Sharp 21YF30 Service Manual page 5

SETTING MODE (SECOND STAGE)
EEPROM ITEMS OSD
STRAPQ-BG F01
STRAPQ-I F02
STRAPQ-DK F03
STRAPQ-M F04
STRAPQ-574 F05
C.CLIP-LVL F06
RGB-CLIP F07
BS F08
ABCL F09
ABCL-GAIN F10
S-OUT-LVL F11
VIF-G F12
SHPG F13
SHPG-P F14
SHPG-S F15
SHPG-N4 F16
SHPG-N3 F17
YDL F18
YDL-P F19
YDL-S F20
YDL-N4 F21
YDL-N3 F22
YDL-AV F23
YDL-AV-P F24
YDL-AV-S F25
YDL-AV-N4 F26
YDL-AV-N3 F27
YDL-YUV F28
COL-AV (OFFSET) F29
COL-P (OFFSET) F30
COL-S (OFFSET) F31
COL-N4 (OFFSET) F32
COL-N3 (OFFSET) F33
COL-ADJ (OFFSET) F34
SHP-AV (OFFSET) F35
SHP-YUV (OFFSET) F36
SHP-P (OFFSET) F37
SHP-S (OFFSET) F38
SHP-N4 (OFFSET) F39
SHP-N3 (OFFSET) F40
TINT-AV (OFFSET) F41
TINT-ADJ (OFFSET) F42
TINT-YUV-ADJ (OFFSET) F43
R-R (OFFSET) F44
B-R (OFFSET) F45
R-B (OFFSET) F46
B-B (OFFSET) F47
DT F48
DT-P F49
DT-S F50
DT-N4 F51
DT-N3 F52
TRAP F53
TRAP-P F54
TRAP-S F55
TRAP-N4 F56
TRAP-N3 F57
DATA LENGTH INITIAL DATA FIX/ADJ/AUTO REMARK
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0~127 95 FIX
0~7 4 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 1 FIX
0~7 5 FIX
0~7 5 FIX
0~7 7 FIX
0~7 5 FIX
0~7 5 FIX
0~7 6 FIX
0~7 6 FIX
0~7 7 FIX
0~7 6 FIX
0~7 6 *FIX BUS SET UP
0~7 6 FIX
-31~0~+31 +10 *FIX BUS SET UP
-30~0~+31 0 FIX
-31~0~+31 +9 FIX
-31~0~+31 -8 FIX
-31~0~+31 -7 FIX
-31~0~+31 0 *FIX BUS SET UP
-31~0~+31 +5 FIX
-31~0~+31 0 FIX
-31~0~+31 0 FIX
-31~0~+31 -5 FIX
-31~0~+31 0 FIX
-31~0~+31 0 FIX
-63~0~+63 0 *FIX BUS SET UP
-63~0~+63 0 *FIX BUS SET UP
-63~0~+63 0 FIX
-63~0~+63 0 FIX
-63~0~+63 -9 FIX
-63~0~+63 -6 FIX
-63~0~+63 +8 FIX
0/1 0 FIX
0/1 0 FIX
0/1 1 FIX
0/1 0 FIX
0/1 0 FIX
0~3 2 FIX
0~3 2 FIX
0~3 2 FIX
0~3 2 FIX
0~3 2 FIX
5-1
SETTING MODE (SECOND STAGE)
EEPROM ITEMS OSD
1W-TV F58
1W-AV F59
V-FREE (NO SYNC) F60
AFC2 (NO SYNC) F61
GAMMA F62
BS-D/C F63
BS-GAIN F64
OM-DET F65
SL-TV F66
SL-AV F67
SL-YUV F68
VD2/VD1/AS/FBP-TV F69
VD2/VD1/AS/FBP-AV F70
VD2/VD1/AS/FBP-YUV F71
VDL F72
UDL F73
AUTO-SCM-KIL-TV F74
SCM-YDL F75
SECAM-BGP F76
N45 F77
DL-REV F78
DL-OUT F79
TXT-POS-H (TELETEXT) F80
TXT-POS-V (TELETEXT) F81
OSD-POS F82
CP F83
SMALL-SURR (S-CTRL) F84
SUB-BASS (S-CTRL) F85
SUB-TREB (S-CTRL) F86
AGC-ADJ (S-CTRL) F87
AGC-SW-OFF (NICAM) F88
AGC-GAIN-ADJ (NICAM) F89
FM-LEVEL-ADJ (NICAM) F90
IGR-LEVEL-ADJ (NICAM) F91
NICAM-BG-LVL-ADJ (NICAM) F92
NICAM-I-LVL-ADJ (NICAM) F93
NICAM-DK-LVL-ADJ (NICAM) F94
NICAM-LOW-ERR-LIM (NICAM) F95
NICAM-UPP-ERR-LIM (NICAM) F96
IGR-GAIN-ADJ (IGR) F97
FM-ID-SPEED (NICAM) F98
NICAM-AUTO-MUTE F99
ANA-OSD F100
AUTO-SCM-KIL-AV-YUV F101
AFC1-GAIN-TV F102
AFC1-GAIN-AV F103
AFC1-GAIN-YUV F104
CON-REDUCE F105
TAKE-OFF-TV F106
TAKE-OFF-AV F107
TAKE-OFF-YUV F108
C-ANGLE (103 DEG/ 95 DEG) F109
STD-BY-WO-BRIGHT F110
AC-FAIL-WO-BRIGHT F111
FORCED-SCM-KIL-TV F112
FORCED-SCM-KIL-AV-YUV F113
DATA LENGTH INITIAL DATA FIX/ADJ REMARK
0/1 0 FIX
0/1 1 FIX
0/1 0 FIX
0/1 0 FIX
0~3 0 FIX
0~15 10 FIX
0/1 0 FIX
0/1 0 FIX
0~7 2 FIX
0~7 4 FIX
0~7 4 FIX
0~15 6 FIX
0~15 14 FIX
0~15 14 FIX
0~3 0 FIX
0~3 0 FIX
0~3 1 FIX
0/1 0 FIX
0~3 0 FIX
0/1 0 FIX
0/1 0 FIX
0/1 0 FIX
0~63 30 FIX
0~63 34 FIX
0~127 9 FIX
0/1 1 FIX
0/1 0 FIX
0~7 6 *FIX BUS SET UP
0~7 0 *FIX BUS SET UP
0~4 0 *FIX BUS SET UP
0(dis)/1(ena) 1 FIX
0~31 16 FIX
-15~0~+15 0 FIX
-15~0~+15 +1 FIX
-15~0~+15 -2 FIX
-15~0~+15 +3 FIX
-15~0~+15 -1 FIX
0~255 35 FIX
0~255 70 FIX
-6~0~+7 0 FIX
0~3 1 FIX
0/1 0 FIX
0(Dig)/1(Ana) 0 FIX
0~3 1 FIX
0~3 0 FIX
0~3 3 FIX
0~3 3 FIX
0(0%)~1(25%)~2(50%) 0 FIX
0/1 1 FIX
0/1 0 FIX
0/1 0 FIX
0 (103deg) / 1 (95deg) 1 FIX
0~255 255 *FIX BUS SET UP
0~255 255 FIX
0~3 2 FIX
0~3 2 FIX
5-2
