Page 1 ® ABB i-bus Fan Coil Actuators FCA/S Product Manual...
Page 3: Table Of Contents
® ABB i-bus Contents General ....................5 Using the product manual ......................5 1.1.1 Notes ............................6 Product and functional overview ....................7 1.2.1 Product overview ..........................7 1.2.2 Functional overview ........................8 ® 1.2.3 Integration in the i-bus Tool ......................9 Device technology ................11 Fan Coil Actuator FCA/S 1.1.1.2, PWM, MDRC .................
Page 4 ® ABB i-bus Contents Commissioning ....................65 Overview ............................ 65 3.1.1 Functions of the inputs ....................... 66 3.1.2 Output functions ......................... 67 Parameters ..........................68 Parameter window General – Settings..................69 3.2.1 Parameter window Manual operation – Settings ................ 72 3.2.2...
Page 5 ® ABB i-bus Contents Planning and application ................237 Fan output ..........................238 4.1.1 Fan operation ........................... 238 4.1.1.1 Fan with changeover switch ..................... 240 4.1.1.2 Fan with step switch ......................... 240 4.1.2 Automatic operation ........................240 4.1.3 Direct operation ........................242 4.1.4...
Page 7: General
® ABB i-bus General General Fans, blower convectors and fan coil units are used for distributed heating and cooling applications. They are installed rooms and powered via central heating and cooling systems. Using fans, room temperature can be quickly adjusted to suit individual preferences.
Page 8: Notes
® ABB i-bus General 1.1.1 Notes Notes and safety instructions are represented as follows in this manual: Note Tips for usage and operation Examples Application examples, installation examples, programming examples Important These safety instructions are used as soon as there is danger of a malfunction without risk of damage or injury.
Page 9: Product And Functional Overview
The devices are modular installation devices in Pro M design with 6-module widths for installation in a ® distribution board. Connection to the ABB i-bus KNX is via the front bus connection terminal. The devices require no auxiliary voltage. The assignment of the physical address, as well as the setting of parameters, is carried out with Engineering Tool Software ETS.
Page 10: Functional Overview
® ABB i-bus General 1.2.2 Functional overview FCA/S 1.1.1.2 FCA/S 1.1.2.2 FCA/S 1.2.1.2 FCA/S 1.2.2.2 Inputs Switch sensor, e.g. window contact Value/forced operation, e.g. operating mode Temperature sensor, e.g. exhaust temperature Outputs 6 A switch 3-speed fan or 2-speed fan or...
Page 11: Integration In The I-Bus
® The i-bus Tool can be downloaded for free from our website (www.abb.com/knx). ETS is not required for the Software Tool. However, Falcon Runtime (version 1.6 or higher and version 1.8 or higher for Windows 7) must be installed to set up a connection between the PC and KNX.
Page 13: Device Technology
ABB i-bus Device technology Device technology Fan Coil Actuator FCA/S 1.1.1.2, PWM, MDRC The device is a modular installation The device is powered via the ABB ® device (MDRC) in Pro M design. It is i-bus KNX and requires no additional intended for installation in distribution auxiliary voltage supply.
Page 14 Operating and display elements For assignment of the physical address Button/LED For toggling between manual Button /, LED ® operation/operation via ABB i-bus KNX and displays Degree of protection IP 20 To DIN EN 60 529 Protection class To DIN EN 61 140...
Page 15: Valve Outputs (Thermoelectric, Pwm)
ETS and the current version of the device application are required for programming. The current version of the application is available on the Internet for download at www.abb.com/knx. After import into ETS it appears in the Catalogs window under Manufacturers/ABB/Heating, Ventilation, Air Conditioning/Fan Coil Actuator PWM.
Page 16: Resolution, Accuracy And Tolerances
® ABB i-bus Device technology 2.1.5 Resolution, accuracy and tolerances Please note that the tolerances of the sensors which are used will need to be added to the listed values. With sensors based on resistance measurement, it is also necessary to consider the cable error.
Page 17 ® ABB i-bus Device technology PT100 The PT100 is precise and exchangeable but subject to faults in the cables (cable resistance and heating of the cables). A terminal resistance of just 200 milliohms causes a temperature error of 0.5 °C.
Page 18: Fan, Rated Current 6 A
® ABB i-bus Device technology 2.1.7 Fan, rated current 6 A Rated values Number 3 contacts 250/440 V AC (50/60 Hz) rated voltage rated current (per output) AC3* operation (cos  = 0.45) Switching currents 6 A/230 V to DIN EN 60 947-4-1 AC1* operation (cos ...
Page 19: Fan, Lamp Load 6 A
(600 s) 100 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 20: Output, Rated Current 16 A
® ABB i-bus Device technology 2.1.9 Output, rated current 16 A Rated values Quantity 250/440 V AC (50/60 Hz) rated voltage rated current 16 A AC3* operation (cos  = 0.45) to Switching currents 8 A/230 V DIN EN 60 947-4-1 AC1* operation (cos  = 0.8) to...
Page 21: Output, Lamp Load 16 A
(600 s) 200 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 22: Connection Diagram (Motor-Driven, 3-Point)
® ABB i-bus Device technology 2.1.11 Connection diagram (motor-driven, 3-point) FCA/S 1.1.1.2 Label carrier Valve V1 (e.g. heating) Programming button Valve V2 (e.g. cooling) Programming LED (red) Bus connection terminal Output H Inputs a, b, c 20 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 23 ® ABB i-bus Device technology All outputs can be controlled independently. The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator and the application: Functions of the output General   - Overload ...
Page 24: Dimension Drawing
® ABB i-bus Device technology 2.1.12 Dimension drawing 22 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 25: Fan Coil Actuator Fca/S 1.1.2.2, Pwm, Mdrc
ABB i-bus Device technology Fan Coil Actuator FCA/S 1.1.2.2, PWM, MDRC The device is a modular installation The device is powered via the ABB i- ® device (MDRC) in Pro M design. It is KNX and requires no additional intended for installation in distribution auxiliary voltage supply.
Page 26 For assignment of the physical address Button/LED Button /LED For toggling between manual ® operation/operation via ABB i-bus KNX and displays Button Output H / switch H For switching and display Fan speed button E, F, G For switching the individual fan speeds...
Page 27: Valve Outputs (Thermoelectric, Pwm)
ETS and the current version of the device application are required for programming. The current version of the application is available on the Internet for download at www.abb.com/knx. After import into ETS it appears in the Catalogs window under Manufacturers/ABB/Heating, Ventilation, Air Conditioning/Fan Coil Actuator PWM.
Page 28: Resolution, Accuracy And Tolerances
® ABB i-bus Device technology 2.2.5 Resolution, accuracy and tolerances Please note that the tolerances of the sensors which are used will need to be added to the listed values. With sensors based on resistance measurement, it is also necessary to consider the cable error.
Page 29 ® ABB i-bus Device technology PT100 The PT100 is precise and exchangeable but subject to faults in the cables (cable resistance and heating of the cables). A terminal resistance of just 200 milliohms causes a temperature error of 0.5 °C.
Page 30: Fan, Rated Current 6 A
® ABB i-bus Device technology 2.2.7 Fan, rated current 6 A Rated values Number 3 contacts 250/440 V AC (50/60 Hz) rated voltage rated current (per output) AC3* operation (cos  = 0.45) to Switching currents 6 A/230 V DIN EN 60 947-4-1 AC1* operation (cos ...
Page 31: Fan, Lamp Load 6 A
(600 s) 100 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 32: Output, Rated Current 20 Ax
® ABB i-bus Device technology 2.2.9 Output, rated current 20 AX Rated values Quantity 250/440 V AC (50/60 Hz) rated voltage rated current 20 A AC3* operation (cos  = 0.45) to DIN EN 60 947-4-1 Switching currents 16 A/230 V AC1* operation (cos  = 0.8) to DIN EN 60 947-4-1 20 A/230 V 20 A/250 V (140 F)
Page 33: Output, Lamp Load 20 Ax
(600 s) 300 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 34: Connection Diagram (Thermoelectric, Pwm)
® ABB i-bus Device technology 2.2.11 Connection diagram (thermoelectric, PWM) FCA/S 1.1.2.2 Label carrier Output H Programming button Manual operation button/LED (yellow) Valve output A/B buttons/LEDs Programming LED (red) (e.g. heating) (yellow) Valve output C/D buttons/LEDs Bus connection terminal (e.g. cooling) (yellow)
Page 35 ® ABB i-bus Device technology All outputs can be controlled independently. The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator and the application: Functions of the output General   - Overload ...
Page 36: Dimension Drawing
® ABB i-bus Device technology 2.2.12 Dimension drawing 34 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 37: Fan Coil Actuator Fca/S 1.2.1.2, 0-10V, Mdrc
® ABB i-bus Device technology Fan Coil Actuator FCA/S 1.2.1.2, 0-10V, MDRC The device is a modular installation The device is powered via the ABB ® device (MDRC) in Pro M design. It is i-bus KNX and requires no additional intended for installation in distribution auxiliary voltage supply.
Page 38 Operating and display elements For assignment of the physical address Button/LED Button /, LED For toggling between manual ® operation/operation via ABB i-bus KNX and displays Degree of protection IP 20 To DIN EN 60 529 Protection class To DIN EN 61 140...
Page 39: Outputs, Valve V1/2, Analog
ETS and the current version of the device application are required for programming. The current version of the application is available on the Internet for download at www.abb.com/knx. After import into ETS it appears in the Catalogs window under Manufacturers/ABB/Heating, Ventilation, Air Conditioning/Fan Coil Actuator 0-10V.
Page 40: Resolution, Accuracy And Tolerances
® ABB i-bus Device technology 2.3.4 Resolution, accuracy and tolerances Please note that the tolerances of the sensors which are used will need to be added to the listed values. With sensors based on resistance measurement, it is also necessary to consider the cable error.
Page 41 ® ABB i-bus Device technology PT100 The PT100 is precise and exchangeable but subject to faults in the cables (cable resistance and heating of the cables). A terminal resistance of just 200 milliohms causes a temperature error of 0.5 °C.
Page 42: Fan, Rated Current 6 A
® ABB i-bus Device technology 2.3.6 Fan, rated current 6 A Rated values Number 3 contacts 250/440 V AC (50/60 Hz) rated voltage rated current (per output) AC3* operation (cos  = 0.45) to Switching currents 6 A/230 V DIN EN 60 947-4-1 AC1* operation (cos ...
Page 43: Fan, Lamp Load 6 A
(600 s) 100 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 44: Output, Rated Current 16 A
® ABB i-bus Device technology 2.3.8 Output, rated current 16 A Rated values Quantity 250/440 V AC (50/60 Hz) rated voltage rated current 16 A AC3* operation (cos  = 0.45) to DIN EN 60 947-4-1 Switching currents 8 A/230 V AC1* operation (cos  = 0.8) to DIN EN 60 947-4-1 16 A/230 V 16 A/250 V (70 F)
Page 45: Output, Lamp Load 16 A
(600 s) 200 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 46: Connection Diagram
® ABB i-bus Device technology 2.3.10 Connection diagram FCA/S 1.2.1.2 Label carrier Valve V1 (e.g. heating) Programming button Valve V2 (e.g. cooling) Programming LED (red) Bus connection terminal Output H Inputs a, b, c Note Terminals 1 and 4 on the FCA/S 1.2.1.2 are not used internally.
Page 47 ® ABB i-bus Device technology All outputs can be controlled independently. The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator and the application: Functions of the output General   - Overload ...
Page 48: Dimension Drawing
® ABB i-bus Device technology 2.3.11 Dimension drawing 46 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 49: Fan Coil Actuator Fca/S 1.2.2.2, 0-10V, Mdrc
® ABB i-bus Device technology Fan Coil Actuator FCA/S 1.2.2.2, 0-10V, MDRC The device is a modular installation The device is powered via the ABB ® device (MDRC) in Pro M design. It is I-bus KNX and requires no additional intended for installation in distribution auxiliary voltage supply.
Page 50 For assignment of the physical address Button/LED Button /LED For toggling between manual ® operation/operation via ABB i-bus KNX and displays Button Output H / switch H For switching and display Fan speed button E, F, G For switching the individual fan speeds...
Page 51: Outputs, Valve V1/2, Analog
ETS and the current version of the device application are required for programming. The current version of the application is available on the Internet for download at www.abb.com/knx. After import into ETS it appears in the Catalogs window under Manufacturers/ABB/Heating, Ventilation, Air Conditioning/Fan Coil Actuator 0-10V.
Page 52: Resolution, Accuracy And Tolerances
® ABB i-bus Device technology 2.4.4 Resolution, accuracy and tolerances Please note that the tolerances of the sensors which are used will need to be added to the listed values. With sensors based on resistance measurement, it is also necessary to consider the cable error.
Page 53 ® ABB i-bus Device technology PT100 The PT100 is precise and exchangeable but subject to faults in the cables (cable resistance and heating of the cables). A terminal resistance of just 200 milliohms causes a temperature error of 0.5 °C.
Page 54: Fan, Rated Current 6 A
® ABB i-bus Device technology 2.4.6 Fan, rated current 6 A Rated values Number 3 contacts 250/440 V AC (50/60 Hz) rated voltage rated current (per output) AC3* operation (cos  = 0.45) to DIN EN 60 947-4-1 Switching currents 6 A/230 V AC1* operation (cos ...
Page 55: Fan, Lamp Load 6 A
(600 s) 100 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 56: Output, Rated Current 20 Ax
® ABB i-bus Device technology 2.4.8 Output, rated current 20 AX Rated values Quantity 250/440 V AC (50/60 Hz) rated voltage rated current 20 A AC3* operation (cos  = 0.45) to DIN EN 60 947-4-1 Switching currents 16 A/230 V AC1* operation (cos  = 0.8) to DIN EN 60 947-4-1 20 A/230 V 20 A/250 V (140 F)
Page 57: Output, Lamp Load 20 Ax
(600 s) 300 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
Page 58: Connection Diagram
® ABB i-bus Device technology 2.4.10 Connection diagram FCA/S 1.2.2.2 Label carrier Output H Programming button Manual operation button/LED (yellow) Valve output A buttons/LEDs Programming LED (red) (e.g. heating) (yellow) Valve output C buttons/LEDs Bus connection terminal (e.g. cooling) (yellow)
Page 59 ® ABB i-bus Device technology All outputs can be controlled independently. The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator and the application: Functions of the output General   - Overload ...
Page 60: Dimension Drawing
® ABB i-bus Device technology 2.4.11 Dimension drawing 58 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 61: Mounting And Installation
DIN VDE 0100-520. Commissioning requirement ® In order to commission the device, a PC with ETS, as well as a connection to the ABB i-bus , e.g. via a KNX interface, is required. The device is ready for operation after the bus voltage is applied. No additional auxiliary voltage is required.
Page 62 ® ABB i-bus Device technology Supplied state The device is supplied with the physical address 15.15.255. The application is pre-installed. The complete application can be reloaded if required. Downloads may take longer after a change of application or a discharge.
Page 63: Manual Operation
® ABB i-bus Device technology Manual operation Function of manual operation Manual operation facilitates on-site operation of the device. Manual operation is enabled as standard and can be switched on and off using the Manual operation button Switching on manual operation:...
Page 64: Display Elements
® ABB i-bus Device technology 2.6.1 Display elements Indicator LEDs are located on the front of the device. All LEDs Output X indicate the current state. In KNX operation the LED is off. The response of the display elements is described in the following table:...
Page 65: Operating Controls
® ABB i-bus Device technology 2.6.2 Operating controls Buttons for manual operation are located on the front of the devices. The reaction of the operating elements is described in the following table according to the operating states KNX operation and Manual operation:...
Page 66 ® ABB i-bus Device technology Button KNX operation Manual operation Short button push ≤ 1.5 sec.: As switch actuator: Press: ON <-> OFF As fan: Press: ON Switching can only be performed in the following order: … No reaction "E" => fan speed 1 Output E...G...
Page 67: Commissioning
® ABB i-bus Commissioning Commissioning Overview The application Fan Coil Actuator PWM/2 is available for the Fan Coil Actuator FCA/S 1.1.1.2. The application Fan Coil Actuator 0-10V/2 is available for the Fan Coil Actuator FCA/S 1.2.1.2. The application Fan Coil Actuator PWM M/2 is available for the Fan Coil Actuator FCA/S 1.1.2.2.
Page 68: Functions Of The Inputs
® ABB i-bus Commissioning Configuration design types A Fan Coil unit can be configured as a compact device or a modular installation device:  Compact devices: These are supplied with enclosures and are available as self-contained units or for wall or ceiling mounting.
Page 69: Output Functions
® ABB i-bus Commissioning 3.1.2 Output functions The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator and the application: Functions of the output General   - Overload   - Parallel operation...
Page 70: Parameters
Parameters The ETS Engineering Tool Software is used to parameterize the device. The application appears in ETS in the Catalogs window under Manufacturers/ABB/Heating, Ventilation/ Fan Coil Actuator single. The following chapters describe the device parameters using the parameter windows. Parameter windows are structured dynamically so that further parameters may be enabled depending on the parameterization and function of the outputs.
Page 71: Parameter Window General - Settings
® ABB i-bus Commissioning Parameter window General – Settings 3.2.1 Settings of higher-level parameters: Sending and switching delay after bus voltage recovery Options: 2/3/5/10/30/60 seconds 2/3/4 minutes During the sending and switching delay, telegrams are only received. However, the telegrams are not processed and the outputs remain unchanged.
Page 72 ® ABB i-bus Commissioning Rate of telegrams Options: Do not limit 1/2/3/5/10/20 telegram(s)/second 0.05/0.1/0.2/0.3/0.5 seconds/telegram Using this parameter, the bus load generated by the device can be limited.  1/2/3/5/10/20 telegram(s)/second: X telegrams per second are sent.  0.05/0.1/0.2/0.3/0.5 seconds/telegram: A telegram is sent every x seconds.
Page 73 ® ABB i-bus Commissioning Enable communication object "Request status values" 1 bit Options: Via this communication object, all status messages can be requested, provided that they have been parameterized with the option After a change or request.  Yes: The 1-bit communication object Request status values is enabled.
Page 74: Parameter Window Manual Operation - Settings
® ABB i-bus Commissioning Parameter window Manual operation – Settings 3.2.2 Note This parameter window is only visible for devices with manual operation. Settings for manual operation: Manual operation Options: Disabled Enabled Enable/disable via comm. object This parameter defines if the switchover between the operating states Manual operation and KNX operation is possible via the button on the device or via a communication object.
Page 75 ® ABB i-bus Commissioning  Enabled: The operating states Manual operation and KNX operation can be toggled via button .  Enable/disable via communication object: The communication object Block manual operation - General appears. Telegram value: 0 = Enable button...
Page 76 ® ABB i-bus Commissioning Enable communication object "Status Man. operation" (1-bit) Options:  Yes: The 1-bit communication object Status Man. operation is enabled. Dependent parameter: Send object value Options: No, update only On change After request After a change or request ...
Page 77 ® ABB i-bus Commissioning Input a, b and c Options: Disabled Switch Button With this parameter, the button can be disabled or programmed as a switch or push button.  Disabled: Button disabled LEDs not functioning  Switch: With every actuation, the states of the input and the LED are changed.
Page 78: Parameter Window Outputs A
® ABB i-bus Commissioning 3.2.3 Parameter window Outputs A...H 3.2.3.1 Parameter window Enable output A...D In this parameter window, outputs A...D are enabled. Fan coil operating mode Options: 1 control value/1 valve 2 control values/1 valve 2 control values/1 valve/ with switching object...
Page 79: Description Of The Fan Coil Operating Modes With Valve Drive, Thermoelectric (Pwm)
® ABB i-bus Commissioning 3.2.3.1.1 Description of the Fan Coil operating modes with valve drive, thermoelectric (PWM) Control values overview Functions of the output General   - Overload   - Parallel operation free free Valve drives allocated to the Fan Coil unit ...
Page 80 ® ABB i-bus Commissioning Fan Coil operating mode: 1 control value/1 valve What does the option control value input "1 control value/1 valve" mean? Example: Heating valve and three-speed fan Control value processing in the device Output A Output B...
Page 81 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values/1 valve What does the option control value input "2 control values/1 valve" mean? Example: Valve and three-speed fan Control value processing in the device Output A Output B Output C...
Page 82 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values/1 valve / with switching object What does the option control value input: "2 control values/1 valve / with switching object" mean? Example: Valve and three-speed fan Control value processing in the device...
Page 83 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values / 2 valves What does the option control value input "2 control values / 2 valves" mean? Example: 2 valves and three-speed fan Control value processing in the device...
Page 84 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values/2 valves / with switching object What does the option control value input: "2 control values/2 valves / with switching object" mean? Example: 2 valves and three-speed fan Control value processing in the device...
Page 85: Description Of The Fan Coil Operation Modes With Valve Drive, Motor-Driven (3-Point) And Analog
® ABB i-bus Commissioning 3.2.3.1.2 Description of the Fan Coil operation modes with valve drive, motor-driven (3-point) and analog Control values overview Functions of the output General   - Overload   - Parallel operation free free Valve drives allocated to the Fan Coil unit - Analog (0…10 V)
Page 86 ® ABB i-bus Commissioning Fan Coil operating mode: 1 control value/1 valve What does the option control value input "1 control value/1 valve" mean? Example: Heating valve and three-speed fan Control value processing in the device Analog: Output A Output C Control value input ...
Page 87 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values/1 valve What does the option control value input "2 control values/1 valve" mean? Example: Valve and three-speed fan Control value processing in the device Analog: Output A Output C Control value input ...
Page 88 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values/1 valve / with switching object What does the option control value input: "2 control values/1 valve / with switching object" mean? Example: Valve and three-speed fan Control value processing in the device...
Page 89 ® ABB i-bus Commissioning If the option 2 control values/1 valve / with switching object is selected, the control values will operate on output A (B). Which of the two control values operates on outputs A and C is decided via the communication object "Toggle heating".
Page 90 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values / 2 valves What does the option control value input "2 control values / 2 valves" mean? Example: 2 valves and three-speed fan Control value processing in the device...
Page 91 ® ABB i-bus Commissioning If the option 2 control values/2 valves is selected, the control values will operate directly on output A (B) and output C (D). Which of the two control values operates on outputs A and C is decided via the communication object "Toggle heating".
Page 92 ® ABB i-bus Commissioning Fan Coil operating mode: 2 control values/2 valves / with switching object What does the option control value input: "2 control values/2 valves / with switching object" mean? Example: 2 valves and three-speed fan Control value processing in the device...
Page 93 ® ABB i-bus Commissioning If the option 2 control values/2 valves / with switching object is selected, the control values will operate directly on output A (B) and output C (D). Which of the two control values operates on outputs A and C is decided via the communication object "Toggle heating".
Page 94 ® ABB i-bus Commissioning Note If the options with 2 valves are selected, parallel mode can be enabled via the communication object Valve control values parallel mode. communication object "Valve control values parallel mode" 1-bit Options:  Yes: The 1-bit communication object Valve control values parallel operation is enabled.
Page 95 ® ABB i-bus Commissioning Note If the options with switching object are selected, an additional parameter Toggle to heating with will appear Toggle to heating with Options:  0: A telegram with the value 0 switches.  1: A telegram with the value 1 switches.
Page 96 ® ABB i-bus Commissioning Parameter window Enable output A...D – Fan Coil Actuator, PWM Operation mode output A and B Options: Individual Valve drive, motor-driven (3-point) This parameter determines whether the operation modes of outputs A and B can be parameterized individually or whether the outputs are operated in operation mode Valve drive, motor-driven (3-point).
Page 97 ® ABB i-bus Commissioning Operation mode output C and D Options: Individual Valve drive, motor-driven (3-point)  This parameter determines whether the operation modes of outputs C and D can be parameterized individually or whether the outputs are operated in operation mode Valve drive, motor-driven (3-point).
Page 98 ® ABB i-bus Commissioning Parameter window Enable output A...D – Fan Coil Actuator, 0...10 V Output A Options: Disabled Valve drive, analog (0...10 V) This parameter defines the individual operation mode of the output.  Disabled: No operation mode selected.
Page 99: Parameter Window A: Output (Valve Drive, Thermoelectric (Pwm))
® ABB i-bus Commissioning 3.2.3.2 Parameter window A: Output (Valve drive, thermoelectric (PWM)) All settings for the output A/B as valve drive, thermoelectric (PWM) are made in this parameter window. Note This parameter window is visible for the products FCA/S 1.1.1.2 and FCA/S 1.1.2.2.
Page 100 ® ABB i-bus Commissioning Reaction after bus voltage recovery Options: Unchanged Select This parameter determines the reaction of the output at bus voltage recovery.  Unchanged: The last valve control is restored.  Select: A value is determined. Active priorities override the parameterized control.
Page 101 ® ABB i-bus Commissioning Valve is Options: Heating valve Cooling valve This parameter determines whether the valve is defined as a heating valve or cooling valve. Note In the option 2 control values/2 valves (with or without switching object), one valve must be parameterized as a heating valve and the other as a cooling valve, according to the installation conditions.
Page 102 ® ABB i-bus Commissioning  1-byte: The control value is sent by the room thermostat as a continuous positioning telegram (0…255). Note 1 byte control For 1 byte control, a value of 0…255 (corresponds to 0%…100%) is preset by the room thermostat.
Page 103 ® ABB i-bus Commissioning Cycle time of PWM in s [10...6,000] Options: 10…180…6,000 For setting the cycle time for the pulse width modulation. If the control value is received via a 1 bit value, this parameter serves as the basis for calculation of the control of the output with ...
Page 104 ® ABB i-bus Commissioning Monitoring control values e.g. thermostat Options: This parameter is activated for monitoring cyclic sending of the control value, e.g. of the room thermostat. The reaction to the absence of a control value is defined in monitoring of the control value. This ensures emergency operation.
Page 105 ® ABB i-bus Commissioning Control value after control fault Options: This parameter defines the control value with a control fault.  No: No control value is set.  Yes: A value is set. Dependent parameter: Control value in % [0...100] Options: 0…100...
Page 106: Parameter Window Ab: Output (Valve Drive, Motor-Driven (3-Point))
® ABB i-bus Commissioning 3.2.3.3 Parameter window AB: Output (valve drive, motor-driven (3-point)) All settings for output A/B as valve drive, motor-driven (3-point) are made in this parameter window. Note This parameter window is visible for the products FCA/S 1.1.1.2 and FCA/S 1.1.2.2.
Page 107 ® ABB i-bus Commissioning Reaction after bus voltage recovery Options: Unchanged Select This parameter determines the reaction of the output at bus voltage recovery. After bus voltage recovery, a Reference adjustment of the valve drive is always carried out. After this, the current control value is controlled.
Page 108 ® ABB i-bus Commissioning Automatic adjustment of the valve drive Options: If the control value 0% is only rarely achieved in ongoing operation, this can lead to inaccuracies in positioning control. This parameter activates automatic adjustment to move the valve drive in a defined manner to the 0% position.
Page 109 ® ABB i-bus Commissioning Monitoring control values e.g. thermostat Options: This parameter is activated for monitoring cyclic sending of the control value, e.g. of the room thermostat. The reaction to the absence of a control value is defined in monitoring of the control value. This ensures emergency operation.
Page 110 ® ABB i-bus Commissioning Control value after control fault Options: This parameter defines the control value with a control fault.  No: No control value is set.  Yes: A value is set. Dependent parameter: Control value in % [0...100] Options: 0…100...
Page 111: Parameter Window A: Output (Valve Drive, Analog (0
® ABB i-bus Commissioning 3.2.3.4 Parameter window A: Output (valve drive, analog (0...10 V)) All settings for Valve drive analog (0...10 V) are made in this window. Note This parameter window is visible for the products FCA/S 1.2.1.2 and FCA/S 1.2.2.2.
Page 112 ® ABB i-bus Commissioning Reaction after bus voltage recovery Options: Unchanged Select This parameter determines the reaction of the output at bus voltage recovery.  Unchanged: The last valve control is restored.  Select: A value is determined. Active priorities override the parameterized control.
Page 113 ® ABB i-bus Commissioning Valve is Options: Heating valve Cooling valve This parameter determines whether the valve is defined as a heating valve or cooling valve. Monitoring control values e.g. thermostat Options: This parameter is activated for monitoring cyclic sending of the control value, e.g. of the room thermostat.
Page 114 ® ABB i-bus Commissioning Control value after control fault Options: This parameter defines the control value with a control fault.  No: No control value is set.  Yes: A value is set. Dependent parameter: Control value in % [0...100] Options: 0…100...
Page 115: Parameter Window Function
® ABB i-bus Commissioning 3.2.3.5 Parameter window Function In this parameter window, various functions for each output can be activated. The functions are identical for the operation modes Valve drive, thermoelectric (PWM), Valve drive, motor-driven (3-point) and Valve drive, analog (0...10 V).
Page 116 ® ABB i-bus Commissioning Send object value Options: No, update only On change After request After a change or request  No, update only: The object value is updated but not sent.  On change: The object value is sent when a change occurs.
Page 117 ® ABB i-bus Commissioning Enable valve purge Options:  Yes: The 1-bit communication object Activate purge, p. 213, is enabled. Note If purging is interrupted by higher priorities, e.g. forced operation, the higher priority action is carried out. If the interruption duration is longer than the period of valve purge, the valve purge will no longer be executed, after the higher priority has been rescinded.
Page 118 ® ABB i-bus Commissioning Automatic valve purge Options: Selection of option Yes: Dependent parameters: Purge cycle in weeks   [1…12] 1…6…12 Options: The internal automatic purge timer starts directly after a download. The time is reset each time it is downloaded.
Page 119: Parameter Window Security
® ABB i-bus Commissioning 3.2.3.5.1 Parameter window Security The function Security is identical for Valve drive, thermoelectric (PWM); Valve drive, motor-driven (3-point) and Valve drive, analog (0...10 V). The parameter window is enabled if the parameter Enable function "Priority and safety operation" has been selected with the option Yes in the...
Page 120 ® ABB i-bus Commissioning Control value on forced operation in % [0...100] Options: 0…100 With active forced operation, the output is controlled with the control value defined here and the operation is blocked. Note This parameter is only enabled with forced operation. All the following parameters are enabled and identical for the function Forced operation as well as Block.
Page 121: Parameter Window Characteristic Curve
® ABB i-bus Commissioning 3.2.3.5.2 Parameter window Characteristic curve The characteristic curve is identical for Valve drive, thermoelectric (PWM); Valve drive, motor-driven (3- point) and Valve drive, analog (0…10 V). The parameter window is enabled if the parameter Enable characteristic curve has been selected with the option Yes in the Parameter window Function, p.
Page 122 ® ABB i-bus Commissioning Example: Value pair 1 (VP1) Value pair 2 (VP2) Control value in % [0...100] Control value in % [0...100] Control value in % [0...100] Control value in % [0...100] Implemented characteristic curve: Actuating value Control 0…10 %...
Page 123 ® ABB i-bus Commissioning Value pair x   Control value in % [0...100] Options: 0…100 Control value in % [0...100] Options: 0…100 The possibility of activating other value pairs allows different curve characteristics to be realized. A total of four value pairs can be set.
Page 124: Parameter Window Output B, C, D
® ABB i-bus Commissioning 3.2.3.6 Parameter window Output B, C, D The setting options of valve outputs B, C and D or C/D do not differentiate from those of output A or A/B. The descriptions of the parameter setting options and the adjustable communication objects for outputs B,...
Page 125: Parameter Window Enable Output E
® ABB i-bus Commissioning 3.2.3.7 Parameter window Enable output E...H Outputs E, F, G Options: Enabled as switch actuators Enabled as fan Outputs E, F and G can be programmed as switch actuators and as fans.  Enabled as switch actuators: Outputs E, F and G appear as individual parameters and can be enabled individually.
Page 126: Parameter Window E, F, G: Fan (Multi-Level)
® ABB i-bus Commissioning 3.2.3.8 Parameter window E, F, G: Fan (Multi-level) All settings for the Multi-level fan are made in this parameter window. Fan type Options: Multi-level One-level This parameter defines the fan type which is to be controlled.
Page 127 ® ABB i-bus Commissioning Fan operating mode (note technical data of fan!) Options: Changeover Step switch Control of the fan is set with this parameter. The mode of fan control should be taken from the technical data of the fan.
Page 128 ® ABB i-bus Commissioning Fan speed on bus voltage recovery Options: Unchanged  Unchanged: The fan's speeds remain unchanged.  OFF: The fan is switched off.  1, 2 or 3: The fan switches to fan speed 1, 2 or 3.
Page 129 ® ABB i-bus Commissioning Forced operation on object value Options:  0: Forced operation is activated by a telegram with value 0.  1: Forced operation is activated by a telegram with value 1. Note During forced operation the settings set in Automatic control are ignored. Automatic control is updated after forced operation has been rescinded.
Page 130 ® ABB i-bus Commissioning Limitation on forced operation Options: 3, 2, 1, OFF Unchanged 1, OFF 2, 1 2, 1, OFF 3, 2 3, 2, 1 This parameter sets which fan speed is set, or may not be over/undershot, when forced operation is active.
Page 131: Parameter Window Status Messages (Multi-Level)
® ABB i-bus Commissioning 3.2.3.9 Parameter window Status messages (Multi-level) This is the parameter window where status messages are defined. Enable communication object "Status Fan speed x" 1-bit Options: The setting of a fan speed is displayed via these communication objects. You can parameterize whether or not the status of a current or required fan speed is displayed.
Page 132 ® ABB i-bus Commissioning What is current fan speed? The Current fan speed is the speed at which the fan is actually operating. What is required fan speed? The Required fan speed is the fan speed which has to be reached, e.g. when the transition and dwell times have elapsed.
Page 133 ® ABB i-bus Commissioning Enable communication object "Status Fan speed" 1-byte Options: This status byte defines the figure value of the fan speed. This display can be differentiated from Required fan speed by selecting Current fan speed. Initially, the switchover times, dwell times and start-up phase must be completed before the required fan speed is reached.
Page 134 ® ABB i-bus Commissioning Enable communication object "Status byte fan" 1-byte Options: From this status byte the states heating, cooling, automatic, forced operation and the four limitations are indicated directly via a 1 bit coding. For further information see: Status byte fan, p.
Page 135 ® ABB i-bus Commissioning Enable communication object "Status Fan On/Off" 1-bit Options: This parameter enables the communication object Status Fan ON/OFF. Some fans initially need an ON telegram before they are set to a fan speed from the OFF state. This ON telegram has effect on a main switch which has to be switched on.
Page 136: Parameter Window Thresholds (Multi-Level)
® ABB i-bus Commissioning 3.2.3.10 Parameter window Thresholds (Multi-level) The thresholds are defined in this parameter window. Important The device evaluates threshold values in ascending order, i.e. first it checks the threshold value for Off - > Fan speed 1, then Fan speed 1 -> Fan speed 2, and so on.
Page 137 ® ABB i-bus Commissioning Hysteresis is only taken into account in automatic operation Note Hysteresis threshold value in % +/- [0...20 %] 0…5…20 Options: This sets a hysteresis at which switchover to the next fan speed occurs. The hysteresis applies for all three threshold values.
Page 138 ® ABB i-bus Commissioning Example: Three-speed fan, fan control with hysteresis Using hysteresis avoids continual switching between the fan speeds caused by fluctuating input signals around the threshold value. Important How does the fan react if the switch thresholds overlap as a result of using hysteresis? 1) Hysteresis defines the speed at which the speed change occurs.
Page 139: Parameter Window Automatic Control (Multi-Level)
® ABB i-bus Commissioning 3.2.3.11 Parameter window Automatic control (Multi-level) This parameter window is visible if the option Yes has been selected with the parameter Enable automatic operation in Parameter window E, F, G: Fan (Multi-level), p. 124. The limits can be enabled in this parameter window.
Page 140 ® ABB i-bus Commissioning Minimum dwell period in fan speed in s [0...65,535] Options: 0…65,535 This parameter defines the dwell time for a fan speed of the fan until it switches to the next higher or lower fan speed. The input is made in seconds.
Page 141 ® ABB i-bus Commissioning Activate monitoring control values Options: This parameter sets the monitoring for the control value input(s). Any remaining telegrams on the communication object(s) are detected.  No: Control value monitoring is deactivated.  Yes: Control value monitoring is activated.
Page 142 ® ABB i-bus Commissioning Send object value Options: No, update only On change After request After a change or request  No, update only: The status is updated but not sent.  On change: The status is sent when a change occurs.
Page 143 ® ABB i-bus Commissioning Enable limitations Options: Selection of option Yes: Dependent parameter: Limitation 1 Limitation 2 Limitation 3 Limitation 4 Options: 3, 2, 1, OFF Unchanged 1, OFF 2, 1 2, 1, OFF 3, 2 3, 2, 1 This parameter sets which fan speed is set, or may not be over/undershot, when forced operation is active.
Page 144 ® ABB i-bus Commissioning Four limitations are available. They can be used, for example, for the control of various operating modes, e.g. frost/heat protection, comfort, night shut down and standby. In normal cases, the room thermostat takes these operating modes into account in its control variable for the actuator.
Page 145: Parameter Window Direct Operation (Multi-Level)
® ABB i-bus Commissioning 3.2.3.12 Parameter window Direct operation (Multi-level) This parameter window is visible if option Yes has been selected with the parameter Enable direct operation in Parameter window E, F, G: Fan (Multi-level), p. 124. Enable communication object "Switch speed x"...
Page 146 ® ABB i-bus Commissioning Enable communication object "Fan speed up/down" 1-bit Options:  Yes: A 1 bit Fan speed up/down communication object is enabled. Telegram 1 = A fan speed is switched UP value: 0 = A fan speed is switched DOWN If the maximum fan speed is reached and a further telegram with the value 1 is received, the speed will remain as it is.
Page 147: Parameter Window Startup/Run-On
® ABB i-bus Commissioning 3.2.3.13 Parameter window Startup/Run-on This parameter window is visible if the option Yes has been selected with the parameter Set startup/run-on Parameter window E, F, G: Fan (Multi-level), p. 124,. Start-up behavior Options: This parameter enables the fan to start from the OFF state with a defined fan speed. This fan speed is immediately applied.
Page 148 ® ABB i-bus Commissioning Example: Start-up behavior of a three-speed fan The illustration shows the reaction in automatic operation with the option Switch on over fan speed 3, if the fan receives the telegram from the OFF state to set Fan speed 1.
Page 149 ® ABB i-bus Commissioning Run-on behavior Options: This parameter activates a run-on for the fan. If the fan changes to a lower speed, it remains in the previous speed for the parameterized run-on time and only then reduces the speed by one level.
Page 150: Parameter Window E, F, G: Fan (Two-Level)
® ABB i-bus Commissioning 3.2.3.14 Parameter window E, F, G: Fan (Two-level) All settings for the two-level fan are made in this parameter window. If you wish to use the device for controlling a two-level fan, set the parameters as follows: ...
Page 151: Parameter Window E, F, G: Fan (One-Level)
® ABB i-bus Commissioning 3.2.3.15 Parameter window E, F, G: Fan (One-level) All settings for the one-level fan are made in this parameter window. Fan type Options: Multi-level One-level This parameter sets which type of fan is to be controlled.
Page 152 ® ABB i-bus Commissioning Fan speed on bus voltage recovery Options: Unchanged The reaction of the fan on bus voltage recovery is defined here.  Unchanged: The fan speed remains the same.  OFF: The fan is switched off. ...
Page 153 ® ABB i-bus Commissioning Function Time on OFF Options: None Switching delay Minimum time This defines the Time function on Fan OFF.  None: No Time function is executed.  Switching delay: The fan is switched off after this delay.
Page 154: Parameter Window Status Messages (Single Speed)
® ABB i-bus Commissioning 3.2.3.16 Parameter window Status messages (single speed) This is the parameter window where status messages are defined. This parameter window is visible if the option Enabled as fan has been selected under the parameter Outputs E, F, G in Parameter window Enable output E...H, p.
Page 155 ® ABB i-bus Commissioning Enable communication object "Status Fan On/Off" 1-bit Options: This parameter enables the communication object Status Fan ON/OFF. Some fans initially require an ON telegram before they are set to a fan speed from the OFF state. This ON telegram has effect on a main switch which has to be switched on.
Page 156: Parameter Window Threshold (One-Level)
® ABB i-bus Commissioning 3.2.3.17 Parameter window Threshold (One-level) The thresholds are defined in this parameter window. Threshold value OFF <-> ON in % [1...100] 1…10…100 Options: This defines the threshold value at which switch on occurs. If the value in the control value communication object is greater than or equal to the parameterized threshold value, it is switched on.
Page 157 ® ABB i-bus Commissioning Example, a three speed fan, hysteresis with fan control Using hysteresis, a continuous switching between the fan speeds around the threshold value with deviating input signals can be avoided. FCA/S 1.x.x.1 | 2CDC508134D0202 155...
Page 158: Parameter Window Automatic Control (One-Level)
® ABB i-bus Commissioning 3.2.3.18 Parameter window Automatic control (One-level) This parameter window is visible if the option Yes has been selected under the parameter Enable automatic operation in Parameter window E, F, G: Fan (One-level), p. 149. This is the parameter window where you define the threshold values for switchover of the fan speed. You can also enable limitations here.
Page 159 ® ABB i-bus Commissioning Number of control value inputs Options: This parameter defines the number of control value inputs (communication objects) for automatic operation.  1: There is only one Control value communication object.  2: There are two communication objects – Control value A and Control value B.
Page 160 ® ABB i-bus Commissioning Function of monitoring Options: Monitoring current control values Monitoring active and inactive control values This parameter determines the scope of monitoring.  Monitoring current control values: Only the currently selected control value input is monitored for incoming telegram continuity. After a switchover (via Communication object "Toggle control value A/B"...
Page 161 ® ABB i-bus Commissioning Reset time for automatic operation in s [1...65,535], 0 = inactive Options: 1…65,535 This parameter determines after which time the automatic operation is reset.  0: If 0 is selected, automatic operation is not reset. ...
Page 162 ® ABB i-bus Commissioning Enable limitations Options: Selection of option Yes: Dependent parameter: Limitation 1 Limitation 2 Limitation 3 Limitation 4 Options: 3, 2, 1, OFF Unchanged 1, OFF 2, 1 2, 1, OFF 3, 2 3, 2, 1 This parameter sets which fan speed is set, or may not be over/undershot, when forced operation is active.
Page 163 ® ABB i-bus Commissioning Four limitations are available. They can be used, for example, for the control of various operating modes, e.g. frost/heat protection, comfort, night shut down and standby. In normal cases, the room thermostat takes these operating modes into account in its control variable for the actuator.
Page 164: Parameter Window E, F, G: Output (Switch Actuators)
® ABB i-bus Commissioning 3.2.3.19 Parameter window E, F, G: Output (switch actuators) The setting options of valve outputs E, F and G do not differentiate from those of output H. The descriptions of the parameters and communication objects for outputs E, F and G are contained in Parameter window H: Output, p.
Page 165: Parameter Window H: Output
® ABB i-bus Commissioning 3.2.3.20 Parameter window H: Output All settings for output H are made in this parameter window. This parameter window is visible if Output H has been enabled in Parameter window Enable output E...H, p. 123. Reaction of output Options: This parameter sets whether the output operates as a normally closed contact or normally open contact.
Page 166 ® ABB i-bus Commissioning Object value "Switch" on bus voltage recovery Options: Do not write Write with "0" Write with "1" This parameter determines the reaction of the communication object Switch after a bus voltage recovery. As standard the communication object Switch receives the value 0.
Page 167 ® ABB i-bus Commissioning Enable communication object "Status Switch" 1-bit Options: Selection of option Yes. Dependent parameters: Send object value Options: No, update only On change After request After a change or request  No, update only: The status is updated but not sent.
Page 168: Parameter Window Time
® ABB i-bus Commissioning 3.2.3.20.1 Parameter window Time All settings for the Time: Staircase lighting function are made in this parameter window. This parameter window is visible if the parameter Enable function Time has been enabled in Parameter window H: Output, p.
Page 169 ® ABB i-bus Commissioning Extending staircase lighting time by multiple operation ("Pumping up") Options: No (not retriggerable) Yes (retriggerable) Up to max. 2 x staircase lighting time Up to max. 3 x staircase lighting time Up to max. 4 x staircase lighting time Up to max.
Page 170 ® ABB i-bus Commissioning Restart of staircase time after end of permanent ON Options:  No: The lighting switches off if Permanent ON is ended.  Yes: The lighting remains on and the staircase lighting time restarts. The function of Permanent ON is controlled via the Permanent ON communication object value. If...
Page 171 ® ABB i-bus Commissioning How does the staircase lighting react on bus voltage failure? Reaction in the event of bus voltage failure is specified by the parameter Contact position on bus voltage failure in parameter window H: Output. How does the staircase lighting react on bus voltage recovery? Reaction on bus voltage recovery is defined by two conditions.
Page 172: Parameter Window Inputs A
® ABB i-bus Commissioning 3.2.4 Parameter window Inputs a...c Parameter window Enable inputs a…c 3.2.4.1 Settings for enabling and description of inputs a...c: Note In the following, the setting possibilities of inputs a…c are explained using input a as an example.
Page 173: Parameter Window A: Switch Sensor
® ABB i-bus Commissioning 3.2.4.2 Parameter window a: Switch sensor This parameter window is visible if the option Switch sensor has been selected under the parameter Input Parameter window Enable inputs a…c, p. 170. a in Note The device features several inputs. However, as the functions for all inputs are identical, only the functions of input a will be described.
Page 174 ® ABB i-bus Commissioning Example: Maximum dead time of the input signal for a detected edge: After detection of an edge on the input, further edges are ignored for the maximum dead time T Distinction between long and short operation Options: Using this parameter, you set if the input differentiates between short and long operation.
Page 175: Parameter Distinction Between Long And Short Operation - No
® ABB i-bus Commissioning Parameter  Distinction between long and short operation – No 3.2.4.2.1 If the option No has been selected with the parameter Distinction between long and short operation, the following parameters appear in Parameter window a: Switch sensor, p. 171: Opening the contact ->...
Page 176 ® ABB i-bus Commissioning What is the minimum signal duration? In contrast to the maximum dead time, a telegram is only sent after the minimum signal duration has elapsed. The individual functions are: If an edge is detected on the input, the minimum signal duration will commence. No telegram is sent on the bus at this time.
Page 177 ® ABB i-bus Commissioning Scan input after download,  ETS reset and bus voltage recovery Options:  No: The object value is not scanned after a download, ETS reset and bus voltage recovery.  Yes: The object value is scanned after a download, ETS reset and bus voltage recovery.
Page 178 ® ABB i-bus Commissioning Enable communication object "Switch 1" Options:  Yes: The communication object Switch 1 appears. Dependent parameters: Reaction on event 0 Options: No edge evaluation Toggle Terminate cyclic transmission Reaction on event 1 Options: No edge evaluation...
Page 179 ® ABB i-bus Commissioning Internal connection Options: Output E Output F Output G Output H With this parameter, a direct connection of the binary input with an output can be established. With this connection, no assignment of the group address is necessary.
Page 180 ® ABB i-bus Commissioning Cyclic sending Options: What is cyclic sending? Cyclic transmission enables the communication object Switch to send automatically at a fixed interval. If cyclic transmission is only carried out for a specific object value (ON or OFF), this condition refers to the value of the communication object. It is therefore possible in principle to start cyclic transmission by sending a value to the communication object Switch.
Page 181 ® ABB i-bus Commissioning Enable communication object "Switch 2" "Switch 3" Options:  Yes: The communication object Switch 2/3 becomes visible. Dependent parameters: Reaction on event 0 Options: No edge evaluation Toggle Terminate cyclic transmission Reaction on event 1 Options:...
Page 182: Parameter Distinction Between Long And Short Operation - Yes
® ABB i-bus Commissioning Parameter Distinction between long and short operation – Yes 3.2.4.2.2 If the option Yes has been selected with the parameter Distinction between long and short operation, the following parameters appear in Parameter window a: Switch sensor, p. 171: Short operation ->...
Page 183: Parameter Window A: Value/Forced Operation
® ABB i-bus Commissioning 3.2.4.3 Parameter window a: Value/forced operation This operating mode allows the sending of values of any data types. This parameter window is visible if the option Value/forced operation has been selected in the parameter Parameter window Enable inputs a…c, p.
Page 184 ® ABB i-bus Commissioning Example: Maximum dead time of the input signal for a detected edge: After detection of an edge on the input, further edges are ignored for the maximum dead time T Enable communication object "Block" 1-bit Options: ...
Page 185 ® ABB i-bus Commissioning Distinction between long and short operation Options: Using this parameter, you set if the input differentiates between short and long operation.  Yes: After opening/closing the contact, it must first of all be ascertained if a short or long operation has occurred here.
Page 186: Parameter Distinction Between Long And Short Operation - No
® ABB i-bus Commissioning Parameter  Distinction between long and short operation – No 3.2.4.3.1 If the option No has been selected with the parameter Distinction between long and short operation, the following parameters appear in Parameter window a: Value/forced operation, p. 181: Opening the contact ->...
Page 187 ® ABB i-bus Commissioning What is the minimum signal duration? In contrast to the maximum dead time, a telegram is only sent after the minimum signal duration has elapsed. The individual functions are: If an edge is detected on the input, the minimum signal duration will commence. No telegram is sent on the bus at this time.
Page 188 ® ABB i-bus Commissioning Scan input after download,  ETS reset and bus voltage recovery Options:  No: The object value is not scanned after a download, ETS reset and bus voltage recovery.  Yes: The object value is scanned after a download, ETS reset and bus voltage recovery.
Page 189 ® ABB i-bus Commissioning Value 1 (event 0 or on short operation) Options: Do not send 1-bit value [0/1] 2-bit value (forced operation) 1-byte value [-128...127] 1-byte value [0...255] 1-byte value (8-bit scene) 2-byte value [-32,768...32,767] 2-byte value [0...65,535] 2-byte value (floating point)
Page 190 ® ABB i-bus Commissioning In the following table, the Forced operation function is explained: Bit 1 Bit 0 Access Description Enabled The communication object Switch of the actuator is enabled by the binary input. The assigned sensor can control the actuator via the Switch communication object. The binary Enabled input does not control the actuator.
Page 191 ® ABB i-bus Commissioning Value 2 (event 1 or on long operation) Note The options and parameter descriptions of the parameter Value 2 correspond with those of parameter Value 1. FCA/S 1.x.x.1 | 2CDC508134D0202 189...
Page 192: Parameter Distinction Between Long And Short Operation - Yes
® ABB i-bus Commissioning Parameter Distinction between long and short operation – Yes 3.2.4.3.2 If the option Yes is selected with the parameter Distinction between long and short operation, the following parameters appear: Short operation -> Event 0 Long operation -> Event 1 <−−−...
Page 193: Parameter Window A: Pt100, Pt1000 And Kty
® ABB i-bus Commissioning 3.2.4.4 Parameter window a: PT100, PT1000 and KTY 3.2.4.4.1 Parameter window a: PT100/PT1000 This operating mode allows the sending of temperature values. This parameter window is visible if one of the options PT100 or PT1000 has been selected in the Parameter window Enable inputs a…c, p.
Page 194 ® ABB i-bus Commissioning Temperature offset in 0.1 °C [-50...+50] Options: -50...0...+50 A maximum offset of ±5 °C can be added to the recorded temperature with this parameter. Line fault compensation Options: None Via cable length Via cable resistance This parameter is used for setting the line fault compensation.
Page 195 ® ABB i-bus Commissioning Send output value Options: On request On change Cyclically On change and cyclically This parameter defines how the output value should be sent.  On request: The output value is sent on request. The Request output value – Input a communication object appears.
Page 196 ® ABB i-bus Commissioning Use Threshold 1 Options:  No: The parameter window remains disabled and invisible.  Yes: The Threshold 1 parameter window appears. After the Threshold function has been enabled, the parameter window a: Threshold 1 is enabled. Further settings can be made here, e.g.
Page 197: Parameter Options For Kty
® ABB i-bus Commissioning 3.2.4.4.2 Parameter options for KTY This parameter window is visible if the option KTY has been selected in the parameter Input a in Parameter window Enable inputs a…c, p. 170. Manufacturer designation Options: KT 100 / 110 / 130...
Page 198 ® ABB i-bus Commissioning KTY user-defined The following ohmic values must rise to higher temperatures <- Note To ensure correct functioning of the Analogue Input with respect to the user-defined entries, the ohm (resistance) values as visible for the preset values must be in ascending order.
Page 199: Line Fault Compensation Via Cable Length
® ABB i-bus Commissioning 3.2.4.4.3 Line fault compensation Via cable length: Cable length, single distance [1...30 m] Options: 1...10...30 For setting the single cable length of the connected temperature sensor. Important The maximum cable length permitted between the sensor and device input is 30 m.
Page 200: Line Fault Compensation Via Cable Resistance
® ABB i-bus Commissioning 3.2.4.4.4 Line fault compensation Via cable resistance Cable resistance in milliohms (total of forw. and ret. conduct.) Options: 0...500...10,000 Using this parameter the level of cable resistance of the connected temperature sensor is set. Important In order to correctly measure the cable resistance, the conductors must be shorted together at the end of the cable and should not be connected to the Analogue Input.
Page 201: Parameter Window A: Threshold 1
® ABB i-bus Commissioning 3.2.4.4.5 Parameter window a: Threshold 1 The following details also apply to Threshold 2. Tolerance band lower limit Input in 0.1 °C Options: -500…1500 Tolerance band upper limit Input in 0.1 °C Options: -500…1500 The upper and lower limits of the tolerance band are set via these two parameters.
Page 202 ® ABB i-bus Commissioning Threshold 1 can be changed via the bus Options: This parameter specifies whether the limits can be changed via the bus.  Yes: The following communication objects appear: Modify – Input a Threshold 1 lower limit Modify –...
Page 203 ® ABB i-bus Commissioning Selection of option 1-byte [0...+255]: Dependent parameters: Send if threshold fallen below [0...+255] Send if threshold exceeded [0...+255] Options: 0...255 A value of 0 to 255 can be entered in single steps. Min. duration of the undershoot Min.
Page 204: Parameter Window A: Threshold 1 Output
® ABB i-bus Commissioning 3.2.4.4.6 Parameter window a: Threshold 1 Output The details in the following also apply to a: Threshold 2 Output. Send threshold object Options: On change On change and cyclically This parameter is used to specify the send behavior of the threshold object.
Page 205: Communication Objects
® ABB i-bus Commissioning Communication objects 3.3.1 Summary of communication objects Flags Data Point Functionality Name Length Type (DPT) In operation General 1.002 1 bit Request status values General 1.017 1 bit Block manual operation General 1.003 1 bit Status Manual operation General 1.003...
Page 206 ® ABB i-bus Commissioning Flags Data Point Functionality Name Length Type (DPT) 20… Output B CO as for output A 30… Output C CO as for output A 40… Output D CO as for output A 204 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 207 ® ABB i-bus Commissioning Flags Data Point Functionality Name Length Type (DPT) Switch speed Fan EFG (Multi-level) 5.001 1 byte Switch speed Fan EFG (Multi-level) 5.010 1 byte Switch Output E 1.001 1 bit Switch speed 1 Fan EFG (Multi-level) 1.001...
Page 208 ® ABB i-bus Commissioning Flags Data Point Functionality Name Length Type (DPT) Switch Output H 1.001 1 bit Permanent on Output H 1.003 1 bit Disable function Time Output H 1.003 1 bit Status Switch Output H 1.001 1 bit 84…89...
Page 209: Communication Objects General
® ABB i-bus Commissioning 3.3.2 Communication objects General Functionality communication object name Data type Flags In operation General 1 bit C, R, T DPT 1.002 The communication object is enabled if the parameter Enable communication object "In operation", 1-bit has been selected Parameter window General –...
Page 210 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status byte General 1 byte C, R, T none DPT The status byte reflects the current state of the input. Bit sequence 76543210 Bit 7: Heating or cooling mode (only in fan coil valves)
Page 211 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Fault (overload/short-circuit) Output A 1 bit C, R, T Output A/B DPT 1.005 If there is a fault on an output, e.g. due to a short-circuit or overload, the LED A and B will flash. The communication object Fault (overload/short-circuit) simultaneously sends a telegram with the value 1.
Page 212 ® ABB i-bus Commissioning Functionality communication object name Data type Flags 2nd control value, cooling, Output A 1 byte C, R continuous (PWM) DPT 5.001 This communication object is enabled if a Fan Coil operating mode with two control values and one valve has been selected Parameter window Enable output A...D, p.
Page 213: Communication Objects Valve Drive, Thermoelectric (Pwm) And Motor-Driven (3-Point)
® ABB i-bus Commissioning 3.3.3 Communication objects Valve drive, thermoelectric (PWM) and motor-driven (3-point) Note As the functions for all outputs are identical, only the functions of output A and A/B will be described. Functionality communication object name Data type...
Page 214 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status Control value Output A 1 byte C, R, T Output A/B DPT 5.001 This communication object is enabled with the option Yes via the parameter Enable communication object "Status control value"...
Page 215 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Fault control value Output A 1 bit C, R, T Output A/B DPT 1.005 This communication object is enabled if the parameter Monitoring control values e.g. thermostat has been selected with the...
Page 216 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status Valve purge Output A 1 bit C, R, T Output A/B DPT 1.003 This communication object is enabled with the option Yes via the parameters Enable valve purge and the communication object Status Valve purge 1 bit in Parameter window Function.
Page 217 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status byte Output A 1 byte C, R, T Output A/B non DPT This is a diagnostics byte for the output. The value of the communication object is sent when a telegram is received on the communication object Request status values.
Page 218: Communication Objects Fan E, F, G
® ABB i-bus Commissioning 3.3.4 Communication objects Fan E, F, G Note All three fan speeds can also be individually parameterized as outputs E, F and G. The descriptions of the communication objects for this can be found under Communication objects Switch actuators p.
Page 219 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Switch speed 1 Fan E, F, G 1 bit C, W DPT 1.001 This communication object is enabled if the parameter Enable direct operation has been selected with the option Yes in Parameter window E, F, G: Fan (Multi-level), p.
Page 220 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status Fan speed Fan E, F, G 1-byte C, R, T DPT 5.010 This communication object is enabled if the parameter Enable communication object "Status Fan speed x" 1-byte has been...
Page 221 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Limitation 1 Fan E, F, G 1 bit C, W DPT 1.003 This communication object is enabled if the parameter Enable limitations has been selected with the option Yes in...
Page 222 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Forced operation Fan E, F, G 1 bit C, W DPT 1.003 This communication object is enabled if the parameter Enable communication object "Forced operation" 1-bit has been selected with the option Yes in Parameter window E, F, G: Fan (Multi-level), p.
Page 223 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status byte fan Fan E, F, G 1-byte C, R, T Non DPT This communication object is enabled if the parameter Enable communication object "Status byte fan" 1-byte has been...
Page 224 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Control value A Fan E, F, G 1 byte C, W (if 2 control values) or DPT 5.010 Control value (if only 1 control value) This communication object is enabled if Automatic operation has been enabled in Parameter window E, F, G: Fan (Multi- level), p.
Page 225: Communication Objects Fan One-Level
® ABB i-bus Commissioning 3.3.4.2 Communication objects Fan One-level Functionality communication object name Data type Flags Not assigned Switch Fan E, F, G 1 bit C, W DPT 1.001 This communication object is enabled if the parameter Fan type has been selected with the option One-level in...
Page 226 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Limitation 1 Fan E, F, G 1 bit C, W DPT 1.003 This communication object is enabled if the parameter Enable limitations has been selected with the option Yes in...
Page 227 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Automatic ON/OFF Fan E, F, G 1 bit C, W DPT 1.003 This communication object is enabled if the parameter Enable automatic operation has been selected with the option Yes in Parameter window E, F, G: Fan (One-level), p.
Page 228 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Status byte fan Fan E, F, G 1-byte C, R, T Non DPT This communication object is enabled if the parameter Enable communication object "Status byte fan" 1-byte has been...
Page 229 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Control value A Fan E, F, G 1 byte C, W (if 2 control values) or DPT 5.010 Control value (if only 1 control value) This communication object is enabled if automatic operation has been enabled in Parameter window E, F, G: Fan (One- level), p.
Page 230: Communication Objects Switch Actuators E, F, G
® ABB i-bus Commissioning 3.3.4.3 Communication objects Switch actuators E, F, G Note If the outputs E, F and G are enabled as switch actuators, the parameters and options correspond to those of output H, see Communication objects Output H, p. 229.
Page 231: Communication Objects Output H
® ABB i-bus Commissioning 3.3.4.4 Communication objects Output H Functionality communication object name Data type Flags Switch Output H 1 bit C, W DPT 1.001 This communication object is enabled if the parameter Output H has been enabled in Parameter window Enable output E...H,...
Page 232: Communication Objects Inputs A
® ABB i-bus Commissioning Communication objects Inputs a…c 3.3.5 The communication objects of all Inputs do not differentiate from one another and are explained using Input a. The descriptions of the parameter setting options of Inputs a…c are contained in Parameter window Inputs a...c, p.
Page 233: Communication Objects Switch Sensor
® ABB i-bus Commissioning 3.3.5.1 Communication objects Switch sensor Functionality communication object name Data type Flags Block Input a: Switch sensor 1 bit C, W DPT 1.003 This communication object is enabled if the parameter Enable communication object "Block" 1-bit has been selected with the...
Page 234 ® ABB i-bus Commissioning Start event 0/1 Input a: Switch sensor 1 bit C, W DPT 1.001 This communication object is enabled if the parameter Enable communication object "Start event 0/1" 1-bit has been selected with the option Yes in Parameter window a: Switch sensor, p.
Page 235: Communication Objects Value/Forced Operation
® ABB i-bus Commissioning 3.3.5.2 Communication objects Value/forced operation Functionality communication object name Data type Flags Block Input a: 1 bit C, W Value/forced operation DPT 1.003 This communication object is enabled if the parameter Input a has been selected with the option Value/forced operation in Parameter window Enable inputs a…c, p.
Page 236: Communication Objects Temperature Sensor
® ABB i-bus Commissioning 3.3.5.3 Communication objects Temperature sensor Functionality communication object name Data type Flags Output value Input a: Temperature sensor 2 byte C, R, T DPT 9.001 This communication object is used to send the output value to the bus.
Page 237 ® ABB i-bus Commissioning Functionality communication object name Data type Flags Threshold 1 Input a: Temperature sensor Variable C, R, T DPT variable As soon as the set threshold value is exceeded or below the limit, it is possible to send a...
Page 238: Communication Objects Heating/Cooling
® ABB i-bus Commissioning 3.3.5.4 Communication objects Heating/Cooling Toggle heating General 1 bit C, W DPT 1.100 If a fan coil operating mode with switching object is selected in the Parameter window Enable output A...D, p. 76, the parameter Toggle to heating with will appear. Depending on the selection, the communication object Toggle heating decides whether to use heating or cooling mode.
Page 239: Planning And Application
® ABB i-bus Planning and application Planning and application In this chapter you will find some tips and application examples for practical use of the device. Application examples and practical tips on the topic of temperature control, valve drives, characteristic curve adjustment etc., can be found in the Application manual Heating/Ventilation/Air-Conditioning at...
Page 240: Fan Output
® ABB i-bus Planning and application Fan output In this section, the function charts and application explanations for the fan outputs are explained. 4.1.1 Fan operation In fan operation a single phase fan, blower or convector can be controlled. In combination with a valve control 2, 3 or 4 pipe system can be implemented.
Page 241 ® ABB i-bus Planning and application The device is controlled in accordance with the following schematic principle: With three Switch speed x (x = 1, 2 or 3) communication objects that are independent of each other, the fan stages are controlled via the outputs of the Fan Coil Actuator.
Page 242: Fan With Changeover Switch
® ABB i-bus Planning and application 4.1.1.1 Fan with changeover switch Fans are usually controlled with a changeover switch. The following control table results for a three-stage fan, which simulates the device with a group of switch outputs: Terminal 8...
Page 243 ® ABB i-bus Planning and application Control of the room temperature is implemented using a room thermostat, which generally detects the room temperature as well. The device primarily controls a fan and valves. In addition to manual control of the fan via the communication objects Fan speed x, Fan speed switch or Fan speed up/down, the device can also operate in automatic mode together with a room thermostat.
Page 244: Direct Operation
A single-speed, two-speed or three-speed fan can be connected. ® The device sets the fan speed in accordance with a value received via the ABB i-bus . The value is received as a 1 byte value.
Page 245: Speed Switching Logic
® ABB i-bus Planning and application 4.1.5 Speed switching logic The following illustration shows the speed changeover logic for the device depending on the control values and the parameterized threshold values and hysteresis values. The diagram relates to a three-speed fan without parameterized fan limitations. The fan limitations are only relevant after the fan speed has been determined and do not change the flow chart.
Page 246: Fan Operation Functional Diagram
® ABB i-bus Planning and application 4.1.6 Fan operation functional diagram The following illustration indicates the sequence in which the fan control functions are processed. communication objects, which lead to the same box, have the same priority and are processed in the sequence in which the telegrams are received.
Page 247: Switch Output
® ABB i-bus Planning and application Switch output In this section, the function diagrams and application explanations for the switch outputs are explained. 4.2.1 Function diagram The following illustration indicates the sequence in which the functions are processed. communication objects which lead to the same box have the same priority and are processed in the sequence in which the telegrams are received.
Page 248: Time Function
® ABB i-bus Planning and application 4.2.2 Time function The Time function can be enabled (value 0) and disabled (value 1) via the bus (1 bit communication object Disable function Time). The output operates without a delay as long as the Time function is disabled.
Page 249: Valve Drives, Valves And Controller
® ABB i-bus Planning and application Valve drives, valves and controller 4.3.1 Electromotor Valve Drives Electromotor Valve Drives open and close valves via a small electric motor. Electromotor valve drives are offered as proportional or as 2 or 3-way valve drives.
Page 250: Control Types
® ABB i-bus Planning and application 4.3.3 Control types The following control types are commonly used for the control of valves in heating, air-conditioning and ventilation applications.  Continuous control  Pulse width modulation (PWM)  Pulse width modulation – calculation 4.3.3.1...
Page 251: Pulse Width Modulation (Pwm)
® ABB i-bus Planning and application 4.3.3.2 Pulse width modulation (PWM) With pulse width modulation, the valve is operated as with 2-point control exclusively in the positions fully opened and fully closed. In contrast to a 2-point control, the position is not controlled via limit values, but rather by calculated control values similar to continuous control.
Page 252 ® ABB i-bus Planning and application Example: When the device receives a 1 byte control value (continuous control) as an input signal, this value together with the parameterized cycle time from a PWM calculation is converted into a signal for a 2-point control (ON-OFF-ON).
Page 253: Pulse Width Modulation - Calculation
® ABB i-bus Planning and application Pulse width modulation – calculation 4.3.3.3 With pulse width modulation, control is implemented by a variable mark-space ratio. During the time t the valve is opened and during the time t it is closed.
Page 254: Reaction On Bus Voltage Failure, Recovery, Download And Ets Reset
® ABB i-bus Planning and application Reaction on bus voltage failure, recovery, download and ETS reset The way in which the device reacts on bus voltage failure or recovery, download and ETS reset are described below. Important For system reasons, the device switches the outputs OFF for about 1 second after bus voltage recovery, download or ETS reset.
Page 255: Ets Reset
® ABB i-bus Planning and application 4.4.3 ETS reset What is an ETS reset? Generally an ETS reset is defined as a reset of the device via the ETS. The ETS reset is triggered in the ETS under the menu item Commissioning with the function Reset device. This stops and restarts the application.
Page 256: Priorities
® ABB i-bus Planning and application Priorities The priorities for telegram processing are defined as follows: Bus voltage failure Forced operation Direct operation Limitation of automatic operation Malfunction of automatic operation Control value automatic operation Bus voltage recovery Switch Actuator...
Page 257: Appendix
® ABB i-bus Appendix Appendix Scope of delivery The Fan Coil Actuator is supplied together with the following components. The delivered items should be checked against the list below.  1 x Fan Coil Actuator, alternatively: FCA/S 1.1.1.2 Fan Coil Actuator, PWM, MDRC FCA/S 1.2.1.2 Fan Coil Actuator, 0-10V, MDRC...
Page 258: Status Byte General
® ABB i-bus Appendix Status byte General                                 ...
Page 259: Status Byte Outputs A, B, C, D
® ABB i-bus Appendix Status byte outputs A, B, C, D                             ...
Page 260: Status Byte Fan
® ABB i-bus Appendix Status byte fan                                 ...
Page 261: Ordering Details
® ABB i-bus Appendix Ordering details Short description Description Order No. bbn 40 16779 Weight 1 Packaging pcs. [pcs.] [kg] FCA/S 1.1.1.2 942195 Fan Coil Actuator, PWM, MDRC 2CDG110195R0011 FCA/S 1.1.2.2 Fan Coil Actuator, PWM, 2CDG110194R0011 942188 Manual Operation, MDRC FCA/S 1.2.1.2...
Page 262: Notes
® ABB i-bus Appendix Notes 260 2CDC508134D0202 | FCA/S 1.x.x.1...
Page 264 69123 Heidelberg, Germany notice. Phone: +49 (0)6221 701 607 The agreed properties are definitive for any orders placed. ABB AG shall not be liable for any Fax: +49 (0)6221 701 724 consequences arising from errors or incomplete e-mail: knx.marketing@de.abb.com information in this document.

ABB i-bus KNX Product Manual

1 General

2 Device Technology

Commissioning

Planning and Application

Appendix

Quick Links

Related Manuals for ABB i-bus KNX

Summary of Contents for ABB i-bus KNX

Table of Contents
