- Page 1 PORTABLE REFRIGERATION CFX SERIES CFX100W Compressor Fridge/Freezer Operating manual...
-
Page 3: Table Of Contents
CFX100W Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it. The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation. -
Page 4: Explanation Of Symbols
Explanation of symbols CFX100W Troubleshooting ..........28 Guarantee . -
Page 5: Safety Instructions
CFX100W Safety instructions Safety instructions General safety WARNING! • Do not operate the cooling device if it is visibly damaged. • If this cooling device's power cable is damaged, it must be replaced by the manufacturer, customer service or a similarly qualified person in order to prevent safety hazards. -
Page 6: Operating The Cooling Device Safely
Safety instructions CFX100W • Never pull the plug out of the socket by the cable. • If the cooling device is connected to the DC power supply: Discon- nect the cooling device and other power consuming devices from the battery before connecting a quick charging device. •... -
Page 7: Scope Of Delivery
Available as accessory (not included in scope of delivery): Designation Ref. no. Insulated protective cover CFX-IC95100 9108300206 Fridge slide CFX-SLD95/100 9105306558 Fridge stand (up to 80 kg load) 9108400101 Visit the Dometic website (see back page) for information about a WiFi app with control-, display- and alarm functions. -
Page 8: Intended Use
Intended use CFX100W Intended use The cooler is suitable for cooling and freezing foods. The cooler is designed to be operated from: • a DC auxiliary battery • an AC power supply The cooling device is intended to be used in household and similar applications such •... -
Page 9: Scope Of Functions
CFX100W Function description Scope of functions • Power supply with priority circuit for connecting to the AC mains • Three-level battery monitor to protect the battery • Display with temperature gauge in °C and °F switches off automatically at low battery voltage •... - Page 10 Function description CFX100W Operating panel ° – Item Description Explanation Switches the cooler on or off when the button is pressed for between one and two seconds “P Status indication POWER ” LED lights up green: Compressor is on LED lights up orange: Compressor is off LED flashes orange: display switched off automatically due...
- Page 11 CFX100W Function description Connection sockets 100-240V~AC 12/24V DC NORMAL EMERGENCY OVERRIDE Item Description Connection socket AC voltage supply Fuse holder Emergency switch (when fitted) USB port for power supply Connection socket DC voltage supply...
-
Page 12: Operation
Operation CFX100W Operation Before initial use NOTE Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the chapter “Cleaning and maintenance” on page 27). Reversing the lid opening direction The lid hinges can be moved to the opposite side if you want to open the lid from the opposite direction. - Page 13 CFX100W Operation ➤ Remove the two plastic covers from the centre hinge. ➤ Remove the four screws from the centre hinge and take off the hinge. ➤ Remove the plastic cover from new centre hinge position with a small screw- driver and re-fit to old hinge position.
- Page 14 Operation CFX100W ➤ Remove the three plastic plugs per latch from the new latch position with a small screwdriver. ➤ Remove the three screws per latch and take off the latches. ➤ Re-fit the plastic plugs to the old latch positions. ➤...
-
Page 15: Energy Saving Tips
CFX100W Operation Selecting the temperature units Temperature display units can be switched between Celsius and Fahrenheit as follows: ➤ Switch on the cooler. ➤ Press the “SET” button (fig. 3 4, page 10) twice. ➤ Use the “UP +” (fig. 3 7, page 10) or “DOWN –” (fig. 3 6, page 10) buttons to select Celsius or Fahrenheit. - Page 16 Operation CFX100W Using supplied DC connection cable NOTICE! Danger of damage! For protection of the device the DC cable supplied is fitted with a fuse. Do not remove the fuse. Only use the DC cable supplied. ➤ Before starting up the device for the first time, check whether the operating voltage and the battery voltage correspond (see type plate).
- Page 17 CFX100W Operation Extended DC hard-wiring NOTICE! Danger of damage! To avoid drops in voltage and therefore performance, keep the cable as short as possible and only disconnect it when necessary. For this reason avoid additional switches, plugs or power strips. ➤...
- Page 18 Operation CFX100W ➤ Before starting up the device for the first time, check whether the operating voltage and the battery voltage correspond (see type plate). ➤ Run the extended wiring from DC cable in-vehicle connection point (4) to the battery (6). ➤...
- Page 19 CFX100W Operation Connecting to an AC power supply (e.g. in the home or office) DANGER! Danger of electrocution! • Never handle plugs and switches with wet hands or if you are standing on a wet surface. • If you are operating your cooler on board a boat from a AC power supply, you must install a residual current circuit breaker between the AC power supply and the cooler.
-
Page 20: Using The Battery Monitor
Operation CFX100W Using the battery monitor The device is equipped with a multi-level battery monitor that protects your vehicle battery against excessive discharging when the device is connected to the on-board DC supply. If the cooler is operated when the vehicle ignition is switched off, the cooler switches off automatically as soon as the supply voltage falls below a set level. -
Page 21: Using The Cooler
CFX100W Operation Using the cooler NOTICE! Danger of overheating! Ensure at all times that there is sufficient ventilation so that the heat that is generated during operation can dissipate. Ensure that the ventilation slots are not covered. Make sure that the device is sufficiently far away from walls and other objects so that the air can circulate. -
Page 22: Setting The Temperature
The cooler can be controlled via WiFi using an app that you can install on a compatible device. The app has control, display and alarm functions. For further information go to the Dometic website for your country (see back page). Note that the app may not be available in your country. -
Page 23: Set Brightness Of Display
✓ In both displays “rES” will blink several times before returning to the previous dis- play. ✓ The WiFi settings have been reset to factory settings. For additional information visit the Dometic website from which you downloaded the app. Set brightness of display The display brightness can be dimmed for low ambient light conditions. -
Page 24: Using The Emergency Switch
Operation CFX100W Using the emergency switch The emergency switch (fig. 4 3, page 11) is located below the control panel. For normal operation the switch is in the “NORMAL USE” position. ➤ If an electronic control failure occurs, slide the switch to “EMERGENCY OVERRIDE”... -
Page 25: Defrosting The Cooler
CFX100W Operation 7.12 Defrosting the cooler Humidity can form frost in the interior of the cooling device or on the evaporator. This reduces the cooling capacity. Defrost the device in good time to avoid this. NOTICE! Danger of damage! Never use hard or pointed tools to remove ice or to loosen objects which have frozen in place. -
Page 26: Replacing The Dc Cable Fuse
Operation CFX100W 7.14 Replacing the DC cable fuse ➤ Disconnect the power supply from the cooler. ➤ Remove the protective cover (2) ➤ Replace the defective fuse (1) with a new fuse of the same type and rating (Automotive standard blade fuse, 15 A). ➤... -
Page 27: Cleaning And Maintenance
CFX100W Cleaning and maintenance ➤ Replace the defective light PCB with a new one. ➤ Fit new PCB using reverse of removal instructions. ➤ Press the transparent cover back into the housing. ➤ Reconnect the power supply to the device. Cleaning and maintenance WARNING! Always disconnect the device from the power supply before you clean... -
Page 28: Troubleshooting
Troubleshooting CFX100W Troubleshooting Fault Possible cause Suggested remedy Device does not Battery voltage is too Test the battery and charge it as needed. function, LED does low. not glow. The DC cable fuse is Replace the DC fuse, see chapter defective. -
Page 29: Guarantee
CFX100W Guarantee Guarantee The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your country (see the back of the instruction manual for the addresses) or your retailer. For repair and guarantee processing, please include the following documents when you send in the device: •... -
Page 30: Technical Data
Technical data CFX100W Technical data CFX100W Ref. no.: 9105306556 Connection voltage: 12/24 Vg and 100 – 240 Vw Rated current: 12 Vg: 10.5 A 24 Vg: 5.0 A 100 Vw: 1.25 A 240 Vw: 0.48 A Cooling capacity: +10 °C to –22 °C (+50 °F to –8 °F) Category: Energy efficiency class: Energy consumption:... - Page 31 CFX100W Technical data NOTE If the ambient temperature is above +32 °C (+90 °F), the minimum temperature cannot be attained. Test/certificates: The coolant circuit contains R134a. Contains fluorinated greenhouse gases Hermetically sealed equipment...
- Page 32 Dometic (Pty) Ltd. Dometic Branch Office Belgium MEXICO Regional Office Zincstraat 3 Dometic Mx, S. de R. L. de C. V. South Africa & Sub-Saharan Africa B-1500 Halle Circuito Médicos No. 6 Local 1 Unit 6-7 on Mastiff Linbro Park ...
