Summary of Contents for D-Link DGS-1026MP
-
Page 2: Table Of Contents
D-Link Switch User Manual Table of Contents About This Guide ............................. 1 Terms/Usage ..............................1 Copyright and Trademarks ..........................1 Product Introduction ............................2 Package Contents ............................2 Product Overview ............................2 Front Panel ..............................2 Rear Panel ..............................2 Indicator LEDs ............................ -
Page 3: About This Guide
This guide provides instructions to install the D-Link DGS-1026MP 26-Port Unmanaged PoE Gigabit Switch. Terms/Usage In this guide, the term “Switch” (first letter capitalized) refers to the DGS-1026MP, and “switch” (first letter lower case) refers to other Ethernet switches. Some technologies refer to the terms “switch”, “bridge” and “switching hubs”... -
Page 4: Product Introduction
The first 24 10/100/1000 Mbps ports of the DGS-1026MP support IEEE 802.3af/at Power over Ethernet (PoE) and are capable of supplying up to 30 watts of power per port. The DGS-1026MP is easy to install and requires no configuration. With these features combined, the DGS-1026MP provides an ideal solution for Small and Medium Business (SMB) users who have limited budgets but require PoE capability in a switch. -
Page 5: Indicator Leds
D-Link Switch User Manual Item Description Kensington The DGS-1026MP adds additional value by providing users with a simple, reliable, built- Security Lock in security solution to prevent theft in the form of a Kensington Security Slot on the rear panel of the Switch. -
Page 6: Hardware Installation
D-Link Switch User Manual Hardware Installation This chapter provides more detailed instructions for grounding and installing the DGS-1026MP. CAUTION: Ensure the power cable is disconnected before installing the switch. Installation Precautions For safe installation and operation of the Switch, it is recommended to: •... -
Page 7: Attaching The Rubber Feet
Attaching the Rubber Feet The DGS-1026MP comes with a strip of four adhesive rubber pads that can be placed on the bottom of the device to prevent the Switch from damaging the surface it is placed on. This allows the Switch to be placed virtually anywhere. -
Page 8: Powering On The Switch
Switch back in. Connecting the Switch After the DGS-1026MP has been successfully installed, the Switch can be integrated into the network through one of the following three connection methods: NOTE: All Ethernet ports auto-detect MDI/MDIX, port speed (10, 100, or 1000 Mbps), and duplex mode of the device connected to the Switch. -
Page 9: Connect To A Hub Or Switch
D-Link Switch User Manual Connect to a Hub or Switch Use a straight or crossover cable to connect the Switch to another switch or hub. Figure 9 – Connecting the Switch to another switch or hub Connect to a Network Backbone or Server Use any port on the device to connect the Switch to a network backbone or network server. -
Page 10: Understanding The Switch's Features
The DGS-1026MP supports many PoE features to guarantee the safety and stability of the Switch and the connected powered devices. PoE Power Budget: The total PoE budget of the DGS-1026MP is limited to a maximum of 370 watts to both protect the Switch and to stabilize the power being transmitted to the PoE-powered devices. -
Page 11: Appendix A - Technical Specifications
D-Link Switch User Manual Appendix A - Technical Specifications Hardware Specifications Key Components / Performance Operation Humidity: 0% to 95% RH Storage Humidity: 0% to 95% RH Switching Capacity: 52 Gbps Max. Forwarding Rate: 38.69 Mpps Forwarding Mode: Store-and-forward Emission (EMI) Certifications... -
Page 12: Appendix B - Regulatory Statements
D-Link Switch User Manual Appendix B - Regulatory Statements FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
