PARAMETER
Physical/Electrical – DHU
Weight
RF connection
Alarm connection
Optical connection
DC pwr output connection
Power input
AC power connection
Power consumption
Current rating
Physical/Electrical – DEU
Weight
Optical connection
DC pwr output connection
Power input
AC power connection
Power consumption
Current rating
Physical/Electrical – DRU
Weight
RF connection
800 MHz antenna types
1900 MHz antenna types
Optical connection
DC pwr input connection
Power input
DC power cable
maximum length (Cat-3
or -5 cable)
Power consumption
Current rating
Note: The noise from all remotes is added at the host. Given N units with identical gain and noise,
the formula applies exactly. Slight unit to unit noise figure and gain variations make this a very useful
approximation.
Table 5. System Specifications, continued
SPECIFICATION
18.5 lbs (8.4 kg)
Type N
Screw terminals (14–26 AWG)
Duplex LC transceiver
RJ-45
120/240 Vac, 50–60 Hz
IEC 320
250 W
85–250 Vac, 2 Amp input
18.5 lbs (8.4 kg)
Duplex LC transceiver
RJ-45
120/240 Vac, 50–60 Hz
IEC 320
250 W
85–250 Vac, 2 Amp input
1.5 lbs (708 g)
SMA
Ceiling mount omni directional
70º directional panel
90º directional panel
Ceiling mount hallway
Ceiling mount omni directional
90º directional panel
Ceiling mount hallway
Duplex LC transceiver
RJ-45
34 to 48 Vdc
500 meters (1,641 ft)
17 W
48 Vdc, 350 mA input
ADCP-75-110 • Issue 2B • July 2001
REMARKS
Female
NO, NC, and COM
Female
Male
Maximum
Female
Male
Maximum
Female
2.5 dBi gain
8 dBi gain
7.5 dBi gain
4 dBi gain
2.5 dBi gain
7.5 dBi gain
4 dBi gain
Female
Any distance beyond 500 meters
requires alternate power sourcing
Typical
