.g. Turn on/off Tx Channel Disable, Turn on/off Tx Squelch Disable  Alarm channel control: e.g. TX LOS Mask  Tx Equalization settings on a per channel basis Avago Technologies Confi dential. Restricted under NDA...
  • Page 14  High speed channel control: e.g. Turn on/off Rx Channel Disable, Turn on/off Rx Squelch Disable  Alarm channel control: e.g. RX LOS Mask  Rx Amplifi er and Pre-Emphasis settings on a per channel basis Avago Technologies Confi dential. Restricted under NDA...
  • Page 15 Tx/Rx Host Board Pattern - TOP VIEW Vcc33 Noise inj 3.3V J18 3.3V 3.3V Vcc33 10 uH 10.0uF 0.1uF 2.5V J19 2.5V 2.5V Vcc25 10 uH 10.0uF 0.1uF J20 Gnd J21 Gnd Vcc25 Noise inj Avago Technologies Confi dential. Restricted under NDA...
  • Page 16 2.5V MISO ADR2 Vcc25 MOSI ADR1 Vcc33 Ureset ADR0 3.3V JTAG HEADER 2X3 4 HEADER Vcc33 Vcc33 Vcc33 Vcc33 Vcc33 OPEN OPRN OPEN OPEN INTL OPEN OPEN OPEN INTL Ureset Amux0 Amux1 TOSC2 Avago Technologies Confi dential. Restricted under NDA...
  • Page 17 0.22uF 0.22uF 0.22uF 0.22uF 0.22uF 0.22uF 0.22uF D10+ +D10 D10+ 0.22uF 0.22uF D10- -D10 D10- 0.22uF 0.22uF D11+ +D11 D11+ 0.22uF 0.22uF D11- -D11 D11- 0.22uF 0.22uF Vcc33 Vcc25 200R 200R DV33 DV25 Avago Technologies Confi dential. Restricted under NDA...
  • Page 18: Appendix A - Molex Connector Drawing
