T
HE USER INTERFACE
Navigator
The main window
• Several tool bars that are used to issue commands.
• Several control panels that are used to set measurement parameters.
• The Navigator that is used to quickly select between the most often used
operating windows and panels.
• The Status bar that displays the state of the instrument.

Operating windows

Operating windows are used to perform specific operations with the micro-
scope. These operations are controlled using specific panels and tool bars
that are part of these windows. The Operating windows are:
• Positioning window: positioning the tip with respect to the sample, with
the aid of the built-in optical microscope (chapter
88
Main menu
Panel
Tool bar
Operating window Status bar
Positioning (p.115)).
